Euro Communication EquipementS BTF4XT BTF4XT User Manual SUPERTOOTH MOTO II
Euro Communication Equipement SAS BTF4XT SUPERTOOTH MOTO II
Users Manual
![](/img.php?id=2006973&img=bg1.png)
BTF4XT
Bluetooth Headset for Motorcycle
Features
VOX Technology
A2DP Music Streaming
Auto-Volume Level Adjusting
1
![](/img.php?id=2006973&img=bg2.png)
A. PRODUCT DESCRIPTION:
BTF4XT is a Bluetooth Headset designed for motorcycle rider or passenger who
wishes to have reliable hands-free, wireless and clear communications while
driving. This headset is equipped with hi-tech features such as: VOX
Technology, A2DP (Advance Audio Distribution Profile) music streaming and
Auto-Volume Level Adjusting.
1. MFB or Multi-Function Button
(power on & off / pairing / answer /
hang-up / reject / voice dial / etc.)
2. Headset Plug
3. Front button - Volume Up
4. Back button - Volume Down
5. Up button - Next
6. Down button - Previous
7. Status Indicator
8. Left/Right (L/R) Ear Speaker
9. Microphone (On the flexible boom)
10. Charger and Headset Socket
11. Hook
B. CHARGING:
1. When the Status Indicator (7) turns Red, the battery is low. Charge the
unit using the provided charger.
2. Connect the charger’s plug to the Charger Socket (8) of the BTF4XT. Then,
plug the charger to an external power source. (Note: Status Indicator (7)
turns Red when charging).
3. When the Status Indicator (7) turns Green, charging is complete.
4. Disconnect the charger.
C. POWER ON OR OFF:
Power On: Press the MFB (1) until Status Indicator (7) turns blue. Or press for
approximately 3 seconds, a beep will be heard.
Power Off: Press the MFB (1) until Status Indicator (7) turns red. Or press for
approximately 5 seconds, a beep will be heard.
D. PAIRING TO YOUR BLUETOOTH MOBILE PHONE:
1. From OFF, press and hold the MFB (1) of the BTF4XT until the Status
Indicator (7) turns blinking red/blue.
2. While the headset is in pairing mode, access the Bluetooth menu of your
phone. Turn on the Bluetooth function then execute a Bluetooth search. (See
your phone’s manual).
3. When the phone displays the list of Bluetooth devices, select BTF4XT then
enter 0000 and press ok. Pairing is successful if the alternating red/blue
lights of the Status Indicator (7) changes to blinking blue.
2
![](/img.php?id=2006973&img=bg3.png)
Note: Some phones do not connect automatically to the kit after pairing. You
need to press the MFB (1) (1st beep) to connect.
Or use the menu of your phone:
Go back to Bluetooth > Paired devices > highlight the name of this
headset (BTF4XT) > press Options > then press Connect.
The BTF4XT is now ready to use.
E. BASIC OPERATION:
IMPORTANT:
The BTF4XT needs to be ‘paired’ with your Bluetooth mobile phone before you
can use the following functions. (See Pairing to your Bluetooth Mobile Phone
on section D.)
Make a Call:
- Dial the number using your phone. Audio will automatically be on the
headset.
Note: With some phones, audio is always on the phone during an outgoing call.
You will need to press the MFB (1) to transfer the audio to your headset.
Answer a Call:
-Assuming the VOX is activated: Accept a call by loudly saying a word within
10 seconds. (Example: When you receive the ring tone, Say loudly ”Ok!”)
The call will be answered. Audio will be on the headset. (See VOX
Activation / Deactivation on section F.)
-You also have the option to answer the call normally by pressing the MFB
(1) for 1 second (1st beep).
End a Call:
-Press the MFB (1) for 1 second to end the call (1st beep).
Reject a Call (For Handsfree Profile Phones only):
-Assuming the VOX is activated: Reject a call by being silent for 10 seconds.
The call will automatically be rejected. (See VOX Activation / Deactivation
on section F.)
-You also have the option to reject the call normally by pressing the MFB (1)
for 3 second (2nd beep).
Voice Dial:
IMPORTANT: First, make sure to activate the voice dial function of your phone.
Record at least one voice tag. (Kindly refer to the procedure in your phone’s
manual.)
3
![](/img.php?id=2006973&img=bg4.png)
Note: Voice dialing entries must be stored in the phone’s memory, not on the
SIM card!
1. Press the MFB (1) for 1 second (1st beep) to make a voice dial. A voice dial
tone/ beep will be heard on the headset prompting the user to say the voice
tag of the contact to call.
2. Say the voice tag. The voice will be played back to you, and then the phone
will dial the number automatically.
Redial:
-Press the MFB (1) for 3 seconds (2nd beep). The last dialed number will be
redialed.
Audio Transfer (For Handsfree Profile Phones only):
-During an ongoing call, you can transfer the audio.
Headset to Phone: Press and hold the MFB (1) for 3 seconds (2nd
beep) and the audio will be transferred to the phone.
Phone to Headset: Press the MFB (1) for 1 second (1st beep) and the
audio will be transferred to the headset.
Note: For some phones, you may need to accept a connection prompt on the
phone before automatic transfer takes place.
Set the Volume:
-Press the Volume Up (3) or Down (4) button repeatedly until the desired
level is reached.
F. SPECIAL FEATURE: VOX Activation / Deactivation:
- When activated, the user can accept a call by saying any word within 10
seconds. The user can also reject a call by being silent for 10 seconds.
-When deactivated, use the MFB (1) to answer a call.
The Voice Answer Mode can be enable or disable when the kit is in standby
mode (no ongoing call and close any multi media player).
Activation:
1. From Connected and standby, press and hold the Volume Up (3)
button for 5 seconds.
2. A beep will be heard. Then release.
Deactivation:
1. From Connected and standby, press and hold the Volume Down (4)
button for 5 seconds.
2. A beep will be heard. Then release.
4
![](/img.php?id=2006973&img=bg5.png)
G. STREAM MUSIC FROM YOUR A2DP BLUETOOTH MOBILE PHONE:
If a phone supports A2DP, you can stream music from your phone to the
BTF4XT.
Note: The BTF4XT needs to be ‘paired’ with your Bluetooth mobile phone before
you can use the following functions. (See Pairing to your Bluetooth Mobile
Phone on section D.)
Using A2DP Music Streaming
To Stream Music:
-Go to your phone’s music player and play a track via A/V bluetooth. (See
your phone’s manual).
-Or Long Press the UP button (5) to play/pause music streaming.
To Choose Music File:
- Press the UP button (5) , music will go to the next music file.
- Press the DOWN button (6), music will go back to the previous music
file.
To Set the Volume:
-Press the Volume Up (3) or Down (4) button repeatedly until the desired
level is reached.
To prevent possible hearing damage, do not listen at high volume levels
for long periods.
5
![](/img.php?id=2006973&img=bg6.png)
FCC/IC statements :
Federal Communications Commission (FCC) Statement
Industry Canada (IC) Statement
15.21
You are cautioned that changes or modifications not expressly approved by the part responsible for
compliance could void the user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC/IC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures :
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC rules and Industry Canada licence-exempt RSS standard(s)
Operation is subject to the following two conditions :
1)This device may not cause interference and
2)This device must accept any interference, including interference that may cause undesired operation of
the device.
FCC/IC RF Radiation Exposure Statement :
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment.
End users must follow the specific operating instructions for satisfying RF exposure compliance. This
transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use
of such marks by Euro-CB is under license. Other trademarks and trade names are those of their respective
owners.
English
English
Hereby
Hereby,
, EURO
EURO
COMMUNICATION
COMMUNICATION
EQUIPEMENTS
EQUIPEMENTS,
, represented
represented
by
by
MARCHANT
MARCHANT,
, CEO
CEO,
, declares
declares
that
that
the
the
Interphone MODEL
Interphone MODEL BT
BTF
F4
4XT
XT,
, is
is
in
in
compliance
compliance
with
with
the
the
essential
essential
requirements
requirements
and
and
other
other
relevant
relevant
provisions
provisions
of
of
Directive
Directive 1999/5/
1999/5/EC
EC
of
of
the
the
European
European
Parliament
Parliament
and
and
of
of
the
the
Council
Council
of
of 9
9 March
March 1999
1999 on
on
radio
radio
equipment
equipment
and
and
telecommunications
telecommunications
terminal
terminal
equipment
equipment
and
and
the
the
mutual
mutual
recognition
recognition
of
of
their
their
conformity
conformity.
.
For
For
the
the
whole
whole
declaration
declaration
please
please
visit
visit
:
:
http
http
://
://
www
www
.
.
SuperTooth
SuperTooth
.net/
.net/
download
download
Euro
Euro
Communication
Communication
Equipements
Equipements
Sas
Sas
Route
Route
de
de
Foix
Foix
D
D117
117
11 500
11 500 NEBIAS
NEBIAS
FRANCE
FRANCE
6
![](/img.php?id=2006973&img=bg7.png)
Déclarations FCC / IC :
Commission Federale des Communications (FCC)
Déclaration Industrie Canada (IC)
15,21
Vous êtes averti que les changements modications non expressément approuvés par la partie responsable
de la conformité pourraient annuler l'autorité de l'utilisateur d'exploiter cet équipement.
15.105 (b)
Cet équipement a été testé et jugé conforme aux limites pour un appareil numérique de classe B,
conformément à la partie 15 des règles de la FCC / IC. Ces limites sont conçues pour fournir une protection
raisonnable contre les interférences nuisibles dans une installation résidentielle. Cet équipement génère,
utilise et peut émettre des fréquences radio et, s'il n'est pas installé et utilisé conformément aux instructions,
peut causer des interférences nuisibles aux communications radio. Cependant, il n'existe aucune garantie
que ces interférences ne se produiront pas dans une installation particulière. Si cet équipement provoque
des interférences nuisibles à la réception radio ou télévision, ce qui peut être déterminé en éteignant et
rallumant l'équipement, l'utilisateur est encouragé à essayer de corriger l'interférence par une ou plusieurs
des mesures suivantes:
- Réorienter ou déplacer l'antenne réceptrice.
- Augmenter distance entre l'équipement et le récepteur.
- Brancher l'équipement dans une sortie sur un circuit différents-de celui sur lequel est branché le récepteur.
Consulter le revendeur ou un technicien radio / TV qualifié.
Cet appareil est conforme a la partie 15 des regles FCC et aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence.
L'opération est soumise aux deux conditions suivantes:
1) Cet appareil ne peut causer d'interférences et
2) Cet appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais
fonctionnement de l'appareil.
FCC / IC Déclaration d'exposition aux radiations RF:
Cet équipement est conforme aux normes FCC / IC limites d'exposition aux radiations dans un
environnement non contrôlé. Les utilisateurs doivent suivre les instructions de fonctionnement spéciques de
la conformité d'exposition aux RF. Cet émetteur ne doit pas être co-localisés ou fonctionnant en conjonction
avec une autre antenne ou transmetteur.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use
of such marks by Euro-CB is under license. Other trademarks and trade names are those of their respective
owners.
Par la présente, Euro Communication Equipements, représentée par Xavier Marchant, Président Directeur
Général, déclare que l'appareil Interphone, MODELE BTF4XT, est conforme aux exigences essentielles de
la directive 1995/5/EC du Parlement Européen et du Conseil du 9 Mars 1999 concernant les équipements
hertziens et les équipements terminaux de télécommunications et la reconnaissance mutuelle de leur
conformité.
Pour
Pour
la
la
déclaration
déclaration
complète
complète
visitez
visitez
:
:
http
http
://
://
www
www
.
.
SuperTooth
SuperTooth
.net/
.net/
download
download
Euro
Euro
Communication
Communication
Equipements
Equipements
Sas
Sas
Route
Route
de
de
Foix
Foix
D
D117
117
11 500
11 500 NEBIAS
NEBIAS
7
