Gibson Innovations SHB4385 Bluetooth Headphone User Manual
Gibson Innovations Limited Bluetooth Headphone Users Manual
Users Manual
![](/img.php?id=3592814&img=bg1.png)
SHB4385
BASS+
User manual
Register your product and get support at
www.philips.com/support
![](/img.php?id=3592814&img=bg3.png)
1EN
Contents
Contents
1 Important safety instructions 2
Hearing Safety 2
General information 2
2 Your Bluetooth wireless
headset 3
What's in the box 3
Other devices 3
Overview of your Bluetooth
wireless headset 4
3 Get started 5
Charge the battery 5
Pair between both sides of the
headset 5
Pair your headset with the
Bluetooth device 6
4 Use your headset 7
Connect the headset to a
Bluetooth device 7
Power on/o 7
Manage your calls and music 7
LED indicator status 8
How to wear 8
5 Technical data 9
6 Notice 10
Declaration of conformity 10
Disposal of your old product
and battery 10
Compliance with EMF 11
Trademarks 11
7 Frequently asked questions 12
![](/img.php?id=3592814&img=bg4.png)
2EN
1 Important
safety
instructions
Hearing Safety
Danger
•To avoid hearing damage, limit the time you
use headset at high volume and set the
volume to a safe level. The louder the volume,
the shorter the safe listening time is.
Be sure to observe the following
guidelines when using your headset.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the volume
continuously upwards as your
hearing adapts.
• Do not turn up the volume so high
that you can’t hear what’s around
you.
• You should use caution or
temporarily discontinue use in
potentially hazardous situations.
• Excessive sound pressure from
earphones and headset can cause
hearing loss.
• Using headset with both ears
covered while driving is not
recommended and may be illegal in
some areas while driving.
• For your safety, avoid distractions
from music or phone calls while in
trac or other potentially dangerous
environments.
General information
To avoid damage or malfunction:
Caution
•Do not expose headset to excessive heat.
•Do not drop your headset.
•Headset shall not be exposed to dripping or
splashing.
•Do not allow your headset to be submerged
in water.
•Do not use any cleaning agents containing
alcohol, ammonia, benzene, or abrasives.
•If cleaning is required use a soft cloth, if
necessary dampened with a minimum amount
of water or diluted mild soap, to clean the
product.
•The integrated battery shall not be exposed
to excessive heat such as sunshine, re or the
like.
•Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
About operating and storage
temperatures and humidity
• The storage temperature is between
-15°C to 55 °C. The operation
temperature is 45°C (max.) (up to
90% relative humidity).
• Battery life may be shorter in high or
low temperature conditions.
![](/img.php?id=3592814&img=bg5.png)
3EN
2 Your
Bluetooth
wireless
headset
Congratulations on your purchase, and
welcome to Philips! To fully benet
from the support that Philips oers,
register your product at www.philips.
com/welcome.
With this Philips wireless headset, you
can:
• enjoy convenient wireless
handsfree calls;
• enjoy and control wireless music;
• switch between calls and music.
What's in the box
Philips True Wireless headset BASS+
SHB4385
Replaceable rubber ear caps x 2 pairs
Charging case
USB charging cable (for charging only)
Quick start guide
Other devices
A mobile phone or device (e.g.
notebook, PDA, Bluetooth adapters,
MP3 players etc) which supports
Bluetooth and is compatible to the
headset (see ‘Technical data” on page
9).
![](/img.php?id=3592814&img=bg6.png)
4EN
Overview of your
Bluetooth wireless
headset
3
a Multi-function buttons
b LED indicator
c Micro USB charging slot
2
1
![](/img.php?id=3592814&img=bg7.png)
5EN
3 Get started
Charge the battery
Note
•Before you use your headset/charging case for
the rst time, charge the battery for 5 hours for
optimum battery capacity and lifetime.
•Use only the original USB charging cable to
avoid any damage.
•Finish your call before charging the headset,
as connecting the headset for charging will
power the headset o.
Charging case
Connect one end of the USB cable into
the charging case, and another end into
the power source.
» The charging case starts charging.
• When the charging case is charging,
a white LED light will be displayed.
• When the charging case is fully
charged, the white light goes o.
Headset
Place the headset on the charging case.
» The headset start charging.
• When the headset is charging, a
white LED light will be displayed.
• When the headset is fully charged,
the white light goes o.
Tip
•Normally, a full charge takes 2 hours (for the
headset or charging case).
Pair between both sides
of the headset
1 Make sure that the headset is fully
charged.
2 Press and hold the multi-function
buttons on both sides of the
headset for 2 seconds.
» The white LED lights on both
side of the headset ash 3 times.
» Both sides of the headset are
connected automatically.
» The headset is ready to pair with
the Bluetooth device.
![](/img.php?id=3592814&img=bg8.png)
6EN
Pair your headset with
the Bluetooth device
1 Turn on the Bluetooth function of
your mobile phone.
2 Pair the headset with the mobile
phone. For detailed information,
refer to the user manual of your
mobile phone.
Tip
•The headset stores the last 2 devices in the
memory. If you try to pair more than 2 devices,
the earliest paired device is replaced by the
new one.
The following example shows you how
to pair the headset with your mobile
phone.
1 Activate the Bluetooth feature
of your mobile phone, select
Philips SHB4385.
2 Enter the headset password "0000"
(4 zeros) if prompted. For those
mobile phones featuring Bluetooth
3.0 or higher, no need to enter a
password.
Philips SHB4385
SHB4405
![](/img.php?id=3592814&img=bg9.png)
7EN
4 Use your
headset
Connect the headset to a
Bluetooth device
1 Turn on your mobile
phone/Bluetooth device.
2 Press and hold the multi-function
buttons on both sides of the
headset for 2 seconds.
» The white LED lights on both
sides of the headset ash 3
times.
» Both sides of the headset are
connected automatically.
» The headset is reconnected
to the last connected mobile
phone/Bluetooth device
automatically. If the last one is
not available, the headset tries
to reconnect to the second last
connected device.
Tip
•If you turn on the mobile phone/Bluetooth
device or activate the Bluetooth feature after
turning on the headset, you have to reconnect
the headset and mobile phone/Bluetooth
device manually.
Note
•If the headset fails to connect to any
Bluetooth device within 5 minutes, it will
switch o automatically to save the battery life.
Power on/o
Task Multi-
function
button
Operation
Turn the
headset on.
Right and
left head-
set
Press and
hold for 2
seconds.
Turn the
headset o.
Right and
left head-
set
Press and
hold for 3
seconds.
» The
white
LED
ashes
for 3
times.
Manage your calls and
music
Music control
Task Multi-
function
button
Operation
Play or pause
music.
Right
headset
Press once.
Volume up Left
headset
Press twice.
Volume down Left
headset
Press once.
Skip forward. Right
headset
Press twice.
Skip
backward.
Right
headset
Press 3
times..
![](/img.php?id=3592814&img=bga.png)
8EN
Call control
Task Multi-
function
button
Operation
Pick up/hang
up a call.
Right
headset
Press once.
» 1 beep.
Reject an
incoming call.
Right
headset
Press and
hold for 1
second.
» 1 beep.
Switch caller
during a call.
Right
headset
Press twice.
Voice control
Task Multi-
function
button
Operation
Siri/Google
Now.
Right
headset
Press twice
and hold for 1
second.
LED indicator status
Headset status Indicator
The headset is
connected to a
Bluetooth device,
while the headset
is in standby
mode or while
you are listening
to music.
The blue LED
ashes for every 5
seconds.
The headset is
ready for pairing.
The white LED
ashes 3 times.
The headset
is on but not
connected to a
Bluetooth device.
The blue LED
ashes for every 5
seconds.
If no connection
can be made, the
headset will turn
itself o within 5
minutes.
Low battery level
(headset).
You will hear
“battery low” on
the headset.
Low battery level
(charging case).
The red LED on
the charging case
ashes every 1
second.
Battery is
fully charged
(headset).
The white LED on
the headset is o.
Battery is fully
charged (charging
case).
The white LED on
the charging case
is o.
How to wear
1 2
3
![](/img.php?id=3592814&img=bgb.png)
9EN
5 Technical
data
Headset
• Music time: 6 hours (additional 6
hrs with charging case)
• Talk time: 6 hours (additional 6 hrs
with charging case)
• Standby time: 200 hours
• Charging Time: 2 hours
• Normal time for a full charge: 2
hours
• Rechargeable lithium ion battery:
(105mAh)
• Bluetooth 4.2, Bluetooth mono
support (Headset Prole - HSP,
Hands-Free Prole - HFP),
Bluetooth stereo supported
(Advanced Audio Distribution
Prole - A2DP; Audio Video Remote
Control Prole - AVRCP)
• Support audio codec (SBC)
• Frequency range: 2.402-2.480GHz
• Transmitter power: <20dBm
• Operating range: Up to 10 meters
(33 feet)
• Digital echo & noise reduction
• Auto power o
Charging case
• Charging time: 2 hrs
• Rechargeable Li-ion battery : 350
mAh
• Number of recharges supported: 1
Note
•Specications are subject to change without
notice.
![](/img.php?id=3592814&img=bgc.png)
10 EN
6 Notice
Declaration of conformity
Hereby, Gibson Innovations declares
that this product is in compliance
with the essential requirements
and other relevant provisions of
Directive 2014/53/EU. You can nd the
Declaration of Conformity on www.p4c.
philips.com.
Disposal of your old
product and battery
Your product is designed and
manufactured with high quality
materials and components, which can
be recycled and reused.
This symbol on a product means that
the product is covered by European
Directive 2012/19/EU.
This symbol means that the product
contains a built-in rechargeable
battery covered by European Directive
2013/56/EU which cannot be disposed
of with normal household waste. We
strongly advise you to take your product
to an ocial collection point or a Philips
service centre to have a professional
remove the rechargeable battery.
Inform yourself about the local separate
collection system for electrical and
electronic products and rechargeable
batteries. Follow local rules and
never dispose of the product and
rechargeable batteries with normal
household waste. Correct disposal of
old products and rechargeable batteries
helps prevent negative consequences
for the environment and human health.
Remove the integrated battery
If there is no collection/recycling system
for electronic products in your country,
you can protect the environment by
removing and recycling the battery
before disposing the headset.
• Make sure the headset is
disconnected from the charging
case before removing the battery.
![](/img.php?id=3592814&img=bgd.png)
• Make sure the charging case is
disconnected from the USB charging
cable before removing the battery.
Compliance with EMF
This product complies with all applicable
standards and regulations regarding
exposure to electromagnetic elds.
Environmental information
All unnecessary packaging has been
omitted. We have tried to make the
packaging easy to separate into three
materials: cardboard (box), polystyrene
foam (buer) and polyethylene (bags,
protective foam sheet.)
Your system consists of materials
which can be recycled and reused if
disassembled by a specialized company.
Please observe the local regulations
regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
1
2
3
Trademarks
Bluetooth
The Bluetooth® word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such
marks by Gibson Innovations Limited is
under license.
Siri
Siri is a trademark of Apple Inc., registered
in
the U.S. and other countries.
Google
Google and the Google Logo are
registered trademarks of Google Inc.
12
7 Frequently
asked
questions
My Bluetooth headset does not switch
on.
The battery level is low. Charge the
headset.
I cannot pair my Bluetooth headset
with a mobile phone.
The Bluetooth is disabled. Enable
the Bluetooth feature on your mobile
phone and turn on the mobile phone
before you turn on the headset.
Pairing does not work.
Make sure the headset is in pairing
mode.
• Follow the steps described in this
user manual (see ‘Pair your headset
with the Bluetooth device” on page
6).
Make sure the left and right sides of the
headset are successfully connected.
• Make sure that the white LED lights
on both side of the headset ash 3
times.
If there is still pairing issue, power o the
headset. Then power on the headset
and repeat the pairing procedure.
The mobile phone cannot nd the
headset.
•The headset may be connected to a
previously paired device. Turn o the
connected device or move it out of
range.
•Pairing may have been reset or the
headset has been previously paired
with another device. Pair the headset
with the mobile phone again as
described in the user manual (see
‘Pair your headset with the Bluetooth
device” on page 6).
My Bluetooth headset is connected to a
Bluetooth stereo enabled mobile phone,
but music only plays on the mobile
phone speaker.
Refer to the user manual of your mobile
phone. Select to listen to music through
the headset.
The audio quality is poor and crackling
noise can be heard.
The Bluetooth device is out of range.
Reduce the distance between your
headset and Bluetooth device, or remove
obstacles between them.
The audio quality is poor when streaming
from the mobile phone is very slow, or
audio streaming does not work at all.
Make sure your mobile phone not only
supports (mono) HSP/HFP but also
supports A2DP (see ‘Technical data” on
page 9).
I hear but cannot control music on my
Bluetooth device (e.g. play/pause/skip
forward/backward).
Make sure the Bluetooth audio source
supports AVRCP (see ‘Technical data” on
page 9).
13
The volume level of the headset is too
low.
Some Bluetooth devices cannot link the
volume level with the headset through
volume sync. In this case, you have to
adjust the volume on your Bluetooth
device and headset independently to
achieve an appropriate volume level.
How can I restore all original headset
settings?
1 When the headset is powered o,
press and hold the multifunction
button for 10 seconds.
» You will hear doo-doo sound.
The headset is o
2 Remove the old device name on
the headset.
3 Power on the headset.
» The headset will enter the
pairing mode again.
4 Pair between both sides of the
headset (see ‘Pair between both
sides of the headset” on page
5).
5 Pair your headset with the
Bluetooth device (see ‘Pair your
headset with the Bluetooth device”
on page 6).
For further support, visit www.philips.
com/support.
![](/img.php?id=3592814&img=bg10.png)
Copyright © Gibson Innovations Limited 2017. All rights reserved
This product has been manufactured by, and is sold
under the responsibility of Gibson Innovations Ltd., and
Gibson Innovations Ltd. is the warrantor in relation to
this product.
Philips and the Philips Shield Emblem are registered trademarks of Koninklijke
Philips N.V. and are used under license
UM_SHB4385_00_EN_V0.2
WK1732
![](/img.php?id=3592814&img=bg11.png)
English:
Notice of compliance
The device complies with the FCC rules, Part 15. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired
operation.
FCC rules
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
Relocate the receiving antenna.
Increase the separation between equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Canada:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following
Two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
CAN ICES-3(B)/NMB-3(B)
IC Radiation Exposure Statement:
This equipment complies with Canada radiation exposure limits set forth for uncontrolled environments.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Model: SHB4385
FCC ID: 2AANUSHB4385
ISED Cerification Number: 11260A-SHB4385
This equipment should be installed and operated with a minimum distance of 5 millimeters between
the radiator and your body.
The RF exposure complicance distance is 5 millimeters.
![](/img.php?id=3592814&img=bg12.png)
French:
Avis de conformité
Cet appareil satisfait aux règlements de la FCC partie 15 du Code of Federal Regulations. Son fonctionnement est
assujetti aux deux conditions suivantes :
1. Cet appareil ne doit pas causer d’interférence préjudiciable et
2. l’appareil doit accepter toute interférence reçue, y compris les interférences qui peuvent causer un
fonctionnement non désiré.
Règlement de la FCC
Cet équipement a été testé et jugé compatible avec les limites s’appliquant aux appareils numériques de la classe B,
conformément à l’article 15 du règlement de la FCC. Ces limites ont été définies pour fournir une protection
raisonnable contre les interférences nuisibles dans le cadre d’une installation résidentielle. Cet équipement génère,
utilise et peut émettre de l’énergie radiofréquence et, s’il n’est pas installé ni utilisé conformément aux instructions,
peut causer des interférences gênantes pour les communications radio.
Rien ne garantit toutefois que des interférences ne surviendront pas dans une installation particulière. Si cet
équipement cause des interférences nuisibles pour la réception de la radio ou de la télévision, ce qui peut être
déterminé en mettant l’équipement hors tension puis sous tension, l’utilisateur devra essayer de corriger ces
interférences en effectuant une ou plusieurs des opérations suivantes :
Déplacez l’antenne de réception.
Augmentez la distance entre l’équipement et le récepteur.
Branchez l’équipement à une prise d’un circuit autre que celui sur lequel le récepteur est branché.
Consultez le détaillant ou un technicien de radiotélévision expérimenté.
Canada :
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2)
l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
CAN ICES-3(B)/NMB-3(B)
Déclaration d’IC sur l’exposition aux radiations:
Cet équipement est conforme aux limites d’exposition aux radiations définies par le Canada pour des
environnements non contrôlés.
Cet émetteur ne doit pas être installé au même endroit ni utilisé avec une autre antenne ou un autre
émetteur.
radiateur et votre corps.
Cet équipement devrait être installé et actionné avec une distance minimum de 5 millimètres entre le
La distance de conformité à l'exposition RF est de 5 millimètres
