Page 1 of 13
B2CH072AA
B2CH072AA Product Manual
4.9 GHz Public Safety Band Radio Module
Document Date: February 20, 2007
Document Number: PM-B2CH072AA
Document Version Number: 2
Document Status: Release
© Copyright 2006 by BelAir Networks.
All rights reserved..
![](/img.php?id=766631&img=bg2.png)
B2CH072AA Product Manual –4.9 GHz Public Safety Band Radio Module
Page 2 of 13
Contents
About this Document ............................................................. 2
Introduction............................................................................. 3
Conditions of Use.................................................................... 4
Module Installation and Service ............................................ 6
Final Product Requirements.................................................. 7
Regulatory Statements......................................................... 10
About this Document
This document is a product manual for the B2CH072AA 4.9 GHz Public Safety
Band Radio Module, including its limitations on use in any product marketed or
offered for sale. It is intended as a supplement to training and documentation
by BelAir Networks Inc. or its authorized agents.
![](/img.php?id=766631&img=bg3.png)
B2CH072AA Product Manual –4.9 GHz Public Safety Band Radio Module
Page 3 of 13
Introduction
The B2CH072AA(hereafter referred to as “the module”) is a 4.9 GHz radio
module compatible with the IEEE 802.11 standard for Wireless LAN
operation. It is designed to be interoperable with WLAN products which are
based on Direct Sequence Spread Spectrum (DSSS) radio technology.
The module contains a complete 802.11a radio and Medium Access Control
(MAC) protocol engine which allows implementation of an 802.11a module.
The module is not intended for stand-alone operation. It will only be
marketed as a complete product, in conjunction with a package, DC power
supply and antenna (hereafter referred to as “the product” or the “final
product”).
Since the module has a BelAir networks proprietary digital interface, it cannot
be directly connected to any standard telecommunications or computer
devices. It can only be used with final products designed and authorized
specifically for that purpose.
![](/img.php?id=766631&img=bg4.png)
B2CH072AA Product Manual –4.9 GHz Public Safety Band Radio Module
Page 4 of 13
Conditions of Use
General Conditions of Use
This manual is intended to supplement training provided by BelAir Networks
or authorized parties. The module B2CH072AAis only intended for use in
BelAir Networks products and is not for sale to the general public as a stand-
alone module.
Please read this entire document, including the Regulatory Statements section
before attempting to install or operate the module.
Warning: Any use of B2CH072AAin any manner which is not expressly
specified within this manual or specifically approved by BelAir Networks or its
authorized agents will void the user’s right to operate this module, and is
expressly forbidden by BelAir Networks. This includes any modification of the
module, installation of the module in a configuration or used with an antenna
which is not expressly listed in this document or approved by BelAir
Networks.
List of Approved Final Products
The B2CH072AAmodule is only approved for use in the following BelAir
Networks products:
• BelAir200. See BelAir200 documentation for complete manufacturing
instructions.
• BelAir100. See BelAir100 documentation for complete manufacturing
instructions.
• BelAir50c. See BelAir50c documentation for complete manufacturing
instructions.
Operation of the module within the products expressly listed above is
required to ensure compliance to all FCC regulations. Any modification of the
module, or its use in any configuration not expressly listed above may void the
user’s right to operate this module.
![](/img.php?id=766631&img=bg5.png)
B2CH072AA Product Manual –4.9 GHz Public Safety Band Radio Module
Page 5 of 13
Country of Use
B2CH072AA is certified with limited modular approval for use as an
Intentional Radiator in the United States as device: FCC ID: RAR20004001.
Please read all regulatory statements at the end of this document before any
attempt to install or operate this module.
The module is only certified for operation in the United States. Before
attempting to install and operate this module in any other country, contact
BelAir Networks for approval.
Module Labeling
One or more labels are applied to the module during manufacture, including a
label which identifies the FCC identification numbers. Do not attempt to
remove any labels from the module.
![](/img.php?id=766631&img=bg6.png)
B2CH072AA Product Manual –4.9 GHz Public Safety Band Radio Module
Page 6 of 13
Module Installation and Service
Installation into a Product
The module shall only be installed by a technician trained by BelAir Networks
or its authorized agents. It should only be installed into an approved product
(see above) following all manufacturing and service procedures for that
product. The module should only be installed into a final product in a
manufacturing or service depot site.
Caution: B2CH072AAis an electro-static discharge (ESD) sensitive device.
All appropriate ESD measures must be taken when handling the module.
Failure to employ appropriate ESD protection may damage the module.
Module Service
The module is not intended as a field-serviceable unit. It contains no field-
replaceable or field-serviceable parts, or any external adjustable mechanisms.
The module should only be serviced in a manufacturing or service depot site
approved by BelAir Networks or its authorized agents.
![](/img.php?id=766631&img=bg7.png)
B2CH072AA Product Manual –4.9 GHz Public Safety Band Radio Module
Page 7 of 13
Final Product Requirements
The requirements below apply to any final product in which the
B2CH072AAmodule is installed.
Antenna Usage and Module Transmit Power
B2CH072AAmodule shall only be used in conjunction with the following
antenna types as outlined in the table below. Antennas are approved for
outdoor use only.
In order to comply with the FCC rules in the USA, it is required to respect
the maximum transmit power limits as follows for each of the antenna types.
Antenna Models and Maximum Allowable Power Setting
Frequency Band Channels Location Maximum Rated Transmit Power with Antenna
Type
4.940-4.990 GHz 4950,-55,-
60,-65,-70,-
75,-80
Outdoor Only
Antenna Gain Max Rated Transmit
Power
MaxRad MFB49009 9 dBi 20 dBm
MTI MT-462002/NV 8.5 dBi 20 dBm
MTI MT—444003/NV 15.5 dBi 20 dBm
MTI MT-465005/N 21 dBi 20 dBm
Warning: Use of this module in conjunction with any antenna not
expressly listed above will void authority to install or operate this equipment.
Warning: Setting of module transmit power above the limits specified in
the above table for a particular combination of antenna type, frequency of
operation, and type of usage, will exceed FCC limits and void authority to
install or operate this equipment.
![](/img.php?id=766631&img=bg8.png)
B2CH072AA Product Manual –4.9 GHz Public Safety Band Radio Module
Page 8 of 13
Product Installation
Products which contain B2CH072AA-A shall only be installed by professional
installers trained by BelAir Networks or its authorized agents. In addition to normal
installation procedures and good installation practice, professional installers are
responsible to ensure that:
Only an approved antenna (see above) is connected to the module, and the antenna
is mounted in such a manner and in such a location that access to the antenna by the
general population is minimized. Access to the antenna by the general population
should be limited to more than the minimum safety distance. This distance is:
RF Exposure Radios
Minimum
Safety
Distance
Radios
Other
combinations
Minimum
Safety
Distance
BelAir50C
BelAir50S
Radios
1 x RAR20004001
(PSM1) w. 21 dBi
antenna
40 cm ( 16
inches) NONE -------
BelAir100
BelAir100S
BelAir100C
Radios
1 x RAR20001003
and 23 dbi antenna
1 x RAR20004001
(PSM1) w. 21 dBi
antenna
60 cm ( 24
inches)
1 x RAR20004001(PSM1)
w. 9 dBi antenna and 1 x
RAR20000003 (ARM3)
20 cm ( 8
inches)
BelAir200
1 x RAR20001003
and 23 dbi antenna
and 1 x
RAR20004001(PS
M1) w. 21 dBi
antenna and 1 x
RAR20000003
(ARM3)
72 cm ( 28.3
inches)
1 x RAR20004001(PSM1)
w. 21 dBi antenna1 x
RAR20001003 (BRM3)
with 15 dBi ant.and 1
RAR20000003 (ARM3)
50 cm ( 20
inches)
Adherence to these rules by the professional installer is mandatory. See full
installation procedures for the particular product for details.
![](/img.php?id=766631&img=bg9.png)
B2CH072AA Product Manual –4.9 GHz Public Safety Band Radio Module
Page 9 of 13
Product Labeling
The following permanent label, or one containing equivalent information, must
be affixed in a conspicuous location on the exterior of every product
containing this module:
FCC ID: RAR20004001
![](/img.php?id=766631&img=bga.png)
B2CH072AA Product Manual –4.9 GHz Public Safety Band Radio Module
Page 10 of 13
Regulatory Statements
The following regulatory notes apply to the product which contains module
B2CH072AA. The following sections or equivalent information shall appear in
the user-manual of the final product.
Regulatory Information and Disclaimers
Installation and use of this device must be in strict accordance with the
instructions included in the user documentation provided with the product.
Any changes or modifications to this product not expressly approved by the
party responsible for compliance could void the user’s authority to operate
this equipment.
The manufacturer is not responsible for any interference to radio or television
equipment caused by unauthorized modification of this device, or attachment
of any antennas or equipment other than those specified by the manufacturer.
The manufacturer or its authorized resellers or distributors will assume no
liability for any damage or violation of government regulations arising from
failing to comply with these guidelines.
Manufacturer’s FCC Conformity Statement
This device complies with Part 90 of the FCC Rules.
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 90 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
![](/img.php?id=766631&img=bgb.png)
B2CH072AA Product Manual –4.9 GHz Public Safety Band Radio Module
Page 11 of 13
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
RF Exposure Statement
This Wireless LAN radio device has been evaluated under FCC Bulletin OET
65C and found to be compliant to the requirements set forth in CFR 47
90.1335 and Sections 2.1091, 2.1093, addressing RF exposure from radio
frequency devices.
This device complies with FCC RF radiation exposure limits for an
uncontrolled environment. The radiated output power of this Wireless LAN
device is below the FCC radio frequency exposure limits. However, this
device should still be installed and used in such a manner that the potential for
human contact during normal operation is minimized. In order to comply with
RF exposure limits established in the ANSI C95.1 standard, this equipment
should be installed and operated at a minimum distance between the radiator
and a human body. This minimum distance for allowable combinations of
radios and antenna is:
![](/img.php?id=766631&img=bgc.png)
B2CH072AA Product Manual –4.9 GHz Public Safety Band Radio Module
Page 12 of 13
RF Exposure Radios
Minimum
Safety
Distance
Radios
Other
combinations
Minimum
Safety
Distance
BelAir50C
BelAir50S
Radios
1 x RAR20004001
(PSM1) w. 21 dBi
antenna
40 cm ( 16
inches) NONE -------
BelAir100
BelAir100S
BelAir100C
Radios
1 x RAR20001003
and 23 dbi antenna
1 x RAR20004001
(PSM1) w. 21 dBi
antenna
60 cm ( 24
inches)
1 x RAR20004001(PSM1)
w. 9 dBi antenna and 1 x
RAR20000003 (ARM3)
20 cm ( 8
inches)
BelAir200
1 x RAR20001003
and 23 dbi antenna
and 1 x
RAR20004001(PS
M1) w. 21 dBi
antenna and 1 x
RAR20000003
(ARM3)
72 cm ( 28.3
inches)
1 x RAR20004001(PSM1)
w. 21 dBi antenna1 x
RAR20001003 (BRM3)
with 15 dBi ant.and 1
RAR20000003 (ARM3)
50 cm ( 20
inches)
![](/img.php?id=766631&img=bgd.png)
B2CH072AA Product Manual –4.9 GHz Public Safety Band Radio Module
Page 13 of 13
BelAir Networks Inc.
603 March Road
Kanata, Ontario
Canada
K2K 2M5
613-254-7070
Sales
sales@belairnetworks.com
Support
support@belairnetworks.com
General Information
Info@belairnetworks.com
