HB157 Bluetooth Keyboard
Packing Contents:
1. Keyboard
2. User manual
3. Micro-USB charging cable
一.Bluetooth Keyboard Features:
1. Built-in Broadcom Bluetooth 3.0 module keyboard
2. For IPAD, Samsung, and other tablets which supports HID
3. MICRO interface, easy to charge
4. Built-in rechargeable lithium battery
5. Light weight, quiet keystrokes, dust-proof
7. Energy saving keyboard sleep mode
二. Bluetooth Keyboard Specification:
1.Bluetooth 3.0 interface standard
2.Operating Distance to 10 meters
3.Modulating System: GFSK
4.Operation Voltage: 1.8-3.6V
5.Working Current: <2.0mA
6.Standby Current::<0.3mA
7.Sleeping Current: <40uA
8.Charging Current:≥ 200mA
9.Standby Time: >30 days
10.Charging Time: <2 hours
11.Lithium Battery Capacity:160mA
12.Uninterrupted Working Time: 64 hours
13.Lithium Battery Life: 3 years
14.Lithium Battery Specification: 2.5*20*40mm
15.Key Strength: 80±10g
16.Key life: 5 million strokes
17.Operating Temperature: -10-+55 C
三.Bluetooth Keyboard Pairing method
Step1: Press the button about 3 seconds. The blue status light will be on for 2 seconds and then
off .
Step2: Press the button again, the indicator light will be blinking,now the keyboard is
ready to connect to your device.
Step3: Turn your device bluetooth on and search our keyboard bluetooth signal,find”bluetooth 3.0
keyboard”
Step4: Input the code on the keyboard and press enter; when connected the indicator light will
be turn off automatically.
![](/img.php?id=3079361&img=bg2.png)
四.Keyboard status light
1. :Caps lock light: When press the status light will be on in blue,input words are
upper-ase status ,press the blue light will be off,the input words are lower-case status.
2. : Bluetooth status light: Press on the button, the status light will be blinking in
blue,status light will stay on until the keyboard connect with your device.
3. “ ”: Charging light(Red): it will be red when charing and turn off when fully charged.
“ ”: Battery status light in Blue: when switch the keyboard bluetooth on,it is in blue
blinking and will be off in 3 seconds,When the power voltage under 3.2V, it is blue blinking
will blinking blue untill keyboard is out of power, light will be turn off automatically.
五.Battery
The long-lasting rechargeable battery can service you for several weeks
With no memory effect, the lithium battery can be charged at any time.
In order to extend service life,we recommend you turn the keyboard off when there is long time
with no interactive.
六.Charging
When the battery power is low, the[power] indicator light will start blinking,it is time to recharge
the keyboard.
Step1: Connect Mirco-USB of the native USB power cable to the keyboard charging interface.
Step2: Connect USB-A to the power adapter or computer's USB interface.
Step3:the red indicator light will stay on when the keyboard is charging. Once it finished
charging the indicator light will turn off.
七.Energy Saving Sleep Mode
The keyboard will kick into sleep mode when it is inactive for 15 minutes. To activate from sleep
mode, just press any key and wait 3 seconds ,the keyboard will come back on.
八:Safety Caution
1. Keep the item away from sharp objects.
2. Do not place heavy object on top of the keyboard.
3. Do not Microwave the item.
4. Do not force or distorted the keyboard
5. Keep away from oil.chemical or any other organic liquid
九.Cleaning
Clean the silicone keyboard with water, alcohol or alcohol based disinfectant
十.Troubleshooting
A. Unable to connect
![](/img.php?id=3079361&img=bg3.png)
1.Make sure the power switch is on. (the power indicator is shine)
2.Make sure the keyboard is within the operating distance.(within 10 meters)
3.Make sure the battery storage have power.
4.Make sure the Bluetooth in tablet pc is on .
5.Press the key””, check the Bluetooth status.
6.The solution of above 1-5 questions:
The keyboard may long use has out of power, in such case charge battery can solve.
B.Unable to Charge Keyboard
1.Make sure the USB power cable is connected properly to the keyboard and the power source.
2.Make sure the wall charger is plug into the power outlet.
十一.Special Keys Description
Long press Fn and combination with F1-F12 and insert keys to the shift multimedia keys, and
mainly be used in the operation of tablets multimedia.
十二:Storing the Ipad for Travel
To store the Ipad
1.Line up the 30-pin port connector on the Ipad with the slot on the short end of the keyboard
case.
2.Place the Ipad screen down,into the keyboard case.
十三.Disposal of Waste batteries
Insert screwdriver between plastic top and metal case at keyboard top or bottom and Pry up
plastic top and remove it completely. This action destroys keyboard separate battery from
circuit board,it is your responsible to hand this over to an applicable collection and recycling will
help to conserve natural resources and prevent potential negative consequences for human health
and the environment due to the possible presence of hazardous in batteries and electrical and
electronic equipment.
According to China << Electronic information products pollution control measures>>
ingredients
(Pb)
(Hg)
(Cd)
(Cr(VI))
(PBB)
(PBDE)
Cable
X
O
O
O
O
O
PWAs
X
O
O
O
O
O
Plastic parts
O
O
O
O
O
O
Membrane
O
O
O
O
O
O
Meter parts
X
O
O
O
O
O
Rubber dome
O
O
O
O
O
O
O=stands for this toxic and hazardous content in homogeneous material is under the
SJ/T11363-2006 Standards limits
X=stands for this toxic and hazardous content in homogeneous material is beyond the
SJ/T11363-2006 Standards limits
Under the ingredients with "X" in the form all are up to ROHS
"on 27 January 2003 the European parliament and the council announce electronic equipment
![](/img.php?id=3079361&img=bg4.png)
in limiting the use of certain hazardous substances directive 2002/95/EC"
Note: the environmental protection using period reference standard depends on the product of
regular work temperature and humidity conditions
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
