HYUNDAI MOBIS IBU-4E02 Smart Key ECU User Manual
HYUNDAI MOBIS CO., LTD. Smart Key ECU Users Manual
User manual
![](/img.php?id=3708331&img=bg1.png)
1. GENERAL DISCRIPTION
The SMART KEY ECU is a part of START-STOP BUTTON SYSTEM.
It is possible to output the LF(125kHz) signal by pushing the button of door handle and SSB.
If the button of door handle or SSB button is pressed, SMART KEY ECU output the LF(125kHz) signal.
1) LF signal output for engine start
SSB button is pressed, SMART KEY ECU output LF signal through the interior LF antenna
2) LF signal output for door lock/unlock and trunk release
The button of door handle or trunk is pressed, SMART KEY ECU output LF signal thtough the exterior
LF antenna for Fob searching
2. ELECTRICAL CHARACTERISTICS
Dark current 5mA Max.
Modulation ASK
Operating temperature -30℃ ~ +75℃
Operating frequency 125KHz
Manual of SMART KEY ECU
Operating voltage 9V ~ 16V
SMART KEY ECUmodel name
for Fob searching.
Product: Smart Key ECU
Model Name: IBU-4E02
FCC Warning
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
■Reorient or relocate the receiving antenna.
■Increase the separation between the equipment and receiver.
■Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
■Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void
your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
IC Warning
"This device complies with Industry Canada licence-exempt RSS standard(s)."
Operation is subject to the following conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas provoquer de brouillage, et (2)
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
