Programming and Information Guide Programming and Information Guide
The HomeLink Wireless Control System provides a convenient way to replace up to three
hand-held radio-frequency (RF) transmitters used to activate devices such as gate
operators, garage door openers, entry door locks, security systems, even home lighting.
Additional HomeLink information can be found on the Internet at www.homelink.com
The HomeLink Wireless Control System provides a convenient way to replace up to three
hand-held radio-frequency (RF) transmitters used to activate devices such as gate
operators, garage door openers, entry door locks, security systems, even home lighting.
Additional HomeLink information can be found on the Internet at www.homelink.com or
by calling 1-800-355-3515.
Precautions!
Before programming HomeLink to a garage door opener or gate operator, make sure
that people and objects are out of the way of the device to prevent potential harm or
damage. When programming a garage door opener, it is advised to park outside of the
garage. Do not use HomeLink with any garage door opener that lacks safety stop and
reverse features as required by U.S. federal safety standards (this includes any garage
door opener model manufactured before April 1, 1982). A garage door that cannot detect
an object - signaling the door to stop and reverse - does not meet current U.S. federal
safety standards. For more information, contact HomeLink at: www.homelink.com or
by calling: 1–800–355–3515.
Retain the original transmitter of the RF device you are programming for use in other
vehicles as well as for future HomeLink programming. It is also suggested that upon
the sale of the vehicle, the programmed HomeLink buttons be erased for security
purposes. Refer to “Programming” (step #1 only) or, for assistance, contact HomeLink
at: www.homelink.com or by calling: 1-800-355-3515.
Programming HomeLink
Note: Some vehicles may require the ignition switch to be turned to the second (or
“accessories”) position for programming and/or operation of HomeLink. It is also
recommended that a new battery be placed in the hand-held transmitter of the device
being programmed to HomeLink for quicker training and accurate transmission of the
radio-frequency signal. Do not repeat “Programming” - step one to train additional
devices to a second or third HomeLink button. Begin with “Programming” – step two.
1. Press and hold the two outer HomeLink buttons (buttons one and three) - releasing
only when the indicator light begins to flash (after 10 seconds). Do not hold the
buttons for longer than 30 seconds and do not repeat step one to program a
second and/or third hand-held transmitter to the remaining two HomeLink buttons.
2. Position the end of your hand-held transmitter 1–3 inches (5–14 cm) away from the
HomeLink button you wish to program while keeping the indicator light in view.
3. Simultaneously press and hold both the chosen HomeLink and hand-held transmitter
buttons. Do not release the buttons until step 4 has been completed.
(Note: Some gate operators and garage door openers may require you to replace
this Programming Step 3 with procedures noted in the “Gate Operator / Canadian
Programming” section.)
![](/img.php?id=2341876&img=bg2.png)
Programming (cont’d.)
4. After the HomeLink indicator light changes from a slow to a rapidly blinking light,
release both the HomeLink and hand-held transmitter buttons.
Note: If the HomeLink indicator light does not change to a rapidly blinking light, contact
HomeLink at www.homelink.com or call 1-800-355-3515 for assistance.
5. Press and hold the just-trained HomeLink button and observe the indicator light.
If the indicator light stays on constantly, programming is complete and your
device should activate when the HomeLink button is pressed and released.
Note: To program the remaining two HomeLink buttons, begin with “Programming” - step
two. Do not repeat step one.
If the indicator light blinks rapidly for two seconds and then turns to a constant
light continue with “Programming” steps 6-8 to complete the programming of a
rolling code equipped device (most commonly a garage door opener).
6. At the garage door opener receiver (motor-head unit) in the garage, locate the “learn”
or “smart” button. This can usually be found where the hanging antenna wire is
attached to the motor-head unit.
7. Firmly press and release the “learn” or “smart” button. (The name and color of the
button may vary by manufacturer.)
Note: There are 30 seconds in which to initiate step eight.
8. Return to the vehicle and firmly press, hold for two seconds and release the
programmed HomeLink button. Repeat the “press/hold/release” sequence a
second time, and, depending on the brand of the garage door opener (or other rolling
code equipped device), repeat this sequence a third time to complete the
programming process.
HomeLink should now activate your rolling code equipped device.
Note: To program the remaining two HomeLink buttons, begin with “Programming” - step
two. Do not repeat step one.
For questions or comments, please contact HomeLink at www.homelink.com or
1–800–355–3515.
![](/img.php?id=2341876&img=bg3.png)
Gate Operator /
Canadian Programming
Canadian radio-frequency laws require transmitter signals to “time-out” (or quit) after several
seconds of transmission – which may not be long enough for HomeLink to pick up the signal
during programming. Similar to this Canadian law, some U.S. gate operators are designed to
“time-out” in the same manner.
If you live in Canada or you are having difficulties programming a gate operator by using the
“Programming” procedures (regardless of where you live), replace “Programming
HomeLink” step 3 with the following:
Note: If programming a garage door opener or gate operator, it is advised to unplug the device during the
“cycling” process to prevent possible overheating.
3. Continue to press and hold the HomeLink button while you press and release - every
two seconds (“cycle”) your hand-held transmitter until the frequency
signal has successfully been accepted by HomeLink. (The indicator light will flash slowly
and then rapidly.)
Proceed with “Programming” step four to complete.
Using HomeLink
To operate, simply press and release the programmed HomeLink button. Activation will now occur
for the trained device (i.e. garage door opener, gate operator, security system, entry door lock,
home/office lighting, etc.). For convenience, the hand-held transmitter
of the device may also be used at any time. In the event that there are still programming difficulties
or questions, contact HomeLink at: www.homelink.com or 1–800–355–3515.
Erasing HomeLink Buttons
To erase programming from the three buttons (individual buttons cannot be erased but can be
“reprogrammed” as outlined below), follow the step noted:
• Press and hold the two outer HomeLink buttons until the indicator light
begins to flash-after 20 seconds. Release both buttons. Do not hold for
longer that 30 seconds. HomeLink is now in the train (or learning) mode
and can be programmed at any time beginning with “Programming” - step 2.
Reprogramming a Single HomeLink Button
To program a device to HomeLink using a HomeLink button previously trained, follow these
steps:
1. Press and hold the desired HomeLink button. DO NOT release the button.
2. The indicator light will begin to flash after 20 seconds. Without releasing the
HomeLink button, proceed with “Programming” - step 2
For questions or comments, contact HomeLink at: www.homelink.com or 1–800–355–3515.
![](/img.php?id=2341876&img=bg4.png)
This device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt
RSS standard(s). Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any interference received, including
interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Note: Changes or modifications not expressively approved by the party responsible for
compliance could void the user's authority to operate the equipment.
HomeLink and the HomeLink house are registered trademarks of Gentex Corporation
