User manual
![](/img.php?id=746096&img=bg1.png)
Setting the Volume
Press and hold while rotating until you reach a comfortable
listening level.
1. Rotate clockwise to increase the volume
2. Rotate counterclockwise to decrease the volume.
Do not hold the radio close to your ear. If the volume is set to an
uncomfortable level, it could hurt your ear.
Two-Way Radio
User’s Guide
Model FV700/
FV750 series
Safety and General Information FCC Licensing Information
Control Buttons
Display Screen Guide
KEM-PK14190-43
Important Information on Safe and Efficient Operation
Read This Information Before Using Your Radio.
The information provided in this document supersedes the general
safety information in user guides published prior to December 1, 2002.
Transmit and Receive Procedure
Your two-way radio contains a transmitter and a receiver. To control
your exposure and ensure compliance with the general
population/uncontrolled environment exposure limits, always adhere to
the following procedure:
Transmit no more than 50% of the time.
To receive calls, release the PTT button.
To transmit (talk), press the Push to Talk (PTT) button.
Transmitting 50% of the time, or less, is important because the radio
generates measurable RF energy exposure only when transmitting (in
terms of measuring standards compliance).
Exposure to Radio Frequency Energy
Your Motorola two-way radio complies with the following RF energy
exposure standards and guidelines:
United States Federal communications Commission, Code of Federal
Regulations; 47CFR part 2 sub-part J
American National Standards Institute (ANSI)/Institute of Electrical
and Electronic Engineers (IEEE) C95. 1-1992
Institute of Electrical and Electronics Engineers (IEEE) C95.1-1999
Edition
International Commission on Non-Ionizing Radiation Protection
(ICNIRP) 1998
Getting Started
Installing the Batteries:
Your radio uses three AAA Alkaline batteries and beeps when the
batteries are low.
1. Turn the radio off.
2. With the back of the radio facing you, lift the battery latch up to
release the battery cover and remove the cover.
3. Insert three AAA Alkaline batteries as shown on the inside of the
battery compartment.
4. Reposition the battery cover and press down to secure.
NOTE:
The FV700/ FV750 model radio can use a NiMH rechargeable
battery instead of three AAA batteries.
Installing the NiMH Battery Pack:
1. Follow step 2 above to remove the battery cover.
2. Remove the battery pack from the clear plastic bag.
Do not
disassemble or unwrap the battery pack.
3. Insert the NiMH battery pack so the “This Side Up” is showing.
4. Reposition the battery cover and press down to secure.
Battery Meter
The battery icon shows the battery charge level, from full
to empty . When the battery is empty, the radio chirps periodically
or after releasing (Low Battery Alert).
Note:
Remove the batteries before storing your radio for extended
periods of time. Batteries corrode over time and may cause permanent
damage to your radio.
Talking and Listening
To communicate, all radios in your group must be set to the same
channel and Interference Eliminator Code.
1. To talk, press and hold .
2. When you are finished talking, release .
For maximum clarity, hold the radio two to three inches away from your
mouth and speak directly into the microphone. Do not cover the
microphone while talking.
Talk Range
Your radio is designed to maximize performance and improve
transmission range. Do not use the radios closer than five feet apart.
Monitor Button
Pressing and holding for three seconds allows you to listen to the
volume level of the radio when you are not receiving. This allows you
to adjust the volume, if necessary. You can also press to check
for activity on the current channel before you talk.
Push to Talk Timeout Timer
To prevent accidental transmissions and save battery life, the radio
emits a continuous warning tone and stops transmitting if you press
for 60 continuous seconds.
Using the Battery Charger (Optional Accessory)
The battery charger provides drop-in charging convenience for
NiMH batteries and can be placed on any flat surface, such as a desk
or workbench. Charge the NiMH battery overnight (at least 16 hours)
before using it for the first time. After the initial charge, an empty
battery is fully charged within 14 hours.
1. Follow the steps above to install a NiMH Battery Pack.
2. Plug the AC power supply into the plug on the desk stand.
3. Plug the AC power supply into a standard wall outlet.
4. With a radio facing forward, slide it into one of the charging pockets.
Notes
The light on the charging base will glow continuously when
radio/battery is inserted.
When moving between hot and cold temperatures, do not charge the
battery until the battery temperature acclimates (usually about 20
minutes).
For optimal battery life, remove the radio or battery from the charger
within 16 hours. Do not store the radio in the charger.
Turn radio off while in charging tray.
Attaching and Removing the belt clip
1. Align the belt clip post with the hole in the back of the radio.
2. Gently push until the clip clicks in place
To Remove
1. Push down on the release tab at the top of the belt clip to release
the catch.
2. Pull the belt clip away from the back of the radio.
Turning Your Radio On and Off
Turn clockwise to turn the radio on and counterclockwise to turn
the radio off.
1. The radio chirps and briefly shows all features icons available on
your radio.
2. The display then shows the current channel, code and features that
are selected.
Initial Setup
Selecting the Channel
Your radios has 22 channels. Channels 8-14 are FRS 0.5 Watt only and
all other channels are GMRS.
1. With the radio on, press . When the radio is on a 0.5 watt
channel, displays. When the radio is on a 1 watt channel,
displays. The current channel flashes.
2. Press or to set the channel.
3. Press to save the channel setting or to continue set up.
For More Information
For further information, you may call Motorola at 1-800-638-5119 (U.S.
and Canada) or visit us on the Internet at http://www.motorola.com.
Setting and Transmitting Call Tones
Your radio can transmit different call tones to other radios in your group
so you can alert them that you want to talk. You have 10 call tones from
which to choose.
To set a call tone:
1. With the radio on, short press until the current call tone setting
flashes and appears.
2. Press or to change and hear the call tone.
3. Press to set the new call tone or to continue set up.
To transmit your call tone to other radios set to the same channel and
Interference Eliminator Code as your radio, press .
Note:
Setting the call to 0 disables the call tone feature.
Interference Eliminator Code
Interference Eliminator Codes help minimize interference by providing
you with a choice of code combinations. Your radio has 121
Interference Eliminator Codes. Codes 1 – 38 are the standard codes
that appear on other FRS/GMRS radios. Codes 39 – 121 are additional
codes added for superior interference protection.
To set the code for a channel:
1. Short press until the code starts to flash.
2. Press or to select the code.
3. Press to save the code setting or to continue set up.
You can set a different code for each channel using this procedure. An
extended press of or allows you to scroll through the
Interference Code rapidly so you can quickly reach the code you want.
Note: You must set the Interference Eliminator Code to 0 on a radio that
uses Interference Eliminator Codes to communicate with radios that do
not have Interference Eliminator Codes. Select 0 for “no tone, no code”
and OFF will flash on your radio’s display.
Hands-Free Use Without Accessories (iVOX)
You can use the iVOX feature to transmit, hands-free without the need
for any voice activation accessories. Once iVOX is turned on, the radio
detects your voice and transmits when you speak.
1. Short press until appears on the display. The current
setting On/Off will flash.
2. Press or to select On or Off.
3. Press to set or to continue set up.
Setting the Sensitivity Level When in VOX or iVOX Mode
Adjusting the radio’s sensitivity level helps minimize the possibility of
unintended noises triggering a transmission and helps the radio pick up
soft voices.
1. Short press after setting iVOX. VOX will still appear.
2. Press or to select the sensitivity level.
3.Press to set or to continue set up.
Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure
to Radiofrequency Electromagnetic Fields in the Frequency Range
from 3 KHz to 300 GHz, 1999
Australian communications Authority Radiocommunications
(Electromagnetic Radiation—Human Exposure) Standard, 2003
ANATAL ANNEX to Resolution No. 303 of July 2, 2002 “Regulation of
limitation of exposure to electrical, magnetic and electromagnetic
fields in the radio frequency range between 9 KHz and 300GHz” and
“Attachment to resolution #303 from July 2, 2002”
To assure optimal radio performance and make sure human exposure
to radio frequency electromagnetic energy is within the guidelines set
forth in the above standards, always adhere to the following
procedures.
Portable Radio Operation and EME Exposure
Antenna Care
Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could damage
the radio and may violate FCC regulations.
Do NOT hold the antenna when the radio is “IN USE.” Holding the
antenna affects the effective range.
Body-Worn Operation
To maintain compliances with FCC/Health Canada RF exposure
guidelines, if you wear a radio on your body when transmitting, always
place the radio in a Motorola-supplied or approved clip, holder, holster,
case or body harness for this product. Use of non-Motorola-approved
accessories may exceed FCC/Health Canada RF exposure guidelines.
If you do not use one of the Motorola-supplied or approved body-worn
accessories and are not using the radio held in the normal use
position,
ensure the radio and its antenna are at least 1 inch (2.5 cm)
from your body when transmitting.
Battery Charger Safety Instructions:
Save these Instructions
1. Do not expose the charger to rain or snow.
2. Do not operate or disassemble the charger if it has received a sharp
blow, or has been dropped or damaged in any way.
3. Never alter the AC cord or plug provided with the unit. If the plug will
not fit the outlet, have the proper outlet installed by a qualified
electrician. An improper condition can result in a risk of electric
shock.
4. To reduce the risk of damage to the cord or plug, pull the plug rather
than the cord when disconnecting the charger from the AC receptacle.
5. To reduce the risk of electric shock, unplug the charger from the outlet
before attempting any maintenance or cleaning.
6. Use of an attachment not recommended or sold by Motorola may
result in a risk of fire, electric shock or personal injury.
7. Make sure the cord is located so it will not be stepped on, tripped over
or subjected to damage or stress.
8. An extension cord should not be used unless absolutely necessary.
Use of an improper extension cord could result in a risk of a fire
and/or electric shock. If an extension cord must be used, make sure
that:
The pins on the plug of the extension cord are the same number, size
and shape as those on the plug of the charger.
The extension cord is properly wired and in good electrical condition.
The cord size is 18 AWG for lengths up to 100 feet, and 16 AWG for
lengths up to 150 feet.
9. The supply cord of this charger cannot be replaced. If the cord is
damaged, call customer service at 1-800-638-5119 (U.S. and Canada).
Potentially Explosive Atmospheres
Turn off your radio prior to entering any area with a potentially explosive
atmosphere. Only radio types that are especially qualified should be
used in such areas as “Intrinsically Safe.” Do not remove, install or
charge batteries in such areas. Sparks in a potentially explosive
atmosphere can cause an explosion or fire resulting in bodily injury or
even death.
Note:
The areas with potentially explosive atmospheres referred to
above include fueling areas such as below decks on boats, fuel or
chemical transfer or storage facilities, areas where the air contains
chemicals or particles (such as grain, dust or metal powders) and any
other area where you would normally be advised to turn off your vehicle
engine. Areas with potentially explosive atmospheres are often—but not
always—posted.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn off your
radio when you are near electrical blasting caps, in a blasting area, or in
areas posted “Turn off two-way radios.” Obey all signs and instructions.
Operational Cautions
Antennas
Do not use any portable radio that has a damaged antenna.
If a
damaged antenna comes into contact with your skin, a minor burn can
result.
Batteries
All batteries can cause property damage and/or bodily injury such as
burns if a conductive material—like jewelry, keys or beaded chains—
touch exposed terminals. The conductive material may complete an
electrical circuit (short circuit) and become quite hot. Exercise care in
handling any charged battery, particularly when placing it inside a
pocket, purse or other container with metal objects.
Your Motorola radio operates on General Mobile Radio Service (GMRS)
frequencies and is subject to the Rules and Regulations of the Federal
Communications Commission (FCC). The FCC requires that all operators
using GMRS frequencies obtain a radio license before operating their
equipment. To obtain the FCC forms, please request Form
605
and
159
,
which includes all of the forms and instructions you will need.
If you wish to have the document faxed or mailed, or if you have
questions, please use the following contact information:
You may also visit the FCC’s Web site at http://www.fcc.gov.
Changes or modifications not expressly approved by Motorola may void
the user’s authority granted by the FCC to operate this radio and should
not be made. To comply with FCC requirements, transmitter adjustments
should be made only by or under the supervision of a person certified as
technically qualified to perform transmitter maintenance and repairs in
the private land mobile and fixed services as certified by an organization
representative of the user of those services. Replacement of any
transmitter component (crystal, semiconductor, etc.) not authorized by
the FCC equipment authorization for this radio could violate FCC rules.
Note:
Use of this radio outside the country where it was intended to be
distributed is subject to government regulations and may be prohibited.
Data Operation
If applicable, when using any data feature of the radio with or without
an accessory cable,
position the radio and its antenna at least one
inch (2.5 cm) from the body
.
Approved Accessories
For a list of approved Motorola accessories, visit out Web site at
www.motorola.com.
Electromagnetic Interference/Compatibility
Note:
Nearly every electronic device is susceptible to electromagnetic
interference (EMI) if inadequately shielded, designed or otherwise
configured for electromagnetic compatibility. This device complies with
Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference; and
2. This device must accept any interference received, including
interference that may cause undesired operation.
Facilities
To avoid electromagnetic interference and/or compatibility conflicts,
turn off your radio in any facility where posted notices instruct you to
do so. Hospitals or health care facilities may be using equipment that is
sensitive to external RF energy.
Aircraft
When instructed to do so, turn off your radio when onboard an aircraft.
Any use of a radio must be in accordance with applicable regulations
per airline crew instructions.
Medical Devices – Pacemakers
The Advanced Medical Technology Association recommends that a
minimum separation of 6 inches (15 cm) be maintained between a
handheld wireless radio and a pacemaker. These recommendations are
consistent with the independent research by and recommendations of
the U.S. Food and Drug Administration.
People with pacemakers should:
ALWAYS keep the radio more than 6 inches (15 cm) from their
pacemaker when the radio is turned ON.
Not carry the radio in the breast pocket.
Use the ear opposite the pacemaker to minimize the potential for
interference.
Turn the radio OFF immediately if there is any reason to suspect that
interference is taking place.
Medical Devices – Hearing Aids
Some digital wireless radios may interfere with some hearing aids. In
the event of such interference, you may want to consult your hearing
aid manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the manufacturer
of your device to determine if it is adequately shielded from RF energy.
Your physician may be able to assist you in obtaining this information.
Safety and General Use While Driving
Check the laws and regulations regarding the use of radios in the area
where you drive, and always obey them. If you do use your radio while
driving, please:
Give full attention to driving and to the road.
Use hands-free operation, if available.
Pull off the road and park before making or answering a call if driving
conditions so require.
Do not place a portable radio in the area over an air bag or in the air
bag deployment area. Air bags inflate with great force. If a portable
radio is placed in the air bag deployment area and the air bag inflates,
the radio may be propelled with great force and cause serious injury to
occupants of the vehicle.
For a Fax:
Contact the Fax-On
Demand system
1-202-418-0177
For Mail Service:
Call the FCC Forms
Hotline
1-800-418-FORM (3676)
If You Have Questions
about the FCC License:
Call the FCC
1-888-CALL-FCC
(225-5322)
Channel Frequency Description Channel Frequency Description
1 462.5625
MHz
GMRS/FRS 12 467.6625
MHz
FRS
2 462.5875
MHz
GMRS/FRS 13 467.6875
MHz
FRS
3 462.6125
MHz
GMRS/FRS 14 467.7125
MHz
FRS
4 462.6375
MHz
GMRS/FRS 15 462.5500
MHz
GMRS
5 462.6625
MHz
GMRS/FRS 16 462.5750
MHz
GMRS
6 462.6875
MHz
GMRS/FRS 17 462.6000
MHz
GMRS
7 462.7125
MHz
GMRS/FRS 18 462.6250
MHz
GMRS
8 467.5625
MHz
FRS 19 462.6500
MHz
GMRS
9 467.5875
MHz
FRS 20 462.6750
MHz
GMRS
10 467.6125
MHz
FRS 21 462.7000
MHz
GMRS
11 467.6375
MHz
FRS 22 462.7250
MHz
GMRS
– Battery Meter
Numbers for
Channel,
Call Tone
Numbers for
Codes
– Scan
VOX
i– Hands-Free Use
VOX – Hands-Free Use
With Accessories
Without
Accessories
– Call Tone,
Keypad Tone
– Weather Alert
– Channel Indicator
(see Initial Set Up)
– Lock
– Talk Confirmation Tone
(Roger Beep)
ON
OFF
– On/Off for
each feature
QT – Noise Filtering
Channels and Frequencies
3 =
High Sensitivity
for quiet environments
2 =
Medium Sensitivity
for most environments
1 =
Low Sensitivity
for noisy environments
Note:
When you connect a VOX accessory, the radio is automatically
set to the last chosen sensitivity level.
See Special Features section on Accessories.
Continued on back
FV700 / FV750
Use to:
••
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Turn radio on/off.
Increase or decrease volume
Use Push to Talk
to:
•
•
•
Talk
Save a setting
Accessory Jack
Use and
to:
Scroll through
menus
Turn weather
on/off (+)
–+
MENU
MENU
MENU
MENU
MENU
MENU
MENU
MENU
MENU
MENU
MENU
Use to:
Select Menu
options
Exit the Menu
(when pressed
while in a Menu)
Lock and unlock
the keypad (when
held down and
not in a Menu)
Use to:
Transmit call tone
Speaker
Use Monitor
to:
Scan to see if
anyone is on the
selected channel
MON
VOX
i
PTT
PTT
PTT P TT
PTT
PTT
PTT
PTT
PTT
PTT
PTT
MON
MON
MON
+–
+–
+–
+–
+–
+–
Microphone
ON
OFF
QT
VOX
i
![](/img.php?id=746096&img=bg2.png)
Warranty
Consumer Two-Way Radio Products and Accessories
purchased in the United States or Canada.
What Does this Warranty Cover?
Subject to the exclusions contained to the right, Giant International Ltd.
warrants the Motorola branded consumer two-way radios that operate via
Family Radio Service or General Mobile Radio Service that it manufactures
(“Products”), the Motorola branded or certified accessories sold for use
with these Products that it manufactures (“Accessories”) to be free from
defects in materials and workmanship under normal consumer usage for the
period(s) outlined below. This limited warranty is a consumer’s exclusive
remedy, and applies as follows to new Motorola branded Products and
Accessories manufactured by Giant International Ltd., and purchased by
consumers in the United States or Canada, which are accompanied by this
written warranty:
Who is covered?
This warranty extends only to the first consumer purchaser, and is not
transferable.
What will GIANT INTERNATIONAL LTD. do?
GIANT INTERNATIONAL LTD., at its option, will at no charge repair,
replace or refund the purchase price of any Products or Accessories
that does not conform to this warranty. We may use functionally
equivalent reconditioned/ refurbished/ pre-owned or new Products,
Accessories or parts.
For Accessories, please call the telephone number designated above for
the product with which they are used.
You will receive instructions on how to ship the Products or Accessories
at your expense, to a GIANT INTERNATIONAL LTD. Authorized Repair Center.
To obtain service, you must include: (a) a copy of your receipt, bill of sale or
other comparable proof of purchase; (b) a written description of the problem;
(c) the name of your service provider, if applicable; (d) the name and location
of the installation facility (if applicable) and, most importantly; (e) your
address and telephone number.
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS LIMITED
WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR REFUND AS
PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OF IMPLIED. IN NO EVENT SHALL MOTOROLA OR
GIANT INTERNATIONAL LTD. BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE
PRICE OF THE PRODUCT OR ACCESSORY, OR FOR ANY INDIRECT,
INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR
LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION
OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE
ABILITY OR INABILITY TO USE THE PRODUCTS OR ACCESSORIES TO THE FULL
EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.
Some states and jurisdictions do not allow the limitation or exclusion
of incidental or consequential damages, or limitation on the length of
an implied warranty, so the above limitations or exclusions may not
apply to you. This warranty gives you specific legal rights, and you may
also have other rights that vary from state to state or from one
jurisdiction to another.
1-800-638-5119 1-800-638-5119
Products Covered Length of Coverage Exclusions
A. Products and Accessories as
defined above, unless otherwise
provided for below.
1. Decorative Accessories and
Cases. Decorative covers and
cases.
2. Monaural Headsets. Ear buds
and boom headsets that
transmit mono sound through a
wired connection.
3. Consumer Two-Way Radio
Accessories.
4. Products and Accessories that
are Repaired or Replaced.
A. One (1) year from the date of
purchase by the first consumer
purchaser of the product unless
otherwise provided for below.
1. Limited lifetime warranty for the
lifetime of ownership by the first
consumer purchaser of the
product.
2. Limited lifetime warranty for the
lifetime of ownership by the first
consumer purchaser of the
product.
3. Ninety (90) days from the date of
purchase by the first consumer
purchaser of the product.
4. The balance of the original
warranty or for ninety (90) days
from the date returned to the
consumer, whichever is longer.
Normal Wear and Tear. Periodic maintenance, repair and replacement
of parts due to normal wear and tear are excluded from coverage.
Batteries. Only batteries whose fully charged capacity falls below 80%
of their rated capacity and batteries that leak are covered by this limited
warranty.
Abuse & Misuse. Defects or damage that result from: (a) improper
operation, storage, misuse or abuse, accident or neglect, such as
physical damage (cracks, scratches, etc.) to the surface of the product
resulting from misuse; (b) contact with liquid, water, rain, extreme
humidity or heavy perspiration, sand, dirt or the like, extreme heat, or
food; (c) use of the Products or Accessories for commercial purposes
or subjecting the Product or Accessory to abnormal usage or
conditions; or (d) other acts which are not the fault of Motorola or Giant
International Ltd., are excluded from coverage.
Use of Non-Motorola branded Products and Accessories. Defects or
damage that result from the use of Non-Motorola branded or certified
Products, Accessories, Software or other peripheral equipment are
excluded from coverage.
Unauthorized Service or Modification. Defects or damages resulting
from service, testing, adjustment, installation, maintenance, alteration,
or modification in any way by someone other than Motorola, Giant
International Ltd. or its authorized service centers, are excluded from
coverage.
Altered Products. Products or Accessories with (a) serial numbers or
date tags that have been removed, altered or obliterated; (b) broken
seals or that show evidence of tampering; (c) mismatched board serial
numbers; or (d) nonconforming or non-Motorola branded housings, or
parts, are excluded from coverage.
Communication Services. Defects, damages, or the failure of Products,
or Accessories due to any communication service or signal you may
subscribe to or use with the Products or Accessories is excluded from
coverage.
USA Two-Way Radios Canada Two-Way Radios
How to Obtain Warranty Service or Other Information?
To obtain service or information, please call:
Manufactured, distributed or sold by Giant International Ltd., official
licensee for this product. Motorola, the Motorola logo trademarks and
the Motorola trade dress are owned by Motorola, Inc. and are used
under license from Motorola, Inc. Please contact Giant International
Ltd. at 800-638-5119 for questions/comments, warranty, support, or
service related to this product. MOTOROLA and the Stylized M Logo
are registered in the U.S. Patent & Trademark Office. All other product
or service names are the property of their respective owners.
© Motorola, Inc. 2007.
Patent and Copyright Information
Transmitting a Talk Confirmation Tone
You can set your radio to transmit a unique tone when you finish
transmitting. It is like saying “Roger” or “Over” to let others know you
are finished talking.
1. With the radio on, press until the appears. The current
setting On/Off flashes.
2. Press or to turn On or Off.
3. Press to set or to continue set up.
Keypad Tones
You may enable or disable the speaker key tones. You will hear the key
tone each time a button is pushed.
1. Press until appears. The current setting On/Off will flash
2. Press either or to turn On or Off.
3. Press to confirm or to continue set up.
When the Key Tone Feature is off, the following are not disabled:
• Transmit timeout alert tone;
• Power down call tone;
• Low battery alert tone; or
• The transmitted Talk Confirmation Tone.
To transmit to a radio that has QT noise filtering turned on:
1. Select the same channel and Interference Eliminator Code as the
other radio.
2. Press to send a call tone. This allows your voice to pass through
the QT noise filter on the receiving radio.
3. Press and speak normally.
Note: If you skip step 2, the beginning of your message may not be
heard on the receiving radio. For a 30-second period, starting after the
last transmission, all transmissions received on the selected channel
and code will pass through the QT noise filter.
Special Features
Keypad Lock
To avoid accidentally changing your radio settings:
1. Press and hold until displays.
2. When in lock mode, you can turn the radio on and off, adjust the
volume, receive, transmit, send a call tone, and monitor channels. All
other functions are locked.
To unlock the radio, press and hold until is no longer displayed.
Priority Scan
Use scan to monitor channels and codes for transmissions or to find
someone in your group who has accidentally changed channels.
With priority scan, your home channel is scanned more frequently than
any other channel. The home channel is the channel where your radio
was set when you started to scan. If you activate scan while your
radio’s Interference Eliminator Code is set to a number between 1 and
121, the radio checks for activity on each programmed channel and
code combination.
Notes:
• All transmissions using code 0 or any other code are ignored.
• The default code for each channel is 1.
• If scanning on code 0, all channels and code combinations are
scanned.
1. To start scanning, briefly press and release . The scan indicator
displays , and the radio begins to scroll through the channel and
Interference Eliminator Code combinations.
2. When the radio detects channel activity, it stops scanning and you
can hear the transmission.
3. To respond and talk to the person transmitting, press within five
seconds.
4. To stop scanning, briefly press and release .
Note: If you press while the radio is scanning, the radio will
transmit on the channel you selected before you activated scan. If no
transmission occurs within five seconds, scanning will resume.
Hands-Free Use With Accessories (VOX)
You can transmit hands-free with the use of optional accessories. Once
VOX is turned on, the radio detects your voice and transmits when you
speak.
1. Turn the radio off and plug the VOX accessory into the accessory
port.
2. Turn the radio on. VOX shows on the display.
3. Adjust the volume appropriately by rotating . Lower the volume
before placing the accessory on your head or in your ear.
4. To turn off, simply remove accessory.
Note: There is a short delay between the time you start talking and
when the radio transmits. There is a short delay before the
transmission is completed.
Using Audio Accessories:
Many accessories (sold separately) are available for your radio. For
more information, visit our Web site at www.motorola.com or
http://shop.giantintl.com.
Removing Channels from the Scan List (Nuisance Delete
Feature)
1.To prevent the radio from scanning a channel, press and hold or
for at least three seconds, then release, when the scan first
stops on that channel. This temporarily removes the channel from
the scan list.
2. Press to exit scan mode.
3. Press a second time to activate scan again.
4. To restore a previously deleted channel, turn the radio off and then
back on. The channel is now restored.
Note: You cannot remove your home channel from the scan list. The
home channel is the channel your radio was set to when you started
the scanning.
QT Noise Filtering
The QT noise-filtering feature helps to ensure uninterrupted
communication with other Motorola radios that have this feature. This
feature filters out unwanted transmissions from other radios. This is
useful in places where there is heavy radio traffic, such as amusement
parks or ski resorts.
Note: QT noise filtering is not available when the radio is scanning.
To turn QT noise filtering on or off:
1. Short press until displays. The current setting On/Off will
flash.
2. Press or to turn noise filtering On or Off.
3. Press to confirm your selection or to continue set up.
QT
FV700 / FV750
Weather
Your radio can tune in to broadcasts by the United States National
Oceanic and Atmospheric Administration (NOAA) Weather Radio and
Environment Canada Weatheradio.
You can listen to a weather channel or set your radio to alert you to
emergency weather broadcasts that interrupt routine broadcasts.
When you listen to a weather channel, you cannot use your radio in
scan mode or for two-way communications.
Both NOAA and Environment Canada have transmitters located
throughout the United States and Canada, respectively. These
transmitters broadcast watches, forecasts, and other information 24
hours a day.
Weather Channels and Frequencies
Note: NOAA weather radio stations are assigned to cover specific
areas and service may be limited. Please check with your local weather
office for frequency and details, or visit www.nws.noaa.gov/nwr in the
US or www.msc-smc.ec.gc.ca/cd/factsheets/wxradio in Canada to view
the appropriate transmitter for your area.
The use of the NOAA logo does not provide an endorsement or implied
endorsement by NOAA’s National Weather Service, nor does the use of
the Weatheradio logo provide an endorsement or implied endorsement
by Environment Canada.
Turning Weather Channel Reception On and Off
1. To turn weather reception on, press and hold for three seconds.
2. To turn off, press or turn the radio off and then back on.
Setting the Weather Channel
Your radio receives weather frequencies:
1. After turning weather reception on, press . The current channel
flashes.
2.Press or to select the channel.
3. Press to save the weather channel setting.
Setting the Weather Alert
Your radio receives weather frequencies:
1. After turning weather reception on, press twice. On/Off displays.
2.Press or to select On/Off. If you activate Weather Alert and
return to two-way mode, will display.
3. Press to save the weather channel setting.
As with two-way radio reception, weather channel reception depends
on how close you are to a transmitter and whether you are indoors or
outdoors. Because weather channels are transmitted without codes,
they may contain static or noise.
Weather
Channel
WX1
WX2
WX3
WX4
WX5
WX6
Frequency
162.550 MHz
162.400 MHz
162.475 MHz
162.425 MHz
162.450 MHz
162.500 MHz
Weather
Channel
WX7
WX8
WX9
WX10
WX11
Frequency
162.525 MHz
161.650 MHz
161.775 MHz
161.750 MHz
162.000 MHz
MENU
MENU
MENU
MENU
MENU
MENU
MENU
MENU
MENU
MENU
PTT
PTT
PTT
PTT
PTT
PTT
PTT
PTT
+–
+–
+
+
+
+
–
–
+–
+–
MON
MON
MON
MON
