Junlan Electronic BRC20605 BLUETOOTH STEREO HEADSET User Manual
Shenzhen Junlan Electronic Ltd BLUETOOTH STEREO HEADSET
User Manual
![](/img.php?id=2716833&img=bg1.png)
Size: 148.5(W) x 210(H)mm (A5)
BLUETOOTH® STEREO HEADSET
BLUETOOTH® STEREO HEADSET
Model: CBH508-OD
PLEASE READ BEFORE OPERATING THIS EQUIPMENT.
Owner's Manual
2015.08.10
09:14:08
+08'00'
1
FCC INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.These limits are designed to provide residential
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
zReorient or relocate the receiving antenna.
zIncrease the separation between the equipment and receiver.
zConnect the equipment into an outlet on the circuit different from that to which the
receiver is connected.
zConsult the dealer or an experienced radio/TV technician for help.
FCC NOTICE:
To assure continued compliance, follow the attached installation instructions and use only
shielded cables when connecting to other devices. Modifications not authorized by the
manufacturer may void user’s authority to operate this device.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
2015.08.10
09:14:27
+08'00'
![](/img.php?id=2716833&img=bg3.png)
2
1
2
4
5
6
89
1. Volume Up Button
7. Button
6. Button
9. Built-in Microphone
8. Micro USB Port (For Charging Only)
5. Volume Down Button
3. Button
3
2. BT Indicator
Location of Controls
Battery Recharge:
1. Insert the small plug from the USB connection cable to the Micro USB Port on the unit.
2. Insert the other plug to the USB Port on the Computer or any USB Charger having
DC 5V output.
3. During charging, the Charging Indicator will light. When finished, it will turned off.
battery is consumed as follow:
The unit has a built-in Li-ion rechargeable battery, recharge it before use or when the
Your battery will last longer if you follow these simple guidlines for charging
and storing it.
Notes:
7
4. Charging Indicator
2015.08.10
09:14:32
+08'00'
![](/img.php?id=2716833&img=bg4.png)
3
z/
z
z
z
Press the / Button to adjust volume level.
z
5°C~35°C (40°F~95°F).
D. The rechargeable battery incorporated in this product is not replaceable.
C. Battery life naturally shortens slowly over time.
B. Do not overcharge ( longer than 24 hours ). Excessive charging or discharging may
shorten the battery's life.
A. Recharge and store the device within the temperature range of
Operation:
In the first time use or re-pairing to a new Bluetooth device, follow these instructions:
1. Press and hold the Button approx. 1 second to power on the unit. The BT Indicator
will illuminate and fast blink.
2. Power on the external BT device and enter to BT searching mode. Start pairing following
z
z
When the external BT device searched the unit, our model number "CBH508-0D" will
appear on the display of external BT device.
Pairing code "0000" or "1234" may need to enter.
Notes:
Normal operation after pairing:
1. Turn on the BT function of the external BT device.
3. Plays the music in the paired BT device as usual.
4. During playback:
2. Press and hold the Button approx. 1 second to power on the unit.
The BT Indicator will illuminate and fast blink. Wait a few seconds until the unit auto
Press the Button to skip the tracks.
Press the Button to pause, press again to resume.
6. When finishing listening , press and hold the Button approx. 2 seconds to
power off the unit.
5. If the unit is paired to Cell Phone:
When a call is incoming during listening, press the Button to hook off then
speak to the built-in microphone to answer the phone. When finished, press the
Button to hook on then resume to music playback.
Press the Button twice to redial the last dialed phone number.
the on screen instructions on the external BT device. After paired, the blinking frequency
of BT Indicator will slow down. ( For details pairing procedures, please refer to the user's
manual of your BT device.)
(The blinking frequency of BT Indicator will slow down.)
paired to the external BT device.
2015.08.10
09:14:38
+08'00'
![](/img.php?id=2716833&img=bg5.png)
4
Troubleshooting:
Impedance of Earpiece:...................................................................................32 ohm, 25 mW x 2
Audio Power:...................................................................................................22 mW per channel
Can't be power on
No sound
Sound distortion
Battery consumed Recharge the battery.
Volume was set to
mininum level
Volume too high
volume level.
Press the to reduce
volume level.
Specifications:
Accessories:
BT Version: .................................................................................................................. V2.1+EDR
Power Source:..............................Built-in DC 3.7 V; 400 mAH (1.48 WH) rechargeable Li-ion
battery, recharge by DC 5V through Micro USB Port
BT Effective Range:.......................................................................................32 Feet in open area
1 x User's Manual
1 x USB Connection Cable ( for charge only )
SPECIFICATIONS AND ACCESSORIES ARE SUBECT TO CHANGE WITHOUT NOTICE
Press the to increase
Play Time After Fully Charge: ..................................................................... Approximate 6 Hours
