LG Electronics USA 55LM6700UA LED LCD TV Monitor User Manual EMISSION TEST REPORT
LG Electronics USA LED LCD TV Monitor EMISSION TEST REPORT
Users Manual
![](/img.php?id=1601822&img=bg1.png)
G
Order Number
: GETEC-C1-11-305
FCC Part 15 subpart B
Test Report Number
: GETEC-E3-11-135
Page 1 / 1
EUT Type: LED LCD TV/Monitor
FCC ID.: BEJ55LM6700UA
APPENDIX G
: USER’S MANUAL
![](/img.php?id=1601822&img=bg2.png)
www.lg.com
OWNER’S MANUAL
LED LCD TV
Please read this manual carefully before operating your set and retain it
for future reference.
P/NO : MFL67468101 (1111-REV00)
LM6200 series
LM6210 series
LM6250 series
LM7600 series
LM6400 series
LM6450 series
LM6700 series
LM6750 series
![](/img.php?id=1601822&img=bg3.png)
2
ENG
ENGLISH
LICENSES
LICENSES
Supported licenses may differ by model. For more information about licenses, visit www.lg.com.
Manufactured under license from Dolby Laboratories. “Dolby” and the double-D
symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a
subsidiary of Rovi Corporation. This is an official DivX Certified® device that plays
DivX video. Visit divx.com for more information and software tools to convert your
files into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered
in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section in your device setup menu. Go to
vod.divx.com for more information on how to complete your registration.
“DivX Certified® to play DivX® video up to HD 1080p, including premium content.”
“DivX®, DivX Certified® and associated logos are trademarks of Rovi Corporation
or its subsidiaries and are used under license.”
“Covered by one or more of the following U.S. patents:
7,295,673; 7,460,668; 7,515,710; 7,519,274”
![](/img.php?id=1601822&img=bg4.png)
3
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Always comply with the following precautions to avoid dangerous situations and ensure peak performance
of your product.
TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR
BACK). NO USER SERVICEABLE PARTS
INSIDE. REFER TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be
of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompanying
the appliance.
- TO REDUCE THE RISK OF FIRE AND
ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
WARNING/CAUTION
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
y Do not use this apparatus near water.
y Clean only with a dry cloth.
y Do not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions.
y Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
y Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your safety.
If the provided plug does not fit into your
outlet, consult an electrician for replacement
of the obsolete outlet (Can differ by country).
![](/img.php?id=1601822&img=bg5.png)
4
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
y Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
y Only use attachments/accessories specified
by the manufacturer.
y Use only with a cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
y Unplug this apparatus during lightning
storms or when unused for long periods of
time.
y Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
y Never touch this apparatus or antenna during
a thunder or lightning storm.
y When mounting a TV on the wall, make sure
not to install the TV by hanging the power
and signal cables on the back of the TV.
y Do not allow an impact shock or any objects
to fall into the product, and do not drop
anything onto the screen.
y CAUTION concerning the Power Cord
(Can differ by country):
It is recommended that appliances be
placed upon a dedicated circuit; that is, a
single outlet circuit which powers only that
appliance and has no additional outlets or
branch circuits. Check the specification page
of this owner’s manual to be certain. Do not
connect too many appliances to the same
AC power outlet as this could result in fire or
electric shock. Do not overload wall outlets.
Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power
cords, or damaged or cracked wire insulation
are dangerous. Any of these conditions could
result in electric shock or fire. Periodically
examine the cord of your appliance, and
if its appearance indicates damage or
deterioration, unplug it, discontinue use of
the appliance, and have the cord replaced
with an exact replacement part by an
authorized service. Protect the power cord
from physical or mechanical abuse, such as
being twisted, kinked, pinched, closed in a
door, or walked upon. Pay particular attention
to plugs, wall outlets, and the point where
the cord exits the appliance. Do not move
the TV with the power cord plugged in. Do
not use a damaged or loose power cord. Be
sure do grasp the plug when unplugging the
power cord. Do not pull on the power cord
to unplug the TV.
y Warning - To reduce the risk of fire or
electrical shock, do not expose this product
to rain, moisture or other liquids. Do not
touch the TV with wet hands. Do not install
this product near flammable objects such
as gasoline or candles, or expose the TV to
direct air conditioning.
![](/img.php?id=1601822&img=bg6.png)
5
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
y Do not expose to dripping or splashing and
do not place objects filled with liquids, such
as vases, cups, etc. on or over the apparatus
(e.g. on shelves above the unit).
y Grounding
Ensure that you connect the earth ground
wire to prevent possible electric shock
(i.e. a TV with a three-prong grounded AC
plug must be connected to a three-prong
grounded AC outlet). If grounding methods
are not possible, have a qualified electrician
install a separate circuit breaker. Do not try to
ground the unit by connecting it to telephone
wires, lightening rods, or gas pipes.
Short-circuit Breaker
Power Supply
y DISCONNECTING DEVICE FROM THE MAIN
POWER
The power outlet must remain readily
accessed in the event the device needs to
be unplugged.
y As long as this unit is connected to the AC
wall outlet, it is not disconnected from the
AC power source even if the unit is turned
off.
y Do not attempt to modify this product in any
way without written authorization from LG
Electronics. Unauthorized modification could
void the user’s authority to operate this
product.
y ANTENNAS Outdoor antenna grounding
(Can differ by country):
If an outdoor antenna is installed, follow
the precautions below. An outdoor antenna
system should not be located in the vicinity
of overhead power lines or other electric light
or power circuits, or where it can come in
contact with such power lines or circuits as
death or serious injury can occur. Be sure the
antenna system is grounded so as to provide
some protection against voltage surges
and built-up static charges. Section 810 of
the National Electrical Code (NEC) in the
U.S.A. provides information with respect to
proper grounding of the mast and supporting
structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding
conductors, location of antenna discharge
unit, connection to grounding electrodes and
requirements for the grounding electrode.
Antenna grounding according to the National
Electrical Code, ANSI/NFPA 70
NEC: National Electrical Code
Ground Clamp
Antenna Lead in Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductor
(NEC Section 810-21)
Power Service Grounding
Electrode System
(NEC Art 250, Part H)
Electric Service
Equipment
Ground Clamp
y Cleaning
When cleaning, unplug the power cord and
wipe gently with a soft cloth to prevent
scratching. Do not spray water or other
liquids directly on the TV as electric shock
may occur. Do not clean with chemicals
such as alcohol, thinners or benzine.
y Moving
Make sure the product is turned off,
unplugged and all cables have been
removed. It may take 2 or more people to
carry larger TVs. Do not press or put stress
on the front panel of the TV.
y Ventilation
Install your TV where there is proper
ventilation. Do not install in a confined
space such as a bookcase. Do not cover the
product with cloth or other materials while
plugged. Do not install in excessively dusty
places.
y If you smell smoke or other odors coming
from the TV, unplug the power cord and
contact an authorized service center.
y Do not press strongly upon the panel with
your hand or a sharp object such as a nail,
pencil or pen, or make a scratch on it.
y Keep the product away from direct sunlight.
![](/img.php?id=1601822&img=bg7.png)
6
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
y Dot Defect
The Plasma or LCD panel is a high
technology product with resolution of two
million to six million pixels. In a very few
cases, you could see fine dots on the screen
while you’re viewing the TV. Those dots
are deactivated pixels and do not affect the
performance and reliability of the TV.
y Generated Sound
“Cracking” noise: A cracking noise that
occurs when watching or turning off the TV
is generated by plastic thermal contraction
due to temperature and humidity. This noise
is common for products where thermal
deformation is required.
Electrical circuit humming/panel buzzing: A
low level noise is generated from a high-
speed switching circuit, which supplies a
large amount of current to operate a product.
It varies depending on the product.
This generated sound does not affect the
performance and reliability of the product.
y Take care not to touch the ventilation
openings. When watching the TV for a long
period, the ventilation openings may become
hot. This does not affect the performance of
the product or cause defects in the product.
y Viewing 3D Imaging (For 3D TV)
- The vision of young children may still be
developing. 3D contents should not be
viewed by children under the age of 5. All
other children’s viewing of 3D content should
be supervised by a responsible adult.
- Some viewers may experience symptoms of
discomfort such as nausea, eye strain, fatigue
and dizziness when viewing 3D content. All
viewers should take regular breaks to help
avoid these symptoms. If you experience any
symptoms of discomfort, discontinue viewing
and take a break until the symptoms go away.
If symptoms continue, consult a doctor.
- Following the guideline below may lessen the
likelihood of experiencing such discomfort:
· Viewing angle: watch 3D contents at the
eye level of the center of the TV screen.
· Viewing distance: watch 3D contents from
the minimum distance of 2 times the
diagonal size of the TV screen.
y If the TV feels cold to the touch, there may
be a small “flicker” when it is turned on. This
is normal, there is nothing wrong with TV.
Some minute dot defects may be visible on
the screen, appearing as tiny red, green, or
blue spots. However, they have no adverse
effect on the TV’s performance. Avoid
touching the LCD screen or holding your
finger(s) against it for long periods of time.
Doing so may produce some temporary
distortion effects on the screen.
DISPOSAL (Hg lamp only used in LCD TVs)
The fluorescent lamp used in this product contains
a small amount of mercury. Do not dispose of this
product with general household waste. Disposal of
this product must be carried out in accordance to
the regulations of your local authority.
Preventing “Image burn” or “Burn-in” on your TV screen
y If a fixed image displays on the TV screen for
a long period of time, it will be imprinted and
become a permanent disfigurement on the
screen. This is “image burn” or “burn-in” and
not covered by the warranty.
y If the aspect ratio of the TV is set to 4:3 for a
long period of time, image burn may occur on
the letterboxed area of the screen.
y Avoid displaying a fixed image on the TV screen
for a long period of time (2 or more hours for
LCD, 1 or more hours for the Plasma TV) to
prevent image burn.
For USA and Canada
NOTE TO CABLE/TV INSTALLER
This reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the
National Electric Code (U.S.A.). The code provides
guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected
to the grounding system of the building, as close
to the point of the cable entry as practical.
![](/img.php?id=1601822&img=bg8.png)
7
ENG
ENGLISH
TABLE OF CONTENTS
TABLE OF CONTENTS
2 LICENSES
3 IMPORTANT SAFETY INSTRUCTIONS
7 TABLE OF CONTENTS
8 INSTALLATION PROCEDURE
8 ASSEMBLING AND PREPARING
8 Unpacking
10 Optional Extras
11 Parts and buttons
13 Lifting and moving the TV
14 Setting up the TV
14 - Attaching the stand
16 - Mounting on a table
17 - Mounting on a wall
18 - Tidying cables
19 MAKING CONNECTIONS
19 Connecting to an antenna or cable
20 Connecting to a HD receiver, DVD, or VCR
player
20 - HDMI Connection
21 - DVI to HDMI Connection
22 - Component Connection
23 - Composite Connection
24 Connecting to a PC
24 - HDMI Connection, DVI to HDMI Connec-
tion or RGB Connection
26 Connecting to an Audio System
26 - Digital Optical Audio Connection
27 Connecting to a USB
28 REMOTE CONTROL
28 Magic Remote Control Functions
29 - Registering Magic Remote Control
29 - How to use Magic Remote Control
29 - Precautions to Take when Using the
Magic Remote Control
30 WATCHING TV
30 Turning the TV on for the first time
30 USING THE USER GUIDE
31 ENTERTAINMENT
31 Network Connection
31 - Connecting to a wired network
33 - Connecting to a wireless network
34 TROUBLESHOOTING
34 OPEN SOURCE SOFTWARE NOTICE
35 SPECIFICATIONS
39 MAINTENANCE
39 Cleaning Your TV
39 - Screen, frame, cabinet and stand
39 - Power cord
NOTE
y Image shown may differ from your TV.
y Your TV’s OSD (On Screen Display) may
differ slightly from that shown in this manual.
y The available menus and options may differ
from the input source or product model that
you are using.
y New features may be added to this TV in the
future.
![](/img.php?id=1601822&img=bg9.png)
8
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and item.
INSTALLATION PROCEDURE
1 Open the package and make sure all the accessories are included.
2 Attach the stand to the TV set.
3 Connect an external device to the TV set.
4 Make sure the network connection is available.
You can use the TV network functions only when the network connection is made.
NOTE
y The items supplied with your product may vary depending on the model.
y Product specifications or contents of this manual may be changed without prior notice due to
upgrade of product functions.
y For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm (0.39
inches) thick and 18 mm (0.7 inches) width.
y Use an extension cable that supports USB 2.0 if the USB cable or USB memory stick does not fit
into your TV's USB port.
B
AA
B
*A 10 mm (0.39 inches)
*B 18 mm (0.7 inches)
CAUTION
y Do not use any unapproved items to ensure the safety and product life span.
y Any damages or injuries by using unapproved items are not covered by the warranty.
y In case of some model, the thin film on screen is a part of TV, So don’t take it off.
![](/img.php?id=1601822&img=bga.png)
9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Magic Remote Control,
Batteries (AA)
(See p.29)
Owner’s manual Cable holder
(See p.19)
Stand Screws
8 EA, M4 x 20
(See p.15, 14)
Composite video cable
(See p.23, 24)
Component video cable
(See p.23)
Power Cord Cinema 3D Glasses
The number of 3D glasses
may differ depending on the
model or country.
Polishing cloth
(Depending on model)
Use this to remove dust
from the cabinet.
For LM6200, LM6210, LM6250 series
![](/img.php?id=1601822&img=bgb.png)
10
ENG
ENGLISH
ASSEMBLING AND PREPARING
Magic Remote Control,
Batteries (AA)
(See p.29)
Owner’s manual Cable holder
(See p.19)
Stand Screws
8 EA, M4 x 20
(See p.15, 16)
Desk-mount Screw
(See p.17)
Ring spacers
4 EA
(See p.15)
Power Cord Composite video cable
(See p.23, 20)
Component video cable
(See p.23)
Cinema 3D Glasses
The number of 3D glasses
may differ depending on the
model or country.
Polishing cloth
(Depending on model)
Use this to remove dust
from the cabinet.
For LM6400, LM6450, LM6700, LM6750, LM7600 series
![](/img.php?id=1601822&img=bgc.png)
11
ENG
ENGLISH
ASSEMBLING AND PREPARING
AG-F2**, AG-F3**
Cinema 3D Glasses
The model name
or design may be
changed manufacturer’s
circumstances or policies.
AN-MR300
Magic Remote Control
Optional Extras
Optional extras can be changed or modified for quality improvement without any notification.
Contact your dealer to buy these items.
These devices only work with certain models.
Compatibility
LM6200
LM6210
LM6250
LM6400
LM6450
LM6700
LM6750 LM7600
AG-F2**, AG-F3** Cinema 3D
Glasses
AN-MR300 Magic Remote Control
![](/img.php?id=1601822&img=bgd.png)
12
ENG
ENGLISH
ASSEMBLING AND PREPARING
Parts and buttons
SETTINGS
INPUT
OK
Speakers
Screen
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
Touch buttons2
Power indicator
Remote control and
intelligent1 sensors
Touch Button Description
v ^
Scrolls through the saved channels.
- + Adjusts the volume level.
OK ٜSelects the highlighted menu option or confirms an input.
SETTINGS Accesses the main menu, or saves your input and exits the menus.
INPUT Changes the input source.
/ ITurns the power on or off.
NOTE
y You can set the power indicator light to on or off by selecting OPTION in the main menus.
For LM6200, LM6210, LM6250 series
![](/img.php?id=1601822&img=bge.png)
13
ENG
ENGLISH
ASSEMBLING AND PREPARING
SETTINGS
INPUT
OK
Speakers
Screen
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
Buttons
Power indicator
Remote control and
intelligent1 sensors
Button Description
v ^
Scrolls through the saved channels.
- + Adjusts the volume level.
ܯ (OK) Selects the highlighted menu option or confirms an input.
S (SETTINGS) Accesses the main menu, or saves your input and exits the menus.
(INPUT) Changes the input source.
( / I) Turns the power on or off.
NOTE
y You can set the power indicator light to on or off by selecting OPTION in the main menus.
For LM6400, LM6450, LM6700, LM6750, LM7600 series
![](/img.php?id=1601822&img=bgf.png)
14
ENG
ENGLISH
ASSEMBLING AND PREPARING
Lifting and moving the TV
When moving or lifting the TV, read the following
to prevent the TV from being scratched or
damaged and for safe transportation regardless of
its type and size.
CAUTION
y Avoid touching the screen at all times, as
this may result in damage to the screen.
y It is recommended to move the TV in the
box or packing material that the TV originally
came in.
y Before moving or lifting the TV, disconnect
the power cord and all cables.
y When holding the TV, the screen should face
away from you to avoid damage.
y Hold the top and bottom of the TV frame
firmly. Make sure not to hold the transparent
part, speaker, or speaker grill area.
y When transporting a large TV, there should
be at least 2 people.
y When transporting the TV by hand, hold the
TV as shown in the following illustration.
y When transporting the TV, do not expose the
TV to jolts or excessive vibration.
y When transporting the TV, keep the TV
upright, never turn the TV on its side or tilt
towards the left or right.
![](/img.php?id=1601822&img=bg10.png)
15
ENG
ENGLISH
ASSEMBLING AND PREPARING
Setting up the TV
Put your TV on a pedestal stand and mount the TV on a table or wall.
Attaching the stand
If you are not mounting the TV to a wall, use the following instructions to attach the stand.
CAUTION
y Tighten the screws firmly to prevent
the TV from tilting forward. Do not over
tighten.
3
2
CAUTION
y When attaching the stand to the TV
set, place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
NOTE
y Remove the stand before installing the TV
on a wall mount by performing the stand
attachment in reverse.
M4 x 20
4 EA
For LM6200, LM6210, LM6250 series
1
Front
M4 x 20
4 EA
Top View
Stand Body
Stand Base
![](/img.php?id=1601822&img=bg11.png)
16
ENG
ENGLISH
ASSEMBLING AND PREPARING
CAUTION
y Tighten the screws firmly to prevent
the TV from tilting forward. Do not over
tighten.
3
2
CAUTION
y When attaching the stand to the TV
set, place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
NOTE
y Remove the stand before installing the TV
on a wall mount by performing the stand
attachment in reverse.
For LM6400, LM6450, LM6700, LM6750, LM7600 series
M4 x 20
4 EA
1
Front
M4 x 20
4 EA
Top View
Stand Body
Stand Base
![](/img.php?id=1601822&img=bg12.png)
17
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mounting on a table
1 Lift and tilt the TV into its upright position on a
table.
- Leave a 10 cm (4 inches) (minimum) space
from the wall for proper ventilation.
10 cm
10 cm
10 cm
10 cm
(4 inches)
2 Connect the power cord to a wall outlet.
CAUTION
y Do not place the TV near or on sources
of heat, as this may result in fire or other
damage.
NOTE
y Swivel 20 degrees to the left or right and
adjust the angle of the TV to suit your view.
y When adjusting the angle of the TV, watch
out for your fingers.
2020
Securing the TV to a table
(Except LM6700 series)
Fix the TV to a table to prevent from tilting
forward, damage, and potential injury.
To secure the TV to a table, insert and tighten the
supplied screw on the rear of the stand.
WARNING
y To prevent TV from falling over, the TV
should be securely attached to the floor/wall
per installation instructions. Tipping, shaking,
or rocking the TV may cause injury.
![](/img.php?id=1601822&img=bg13.png)
18
ENG
ENGLISH
ASSEMBLING AND PREPARING
Securing the TV to a wall (optional)
1 Insert and tighten the eye-bolts, or TV brackets
and bolts on the back of the TV.
- If there are bolts inserted at the eye-bolts
position, remove the bolts first.
2 Mount the wall brackets with the bolts to the
wall.
Match the location of the wall bracket and the
eye-bolts on the rear of the TV.
3 Connect the eye-bolts and wall brackets tightly
with a sturdy rope.
Make sure to keep the rope horizontal with the
flat surface.
CAUTION
y Make sure that children do not climb on or
hang on the TV.
NOTE
y Use a platform or cabinet that is strong and
large enough to support the TV securely.
y Brackets, bolts and ropes are optional. You
can obtain additional accessories from your
local dealer.
Mounting on a wall
Attach an optional wall mount bracket at the rear
of the TV carefully and install the wall mount
bracket on a solid wall perpendicular to the
floor. When you attach the TV to other building
materials, please contact qualified personnel.
LG recommends that wall mounting be performed
by a qualified professional installer.
10 cm
10 cm
10 cm
10 cm
(4 inches)
Make sure to use screws and wall mount
bracket that meet the VESA standard. Standard
dimensions for the wall mount kits are described
in the following table.
Model 42LM6200
42LM6250
42LM6700
47LM6200
55LM6200
47LM6250
55LM6250
47LM6700
55LM6700
47LM7600
55LM7600
VESA 200 x 200 400 x 400
Standard screw M6 M6
Number of screws 44
Wall mount bracket
(optional)
LSW200BX,
LSW200BXG
LSW400BX,
LSW400BXG
Model 65LM6200
VESA 600 x 400
Standard screw M8
Number of screws 4
Wall mount bracket
(optional)
LSW600B
![](/img.php?id=1601822&img=bg14.png)
19
ENG
ENGLISH
ASSEMBLING AND PREPARING
CAUTION
y Disconnect the power first, and then move
or install the TV. Otherwise electric shock
may occur.
y If you install the TV on a ceiling or slanted
wall, it may fall and result in severe injury.
Use an authorized LG wall mount and contact
the local dealer or qualified personnel.
y Do not over tighten the screws as this may
cause damage to the TV and void your
warranty.
y Use the screws and wall mounts that meet
the VESA standard. Any damages or injuries
by misuse or using an improper accessory
are not covered by the warranty.
NOTE
y Use the screws that are listed on the VESA
standard screw specifications.
y The wall mount kit includes an installation
manual and necessary parts.
y The wall mount bracket is optional. You can
obtain additional accessories from your local
dealer.
y The length of screws may differ depending
on the wall mount. Make sure to use the
proper length.
y For more information, refer to the manual
supplied with the wall mount.
y Place the ring spacers on the set before
installing the wall mounting bracket so that
the inclination of the backside of the set can
be adjusted perpendicularly.
y If you use other manufacturer's wall bracket
for installation, insert the ring spacers into
the VESA hole to mount the set.
However, do not use it when you use LG
wall bracket.
Ring spacers
Tidying cables
1 Gather and bind the cables with the cable
holder.
Cable holder
CAUTION
y Do not move the TV by holding the cable
holder, as the cable holders may break, and
injuries and damage to the TV may occur.
![](/img.php?id=1601822&img=bg15.png)
20
ENG
ENGLISH
MAKING CONNECTIONS
Connecting to an antenna or cable
Connect an antenna, cable, or cable box to watch TV while referring to the following. The illustrations may
differ from the actual items and a RF cable is optional.
NOTE
y Use a signal splitter to use more than 2 TVs.
y Visit http://lgknowledgebase.com for more
information about the antenna and cable
connection. Search for antenna.
CAUTION
y Make sure not to bend the copper wire of
the RF cable.
Copper wire
y Complete all connections between devices,
and then connect the power cord to the
power outlet to prevent damage to your TV.
ANTENNA / CABLE
VHF Antenna
UHF Antenna
Antenna
Terminal
Coaxial (75Ω)
MAKING CONNECTIONS
Connect various external devices to the TV and switch input modes to select an external device. For more
information on external device’s connection, refer to the manual provided with each device.
Available external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC,
gaming devices, and other external devices.
NOTE
y If you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input cable
to the TV through a DVD recorder or VCR. For more information on recording, refer to the manual
provided with the connected device.
y The external device connection may differ from the model.
y Connect external devices to the TV regardless of the order of the TV port.
y If you connect a gaming device to the TV, use the cable supplied with the gaming device.
y Refer to the external equipment’s manual for operating instructions.
![](/img.php?id=1601822&img=bg16.png)
21
ENG
ENGLISH
MAKING CONNECTIONS
Connecting to a HD receiver, DVD, or VCR player
Connect a HD receiver, DVD, or VCR player to the TV and select an appropriate input mode.
HDMI Connection
HDMI is the best way to connect a device.
Transmits the digital video and audio signals from an external device to the TV. Connect the external device
and the TV with the HDMI cable as shown in the following illustration.
NOTE
y Use the latest High Speed HDMI™ Cable with CEC (Customer Electronics Control) function.
y High Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher.
ARC (Audio Return Channel)
y When connected with a high-speed
HDMI cable, digital audio can be sent to a
compactible device without an additional
optical audio cable.
y ARC is only supported on the HDMI input
1 (ARC) port. An external audio device that
supports ARC should be connected to
HDMI 1 if you wish to use ARC.
HDMI
2 3 1
(ARC)
4
(PC)
IN
DVD/ Blu-Ray / HD Cable Box / HD STB
Choose any HDMI input port to connect.
It does not matter which port you use.
(*Not Provided)
NOTE
y DTV Audio Supported Codec: MPEG, Dolby
Digital
y HDMI Audio Supporeted Format: Dolby
Digital, PCM (Up to 192 KHz, 32k/44.1k/48k/
88k/96k/176k/192k) -> Not supported DTS.
![](/img.php?id=1601822&img=bg17.png)
22
ENG
ENGLISH
MAKING CONNECTIONS
AUDIO OUT
DVI OUT
4
(PC)
IN
(RGB/HDMI-PC)
AUDIO
(RGB/HDMI-PC)
AUDIO
DVI to HDMI Connection
Transmits the digital video signal from an external device to the TV. Connect the external device and the
TV with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal, connect an
audio cable.
(*Not Provided)
(*Not Provided)
DVD/ Blu-Ray / HD Cable Box
![](/img.php?id=1601822&img=bg18.png)
23
ENG
ENGLISH
MAKING CONNECTIONS
VIDEO
AUDIO
LR
IN
COMPONENT
AV
PRPBY
AUDIO
VIDEO
Component Connection
Transmits analog video and audio signals from an external device to the TV. Connect the external device
and the TV with a component cable as shown in the following illustration.
NOTE
y If cables are installed incorrectly, it could case the image to display in black and white or with
distorted color.
y Check to ensure the cables are matched with the corresponding color connection.
DVD/ Blu-Ray / HD Cable Box
(*Not Provided)
(*Not Provided)
GREEN
RED
BLUE
GREEN
RED
BLUE
GREEN
RED
BLUE
WHITE
RED
YELLOW
WHITE
RED
WHITE
RED
(Use the composite video cable provided.) (Use the component video cable provided.)
GREENYELLOW
![](/img.php?id=1601822&img=bg19.png)
24
ENG
ENGLISH
MAKING CONNECTIONS
Composite Connection
Transmits analog video and audio signals from an external device to the TV. Connect the external device
and the TV with the composite cable as shown in the following illustration.
NOTE
y If you have a mono VCR, connect the audio cable from the VCR to the AUDIO L/MONO jack of the TV.
y Check to ensure the cables are matched with the corresponding color connection.
VIDEO
MONO
( )
AUDIOLR
IN
COMPONENT
AV
PRPBY
AUDIO
VIDEO
VCR / DVD/ Blu-Ray / HD Cable Box
(*Not Provided)
YELLOW
WHITE
RED
YELLOW
WHITE
RED
YELLOW
WHITE
RED
(Use the composite video cable provided.)
YELLOW
![](/img.php?id=1601822&img=bg1a.png)
25
ENG
ENGLISH
MAKING CONNECTIONS
HDMI
2 3 1
(ARC)
4
(PC)
IN
Connecting to a PC
NOTE
y It is recommended to use the HDMI connection for the best image quality.
y Depending on the graphics card, DOS mode video may not work if a HDMI to DVI Cable is in use.
y In PC mode, there may be noise associated with the resolution, vertical pattern, contrast or
brightness. If noise is present, change the PC output to another resolution, change the refresh rate to
another rate or adjust the brightness and contrast on the PICTURE menu until the picture is clear.
y The synchronization input form for Horizontal and Vertical frequencies is separate.
y Depending on the graphics card, some resolution settings may not allow the image to be positioned
on the screen properly.
HDMI Connection, DVI to HDMI Connection or RGB Connection
Choose method A, B, or C to make connection.
Method A: HDMI Connection
(*Not Provided)
SF
Choose any HDMI input port to connect.
It does not matter which port you use.
![](/img.php?id=1601822&img=bg1b.png)
26
ENG
ENGLISH
MAKING CONNECTIONS
Method B: DVI to HDMI Connection
Method C: RGB Connection
RGB OUT (PC) AUDIO OUT
(PC)
RGB
(RGB/HDMI-PC)
AUDIO
(PC)
RGB
(RGB/HDMI-PC)
AUDIO
(*Not Provided)
(*Not Provided)
SF
AUDIO OUT DVI OUT
4
(PC)
IN
(RGB/HDMI-PC)
AUDIO
(RGB/HDMI-PC)
AUDIO
(*Not Provided)
SF
(*Not Provided)
![](/img.php?id=1601822&img=bg1c.png)
27
ENG
ENGLISH
MAKING CONNECTIONS
Connecting to an Audio System
You may use an optional external audio system instead of the built-in speaker.
NOTE
y If you use an optional external audio device instead of the built-in speaker, set the TV speaker feature
to off.
Digital Optical Audio Connection
Transmits a digital audio signal from the TV to an external device. Connect the external device and the TV
with the optical audio cable as shown in the following illustration.
NOTE
y Do not look into the optical output port. Looking at the laser beam may damage your vision.
y Audio with ACP (Audio Copy Protection) function may block digital audio output.
Digital Audio System
(*Not Provided)
OPTICAL AUDIO IN
OUT
OPTICAL
DIGITAL
AUDIO
![](/img.php?id=1601822&img=bg1d.png)
28
ENG
ENGLISH
MAKING CONNECTIONS
Connecting to a USB
Connect a USB storage device such as a USB flash memory, external hard drive, or a USB memory card
reader to the TV and access the Smart Share menu to use various multimedia files.
NOTE
y To use a USB Hub device, make sure that it is connected to the USB IN 2 USB port.
y To store apps on a USB storage device, make sure that it is connected to the USB IN 3 USB Apps
port.
USB Hub USB Apps
HDD IN
123
USB IN
USB
(*Not Provided)
Choose any USB input port to connect.
It does not matter which port you use.
![](/img.php?id=1601822&img=bg1e.png)
29
ENG
ENGLISH
REMOTE CONTROL
Magic Remote Control Functions
When the message “Magic remote control battery is low. Change the battery.” is
displayed, replace the battery.
To replace batteries, open the battery cover, replace batteries (1.5 V AA) matching
and ends to the label inside the compartment, and close the battery cover. Be
sure to point the remote control at the remote control sensor on the TV.
To remove the batteries, perform the installation actions in reverse.
y Do not mix old and new batteries, as this may damage the remote control.
CAUTION
Make sure to point the remote control at the remote control sensor on the TV.
1
If you press (Wheel) on the Magic remote
control, the following screen appears.
Shows information about the current program
and screen.
2
If you press (Wheel) on the Magic remote
control, the following screen appears.
Set the channel you want.
You can press the CH button on the remote
control to set the channel.
3If you move the Magic remote control to the
bottom of the screen.
You can select Quick Menu.
%ULHI,QIR7LWOH7HVW ,QIR
᱈
$0
79 L
12
3
HOMEBACK
VOL CH
MY APPS
(POWER)
Turns the TV on or off.
Pointer (RF & Bluetooth transmitter)
Blinks the light when operating.
HOME
Accesses the Home menu.
Navigation buttons (up/down/left/right)
Scrolls through menus or options.
BACK
Returns to the previous level.
+ VOL -
Adjusts the volume level.
^ CH v
Scrolls through the saved channels.
(MUTE)
Mutes all sounds.
MY APPS
Shows the list of Apps.
Wheel (OK)
Selects menus or options and confirms
your input;
Scrolls through the saved channels.
If you press the navigation button while
moving the pointer on the screen,
the pointer disappears, and the Magic
remote control works as a regular
remote control.
To display the pointer again, shake the
Magic remote control from side to side.
3D
Uses for viewing 3D video.
![](/img.php?id=1601822&img=bg1f.png)
30
ENG
ENGLISH
REMOTE CONTROL
Registering Magic Remote Control
The Magic remote Control operates by pairing with
your TV. Once you purchased the TV, please
register the Magic remote control as follows;
How to register the Magic Remote Control
To register the remote control, press
the (Wheel) button on the remote
control.
How to Re-register the Magic Remote Control
after Registration Failure
BACK
HOME
1 Press and hold the BACK and
HOME buttons together for 5
seconds to reset, then register it
by following “How to register the
Magic remote control” above. (Once
the reset is complete, the light on
the Pointer blinks.)
2 To re-register the Magic remote
control, press and hold the BACK
button for 5 seconds toward the TV.
(Once the reset is complete, the
light on the Pointer blinks.)
How to use Magic Remote
Control
1 If the pointer disappears, move
the remote control slightly to left
or right. Then, it will automatically
appear on the screen.
» If the pointer has not been used
for a certain period of time, it
will disappear.
2 You can move the pointer by
aiming the Pointer Receiver of
the remote control at your TV
then move it left, right, up or
down.
»If the pointer does not work
properly after clicking the
(Wheel) button, leave
the remote control for 10
seconds then use it again.
Precautions to Take when Using
the Magic Remote Control
y Use the remote control within the maximum
communication distance (10 m, 32.8ft).
Using the remote control beyond this
distance, or with an object obstructing it,
may cause a communication failure.
y A communication failure may occur due to
nearby devices. Electrical devices such as
a microwave oven or wireless LAN product
may cause interference, as these use the
same bandwidth (2.4 GHz) as the Magic
Remote Control.
y The Magic Remote Control may be damaged
or may malfunction if it is dropped or
receives a heavy impact.
y Take care not to bump into nearby furniture
or other people when using the Magic
Remote Control.
y Manufacturer and installer cannot provide
service related to human safety as the
applicable wireless device has possibility of
electric wave interference.
y It is recommended that an Access Point (AP)
be located more than 1 m (3.28 ft) away
from the TV. If the AP is installed closer than
1 m (3.28 ft), the magic remote control may
not perform as expected due to frequency
interference.
![](/img.php?id=1601822&img=bg20.png)
31
ENG
ENGLISH
WATCHING TV
NOTE
y Seleect Home* when prompted. Store*
mode puts the TV in demo mode.
y If you select Store*, the any customized
settings will switch back to the default
settings of Store* in 5 minutes.
y The Power Indicator feature is disabled in
Store Demo mode.
4 When the basic settings are complete,
press (Wheel).
NOTE
y If you do not complete the Initial setting,
it will appear whenever the TV turns on.
y Disconnect the power cord from the
power outlet when you do not use the
TV for a long period of time.
5 To turn the TV off, press the power button on
the remote control.
USING THE USER
GUIDE
User Guide allows you to more easily access the
detailed TV information.
1 Move the Magic remote control on the bottom
of the screen.
2 Select
SETTINGS and press (Wheel).
3 Move the Magic remote control, select
SUPPORT and press (Wheel).
4 Move the Magic remote control, selectUser
Guide and press (Wheel).
NOTE
y You can also access the User Guide by
pressing (User Guide) in the remote
control.
WATCHING TV
Turning the TV on for the first
time
When you turn the TV on for the first time, the
Initial setting screen appears. Select a language
and customize the basic settings.
1 Connect the power cord to a power outlet.
2 In Standby mode, press the power button on
the remote control to turn the TV on.
The Initial setting screen appears if you turn
the TV on for the first time.
NOTE
y You can also access Initial Setting by
accessing OPTION in the main menu.
3 Follow the on-screen instructions to customize
your TV settings according to your preferences.
Language Selection* Selects a language to
display.
Ø
Using the Magic remote
control
Sets the Magic remote
contol.
Ø
Enviroment Selection Select Home* for the
home environment.
Ø
Network Connection Sets your network to
enable network-related
features on the TV.
Ø
Time Zone Setting Selects the time zone
and daylight saving.
Ø
Auto Tuning Scans and saves available
channels automatically.
Ø
Auto Energy Saving
mode Setting
Selects Auto Energy
Saving mode.
Ø
3D-On-Start Setting Selects 3D-On-Start
option. (For 3D TV)
Ø
Setting is complere. Confirms the setting
options.
![](/img.php?id=1601822&img=bg21.png)
32
ENG
ENGLISH
ENTERTAINMENT
ENTERTAINMENT
Network Connection
Connecting to a wired network
Connect the TV to a local area network (LAN) via
the LAN port as shown in the following illustration
and set up the network settings.
After making a physical connection, a small
number of home networks may require the TV
network settings to be adjusted. For most home
networks, the TV will connect automatically
without any adjustments.
For detail information, contact your internet
provider or router manual.
LAN
External modem / Wall outlet / PC
(*Not Provided)
1
&RQQHFWLQJZLUHGQHWZRUN
2
CAUTION
y Do not connect a modular phone cable to the
LAN port.
y Since there are various connection methods,
please follow the specifications of your
telecommunication carrier or internet service
provider.
y After connecting the LAN port, use the
Premium or LG Apps menu.
![](/img.php?id=1601822&img=bg22.png)
33
ENG
ENGLISH
ENTERTAINMENT
To set up the network settings: (Even if your TV
has already connected automatically, running
setup again will not harm anything)
1 Press
SETTINGS to access the Home menu.
2 Press the Navigation buttons to scroll to
NETWORK.
3 Press the Navigation buttons to select
Network Connection and press (Wheel).
4 Press the Navigation buttons to select IP Auto
Setting or IP Manual Setting and press
(Wheel).
1HWZRUN6HWWLQJ
,QVHUWWKH,3DGGUHVV
,30RGH ܁,30DQXDO6HWWLQJ۽
ᯘ,3$GGUHVV
ᯘ6XEQHW0DVN
ᯘ*DWHZD\
'160RGH
,30DQXDO6HWWLQJ
ᯘ'166HUYHU
(QWHU
ᰳ3UHYLRXV ᯙ1H[W
- If selecting IP Manual Setting, press the
Navigation and Number buttons. IP addresses
will need to be input manually.
- IP Auto Setting: Select this if there is a DHCP
server (Router) on the local area network
(LAN) via wired connection, the TV will
automatically be allocated an IP address. If
you’re using a broadband router or broadband
modem that has a DHCP (Dynamic Host
Configuration Protocol) server function. The
IP address will automatically be determined.
- IP Manual Setting: Select if there is no DHCP
server on the network or you want to set the
IP address manually.
4 When you are finished, press Enter.
#NOTE
y If the network setting screen do not
appear automatically, press SETTINGS 䮫
NETWORK 䮫 Network Connection.
y If the network settings are not set correctly,
the functions or services that require the
network connection may not work properly.
y If the options in Network Connection are not
set properly, check your Internet connection
and contact your Internet service provider.
y To use Internet features on the TV, you must
have active broadband Internet connection at
all times.
y If you cannot access the Internet, check the
network status of your computer.
y If the auto IP setting of the router
expires, when using IP Auto Setting,
you may experience temporary network
disconnection. Refer to the owner's manual
of the router for details.
![](/img.php?id=1601822&img=bg23.png)
34
ENG
ENGLISH
ENTERTAINMENT
Connecting to a wireless network
The LG Wireless LAN for Broadband/DLNA
Adaptor allows the TV to connect to a wireless
LAN network.
The network configuration and connection method
may vary depending on the equipment in use
and the network environment. Refer to the setup
instructions supplied with your access point or
wireless router for detailed connection steps and
network settings. The easiest method is the WPS
button method (Third method in this section).
Setting up the AP (Access Point) or the wireless
router is required before connecting the TV to the
network.
Wireless line sharer
NOTE
y For enjoying pictures, music, or video stored
on a PC using the router, a wired connection
or Wireless N (802.11n) connection is
recommended.
y When the wireless port of the router is used,
there may be restrictions on some functions.
y It is recommended that the Access Point
(AP) be located more than 1 m (3.28 ft) away
from the TV. If the AP is installed closer than
1 m, the magic motion remote control may
not perform as expected due to frequency
interference.
![](/img.php?id=1601822&img=bg24.png)
35
ENG
ENGLISH
TROUBLESHOOTING
TROUBLESHOOTING
General
Problem Resolution
Cannot control the TV with the
remote control.
y Check the remote control sensor on the product and try again.
y Check if there is any obstacle between the product and the remote control.
y Check if the batteries are still working and properly installed ( to , to ).
No image display and no sound is
produced.
y Check if the product is turned on.
y Check if the power cord is connected to a wall outlet.
y Check if there is a problem in the wall outlet by connecting other products.
The TV turns off suddenly. y Check the power control settings. The power supply may be interrupted.
y Check if the Auto sleep feature is activated in the Time settings.
y If there is no signal while the TV is on, the TV will turn off automatically after
15 minutes of inactivity.
OPEN SOURCE SOFTWARE NOTICE
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this
product, please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are
available for download.
![](/img.php?id=1601822&img=bg25.png)
36
ENG
ENGLISH
SPECIFICATIONS
SPECIFICATIONS
Product specifications may be changed without prior notice due to upgrade of product functions.
Power requirement USA, Canada, Mexico: AC 120 V ~ 50 / 60 Hz
Other Country: AC 100 - 240 V ~ 50 / 60 Hz
Television System NTSC-M, ATSC, 64 & 256 QAM
Program Coverage VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135
External Antenna Impedance 75 Ω
Environment
condition
Operating
Temperature
0 - 40 °C
Operating Humidity Less than 80 %
Storage Temperature -20 - 60 °C
Storage Humidity Less than 85 %
MODELS 42LM6200
(42LM6200-UE)
47LM6200
(47LM6200-UE)
47LM6210
(47LM6250-UD)
47LM6250
(47LM6250-UD)
Dimensions
(Width x Height x
Depth)
With stand
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
Without stand
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
Weight With stand 29.8 kg (65.6 lbs) 29.8 kg (65.6 lbs)
Without stand 27.5 kg (60.6 lbs) 27.5 kg (60.6 lbs)
Current Value / Power consumption 1.1 A / 110 W 1.4 A / 140 W
MODELS
55LM6200
(55LM6200-UE) 65LM6200
(65LM6200-UE)
55LM6210
(55LM6210-UD)
55LM6250
(55LM6250-UD)
65LM6250
(65LM6250-UD)
Dimensions
(Width x Height x
Depth)
With stand
1390.8 mm x 905.2 mm x 334.7
mm
(54.7 inch x 35.6 inch x 13.1 inch)
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
Without stand
1390.8 mm x 835.5 mm x 52.5 mm
(54.7 inch x 32.8 inch x 2.0 inch)
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
Weight With stand 42.6 kg (93.9 lbs) 29.8 kg (65.6 lbs)
Without stand 38.5 kg (84.8 lbs) 27.5 kg (60.6 lbs)
Current Value / Power consumption 1.6 A / 160 W 1.7 A / 170 W
![](/img.php?id=1601822&img=bg26.png)
37
ENG
ENGLISH
SPECIFICATIONS
MODELS 47LM6400
(47LM6400-UA)
55LM6400
(55LM6400-UA)
Dimensions
(Width x Height x
Depth)
With stand
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
Without stand
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
Weight With stand 29.8 kg (65.6 lbs) 29.8 kg (65.6 lbs)
Without stand 27.5 kg (60.6 lbs) 27.5 kg (60.6 lbs)
Current Value / Power consumption 1.1 A / 110 W 1.4 A / 140 W
MODELS 60LM6450
(60LM6450-UA)
Dimensions
(Width x Height x
Depth)
With stand 1232.0 mm x 795.0 mm x 54.5 mm
(48.5 inch x 31.2 inch x 2.1 inch)
Without stand 1232.0 mm x 716.0 mm x 54.5 mm
(48.5 inch x 28.1 inch x 2.1 inch)
Weight With stand 25.0 kg (55.1 lbs)
Without stand 21.3 kg (46.9 lbs)
Current Value / Power consumption 1.6 A / 160 W
MODELS 42LM6700
(42LM6700-UA)
47LM6700
(47LM6700-UA)
47LM6750
(47LM6750-UA)
Dimensions
(Width x Height x
Depth)
With stand
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
1063.0 mm x 701.0 mm x 263.0 mm
(46.1 inch x 30.3 inch x 11.4 inch)
Without stand
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
1063.0 mm x 628.0 mm x 33.4 mm
(46.1 inch x 28.0 inch x 1.3 inch)
Weight With stand 29.8 kg (65.6 lbs) 29.8 kg (65.6 lbs)
Without stand 27.5 kg (60.6 lbs) 27.5 kg (60.6 lbs)
Current Value / Power consumption 1.1 A / 110 W 1.4 A / 140 W
MODELS
55LM6700
(55LM6700-UA)
55LM6750
(55LM6750-UA)
Dimensions
(Width x Height x
Depth)
With stand 1232.0 mm x 795.0 mm x 331.0 mm
(48.5 inch x 31.2 inch x 13.0 inch)
Without stand 1232.0 mm x 723.0 mm x 33.6 mm
(48.5 inch x 28.4 inch x 1.3 inch)
Weight With stand 25.0 kg (55.1 lbs)
Without stand 21.3 kg (46.9 lbs)
Current Value / Power consumption 1.6 A / 160 W
MODELS 47LM7600
(47LM7600-UA)
55LM7600
(55LM7600-UA)
Dimensions
(Width x Height x
Depth)
With stand
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
Without stand
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
Weight With stand 29.8 kg (65.6 lbs) 29.8 kg (65.6 lbs)
Without stand 27.5 kg (60.6 lbs) 27.5 kg (60.6 lbs)
Current Value / Power consumption 1.4 A / 140 W 1.6 A / 160 W
![](/img.php?id=1601822&img=bg27.png)
38
ENG
ENGLISH
SPECIFICATIONS
Wireless LAN for Broadband/DLNA Adaptor SPEC
This device only works with compatible LG TV.
Standard IEEE802.11a/b/g/n
Frequency Range
2402 to 2483 MHz
5150 to 5250 MHz
5725 to 5850 MHz
Modulation CCK / OFDM / MIMO
Output Power (Typical)
802.11a: 14 dBm
802.11b: 17 dBm
802.11g: 14 dBm
802.11n: 13 dBm
Data rate
802.11a/g: 54 Mbps
802.11b: 11 Mbps
802.11n: 300 Mbps
Antenna Gain (Typical)
2402 to 2483 MHz: 1.17 dBi
5150 to 5250 MHz: 4.67 dBi
5725 to 5850 MHz: 3.30 dBi
Occupied bandwidth 802.11a/b/g: HT20
802.11n: HT20/40
Because band channel used by the country could be different, the user can not change or adjust the
operating frequency and this product is set for the regional frequency table.
y FCC ID of Wi-Fi module inside TV
FCC ID: BEJTWFMB003D
RF module (BM-LDS302) specification
For TV By using a 2.4 GHz bandwidth radio frequency(RF).
y Output: 10 dBm or lower
y Maximum Communication Distance: Line of Open Sight approx. 10 m (30 ft)
y Bandwidth: 2.4 GHz (2.400 GHz ~ 2.4835 GHz)
y Transfer Rate: 3 Mbps
y FCC ID of RF module inside TV
FCC ID: BEJLDS302
![](/img.php?id=1601822&img=bg28.png)
39
ENG
ENGLISH
MAINTENANCE
MAINTENANCE
Cleaning Your TV
Clean your TV regularly to keep the best
performance and to extend the product lifespan.
CAUTION
y Make sure to turn the power off and
disconnect the power cord and all other
cables first.
y When the TV is left unattended and unused
for a long time, disconnect the power cord
from the wall outlet to prevent possible
damage from lightning or power surges.
Screen, frame, cabinet and stand
To remove dust or light dirt, wipe the surface with
a dry, clean, and soft cloth.
To remove major dirt, wipe the surface with a
soft cloth dampened in clean water or a diluted
mild detergent. Then wipe immediately with a dry
cloth.
CAUTION
y Do not push, rub, or hit the surface with
your fingernail or a sharp object, as this may
result in scratches on the screen and image
distortions.
y Do not use any chemicals, such as waxes,
benzene, alcohol, thinners, insecticides, air
fresheners, lubricants, as these may damage
the screen’s finish and cause discoloration.
y Do not spray liquid onto the surface. If water
enters the TV, it may result in fire, electric
shock, or malfunction.
Power cord
Remove the accumulated dust or dirt on the
power cord regularly.
![](/img.php?id=1601822&img=bg29.png)
CHILD SAFETY:
It Makes A Difference How and Where
You Use Your Flat Panel Display
Congratulations on your purchase! As you enjoy your new product,
please keep these safety tips in mind:
THE ISSUE
yThe home theater entertainment experience is a growing trend and
larger flat panel displays are popular purchases. However, flat panel
displays are not always supported on the proper stands or installed
according to the manufacturer’s recommendations.
yFlat panel displays that are inappropriately situated on dressers,
bookcases, shelves, desks, speakers, chests or carts may fall over and
cause injury.
THIS MANUFACURER CARES!
yThe consumer electronics industry is committed to making home
entertainment enjoyable and safe.
TUNE INTO SAFETY
yOne size does NOT fit all. Follow the manufacturer’s
recommendations for the safe installation and use of your flat panel
display.
yCarefully read and understand all enclosed instructions for proper use
of this product.
yDon’t allow children to climb on or play with furniture and television
sets.
yDon’t allow place flat panel displays on furniture that can easily be
used as steps, such as a chest of drawers.
yRemember that children can become excited while watching
a program, especially on a “larger than life” flat panel display.
Care should be taken to place or install the display where it cannot be
pushed, pulled over, or knocked down.
yCare should be taken to route all cords and cables connected to the
flat panel display so that they cannot be pulled or grabbed by curious
children.
WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT
YOUR FLAT PANEL DISPLAY, ALWAYS:
yUse a mount that has been recommended by the display
manufacturer and/or listed by an independent laboratory
(such as UL, CSA, ETL).
yFollow all instructions supplied by the display and wall mount
manufacturers.
yIf you have any doubts about your ability to safely install your flat
panel display, contact your retailer about professional installation.
yMake sure that the wall where you are mounting the display is
appropriate. Some wall mounts are not designed to be mounted
to walls with steel studs or old cinder block construction.
If you are unsure, contact a professional installer.
yA minimum of two people are required for installation.
Flat panel displays can be heavy
![](/img.php?id=1601822&img=bg2d.png)
The model and serial number of the TV is
located on the back and/or one side of the TV.
Record it below should you ever need service.
MODEL
SERIAL
This product qualifies for ENERGY STAR in the
“factory default (Home Use)” setting.
Changing the factory default settings or enabling other
features may increase power consumption that could
exceed the limits necessary to quality for ENERGY STAR.
1-800-243-0000
1-888-865-3026
1-888-542-2623
USA, Consumer User
USA, Commercial User
CANADA
Register your product Online!
LG Customer Information Center
For inquires or comments, visit www.lg.com or call;
(For LM6700/LM7600 series,
42/47/55LS5750, 42/47/55LM6200 USA, Canada, Mexico)
www.lg.com
![](/img.php?id=1601822&img=bg2e.png)
Regulatory Information cont.
FCC Compliance Statement
This equipment has been tested and found to comply
within the limits of a Class B digital device pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio
or television reception (which can be determined by
turning the equipment on and off), the user is encouraged
to try to correct the interference by using one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
the receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
Caution: Changes or modifications not expressly approved
by the party responsible for compliance could void the
user's (or your) authority to operate the equipment. Only
peripherals (digital input/output devices, terminals, printers,
etc.) certified to comply with the Class B limits may be
attached to this monitor. Operation with non-certified
peripherals is likely to result in interference to radio and TV
reception. Only shielded signal cables may be used with
this System.
Canadian DOC Notice
This Class B digital apparatus meets all requirements of
the Canadian Interference-Causing Equipment
Regulations. Cet appareil numérique de la classe B
respecte toutes les exigences du Règlement sur le
matériel brouilleur du Canada.
CE Conformity Notice
(for Europe)
Products with the “CE” Marking comply with the EMC
Directive(89/336/EEC) and LOW VOLTAGE Directive
(73/23/EEC) issued by the Commission of the European
Community.
Compiance with these directives implies conformity to the
following European Norms :
• EN 55022 ; Radio Frequency Interference
• EN 55024 ; Electromagnetic Immunity
• EN 61000-3-2 ; Power Line Harmonics
• EN 61000-3-3 ; Voltage Fluctuations
• EN 60950-1 ; Product Safety
Low Radiation Compliance (MPR II)
This monitor meets one of the strictest guidelines available
today for low radiation emissions, offering the user extra
shielding and an antistatic screen coating. These
guidelines, set forth by a government agency in Sweden,
limit the amount of emission allowed in the Extremely Low
Frequency (ELF) and Very Low Frequency (VLF)
electromagnetic range.
01
NOTICE
The regulations are applied only to the products with the
ID LABEL indicating specific requirements.
NOTICE
The regulations are applied only to the products with the
ID LABEL indicating specific requirements.
NOTICE
The regulations are applied only to the products with the
ID LABEL indicating specific requirements.
TCO'99 (TCO'99 applied model only)
Congratulations!
You have just purchased a TCO’99 approved and labelled
product! Your choice has provided you with a product
developed for professional use. Your purchase has also
contributed to reducing the burden on the environment and
also to the further development of environmentally
adapted electronics products.
![](/img.php?id=1601822&img=bg2f.png)
Regulatory Information cont.
02
Why do we have environmentally labelled computers?
In many countries, environmental labelling has become an
established method for encouraging the adaptation of
goods and services to the environment. With the growing
manufacture and usage of electronic equipment
throughout the world, there is a recognized concern for the
materials and substances used by electronic products
with regards to their eventual recycling and disposal. By
proper selection of these materials and substances, the
impact on the environment can be minimized.
There are also other characteristics of a computer, such as
energy consumption levels, that are important from the
viewpoints of both the work (internal) and natural (external)
environments. Electronic equipment in offices is often left
running continuously, resulting in unnecessary
consumption of large amounts of energy and additional
power generation. From the standpoint of carbon dioxide
emissions alone, it is vital to save energy.
What does labelling involve?
The product meets the requirements for the TCO’99
scheme which provides for international and environmental
labelling of personal computers and/or displays.
The labelling scheme was developed as a joint effort by the
TCO (The Swedish Confederation of Professional
Employees), Svenska Naturskyddsforeningen
(The Swedish Society for Nature Conservation) and
Statens Energimyndighet (The Swedish National
Energy Administration).
Approval requirements cover a wide range of issues:
ecology, ergonomics, emission of electrical and magnetical
fields, energy consumption and electrical safety.
Ecological criteria impose restrictions on the presence and
use of heavy metals, brominated and chlorinated flame
retardants, and other substances. The product must be
prepared for recycling and the manufacturing site(s) shall
be certified according to ISO14001 or EMAS registered.
Energy requirements include a demand that the system
unit and/or display, after a certain period of inactivity,
shall reduce its power consumption to a lower level in one
or more stages. The length of time to reactivate the system
unit shall be reasonable for the user.
Labelled products must meet strict environmental
demands, for example, in respect of the reduction of
electrical and magnetical fields as well as work load and
visual ergonomics.
Below you will find a brief summary of the ecological
requirements met by this product. The complete
ecological criteria document can be found at TCO
Development’s website http://www.tcodevelopment.com
or may be ordered from:
TCO Development
SE-114 94 STOCKHOLM, Sweden
Fax: +46 8 782 92 07
Email : development@tco.se
Information regarding TCO’99 approved and labelled
products may also be obtained at
http://www.tcodevelopment.com
Ecological requirements
Flame retardants
Flame retardants may be present in printed wiring board
laminates, cables, and housings. Their purpose is to
prevent, or at least to delay the spread of fire. Up to 30%
by weight of the plastic in a computer casing can consist of
flame retardant substances. Many flame retardants
contain bromine or chlorine, and these flame retardants
are chemically related to PCBs (polychlorinated
biphenyls). Both the flame retardants containing bromine
or chlorine and the PCBs are suspected of giving rise to
health effects, including reproductive damage in fish-
eating birds and mammals, due to the bio-accumulative*
processes when not disposed of in accordance with strict
standards for disposal.
TCO’99 requires that plastic components weighing more
than 25 grams shall not contain flame retardants with
organically bound bromine or chlorine. Flame retardants
are allowed in the printed wiring board laminates due to
the lack of commercially available alternatives.
Cadmium**
Cadmium is present in rechargeable batteries and in the
colour-generating layers of certain computer displays.
TCO’99 requires that batteries, the colour-generating
layers of display screens, and the electrical or electronics
components shall not contain any cadmium.
Mercury**
Mercury is sometimes found in batteries, relays and
switches. TCO’99 requires that batteries shall not contain
any mercury. It also demands that mercury is not present
in any of the electrical or electronics components
associated with the labelled unit. There is however one
![](/img.php?id=1601822&img=bg30.png)
Regulatory Information cont.
03
exception. Mercury is, for the time being, permitted in the
back light system of flat panel monitors as there today is
no commercially available alternative. TCO aims on
removing this exception when a mercury free alternative is
available.
Lead**
Lead can be found in picture tubes, display screens,
solders and capacitors. TCO’99 permits the use of lead
due to the lack of commercially available alternatives, but
in future requirements TCO Development aims at
restricting the use of lead.
_____________________________________________
* Bio-accumulative is defined as substances which
accumulate in living organisms.
**Lead, Cadmium and Mercury are heavy metals
which are bio-accumulative.
TCO’03
(TCO’03 applied model only)
Congratulations!
The display you have just purchased carries the TCO’03
Displays label.
This means that your display is designed,manufactured
and tested according to some of the strictest quality and
environmental requirements in the world. This makes for a
high performance product, designed with the user in focus
that also minimizes the impact on our natural environment.
Some of the features of the TCO’03 Display requirements:
Ergonomics
• Good visual ergonomics and image quality in order to
improve the working environment for the user and to
reduce sight and strain problems. Important
parameters are luminance, contrast, resolution,
reflectance, colour rendition and image stability.
Energy
• Energy-saving mode after a certain time – beneficial
both for the user and the environment
• Electrical safety
Emissions
• Electromagnetic fields
• Noise emissions
Ecology
• The product must be prepared for recycling and the
manufacturer must have a certified environmental
management system such as EMAS or ISO 14 001
• Restrictions on
chlorinated and brominated flame retardants and
polymers
heavy metals such as cadmium, mercury and lead.
The requirements included in this label have been
developed by TCO Development in co-operation with
scientists, experts, users as well as manufacturers all over
the world. Since the end of the 1980s TCO has been
involved in influencing the development of IT equipment in
a more user-friendly direction. Our labelling system started
with displays in 1992 and is now requested by users and
IT-manufacturers all over the world.
For more information, please visit
www.tcodevelopment.com
Information for Environmental Preservation
LGE. announced the 'LG Declaration for a Cleaner
Environment' in 1994, and this ideal has served as a
guiding managerial principle ever since. The Declaration is
a foundation that has allowed us to undertake
environmentally friendly activities in careful consideration
of economic, environmental, and social aspects.
We promote activities for environmental preservation, and
we specifically develop our products to embrace the
concept of environment-friendly.
We minimize the hazardous materials contained in our
products. For example, there is no cadmium to be found in
our monitors.
Information for recycling
This monitor may contain parts which could be hazardous
to the environment. It is important that this monitor be
recycled after use.
LGE. handles all waste monitors through an
environmentally acceptable recycling method. There are
several take-back and recycling systems currently in
English
![](/img.php?id=1601822&img=bg31.png)
Regulatory Information cont.
04
operation worldwide. Many parts will be reused and
recycled, while harmful substances and heavy metals are
treated by an environmentally friendly method.
If you want to find out more information about our
recycling program, please contact your local LG vendor or
a corporate representative of LG.
We set our vision and policies on a cleaner world by
selecting the issue of the global environment as a task for
corporate improvement. Please visit our website for more
information about our ‘green’ policies.
http://www.lge.com/about/environment/html/Recycling.jsp
Informationen zur Erhaltung der Umwelt
Im Jahr 1994 verkündete LGE die 'LG Declaration for a
Cleaner Environment' (LG Erklärung für eine sauberere
Umwelt). Seitdem dient dieses Ideal als führendes Prinzip
des Unternehmens. Diese Erklärung war die Basis für die
Durchführung von
umweltfreundlichen Aktivitäten, wobei wirtschaftliche,
umweltbezogene und soziale Aspekte in die
Überlegungen mit einbezogen wurden.
Wir fördern Aktivitäten zum Schutz der Umwelt und die
Entwicklung unserer Produkte ist darauf ausgerichtet,
unserem Konzept bezüglich Umweltfreundlichkeit gerecht
zu werden.
Wir sind darauf bedacht, den Anteil der in unseren
Produkten enthaltenen schädlichen Materialien zu
minimieren. So ist in unseren Monitoren beispielsweise
kein Kadmium zu finden.
Informationen zum Thema Recycling
Dieser Monitor enthält Teile, die umweltschädlich sein
können. Es ist unbedingt erforderlich, dass der Monitor
recycelt wird, nachdem er außer Dienst gestellt wurde.
Bei LGE. werden alle ausrangierten Monitore in einem
unter umweltbezogenen Aspekten geeigneten Verfahren
recycelt. Augenblicklich sind weltweit mehrere
Rücknahme- und Recyclingsysteme im Einsatz. Viele
Teile werden wieder verwendet und recycelt. Schädliche
Substanzen und Schwermetalle werden durch
umweltverträgliche Verfahren behandelt.
Falls Sie mehr über unser Recyclingprogramm erfahren
möchten, wenden Sie sich bitte an Ihren lokalen LG-
Händler oder einen Unternehmensvertreter von LG.
Wir richten unsere Firmenpolitik auf eine sauberere
Umwelt hin aus, indem wir umweltspezifische Aspekte als
wichtigen Punkt in die Weiterentwicklung unseres
Unternehmens einfließen lassen. Zusätzliche
Informationen über unsere ‘grüne’ Firmenpolitik erhalten
Sie auf unserer Website.
http://www.lge.com/about/environment/html/Recycling.jsp
Information sur la protection del’environnement
LGE. a publié sa 'Déclaration en faveur d’un
environnement plus propre' en 1994 et celle-ci est restée,
depuis lors, un principe directeur de notre entreprise.
Cette déclaration a servi de base à notre réflexion et nous
a permis de prendre en compte à la fois les aspects
économiques et sociaux de nos activités, tout en
respectant l’environnement.
Nous encourageons les activités en faveur de la
préservation de l’environnement et c’est dans cet esprit
que nous développons nos produits : nous réduisons au
minimum les matières dangereuses qui entrent dans leur
composition et l’on ne trouve pas de cadmium, par
exemple, dans nos moniteurs.
Information sur le recyclage
Ce moniteur peut contenir des composants qui présentent
un risque pour l’environnement. Il est donc important que
celui-ci soit recyclé après usage.
LGE. traite les moniteurs en fin de cycle conformément à
une méthode de recyclage respectueuse de
l’environnement. Nous reprenons nos produits et les
recyclons dans plusieurs sites répartis dans le monde
entier. De nombreux composants sont réutilisés et
recyclés, et les matières dangereuses, ainsi que les
métaux lourds, sont traités selon un procédé écologique.
Si vous souhaitez plus de renseignements sur notre
programme de recyclage, veuillez contacter votre
revendeur LG ou un l’un de nos représentants.
Nous voulons agir pour un monde plus propre et croyons
au rôle de notre entreprise dans l’amélioration de
l’environnement. Pour plus de renseignements sur notre
politique “verte”, rendez visite à notre site :
http://www.lge.com/about/environment/html/Recycling.jsp
Deutsch
Français
![](/img.php?id=1601822&img=bg32.png)
05
Regulatory Information cont.
Informazioni per la tutela dell’ambiente
La LGE. ha annunciato nel 1994 la cosiddetta 'LG
Declaration for a Cleaner Environment' (Dichiarazione di
LG a favore di un ambiente più pulito), un ideale che da
allora funge da principio ispiratore della gestione
aziendale. La dichiarazione rappresenta il fondamento che
consente di intraprendere attività a favore dell'ambiente
tenendo conto degli aspetti economici, ambientali e
sociali.Noi della LG, promuoviamo attività a favore della
tutela dell'ambiente sviluppando appositamente i nostri
prodotti per cogliere il concetto del rispetto dell’ambiente
riducendo i materiali dannosi presenti nei nostri prodotti.
Ad esempio nei nostri monitor non è presente il cadmio.
Informazioni per il riciclaggio
Il monitor può presentare componenti che potrebbero
risultare eventualmente dannosi per l'ambiente. È
importante che il monitor sia riciclato al termine del suo
utilizzo.
La LGE. gestisce tutti i monitor di rifiuto con un metodo di
riciclaggio soddisfacente dal punto di vista ambientale. In
tutto il mondo sono attualmente in funzione numerosi
sistemi di riciclaggio e recupero. I diversi componenti sono
riutilizzati e riciclati, mentre le sostanze dannose e i metalli
pesanti vengono trattati con un metodo rispettoso
dell’ambiente.
Se si desiderano maggiori informazioni in merito al
programma di riciclaggio, è consigliabile rivolgersi al
proprio rivenditore LG o ad un rappresentante aziendale
della LG.
Noi della LG impostiamo la nostra visione e le nostre
politiche a favore di un mondo più pulito ponendo la
questione dell'ambiente dal punto di vista globale come
una mansione rivolta al miglioramento della nostra
azienda. Vi invitiamo a visitare il nostro sito internet per
ulteriori informazioni sulla nostra politica “verde”.
http://www.lge.com/about/environment/html/Recycling.jsp
Información para la conservación
medioambiental
LGE. presentó la 'Declaración para un entorno más limpio
de LG' en 1994 y este ideal ha servido para guiar nuestros
principios empresariales desde entonces. La Declaración
es la base que nos ha permitido llevar a cabo tareas que
respetan el medio ambiente siempre teniendo en cuenta
aspectos sociales,
económicos y medioambientales.
Promocionamos actividades orientadas a la conservación
del medio ambiente y desarrollamos nuestros productos
específicamente para que se ajusten a la filosofía que
protege el entorno.
Reducimos al máximo el uso de materiales de riesgo en
nuestros productos. Un ejemplo de ello es la ausencia
total de cadmio en nuestros monitores.
Información para el reciclaje
Este monitor puede contener piezas que entrañen riesgos
medioambientales. Es importante reciclar este monitor
después de su utilización.
LGE. trata todos los monitores usados siguiendo un
método de reciclaje que no daña al entorno. Contamos
con diversos sistemas de recuperación y reciclaje que
funcionan a nivel mundial en la actualidad. Es posible
reciclar y reutilizar muchas de las piezas, mientras que las
sustancias dañinas y los metales pesados se tratan
siguiendo un método que no perjudique al medio
ambiente. Si desea obtener más información acerca del
programa de reciclaje, póngase en contacto con su
proveedor local de LG o con un representante empresarial
de nuestra marca.
Basamos nuestra visión y nuestras políticas en un mundo
más limpio y para ellos optamos por un entorno global
como tarea principal de nuestra evolución como empresa.
Visite nuestra página Web para obtener más información
sobre nuestras políticas ecológicas.
http://www.lge.com/about/environment/html/Recycling.jsp
Informações relacionadas à preservação
ambiental
A LGE. anunciou a 'LG Declaration for a Cleaner
Environment' (Declaração da LG para um ambiente mais
limpo) em 1994 e esse ideal tem servido desde então
como um princípio administrativo de orientação. A
Declaração é a base que nos tem permitido realizar
atividades favoráveis ao ambiente com consideração
atenta aos aspectos econômicos, ambientais e sociais.
Promovemos atividades de preservação ambiental e
desenvolvemos nossos produtos para englobar
Italiano
Espanõl
Português
![](/img.php?id=1601822&img=bg33.png)
06
Regulatory Information cont.
especificamente o conceito de favorável ao ambiente.
Reduzimos os materiais perigosos contidos em nossos
produtos. Por exemplo, não há cádmio em nossos
monitores.
Informações relacionadas à reciclagem
Este monitor pode conter peças que podem representar
riscos ao ambiente. É importante que ele seja reciclado
após o uso.
A LGE. cuida de todos os monitores descartados através
de um método de reciclagem agradável ao ambiente. Há
vários sistemas de devolução e reciclagem atualmente
em operação no mundo. Muitas peças serão reutilizadas
e recicladas e as substâncias nocivas e os metais
pesados passarão por tratamento através de um método
favorável ao ambiente.
Para obter mais informações sobre nosso programa de
reciclagem, entre em contato com seu fornecedor LG
local ou com um representante corporativo da LG.
Definimos nossa visão e nossas políticas relacionadas a
um mundo mais limpo selecionando a questão do
ambiente global como uma tarefa de aprimoramento
corporativo. Visite nosso site para obter mais informações
sobre nossas políticas de meio ambiente.
http://www.lge.com/about/environment/html/Recycling.jsp
Informatie met betrekking tot het behoud van
het milieu
LGE. publiceerde in 1994 de 'LG Declaration for a Cleaner
Environment' (de LG-verklaring met betrekking tot een
schoner milieu). Deze verklaring en het ideaal van een
schoner milieu fungeren sindsdien als een bestuurlijke
leidraad voor onze onderneming. Op basis van deze
verklaring ontplooien wij milieuvriendelijke activiteiten,
waarbij er zowel met sociale en economische aspecten,
als met milieuaspecten zorgvuldig rekening wordt
gehouden.
Wij ondersteunen activiteiten die zijn gericht op het
behoud van het milieu en wij houden bij het ontwikkelen
onze producten specifiek rekening met de
milieuvriendelijkheid van onze producten.
Wij minimaliseren het gebruik van schadelijke stoffen in
onze producten. Er wordt bijvoorbeeld geen cadmium
verwerkt in onze monitors.
Nederlands
Informatie met betrekking tot recycling
Deze monitor bevat materialen die schadelijk zouden
kunnen zijn voor het milieu. Het is belangrijk dat deze
monitor aan het einde van zijn levensduur wordt
gerecycled.
LGE. verwerkt alle afvalmonitors via een milieuvriendelijke
recyclingmethode. Hiervoor worden er momenteel
wereldwijd verscheidene inname- en recyclingsystemen
gehanteerd. Een groot aantal onderdelen wordt opnieuw
gebruikt en gerecycled, waarbij schadelijke stoffen en
zware metalen volgens een milieuvriendelijke methode
worden verwerkt.
Voor meer informatie over ons recyclingprogramma kunt u
contact opnemen met uw plaatselijke LG-
vertegenwoordiger of een LG-vestiging.
Onze visie en ons beleid met betrekking tot een schonere
wereld vloeien voort uit het feit dat wij het milieu hebben
aangemerkt als een onderwerp dat speciale aandacht
verdient binnen onze onderneming. Bezoek onze website
voor meer informatie over ons 'groene' beleid.
http://www.lge.com/about/environment/html/Recycling.jsp
»ÌÙÓχˆËˇ ÔÓ Óı‡Ì ÓÍÛʇ˛˘ÂÈ Ò‰˚
¬ 1994 „Ó‰Û ÍÓÔÓ‡ˆËˇ LGE ÓÔÛ·ÎËÍÓ‚‡Î‡
'ƒÂÍ·‡ˆË˛ LG ÔÓ Óı‡Ì ÓÍÛʇ˛˘ÂÈ Ò‰˚',
ÍÓÚÓ‡ˇ Ò ÚÂı ÔÓ ÒÎÛÊËÚ ÓÒÌÓ‚Ì˚Ï ÔË̈ËÔÓÏ
ÛÔ‡‚ÎÂÌˡ. Õ‡ ÓÒÌÓ‚Â ˝ÚÓÈ ‰ÂÍ·‡ˆËË Ï˚ ÒÏÓ„ÎË
Ô‰ÔËÌˇÚ¸ ‰ÂÈÒڂˡ, Ó·ÂÒÔ˜˂‡˛˘ËÂ
·ÂÁÓÔ‡ÒÌÓÒÚ¸ ÓÍÛʇ˛˘ÂÈ Ò‰˚, Û‰ÂΡˇ ÔË ˝ÚÓÏ
‰ÓÎÊÌÓ ‚ÌËχÌË ˝ÍÓÌÓÏ˘ÂÒÍËÏ, ˝ÍÓÎӄ˘ÂÒÍËÏ Ë
ÒӈˇθÌ˚Ï ‡ÒÔÂÍÚ‡Ï.
Ã˚ ÒÚËÏÛÎËÛÂÏ ‰ÂˇÚÂθÌÓÒÚ¸ ÔÓ Óı‡ÌÂ
ÓÍÛʇ˛˘ÂÈ Ò‰˚, Û‰ÂΡˇ ÓÒÓ·Ó ‚ÌËχÌËÂ
‡Á‡·ÓÚÍ ̇¯ÂÈ ÔÓ‰Û͈ËË ‚ ÒÓÓÚ‚ÂÚÒÚ‚ËË Ò
ÍÓ̈ÂÔˆËÂÈ ˝ÍÓÎӄ˘ÂÒÍÓÈ ·ÂÁÓÔ‡ÒÌÓÒÚË.
Ã˚ Ò‚Ó‰ËÏ Í ÏËÌËÏÛÏÛ ÒÓ‰ÂʇÌË ÓÔ‡ÒÌ˚ı
‚¢ÂÒÚ‚ ‚ ̇¯ÂÈ ÔÓ‰Û͈ËË. Õ‡ÔËÏÂ, ‚ ̇¯Ëı
ÏÓÌËÚÓ‡ı ‚˚ Ì ̇ȉÂÚ ͇‰Ïˡ.
»ÌÙÓχˆËˇ ÔÓ ÛÚËÎËÁ‡ˆËË ÓÚıÓ‰Ó‚
›ÚÓÚ ÏÓÌËÚÓ ÏÓÊÂÚ ÒÓ‰Âʇڸ ÍÓÏÔÓÌÂÌÚ˚,
ÍÓÚÓ˚ ÏÓ„ÛÚ Ì‡ÌÂÒÚË Û˘Â· ÓÍÛʇ˛˘ÂÈ Ò‰Â.
Russian
![](/img.php?id=1601822&img=bg34.png)
07
Regulatory Information cont.
EPA
(EPA applied model only)
ENERGY STAR
is a set of power-saving guidelines
issued by the U.S. Environmental Protection
Agency(EPA).
NOM MARK (Mexico only)
ÕÂÓ·ıÓ‰ËÏÓ ÛÚËÎËÁËÓ‚‡Ú¸ ÏÓÌËÚÓ ÔÓÒÎÂ
ËÒÔÓθÁÓ‚‡Ìˡ.
KÓÔÓ‡ˆËˇ LGE Ô‡·‡Ú˚‚‡ÂÚ ‚Ò ·‡ÍÓ‚‡ÌÌ˚Â
ÏÓÌËÚÓ˚ Ò ÔÓÏÓ˘¸˛ ˝ÍÓÎӄ˘ÂÒÍË ÔËÂÏÎÂÏÓ„Ó
ÏÂÚÓ‰‡ ÛÚËÎËÁ‡ˆËË ÓÚıÓ‰Ó‚. œÓ ‚ÒÂÏÛ ÏËÛ
‰ÂÈÒÚ‚Û˛Ú ÒËÒÚÂÏ˚ ÛÚËÎËÁ‡ˆËË ÓÚıÓ‰Ó‚ Ë ‚ÓÁ‚‡Ú‡
ËÒÔÓθÁÓ‚‡ÌÌÓÈ ÔÓ‰Û͈ËË. ÃÌÓ„Ë ÍÓÏÔÓÌÂÌÚ˚
·Û‰ÛÚ ‚ÚÓ˘ÌÓ ËÒÔÓθÁÓ‚‡Ì˚ Ë ÛÚËÎËÁËÓ‚‡Ì˚, ‚ ÚÓ
‚ÂÏˇ Í‡Í ‚‰Ì˚ ‚¢ÂÒÚ‚‡ Ë ÚˇÊÂÎ˚ ÏÂÚ‡ÎÎ˚
·Û‰ÛÚ Ó·‡·ÓÚ‡Ì˚ Ò ÔÓÏÓ˘¸˛ ˝ÍÓÎӄ˘ÂÒÍË
ÔËÂÏÎÂÏÓ„Ó ÏÂÚÓ‰‡.
«‡ ·ÓΠÔÓ‰Ó·ÌÓÈ ËÌÙÓχˆËÂÈ ÔÓ Ì‡¯ÂÈ
ÔÓ„‡ÏÏ ÛÚËÎËÁ‡ˆËË ÓÚıÓ‰Ó‚ Ó·‡˘‡ÈÚÂÒ¸ Í
ÏÂÒÚÌÓÏÛ ÔÓÒÚ‡‚˘ËÍÛ ËÎË Ô‰ÒÚ‡‚ËÚÂβ
ÍÓÔÓ‡ˆËË LG.
Ã˚ ÓËÂÌÚËÛÂÏÒˇ ̇ Ó·ÂÒÔ˜ÂÌË ˝ÍÓÎӄ˘ÂÒÍÓÈ
·ÂÁÓÔ‡ÒÌÓÒÚË, ÒÚ‡‚ˇ Ò· ˆÂθ˛ „ÎÓ·‡Î¸ÌÛ˛ Á‡˘ËÚÛ
ÓÍÛʇ˛˘ÂÈ Ò‰˚. ƒÓÔÓÎÌËÚÂθÌÛ˛ ËÌÙÓχˆË˛
Ó Ì‡¯ÂÈ ÔÓÎËÚËÍ ÔÓ Óı‡Ì ÓÍÛʇ˛˘ÂÈ Ò‰˚ ‚˚
ÏÓÊÂÚ ̇ÈÚË Ì‡ ̇¯ÂÏ Ò‡ÈÚÂ:
http://www.lge.com/about/environment/html/Recycling.jsp
As an ENERGY STAR Partner LGE U. S.
A.,Inc. has determined that this product
meets the ENERGY STAR guidelines for
energy efficiency.
![](/img.php?id=1601822&img=bg35.png)
08
Regulatory Information cont.
1.When this crossed-out wheeled bin symbol is attached
to a product it means the product is covered by the
European Directive 2002/96/EC.
2.All electrical and electronic products should be
disposed of separately from the municipal waste
stream via designated collection facilities appointed by
the government or the local authorities.
3.The correct disposal of your old appliance will help
prevent potential negative consequences for the
environment and human health.
4.For more detailed information about disposal of your
old appliance, please contact your city office, waste
disposal service or the shop where you purchased the
product.
Disposal of your old appliance
1.Quando su un prodotto è riportato il simbolo di
1.När den här symbolen med en överkryssad
soptunna på hjul sitter på en produkt innebär det
att den regleras av European Directive
2002/96/EC.
2.Alla elektriska och elektroniska produkter bör
kasseras via andra vägar än de som finns för
hushållsavfall, helst via för ändamålet avsedda
uppsamlingsanläggningar som myndigheterna
utser.
3.Om du kasserar din gamla apparat på rätt sätt
så bidrar du till att förhindra negativa
konsekvenser för miljön och människors hälsa.
4.Mer detaljerad information om kassering av din
gamla apparat kan får av kommunen,
renhållningsverket eller den butik där du köpte
produkten.
1.Als het symbool met de doorgekruiste verrijdbare
afvalbak op een product staat, betekent dit dat
het product valt onder de Europese Richtlijn
2002/96/EC.
2.Elektrische en elektronische producten mogen
niet worden meegegeven met het huishoudelijk
afval, maar moeten worden ingeleverd bij
speciale inzamelingspunten die door de lokale of
landelijke overheid zijn aangewezen.
3.De correcte verwijdering van uw oude toestel
helpt negatieve gevolgen voor het milieu en de
menselijke gezondheid voorkomen.
Smaltimento delle apparecchiature obsolete
Kassering av din gamla apparat
Uw oude toestel wegdoen
1.Ce symbole, représentant une poubelle sur
roulettes barrée d'une croix, signifie que le
produit est couvert par la directive européenne
2002/96/EC.
2.Les éléments électriques et électroniques
doivent être jetés séparément, dans les vide-
ordures prévus à cet effet par votre municipalité.
3.Une élimination conforme aux instructions aidera
à réduire les conséquences négatives et risques
éventuels pour l'environnement et la santé
humaine.
4.Pour plus d'information concernant l'élimination
de votre ancien appareil, veuillez contacter votre
mairie, le service des ordures ménagères ou
encore la magasin où vous avez acheté ce
produit.
Élimination de votre ancien appareil
un bidone della spazzatura barrato da una croce
significa che il prodotto è coperto dalla direttiva
europea 2002/96/EC.
2.Tutti i prodotti elettrici ed elettronici dovrebbero
essere smaltiti separatamente rispetto alla
raccolta differenziata municipale, mediante
impianti di raccolta specifici designati dal
governo o dalle autorità locali.
3.Il corretto smaltimento delle apparecchiature
obsolete contribuisce a prevenire possibili
conseguenze negative sulla salute umana e
sull'ambiente.
4.Per informazioni più dettagliate sullo smaltimento
delle apparecchiature obsolete, contattare il
comune, il servizio di smaltimento rifiuti o il
negozio in cui è stato acquistato il prodotto.
English
French
Italian
Swedish
Dutch
WEEE (for Europe )
![](/img.php?id=1601822&img=bg36.png)
Regulatory Information cont.
09
1.Wenn dieses Symbol eines durchgestrichenen
Abfalleimers auf einem Produkt angebracht ist,
unterliegt dieses Produkt der europäischen
Richtlinie 2002/96/EC.
2.Alle Elektro- und Elektronik-Altgeräte müssen
getrennt vom Hausmüll über dafür staatlich
vorgesehenen Stellen entsorgt werden.
3.Mit der ordnungsgemäßen Entsorgung des alten
Geräts vermeiden Sie Umweltschäden und eine
Gefährdung der persönlichen Gesundheit.
4.Weitere Informationen zur Entsorgung des alten
Geräts erhalten Sie bei der Stadtverwaltung,
beim Entsorgungsamt oder in dem Geschäft, wo
Sie das Produkt erworben haben.
1.ŸÙ·Ó ¤Ó· ÚÔ˚fiÓ ‰È·ı¤ÙÂÈ ÙÔ ‰‡Ì‚ÔÏÔ ÂÓfi˜
‰È·ÁÚ·Ì̤ÓÔ˘ οϷıÔ˘ ·ÔÚÚÈÌÌ¿ÙˆÓ, ÙfiÙ ÙÔ ÚÔ˚fiÓ
ηχÙÂÙ·È ·fi ÙËÓ E˘Úˆ·˚΋ O‰ËÁ›· 2002/96/EOK.
2.H ·fiÚÚÈ„Ë fiÏˆÓ ÙˆÓ ËÏÂÎÙÚÈÎÒÓ Î·È ËÏÂÎÙÚÔÓÈÎÒÓ
ÚÔ˚fiÓÙˆÓ Ú¤ÂÈ Ó· Á›ÓÂÙ·È ¯ˆÚÈÛÙ¿ ·fi Ù· ÁÂÓÈο
ÔÈÎȷο ·ÔÚÚ›ÌÌ·Ù· ̤ۈ ηıÔÚÈṲ̂ӈÓ
ÂÁηٷÛÙ¿ÛÂˆÓ Û˘ÏÏÔÁ‹˜ ·ÔÚÚÈÌÌ¿ÙˆÓ, ÔÈ Ôԛ˜
¤¯Ô˘Ó ‰ËÌÈÔ˘ÚÁËı› ›Ù ·fi ÙËÓ Î˘‚¤ÚÓËÛË ‹ ·fi ÙȘ
ÙÔÈΤ˜ ·Ú¯¤˜.
3.H ÛˆÛÙ‹ ·fiÚÚÈ„Ë Ù˘ ·ÏÈ¿˜ Û·˜ Û˘Û΢‹˜ ı·
‚ÔËı‹ÛÂÈ ÛÙËÓ ·ÔÙÚÔ‹ Èı·ÓÒÓ ·ÚÓËÙÈÎÒÓ Û˘ÓÂÈÒÓ
ˆ˜ ÚÔ˜ ÙÔ ÂÚÈ‚¿ÏÏÔÓ Î·È ÙËÓ ˘Á›· ÙÔ˘ ·ÓıÚÒÔ˘.
4.°È· ÈÔ ÏÂÙÔÌÂÚ›˜ ÏËÚÔÊÔڛ˜ Û¯ÂÙÈο Ì ÙËÓ
·fiÚÚÈ„Ë Ù˘ ·ÏÈ¿˜ Û·˜ Û˘Û΢‹˜, ÂÈÎÔÈÓˆÓ‹ÛÙ ÌÂ
ÙÔ ·ÚÌfi‰›Ô ÙÔÈÎfi ÁÚ·Ê›Ô, ˘ËÚÂÛ›· ‰È¿ıÂÛ˘ ÔÈÎÈ·ÎÒÓ
·ÔÚÚÈÌÌ¿ÙˆÓ ‹ ÙÔ Ì·Á·Í› ·fi ÙÔ ÔÔ›Ô ·ÁÔÚ¿Û·ÙÂ ÙÔ
ÚÔ˚fiÓ.
1.Tämä merkki tuotteessa tarkoittaa, että tuote
kuuluu sähkö- ja elektroniikkalaiteromusta
annetun EU-direktiivin 2002/96/EY
soveltamisalaan.
2.Kaikki elektroniset laitteet ovat ongelmajätettä,
joten ne on toimitettava paikalliseen
keräyspisteeseen.
3.Vanhan laitteen asianmukainen hävittäminen
ehkäisee mahdollisia ympäristöön ja
terveyteen kohdistuvia haittavaikutuksia.
4.Lisätietoa vanhan laitteen hävittämisestä saat
ottamalla yhteyden paikallisiin viranomaisiin,
kierrätyskeskukseen tai myymälään, josta ostit
laitteen.
1.Når der er et tegn med et kryds over en
skraldespand, betyder det, at produktet er
omfattet af EU-direktiv 2002/96/EC.
2.Alle elektriske og elektroniske produkter skal
smides ud et andet sted end gennem den
kommunale affaldsordning ved hjælp af specielle
indsamlingsfaciliteter, der er organiseret af staten
1.Si en un producto aparece el símbolo de un contenedor
de basura tachado, significa que éste se acoge a la
Directiva 2002/96/CE.
2.Todos los aparatos eléctricos o electrónicos se deben
desechar de forma distinta del servicio municipal de
recogida de basura, a través de puntos de recogida
designados por el gobierno o las autoridades locales.
3.La correcta recogida y tratamiento de los dispositivos
inservibles contribuye a evitar riesgos potenciales para el
medio ambiente y la salud pública.
4.Para obtener más información sobre cómo deshacerse de
sus aparatos eléctricos y electrónicos viejos, póngase en
contacto con su ayuntamiento, el servicio de recogida de
basuras o el establecimiento donde adquirió el producto.
Vanhojen laitteiden hävittäminen
Entsorgung von Altgeräten
Sådan smider du dit gamle apparat ud
∞fiÚÚÈ„Ë Ù˘ ·ÏÈ¿˜ Û·˜ Û˘Û΢‹˜
Cómo deshacerse de aparatos eléctricos y
electrónicos viejos
eller de lokale myndigheder.
3.Korrekt bortskaffelse af dit gamle apparat er med
til at forhindre mulige skadevirkninger på miljøet
og menneskelig sundhed.
4.Mere detaljerede oplysninger om bortskaffelse af
dit gamle apparat kan fås ved at kontakte dit
lokale kommunekontor, renovationsselskab eller
den butik, hvor du købte produktet.
Finnish
German
Danish
Greek
Spanish
4.Wilt u meer informatie over de verwijdering van
uw oude toestel? Neem dan contact op met uw
gemeente, de afvalophaaldienst of de winkel
waar u het product hebt gekocht.
![](/img.php?id=1601822&img=bg37.png)
Regulatory Information cont.
10
Portuguese
Slovak
Czech
Croatian
Hungarian
Polish
![](/img.php?id=1601822&img=bg38.png)
Regulatory Information cont.
11
Estonian
Latvian
Lithuanian
