GemTek Technology WMTB-158N Wireless Display Dongle User Manual Wireless Display Dongle GEM
Gemtek Technology Co., Ltd. Wireless Display Dongle Wireless Display Dongle GEM
User Manual.pdf
![](/img.php?id=1976072&img=bg1.png)
- 1 -
![](/img.php?id=1976072&img=bg2.png)
- 2 -
(WMTB-158N_MHL)
(WMTB-158N)
![](/img.php?id=1976072&img=bg3.png)
- 3 -
Preparation
1. WMTB-158N_MHL: Plug WMTB-158N_MHL into the MHL port of your display
(TV, Monitor, or Projector), WMTB-158N_MHL will turn on automatically; it takes less than 30 seconds
until the standby screen shown on display.
2. WMTB-158N: Plug WMTB-158N into the HDMI port of your display
(TV, Monitor, or Projector), plug in the Micro-USB male connector to the Micro-USB port of
WMTB-158N, then plug in the other side of USB cable into AC adapter or USB port of PC, make
sure the USB port can support 5V@0.5A power supply; it takes less than 30 seconds until the standby
screen shown on display.
