MODEL: PBT555
INSTRUCTION MANUAL
PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE USING AND KEEP
IT FOR FUTURE REFERENCE
![](/img.php?id=2020016&img=bg2.png)
The lighting flash with arrowhead symbol, within an equilateral triangle, is
intended to alert user to the presence of uninsulated “dangerous voltage” within
the product’s enclosure, that may be of sufficient magnitude to constitute a risk of
electric.
The exclamation point within an equilateral triangle is intended to alert user to
the presence of important operating and maintenance (servicing) instruction in the
literature accompanying the appliance.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DON’T REMOVE COVER ( OR BACK ). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
USE UNDER SUPERVISION OF AN ADULT DUE TO LONG CORD
This unit has a long cord that can be easily tripped on or pulled on, causing injury, Please
make sure it is arranged so it will not drape over a tabletop, etc. Where it can be pulled on
by children or tripped over accidentally.
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception. Which can be
determined by encouraged to try to correct the interference by one or more of the following
measures:
1. Reorient or relocate the receiving antenna.
![](/img.php?id=2020016&img=bg3.png)
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, follow the attached installation instructions and use only shield
cables when connecting to other devices. Modifications not authorized by the manufacturer may
void user’s authority to operate this device.
Before using the unit, be sure to read all operating instruction carefully, please note that
these are general precautions and may not pertain to your unit. For example, this unit may
not have the capability to be connected to an outdoor antenna.
1.Read these instructions
All safety and operating instructions should be read before the product is operated.
2.Keep these instructions
The safety and operating instructions should be retained for future reference.
3.Heed all warnings
All warnings on the product and in the operating instruction manual should be adhered to.
4.Follow these instructions
All operating and use instructions should be followed.
5.Do not use this apparatus near water
Do not use the product near water and moisture, for example:near a bathtub, washbowl, kitchen
sink or laundry tub; in a wet basement; or near a swimming pool.
6.Clean only with dry cloth
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a dry cloth for cleaning.
7.Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet and in the back or bottom are provided for ventilation, to ensure
reliable operation of the product and to protect it from overheating. These openings must not be
blocked or covered.The openings should never be blocked by placing the product on a bed, sofa,
rug or other similar surface. This product should never be placed near or over a radiator or heat
source. This product should not be placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.
8.Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9.Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades and a third grounding prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of
the obsolete outlet.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11.Only use attachments/accessories specified by the manufacturer.
![](/img.php?id=2020016&img=bg4.png)
12.Use only with the cart, stand , tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture does
not operate normally, or has been dropped.
15. Power source
The product should be operated only from the type of power source indicated on the marking label.
If you are not sure of the type of power supply to your home, consult your appliance dealer or
local power company. For products intended to operate from battery power, or other sources, refer
to the operating instructions.
16. Power lines
An outside antenna system should not be located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into such power lines or circuits. When
installing an outside antenna system, extreme care should be taken to keep from touching such
power lines or circuits as contact with them might be fatal.
17. Overloading
Do not overload wall outlets and extension cords as this can result in a risk or fire or electric
shock.
18. Object and liquid entry
Never push objects of any kind into the product through as they may touch dangerous voltage
points or short out parts that could result in fire or electric shock. Never spill or spray any type of
liquid on the product.
19. Outdoor antenna grounding
If an outside antenna is connected to the product, be sure the antenna
system is grounded so as to provide some protection against voltage
surges and built up static charges, section 810 of the National Electrical
Code, ANSI/NFPA 70,provides information with respect to proper
grounding of the mast and supporting structure, grounding of lead-in
wire to an antenna discharge product, size of grounding conductors,
location of antenna discharge product, connection to grounding
electrodes and requirements for the grounding electrodes.
20. Service
Do not attempt to service this product yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified servicing personnel.
21. Replacement parts
When replacement parts are required, be sure the service technician uses replacement parts
specified by the manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in fire or electric shock or other hazards.
22. Safety check
Upon completion of any service or repairs to this product ask the service technician to perform
safety checks to determine that the product is in proper operating condition.
23. Wall or ceiling mounting
The product should be mounted to a wall or ceiling only as recommend by the manufacturer.
24. Damage requiring service
Unplug the product from the wall outlet and refer servicing to qualified service personnel under
the following conditions:
A: when the power-supply cord or plug is damaged.
B: if liquid has been spilled or objects have fallen into the product.
C: if the product has been exposed to rain or water.
D: if the product does not operate normally by following the operating instructions. Adjust only
those controls that are covered by the operating instructions as improper adjustment may result in
damage and will often require extensive work by a qualified technician to restore the product to its
normal operation.
E:If the product has been dropped or the cabinet damaged in any way.
F: when the product exhibits a distinct change in performance -this indicates a need for service.
25. Note to CATV system installer
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the
VEC that provides guidelines for proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the building, as close to the point of cable
entry as practical.
Note:
Refer all servicing to qualified service personnel. Servicing is required when the unit has been
damaged any way such as the following: the power-supply cord or plug has been damaged, liquid
has been spilled into the unit, the unit has been dropped or the unit does not operate normally.
![](/img.php?id=2020016&img=bg6.png)
Product Overview
Control Panel (Front View)
Control Panel (Top View)
Previous
Next Pause/play/Hands free
Vo
l
u
m
e
-
Volume +
Microphone Indicator
![](/img.php?id=2020016&img=bg7.png)
Control Panel (Back View)
BATTERY CHARGING
The speaker can be powered by the internal rechargeable battery. When the battery is nearly
exhausted, the red indicator will light and flash, the speaker should be charged as soon as possible.
Connect the unit with USB cable to the power source, and the red indicator will be solid while
charging. When charging is completed, the red indicator will be off.
NOTE:
The battery will charge whether the speaker is switched on or off.
BLUETHOOTH
Pairing and connection
1. Move the Power On/Off to the ON position. Blue light will flash slowly and keep flashing
slowly about 10 seconds the blue indicator will flash quickly and enter pairing mode.
2.Please make sure your Bluetooth connection is activated on your device. Each Bluetooth device
is different so refer to your device’s operating manual if you are unsure how to activate your
Bluetooth connection. During searching, the blue indicator will keep flashing. The Bluetooth
device will scan for the unit and identify it as PBT555. Select PBT555 on your Bluetooth device
to connect.
3.When connected, the speaker will beep and the blue indicator will be solid.
NOTE:
--Make sure of disconnecting the AUX IN cable before Bluetooth connecting.
--If asked for a pass code during paring, enter 0000.
--If unable to connect with the speaker, turn the speaker off and try turning on again and
reconnect.
During playback:
Power On/Of
f
USB charge port
AUX IN jack
![](/img.php?id=2020016&img=bg8.png)
--Press + and - buttons to adjust the volume level.
--During playback, press button to pause and press again to resume.
--During playback, press / button to play the previous or next track.
NOTE:
-- Play/Pause functions may not work with some players on your Bluetooth device.
--When the AUX IN cable is connected, the AUX IN source will be selected and there will be no
audio output from Bluetooth source.
When receiving a call
-- If you receive a call, press button to answer the call. Press Hands-free button again if you
want to hang up.
-- If you receive a call, press and hold button to reject a call.
--During track playing, press and hold button to redial the last number called.
AUX IN CONNECTION
1. Connect a stereo 3.5mm jack cable ( supplied ) between the headphone or LINE IN/audio
output of the personal audio player and the AUX IN jack on the back panel.
2. Set your personal audio player/computer to play.
During playback:
--Press + and - buttons to adjust the volume level.
--During playback, press button to pause and press again to resume.
--During playback, press / button to play the previous or next track.
NOTE:
-- If there is no sound or if the volume level is not loud enough, you may need to increase the
volume setting on the panel.
SPECIFICATION
Audio output......................................................... .................................................2x1W
Bluetooth working range........................................................................................33 feet
Playback time..........................................................................................................5hours
( with volume set to 50% of the maximum volume)
TROUBLESHOOTING
No power:
--The battery may be flat. Connect the unit to a USB power source to charge it.
Unable to connect to the speaker:
--Check if the Bluetooth indicator is flashing. If switch off the power, the switch back on and
re-try.
--Check if the Bluetooth connection is activated on your Bluetooth device . If not, activate the
connection.
Connected but no sound from Bluetooth source:
--Check if the AUX IN cable is connected. If yes, unplug the AUX IN cable to disconnect it.
--Check if the Bluetooth connection is out of working distance. If yes, move it closer to the
speaker.
--Check if your Bluetooth source is in playback mode. If not, start the playback.
ACCESSORIES
1x Micro USB cable
1x User Manual
1x 3.5mm AUX IN cable
