Euro Communication EquipementS BTF5XT BTF5XT User Manual INTERPHONE F5
Euro Communication Equipement SAS BTF5XT INTERPHONE F5
User Manual
![](/img.php?id=1908187&img=bg1.png)
INTERPHONE F5XT
Bluetooth Headset
PRODUCT OVERVIEW:
1. Center Button (power on & off / pairing / answer / end a call /
reject a call / activate mode / deactivate mode)
2. Status Indicator
3. Left Button (Volume Down)
4. Right Button (Volume Up)
5. UP Button (Selection Up)
6. DOWN Button (Selection Down)
7. Microphone (On the flexible boom)
8. Charger Socket
9. Left/Right (L/R) Ear Speaker
Charging:
Connect the charger’s plug to the Charger Socket of the
Interphone F5XT. Then connect the charger to an external power
source.
Charge Indicator (2) Status:
Steady Red: Battery Low
Steady Orange: Charging
Steady Green: Battery Full
When fully charged, disconnect the charger.
Power On:
From Off, press center button for 3 seconds. Interphone F5XT
announces “Interphone F5XT ready. Battery ‘level’. Phone.” Then
status indicator blinks blue.
Power Off:
![](/img.php?id=1908187&img=bg2.png)
Press center button for about 5 seconds. Interphone F5XT
announces “Interphone F5 Powering Down” then status indicator
turns red then off.
Pairing Mode:
From Off, press center button for about 5 seconds. Interphone
F5XT announce “British English Selected. From phones Bluetooth
menu, search for devices and select Interphone F5XT. Enter pin
code 0000 if requested.” Then status indicator turns blinking red
and blue.
Pairing to Mobile Phone:
From pairing mode, access the Bluetooth menu of your phone
then execute a Bluetooth search. Then follow the headset and
phone prompts to pair the Interphone F5XT. After the successful
pairing, a voice will announce “Pairing successful to phone”.
Pairing Cancel:
During pairing mode, press center button for 2 seconds to cancel
the pairing process. “Pairing Cancel” will be announced and
stops the pairing search.
Receiving Incoming Call:
Answer Call: Press center button for 1 second to accept the
incoming call.
End Call: Press center button for 1 second to end the received
call.
Reject Call: Press center button for 3 seconds to reject the
incoming call. “Call Rejected” will be announced on Interphone
F5XT.
Volume UP: Press Right button for 1 second to increase the
volume level. “Maximum Volume” or a beep will be heard if
highest level is reached.
Volume DOWN: Press Left button for 1 second to decrease the
volume level. A beep will be heard if minimum level is reached.
![](/img.php?id=1908187&img=bg3.png)
Transfer Conversation from Interphone F5XT to phone: Press and
hold center button for 3 seconds. A beep will be heard and
audio will transfer to phone.
Transfer Conversation from phone to Interphone F5XT: Press and
hold center button for 3 seconds. A beep will be heard and
audio will transfer to Interphone F5XT.
Menu Selection:
Press UP/DOWN button for 1 second to select which menu you
wanted to use. You can select Phone, FM, Music Streaming,
Auxiliary Input and Set-Up on the menu.
Phone Menu:
Activate Phone Mode: Press center button for 1 second to activate
phone mode. “Phone Mode” will be announced on Interphone
F5XT
Redial: Press UP button for 1 second to redial the last number
used on your phone. “redialing last number” announced.
Voice Dial: Press DOWN button for 1 second to activate the
voice dial saved on your phone.
Deactivate Phone Mode: Press center button for 1 second to
deactivate Phone mode. “Phone” will be announced and ready
to select another menu.
FM Menu:
Activate FM Mode: Press center button for 1 second to activate FM
mode. “FM Active” will be announced on Interphone F5XT.
To scan the stored FM Station: Press UP/DOWN button for 1
second to scan memory up. “Scan UP/Scan DOWN” will be
announced on Interphone F5XT. “Memory 1-8 followed by the FM
Station” will be announced on Interphone F5XT.
To scan the FM Station Found: Press UP/DOWN button for 2
seconds to search a new FM station. “Scan UP/Scan DOWN” will
be announced on Interphone F5XT.
![](/img.php?id=1908187&img=bg4.png)
To Store FM Station to memory: Press center button for 2 seconds
to store the current FM station on memory. Use UP/DOWN button
to select your desired memory to store the current station, then
short press center button to confirm. Interphone F5XT announces
“FM station stored to memory 1-8”.
Deactivate FM Mode: Press center button for 1 second to
deactivate FM mode. It will automatically go back to Phone
menu. “Phone” will be announced and ready to select another
menu.
Music Streaming (A2DP) Menu:
Activate Music Streaming (A2DP) Mode: Press center button for 1
second to select phone music streaming (A2DP) mode. “Music
Streaming Active” will be announced on Interphone F5XT.
To select next/previous music: Press UP/DOWN button for 1
second to select songs you wanted to play/stream.
“Next/Previous” will be announced on Interphone F5XT.
To play/pause music: Press center button for 2 seconds to play or
pause the music streaming. Automatically play or paused the
music streaming.
Note: With some phones, you may need to manually play via
Bluetooth on your phone to start streaming music on Interphone
F5XT.
Deactivate Music Streaming (A2DP) Mode: Press center button for 1
second to deactivate Music Streaming (A2DP) mode. It will
automatically go back to phone menu. “Phone” will be
announced and ready to select another menu.
Auxiliary Input (MP3) Menu:
Activate Auxiliary Input (MP3) Mode: Press center button for 1
second to activate auxiliary input mode. “Auxiliary Input Active”
will be announced on Interphone F5XT. Plug in MP3 player and
start
playing music (audio will be automatically stream through
Interphone F5XT).
![](/img.php?id=1908187&img=bg5.png)
Deactivate Auxiliary Input (MP3) Mode: Press center button for 1
second to deactivate Auxiliary Input (MP3) mode. It will
automatically go back to phone menu. “Phone” will be
announced and ready to select another menu.
Set-Up Menu:
Activate Set-Up Mode: Press center button for 1 second to select
Set-Up mode. “Set-UP Active” will be announced on Interphone
F5XT. Then use UP/DOWN button for 1 second to select which
function settings you will need to change. You can select RDS
setting, Caller ID setting, Automatic Volume control setting, Voice
Answer setting and Erase Pairing.
RDS On/Off: Press center for 2 seconds to change the RDS
settings. “RDS On or Off” will be announced on Interphone F5XT.
Caller ID On/Off: Press center button for 2 seconds to change the
Caller ID settings. “Caller ID On or Off” will be announced on
Interphone F5XT.
Automatic Volume Control On/Off: Press center button for 2
seconds to change the Volume Control settings. “Automatic
Volume Control On or Off” will be announced on Interphone
F5XT.
Voice Answer On/Off: Press center button for 2 seconds to
change the Phone VOX settings. “Voice Answer On or Off” will
be announced on Interphone F5XT.
Erase Pairing: Press center button for 2 seconds to erase pairings.
“Pairing Erased” will be announced on Interphone F5XT followed
by indistinct beeps.
Deactivate Functions Menu: Press center button for 1 second to
deactivate Set-Up mode. It will automatically go back to phone
menu. “Phone” will be announced and ready to select another
menu.
![](/img.php?id=1908187&img=bg6.png)
FCC/IC statements :
Federal Communications Commission (FCC) Statement
Industry Canada (IC) Statement
15.21
You are cautioned that changes or modifications not expressly approved by the part responsible for
compliance could void the user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC/IC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures :
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with Industry Canada licence-exempt RSS standard(s)
Operation is subject to the following two conditions :
1)This device may not cause interference and
2)This device must accept any interference, including interference that may cause undesired operation
of the device.
FCC/IC RF Radiation Exposure Statement :
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specific operating instructions for satisfying RF exposure
compliance. This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any
use of such marks by Euro-CB is under license. Other trademarks and trade names are those of their
respective owners.
English
English
Hereby
Hereby,
, EURO
EURO
COMMUNICATION
COMMUNICATION
EQUIPEMENTS
EQUIPEMENTS,
, represented
represented
by
by
MARCHANT
MARCHANT,
, CEO
CEO,
, declares
declares
that
that
the
the Interphone F5XT
Interphone F5XT,
, MODEL
MODEL BT
BTF5XT
F5XT,
, is
is
in
in
compliance
compliance
with
with
the
the
essential
essential
requirements
requirements
and
and
other
other
relevant
relevant
provisions
provisions
of
of
Directive
Directive 1999/5/
1999/5/EC
EC
of
of
the
the
European
European
Parliament
Parliament
and
and
of
of
the
the
Council
Council
of
of 9
9 March
March
1999
1999 on
on
radio
radio
equipment
equipment
and
and
telecommunications
telecommunications
terminal
terminal
equipment
equipment
and
and
the
the
mutual
mutual
recognition
recognition
of
of
their
their
conformity
conformity.
.
For
For
the
the
whole
whole
declaration
declaration
please
please
visit
visit
:
:
http
http
://
://
www
www
.
.
SuperTooth
SuperTooth
.net/
.net/
download
download
Euro
Euro
Communication
Communication
Equipements
Equipements
Sas
Sas
Route
Route
de
de
Foix
Foix
D
D117
117
11 500
11 500 NEBIAS
NEBIAS
FRANCE
FRANCE
NCC Statement:
根據低功率電波幅射性電機管理辦法規定:
第十二條: 經型式認證合格之低功率射頻電機,非經許可,公司、行號或使用者均不得擅自變更頻率,加大功率或變更原設計之特性及功能。
第十四條: 低功率射頻電機之使用不得影響飛航安全及干擾合法通信;經發現有干擾現象時,應立即停用,並改善至無干擾時方得繼續使用。
低功率射頻電機須忍受合法通信或工業、科學及醫療用電波幅射性電機設備之干擾。
