User Manual
![](/img.php?id=3822169&img=bg1.png)
Please read this instruction manual carefully and keep it for future reference
MODEL:MSB3786-EO
HOME THEATER BLUETOOTH SOUNDBAR WITH LIGHT SHOW
AND LED ROOM ILLUMINATION
![](/img.php?id=3822169&img=bg2.png)
WARNING:TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
WARNING: USE UNDER SUPERVISION OF AN ADULT DUE TO LONG
CORD This unit has a long cord that can be easily tripped on or pulled on,
causing injury. Please make sure it is arranged so that it will not drape over a
tabletop, etc. Where it can be pulled on by children or tripped over accidentally.
FCC STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference
that may cause undesired operation. The antenna(s) used for this transmitter
must be installed to provide a separation distance of at least 20 cm from all
persons and must not be co-located or operating in conjunction with any other
antenna or transmitter.
CAUTION: TO REDUCE THE ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK). NO USER SERVICEABLE PART INSIDE, REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DANGEROUS VOLTAGE:The lighting flash with arrowhead symbol within
an equilateral triangle is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock to persons.
ATTENTION:The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
2
![](/img.php?id=3822169&img=bg3.png)
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
●Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING:
To assure continued operation, follow the attached installation instructions and
use only shield cables when connecting to other devices. Changes or
modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Before using the unit, be sure to read all operating instruction carefully, please
note that these are general precautions and may not pertain to your unit. For
example, this unit may not have the capability to be connected to an outdoor
antenna.
1. Read these instructions
All the safety and operating instructions should be read before the appliance is
operated.
2. Keep these instructions
The safety and operating instructions should be kept for future reference.
3. Heed all warnings
All warnings on the appliance and in the operating instructions should be
adhered to.
4. Follow all instructions
All operation and use instructions should be followed.
FCC NOTICE:
5. Do not use this apparatus near water
The appliance should not be used near water; for example, near a bath tub,
3
![](/img.php?id=3822169&img=bg4.png)
washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming
pool.
6. Clean only with dry cloth
The appliance should be cleaned only as recommended by the manufacturer.
7. Do not block any ventilation openings.Install in accordance with the
manufacturer’s instructions.
Slots and openings in the cabinet and in the back or bottom are provided for
ventilation, to ensure reliable operation of the product and to protect it from
overheating. These openings must not be blocked or covered. The openings
should never be blocked by placing the product on a bed, sofa, rug, or similar
surface. This product should never be placed near or over a radiator or heat
source. This product should not be placed in a built-in installation, such as a
bookcase or rack unless proper ventilation is provided or the manufacturer’s
instructions have been adhered to.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide or the third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments / accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury
from tip-over.
An appliance and cart combination should be moved with care. Quick stop,
excessive fore and uneven surfaces may cause the appliance and cart
combination to overturn.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
To protect your product from a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet and disconnect
the antenna or cable system. This will prevent damage to the product due to
lightning and power-line surges.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or
4
![](/img.php?id=3822169&img=bg5.png)
moisture, does not operate normally, or has been dropped.
15. Power source
This product should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power supply to your
home, consult your appliance dealer or local power company. For products
intended to operate from battery power, or other source, refer to the operation
instructions.
16. Power lines
An outside antenna system should not be located in the vicinity of overhead
power lines or other electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside antenna system, extreme
care should be taken to keep from touching such power lines or circuits as
contact with them might be fatal.
17. Overloading
Do not overload wall outlets and extension cords as this can result in a risk of
fire or electric shock.
18. Object and liquid entry
Never push objects of any kind into the product through openings as they may
touch dangerous voltage points or short out parts that could result in fire or
electric shock. Never spill or spray any type of liquid on the product.
19. Outdoor antenna grounding
If an outside antenna is connected to the product, be sure the antenna system
is grounded so as to provide some protection against voltage surges and built
up static charges. Section 810 of the National Electric Code ANSI/ NFPA 70
provides information with respect to proper grounding of the mast and
supporting structure, grounding of the lead- in wire to an antenna discharge
product, size of grounding conductors, location of antenna- discharge product,
connection to grounding electrodes and requirements for the grounding
electrodes.
5
![](/img.php?id=3822169&img=bg6.png)
20. Service
Do not attempt to service this product yourself as opening or removing covers
may expose you to dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
b)If liquid has been spilled or objects have fallen into the product.
c)If the product has been exposed to rain or water.
d)If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions, as an adjustment of other controls may result in damage and will
require extensive work by a qualified technician to restore the product to its
normal operation.
e)If the product has been dropped or the cabinet has been damaged.
f)When the product exhibits a distinct change in performance- this indicates a
need for service.
25. Note to CATV system installer
This reminder is provided to call the CATV system installer' s attention to
Article 820- 40 of the NEC that provides guidelines for proper grounding and,
in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as
practical.
NOTE: Refer all servicing to qualified service personnel. Servicing is
required when the unit has been damaged in any way such as the
following: the power-supply cord or plug has been damaged, liquid has
been spilled into unit, the unit has been exposed to rain or moisture, the
unit has been dropped or the unit does not operate normally.
21. Replacement parts
When replacement parts are required, be sure the service technician uses
replacement parts specified by the manufacturer or those that have the same
characteristics as the original parts. Unauthorized substitutions may result in
fire or electric shock or other hazards.
22. Safety check
Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks to determine that the product is in proper
operating condition.
23. Wall or ceiling mounting
The product should be mounted to a wall or ceiling only as recommended by
the manufacturer.
24. Damage requiring service
Unplug this product from the wall outlet and refer service to qualified service
personnel under the following conditions.
a)When the power- supply cord or plug is damaged.
6
![](/img.php?id=3822169&img=bg7.png)
PROdUCT OvERvIEW
7
1
2
6
CONTROL PANEL
AUX IN
LINE IN
OPTICAL IN
HDMI IN
FRONT VIEW
BOTTOM VIEW 3
4 5
78
REAR PANEL
OPTICAL IN
LINE IN
AUX IN
RL
DC IN
DC 16V, 3.5A
910 11 12 13
1. Remote Sensor
2. Mode Indicator
3. LED Light Effect
4. Volume Down Button
5. Volume Up Button
6. Power On/Off Button
7. Mode Switch Button
8. LED Light Effect Button
9. HDMI IN (ARC) Port
10. OPTICAL IN Jack
12. LINE IN Jacks
11. AUX IN Jack
13. DC IN Jack
HDMI IN(ARC)
![](/img.php?id=3822169&img=bg8.png)
REMOTE CONTROL
8
VOL- VOL+
PAIR EQ
1
2
3
4
5
6
7
8
9
10
11
1. Power On/Off Button
2. Previous Button
3. Volume Down Button
4. PAIR Button
5. Mute Button
6. Next Button
7. Play/Pause Button
8. Volume Up Button
9. Mode Switch Button
10. LED Light Effect Button
11. EQ(equalizer) Button
BATTERY INSTALLATION OF REMOTE CONTROL
FIRST TIME USE
●Remove and discard the insulation tab as figure on the right.
●Replacing Batteries For Remote Control
1. Push and slide out the battery holder as Fig 1 below.
2. Replace the battery with a new CR2025 button cell as
the polarity markings on the rear of the Remote Control.
3. Close the battery holder.
RE LE A SE
PUSH
OPEN
R2 02 5
C
+
SN
Fig.1 Fig.2 Fig.3
.
Fig.2
Fig.3
![](/img.php?id=3822169&img=bg9.png)
9
9
BATTERY PRECAUTIONS
Follow these precautions when using a battery in this device:
1. Use only the size and type of battery specified.
2. Be sure to follow the correct polarity when installing the battery as indicated in the battery
compartment, a reserved battery may cause damage to the device.
3. Do not mix different types of batteries together ( e.g: Alkaline and Carbon -zinc )
or old batteries with fresh ones.
4. If the batteries in the device are consumed or the device is not to be used for a long period of time,
remove the batteries to prevent damage or injury from possible leakage.
5. Do not try to recharge the battery as it is not intended to be recharged; it can overheat and rupture.
(Follow the battery manufacturer’s instructions.)
6. The batteries shall not be exposed to excessive heat such as sunshine or fire.
7. Clean the battery contacts and also those of the device prior to battery installation.
8. The remote control is supplied with a coin/button
cell battery. If the coin button cell battery is
swallowed, it can cause severe internal burns in
just 2 hours and can lead to death. Keep new
and used battery away from children. If the
Battery compartment does not close securely,
stop using the product and keep it away from
children. If you think batteries might have been
swallowed or placed any part of the body, seek
immediate medical attention.
CR2025
Remote control operation range
●When there is an obstacle between the remote and the transmitter, the unit may not operate.
●When direct sunlight, an incandescent lamp, fluorescent lamp or any other strong light
shines on the REMOTE SENSOR of the unit, the operation of the remote may be unstable.
CAUTION
●Danger of explosion if the battery is incorrectly replaced.
●Replace only with the same or equivalent type.
VOL- VOL+
PAIR EQ
AUX IN
LINE IN
OPTICAL IN
HDMI IN
15 Feet (5M)
![](/img.php?id=3822169&img=bga.png)
PLACEMENT AND MOUNTING
1. Placing the device on a table - Ventilation
When placing the Sound Bar on an entertainment center, bookshelf, or any type of
enclosed space, be sure to allow at least 2-3 inches of space around the Sound Bar for
ventilation. If the Sound Bar is enclosed in a tight space, without ventilation, heat
generated from the Sound Bar could produce a potential heat hazard.
2. The Installation Distance
2-3inches
2-3inches
10
921mm (36.26 inches)
![](/img.php?id=3822169&img=bgb.png)
2.1 Mountingto a wooden wall
A. Mark the position of the mounting screws on the wall using a pencil.
C. Put the sound bar onto the mounting screws. Make sure they are firm and stable.
2.2 Mountingto a brick wall
36.26 inches
B. Drill the screws directly into the marks that you have made on the wall and leave
approx. 0.3 inches length to hook the sound bar.
(screws not included)
(screws and plastic fixing plug are not included)
A. Mark the position of the mounting screws on the wall using a pencil.
E. Put the sound bar onto the mounting screws. Make sure they are firm and stable.
C. Insert the fixing plug and hammer into the holes.
D. Secure the screws into the fixing plug and leave approx. 0.3 inches length to hook
the sound bar.
B. Drill 2 holes on wall with a powerful electric drill.
36.26 inches
11
![](/img.php?id=3822169&img=bgc.png)
GENERAL OPERATION
1. Connect the AC/DC adapter to the unit and wall outlet.
3. Press the button on the unit or remote control repeatedly to switch to the
desired mode. The corresponding
12
4. During Playback:
~ Press the + or - button on the unit repeatedly to adjust volume.
~ Press the button on remote control to turn on or turn off sound.
~ Press the EQ button on remote control repeatedly to set to different EQ mode.
2. Press and hold the button on the unit or press the button on remote control
to power on the unit. The LED light effect will light up.
mode indicator on front of the unit will light up.
~ Press the VOL+ or VOL- button on remote control repeatedly to adjust volume.
5 different LED light effect.
~ Press and hold the button on the unit or on remote control to turn on or turn
off the LED light effect.
5. Press and hold the button on the unit or press the button on remote control
to power off the unit.
(POP, ROCK and CLASSIC)
~ Press the button on the unit or on remote control repeatedly to change to
~ Press and hold the EQ button on remote control to set to default EQ mode.
![](/img.php?id=3822169&img=bgd.png)
BLUETOOTH OPERATION
10
5. After successful paired, the Bluetooth indicator will stop blinking.
function are activated and they are in working range.
6. During playback:
~ Press the or button on remote control to skip tracks.
~ Press the button on remote control to pause, press it again to resume.
1. Power on the unit as previously explained.
3. Power on the external Bluetooth enable device and enter Bluetooth mode and try
searching the unit.
NOTE: The unit will be automatically connected with the last paired Bluetooth device
if their Bluetooth
13
2. Press the button on the unit or remote control repeatedly to switch to the
Bluetooth mode, the Bluetooth indicator on front of the unit will turn Blue and blink.
7. Press the PAIR button on remote control to disconnect the current connection.
4. When " " appears, select it and make connection.
MONSTER SB1
![](/img.php?id=3822169&img=bge.png)
OPTICAL IN
LINE IN
AUX IN
RL
DC IN
DC 16V, 3.5A
AUX IN OPERATION
An external Audio player(such as mobile phone, MP3 palyer etc.) can be connected
to this unit and listen through the unit's speakers.
Rear View
Mobile Phone
Connect to the Phones; AUX Out;
Line Out Jack of the external devices
(Such like MP3 Player; cell phones;
iPod/iPad ... etc)
MP3 Player
1. Plug one end of the AUX IN Cable into the AUX IN jack on the unit.
2. Plug another end of the AUX IN Cable into the headphone hack or Aux Out jack
on the external audio player.
5. Power on the connected external player and start playback the music as usual.
14
3. Power on the unit as previously explained.
4. Press the button on the unit or remote control repeatedly to switch to the
AUX IN mode, the AUX IN indicator on front of the unit will turn Green.
HDMI IN(ARC)
![](/img.php?id=3822169&img=bgf.png)
LINE IN OPERATION
An external Audio/Video player(such as TV, DVD palyer etc.) can be connected to
this unit and listen through the unit's speakers.
1. Plug one end of the line in cable into the LINE IN jacks(L&R) on the unit.
2. Plug the other end of the line in cable into the Line Out jacks(L&R) on TV or DVD
palyer etc.
Rear View
Line out jacks of
TV/DVD player etc.
L R Video
15
white red
5. Power on the connected external player and start playback the music as usual.
3. Power on the unit as previously explained.
4. Press the button on the unit or remote control repeatedly to switch to the
LINE IN mode, the LINE IN indicator on front of the unit will turn Green.
OPTICAL IN
LINE IN
AUX IN
RL
DC IN
DC 16V, 3.5A
HDMI IN(ARC)
![](/img.php?id=3822169&img=bg10.png)
OPTICAL-IN OPERATION
4. Power on the connected external player and start playback the music as usual.
Turn on the digital audio output and set it to PCM (Plus Code Modulation) type
similar to the follows figure:
Bass
Treble
Balance
Select Move MENU Exit
Sound Mode Standard
Surround Off
AVL Off
Audio Language English
Picture Time Setup Lock Off
AudioAudio
Digital Output PCMDigital Output PCM
1. Connect the Optical out jack from the external audio player (such as TV, DVD
player etc.) to the OPTICAL IN jack on the rear of the unit with the optical
connection cable as illustated below:(For PCM format only)
OPTICAL OUT
Optical Connection Cable
Rear View
TV or DVD player etc.
16
OPTICAL IN
LINE IN
AUX IN
RL
DC IN
DC 16V, 3.5A
2. Power on the unit as previously explained.
3. Press the button on the unit or remote control repeatedly to switch to the
OPTICAL IN mode, the OPTICAL IN indicator on front of the unit will turn Green.
HDMI IN(ARC)
![](/img.php?id=3822169&img=bg11.png)
17
HdMI IN OPERATION
An external Audio/Video player(such as TV, DVD palyer etc.) can be connected to
this unit and listen through the unit's speakers.
1. Plug one end of the HDMI cable into the HDMI IN(ARC) port on the unit.
2. Plug the other end of the HDMI cable into the HDMI IN (ARC) port on TV or DVD
palyer etc.
HDMI out jacks of
TV/DVD player etc.
LR Video
5. Power on the connected external player and start playback the music as usual.
3. Power on the unit as previously explained.
Rear View
HDMI IN (ARC)
Explanation:
ARC (Audio Return Channel)
OPTICAL IN
LINE IN
AUX IN
RL
DC IN
DC 16V, 3.5A
4. Press the button on the unit or remote control repeatedly to switch to the
HDMI IN mode, the HDMI IN indicator on front of the unit will turn Green.
devices do not have this ARC feature, it will not apply for this product.)
NOTE: The HDMI input channel only works for the HDMI IN with ARC feature, if
all the input
HDMI IN(ARC)
![](/img.php?id=3822169&img=bg12.png)
TROUBLESHOOTING
Play music/movie in the paired/
connected device as usual and make
sure the volume level of it is in high
level.
Sound distortion/rattle Volume level too high Reduce the volume level by pressing
Reduce the volume level of the
paired/connected device.
Bluetooth
reception failure
Put the external BT device close to the
unit.
Have not paired Pair the unit with the BT Device as the
procedures stated in this manual.
Input source incorrect
Press and hold the button
The unit is in power off mode
The paired/connected device
is not in playback mode
The external device is
too far from the unit
Remote Control
not functioning Out of range
The batteries in the remote
control are drained
Point the remote control to the
remote sensor on the unit within
16 feet, +/-30 degress
Replace with new battery
No sound or
sound weak
Volume level in minimum position Raise the volume level by pressing
the + Button on the unit
SYMPTOM POSSIBLE CAUSE POSSIBLE SOLUTION
No power The adapter is not connected Connect the adapter to the unit and
wall outlet
on the unit or press the button
on remote control to power on the unit
Or press VOL+ button on remote control
control to switch to desired mode
the - Button on the top of the unit
Or press VOL- button on remote control
18
Press the button on the unit
or press the button on remote
![](/img.php?id=3822169&img=bg13.png)
SPECIFICATIONS
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT TO CHANGE
WITHOUT NOTICE
19
Power input ............................................................................AC100~240V, 50/60Hz
Power output ......................................................................DC16V 3.5A
Audio output .....................................................................................2x12.5W + 25W
Bluetooth effective working range in open area......................................up to 32 feet
Remote effective working range..............................................................up to 16 feet
PACKAGES
1x User Manual
1x Power Adapter
1x Remote Control
1x AUX IN Cable
1x LINE IN Cable
1x Main Unit
![](/img.php?id=3822169&img=bg14.png)
Hereby, C.I. LTD declares that this wireless speaker is in compliance
with requirements of Radio Equipment Directive 2014/53/EU.
Complete text of the Declaration of Conformity is available at: www.curtisint.com
C.I. LTD, Toronto, Ont. M9W 5C1 CANADA
and are used under license.
Bluetooth logo/brand is a trademark or registered trademark of Bluetooth SIG Inc.
All other product or service names are the property of their respective owners.
All items contained herein are imported by
distributed by Bluetooth SIG Inc.
Monster, the Monster logo and the M design are registered trademarks of Monster,
Inc. and its subsidiaries in the U.S. and other countries
C.I. LTD and are not manufactured,
sponsored, endorsed or
