Elster Solutions REXU REXU Printed Circuit Board Assembly User Manual 12 0259 Exhibit Cover
Elster Solutions, LLC REXU Printed Circuit Board Assembly 12 0259 Exhibit Cover
Manual
![](/img.php?id=1771374&img=bg1.png)
5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598
Certification Exhibit
FCC ID: QZC-REXU
IC: 4557A-REXU
FCC Rule Part: 15.247
IC Radio Standards Specification: RSS-210
ACS Project Number: 12-0259
Manufacturer: Elster Solutions, LLC
Model: REXU
Manual
![](/img.php?id=1771374&img=bg2.png)
![](/img.php?id=1771374&img=bg3.png)
![](/img.php?id=1771374&img=bg4.png)
![](/img.php?id=1771374&img=bg5.png)
IL42-4026G August 2012
4
1
2
3
L
O
A
D
2
1
3
3
21
Form 12S
3 phase, 3 wire delta
self–contained
13H10
600 V service
voltage only
August 2012 IL42-4026G
5
FCC and Industry Canada Compliance
User Information (Part 15.105)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• reorient or relocate the receiving antenna
• increase the separation between the equipment and the receiver
• connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• consult the dealer or an experienced radio/TV technician for help
If you experience trouble with this equipment, please use the Return Material Authorization (RMA) feature available at the Online Customer Services at
www.elstersolutions.com. Do not attempt to repair this equipment yourself unless you are replacing the entire module.
Compliance Statement (Part 15.19)
This device complies with Part 15 of the FCC Rules and Class B digital apparatus requirements for ICES-003. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation of the device.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Énoncé de conformité
Cet appareil est conforme à la Partie 15 des règles de la FCC et aux exigences relatives aux appareils numériques de classe B conformément à l'avis sur la
compatibilité électromagnétique ACEM-3. L'utilisation de cet appareil est soumise aux deux conditions suivantes : (1) Cet appareil ne doit pas provoquer
d'interférences nocives et (2) cet appareil doit accepter toutes les interférences reçues notamment celles pouvant provoquer un fonctionnement intempestif
de l'appareil.
Antenna Compliance
To reduce potential interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.)
is not more than permitted for successful communication. Under Industry Canada regulations, this radio transmitter may only operate using an antenna of
a type and maximum (or lesser) gain approved for the transmitter by Industry Canada.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal
(ouinférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres
utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité
nécessaire à l'établissement d'une communication satisfaisante.
Warning (Part 15.21)
Changes or modifications not expressly approved by Elster could void the user's authority to operate the equipment.
RF Radiation Safety Guidelines
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated to
provide a separation distance of at least 20cm from all persons.
Collocation Statement
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
IL42-4026G August 2012
6
Notes:
August 2012 IL42-4026G
7
Notes:
![](/img.php?id=1771374&img=bg9.png)
IL42-4026G August 2012
DISCLAIMER OF WARRANTIES AND LIMITATIONS OF LIABILITY
There are no understandings, agreements, representations, or warranties either express or implied, including warranties of merchantability or
fitness for a particular purpose, other than those specifically set out by any existing contract between the parties. Any such contract states the entire
obligation of the seller. The contents of this document shall not become part of or modify any prior existing agreement, commitment, or relationship.
The information, recommendations, descriptions, and safety notices in this document are based on Elster experience and judgment with respect to
operation and maintenance of the described product. This information should not be considered as all-inclusive or covering all contingencies. If
further information is required, Elster should be consulted.
No warranties, either expressed or implied, including warranties of fitness for a particular purpose or merchantability, or warranties arising from the
course of dealing or usage of trade, are made regarding the information, recommendations, descriptions, warnings, and cautions contained
herein.
In no event will Elster be responsible to the user in contract, in tort (including negligence), strict liability or otherwise for any special, indirect, incidental,
or consequential damage or loss whatsoever, including but not limited to: damage or loss of use of equipment, cost of capital, loss of profits or
revenues, or claims against the user by its customers resulting from the use of the information, recommendations, descriptions, and safety notices
contained herein.
Elster
Raleigh, North Carolina USA
*IL42-4026G*
© 2012 by Elster
All rights reserved.
Printed in the United States.
