DC140 2.4GHz Wireless Optical Mouse Page 1 of 6 1.0 Edition
2.4GHz Wireless Optical Mouse
DC140-210 USER’S MANUAL
Important Ergonomic Information
Some experts believe that using any mouse or trackball may cause serious injury to hands,
wrists, arms, neck, or back. If you feel pain, numbness, or weakness in these areas, see a
qualified health professional.
TO REDUCE THE RISK OF INJURY, FOLLOW THESE PRECAUTIONS:
Take frequent breaks, get up and walk around several times every hour.
Vary your tasks throughout the day.
Keep your shoulders relaxed with your elbows at your side. Position your keyboard
and mouse so you do not have to reach.
Adjust your chair and keyboard so your upper arms and wrists are straight.
Avoid resting your wrists on sharp edges.
System Requirement
Mouse compatible with standard Microsoft OS
3
rd
button and wheel function require Win98/ ME/ 2000/ XP/ Vista
If your computer’s operating system is Windows 98/ 98SE, please prepare the
Windows98 or 98SE compact disk for system’s request during the installation of mouse.
Before you begin
Keep this installation guide for future reference! It contains Important Troubleshooting
Information.
Keep your old PS/2 or USB mouse as back-up devices.
Getting Started
Congratulations on your purchase of the DC140 Wireless Optical Mouse. The DC140
mouse combines state of the art design with usability. Instead of using your hand and wrist,
your arm will let the optical DC140 mouse float without any effort. The DC140 mouse fits
like a glove and is available in 170mm, 190mm, and 210mm three sizes to match the needs of
all kinds of users, so there is a DC140 for everyone.
By using the advanced RF technology a 360° operation is possible and no line-of-sight
DC140 2.4GHz Wireless Optical Mouse Page 2 of 6 1.0 Edition
is required between the receiver and the mouse. The DC140 designed a low power indicator
on the scroll wheel of the mouse will light to indicate battery low power. With numerous
user-friendly functions and the compact and ergonomic design, the RF mouse may offer users
the best experience of utilization and the most convenience.
Package Contains
Your DC140 Mouse package includes the following:
1. The wireless optical mouse
2. USB storable receiver
3. User’s manual
Note:If any part is missing, please contact your dealer for a replacement immediately.
Precaution
!
!!
!
The optical mouse can not work on a glass or mirror surface. Avoid operating this
mouse on a glossy surface; otherwise, this mouse may not operate normally.
!
!!
!
For consideration of saving battery power, it is strongly recommended to operate an
optical mouse on a bright surface with fine texture to obtain lower power
consumption of the high illumination LED. A very dark surface will cause higher
power consumption.
!
!!
!
For optimal performance, mouse should be no more than 5M away from receiver.
!
!!
!
For a better transmission distance, avoid using this device on a metal plate or
desktop because a large surface of iron, aluminum, copper and other metal will act
as a shield or ground to the RF antenna of the mouse and receiver. Operating on a
metal surface may shorten the transmission distance.
!
!!
!
If your notebook computer has a metal (contains Al or Mg) case, the metal housing
of the LCD panel will isolate partial radiation of the RF signal from the mouse. This
could possibly result in reducing the distance of transmission when you operate the
mouse right in front of the notebook and when the receiver is connected on the back
of the notebook. However, the RF mouse should work properly while you are
operating the mouse just beside your desktop computer.
![](/img.php?id=1109795&img=bg3.png)
DC140 2.4GHz Wireless Optical Mouse Page 3 of 6 1.0 Edition
Overview
Hardware Installation Guide (Mouse)
Connect the receiver with computer.
Plug in the USB receiver to any available USB port or hub connected to your computer.
(Windows will now detect the mouse and install the required drivers automatically).
Synchronize the RF Mouse (Pairing)
If the mouse is in sleep mode click the mouse button once to wake it up.
1. Power on the mouse.
2. Bring the mouse within 1 ft range from the receiver.
3. Hold the mouse upside-down and use a pointed object, such as a pen tip, to click the
CONNECT button (ID button) twice.
CLICK ANY BUTTON, YOUR MOUSE IS NOW READY TO BE USED
Note: * During normal use, please make sure that the mouse is no more than 5M away
from the receiver in order to have reliable connection.
Button #1 – Left mouse click
Button #3 – Centre scroll
wheel
Button#2–Right mouse click
![](/img.php?id=1109795&img=bg4.png)
DC140 2.4GHz Wireless Optical Mouse Page 4 of 6 1.0 Edition
Operation Guide
Charge the mouse
This mouse comes with a Li-ion polymer battery, which is not user replaceable. This battery
should last the whole life span of the mouse if the mouse is recharged properly. So, users not
only can save a lot of money for periodically replacing batteries, but also conserve the
environment.
It is recommended to charge the battery to full before you start using the mouse. The required
charging time is:
4 hours from a USB extension cord.
The Li-ion polymer battery inside the mouse is well protected both on charge and discharge.
Battery Low Indication
When battery becomes low, battery indicator blue LED on the scroll wheel of the mouse will
light. If the mouse is not recharged, and is kept operating for a certain amount of time, the
internal protection circuit will shut off the power. At this time, the mouse is not operable.
Users now should charge the mouse immediately.
Operations On Power Saving Mode
In order to conserve battery power, the mouse is designed to reduce power consumption
gradually from standby mode to sleep mode, if it is not being used.
Stand by modes: The standby mode is entered immediately upon stopping moving mouse.
The optical sensor of the mouse will reduce current consumption gradually.
Sleep mode: When the RF link between the mouse and the receiver is stopped (Ex: host
computer is turned off, or the mouse is out of range the mouse goes to sleep mode. In
sleep mode, pressing any key can boring the mouse back to work.
GENERAL SPECIFICATIONS
3 Buttons Rechargeable Wireless Optical Mouse.
Precision Optical Sensor
Long range/ Less interference wireless connection
Low Power Indicator.
![](/img.php?id=1109795&img=bg5.png)
DC140 2.4GHz Wireless Optical Mouse Page 5 of 6 1.0 Edition
USB Thumb Size Receiver
USB to USB Extension Cable for recharge.
Ergonomic design (universal left and right handed)
Compatible with USB V1.1 low-speed & USB 2.0 high-speed.
Troubleshooting
Common troubleshooting steps
1. If you feel the mouse does not move smooth as usual, please check the battery indicator
on the mouse. If batteries have lost their charge, replace them. Remember do not put
the batteries in the wrong direction
2. Un-plug and re-plug the receiver.
3. Install fresh batteries in the mouse
4. Test the device on another USB port or computer
5. Some surfaces may “trick” the sensor, such as reflective surfaces like glass or mirrors.
As a result this product will not work on glass or mirror surfaces. The sensor should
perform well on all other surfaces.
Electromagnetic Characteristics (EMC)
Tested to comply with FCC standards
For home or office use
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
IMPORTANT NOTE:
DC140 2.4GHz Wireless Optical Mouse Page 6 of 6 1.0 Edition
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. To maintain
compliance with FCC RF exposure compliance requirements, please avoid direct contact to the transmitting antenna during
transmitting. End users must follow the specific operating instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
CE - Type acceptance: EN300 328 FHSS Device
