Supertooth One
Users manual
Bluetooth Handsfree Kit
For Bluetooth Mobile Phones
![](/img.php?id=939124&img=bg2.png)
A. Product Description
SUPERTOOTH ONE is a Bluetooth handsfree kit that supports headset or
handsfree profile phones. Its special features include Full DSP Noise
Cancellation/Echo Cancellation. Thus, it provides an advanced audio quality. It
is designed for easy handsfree operation and superior performance.
Don't forget: Drive safely and within the law.
Check if the national or local legislation into force in your country does limit the
use of mobile phones while driving. It is up to the user of this product to respect
the said legislation in the area where he lives.
B. Product Overview
1 MFB or Multi-function Button
(power on & off / pairing / answer /
voice dial / redial / audio transfer)
2 Volume Down
3 Volume Up
4 End / Reject Button
5 Microphone
6 Charger Port
7 Bluetooth Indicator / Charge Indicator
8 Speaker
C. Charging
1. Connect the charger’s plug into the Charger Port (6) of the SUPERTOOTH
ONE. Connect the charger to an external power source.
Charge Indicator (7) Status:
Steady Red: Battery Low
Steady Orange: Charging
Steady Green: Battery Full
2. When fully charged, disconnect the charger.
2
![](/img.php?id=939124&img=bg3.png)
D. Power On/Off
Power On: Press the MFB (1) for 1 second. The Bluetooth Indicator (7) will
turn blinking blue.
Power Off: Press and hold the MFB (1) for 5 seconds until the Bluetooth
Indicator (7) turns red.
E. Pairing to your Bluetooth Mobile Phone
Pair the SUPERTOOTH ONE to your Bluetooth mobile phone to create the link
or audio connection between the two. This has to be done only at the first
connection to a phone.
1. From OFF, press and hold the MFB (1) for 5 seconds until the Bluetooth
Indicator (7) turns blinking red/blue. The kit is now in pairing mode.
2. While the kit is in pairing mode, access the Bluetooth menu of your phone.
Turn on the Bluetooth function then execute a Bluetooth search. (See your
phone’s manual.)
3. When the phone displays the list of Bluetooth devices, select ST ONE.
4. When the phone asks for the password, enter 0000 and press Ok.
Important Note: The kit is paired now. Most phones automatically connect to
the kit after pairing. With some phones you need to connect manually after
pairing. Go back to Bluetooth > Paired devices > highlight ST ONE > press
Options > then press Connect.
The kit is now ready to use.
F. Installation
1. Place the clip in the slots at the back of the SUPERTOOTH ONE.
2. Slide the clip to its closed side until it locks.
3. The closed side of the clip should be aligned with the top or the bottom of the
SUPERTOOTH ONE.
Note : The clip can be attached to the unit in 2 ways, to suit any position on the
sunvisor.
3
![](/img.php?id=939124&img=bg4.png)
4. Place the SUPERTOOTH ONE on the sunvisor in such a way that its
microphone is directed to the mouth of the user.
G. Basic Operations
IMPORTANT:
The kit needs to be ‘paired’ to your Bluetooth mobile phone, before you can use
the following functions. See Pairing to your Bluetooth Mobile Phone in
Section E.
Make a Call (Normal Dial):
Dial the number on your phone. Audio will automatically be on the kit. During an
ongoing call, the Bluetooth Indicator (7) will turn steady blue.
Note: With some phones, audio is always on the phone during an outgoing call.
You will need to press the MFB (1) for 1 second to transfer the audio to your kit.
Answer a Call:
During the ring tone, press the MFB (1) for 1 second to answer the call. When
call is answered, the Bluetooth Indicator (7) will turn steady blue.
End a Call:
Press the End/Reject Button (4) for 1 second to end the call.
Voice Dial:
Important: Before using this feature, make sure that the voice dialing function of
your phone is activated and at least one voice tag is recorded on your phone.
(Kindly refer to the procedure in your phone’s manual.)
Note: Voice dialing entries must be stored in the phone’s memory, not on the
SIM card!
1. Press the MFB (1) for 1 second.
2. A voice dial beep will be heard on the kit to prompt the user to say the voice
tag of the contact to call and the Bluetooth Indicator (7) will turn steady
blue.
3. Say the voice tag exactly as how you recorded it.
4
![](/img.php?id=939124&img=bg5.png)
4. The voice tag will be played back to you and then the phone will dial the
number automatically.
Redial (For Handsfree Profile Phones only) :
Press the MFB (1) for 3 seconds. The last dialed number will be redialed.
Reject a Call (For Handsfree Profile Phones only) :
During the ring tone, press the End/Reject Button (4) for 1 second. The
incoming call will be rejected.
Volume Setting:
Increase or decrease the volume by pressing the Volume Up (3) or Volume
Down (2) button. Press repeatedly until desired level is reached. The
Bluetooth Indicator (7) will turn violet as lowest and highest levels are reached.
Audio Transfer (For Handsfree Profile Phones only) :
During an ongoing call, you can transfer the audio.
Kit to Phone: Press and hold the MFB (1) for 3 seconds and the audio will
be transferred to the phone.
Phone to Kit: Press the MFB (1) for 1 second and the audio will be
transferred to the kit.
Note: For some phones, you may need to accept connection prompt on the
phone before automatic transfer takes place.
5
![](/img.php?id=939124&img=bg6.png)
SUPERTOOTH ONE Specifications
Bluetooth Compliance: Bluetooth version 2.0 specifications
Supported Bluetooth Profiles: Supports headset and handsfree profiles with
automatic detection
Operating Range: Up to 10 meters
Frequency: 2.4 GHz
Talk Time: Up to 10 hours
Stand-by time: Up to 800 hours
Charging Time: 3 hours
Battery Type: Rechargeable Lithium Ion
Special Features
Full Duplex
Full DSP Noise Cancellation / Echo
Cancellation
Digital Volume Control
Voice Recognition Dialing (If phone
supports)
Last Call Redial
Reject Incoming Call
Can also be charged directly from a PC via
USB Cable (not included)
Compact Size
Installation: Quick fixation on sun visor via plastic clip
Dimensions (mm): 21 x 64 x 120
Weight: 100 g
6
![](/img.php?id=939124&img=bg7.png)
English
English
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
English
This equipment is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
CE info:
http://www.supertooth.fr/download
Euro Communication Equipements sas
D117 Route de Foix
F 11500 NEBIAS
7
(Applicable in the European Union and other European countries with separate
collection systems)
This marking shown on the product or its literature, indicates that it should not be
disposed with other household wastes at the end of its working life. To prevent
possible harm to the environment or human health from uncontrolled waste disposal,
please separate this from other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or
their local government office, for details of where and how they can take this item for
environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product should not be mixed with other commercial wastes for
disposal.
![](/img.php?id=939124&img=bg8.png)
8
Federal Communications Commission (FCC) Statement
15.21
You are cautioned that changes or modifications not expressly approved by
the part responsible for compliance could void the user’s authority to operate
the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Operation is subject to the following two conditions:
1) This device may not cause interference and
2) This device must accept any interference, including interference that may
cause undesired operation of the device.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance. This transmitter must
not be co-located or operating in conjunction with any other antenna or
transmitter.
