LG Electronics USA MS0700A Microwave Oven User Manual 49 401891v03
LG Electronics USA Microwave Oven 49 401891v03
Users Manual
![](/img.php?id=534325&img=bg1.png)
Microwave Oven
Owner’s Manual
700 Watts
Models: JES735
JES739
2
25
Helpful Information
Microwave Terms 25
Care and Cleaning 26
28
If Something Goes Wrong
Before You Call For Service 28
GE Service Numbers 30
Warranty Back Cover
GE Appliances
11
Important Safety Information
Precautions to Avoid Possible Exposure
to Excessive Microwave Energy 2
Special Notes About Microwaving 6
Operating Instructions
Features of Your Microwave 11
The Controls on Your Microwave 12
Time Cooking 15
Automatic Cooking 18
Other Features 22
49-401891v03 3/1/01 8:18 AM Page 1
![](/img.php?id=534325&img=bg2.png)
2
IMPORTANT SAFETY INFORMATION
READ ALL SAFETY
INFORMATION BEFORE USING
FOR YOUR
SAFETY
PRECAUTIONS
TO AVOID
POSSIBLE
EXPOSURE
TO EXCESSIVE
MICROWAVE
ENERGY
For your safety the information in this manual
must be followed to minimize the risk of fire or
explosion or to prevent property damage,
personal injury or loss of life.
Do Not Attempt
to
operate this oven with
the door open since
open-door operation
can result in harmful
exposure to microwave
energy. It is important
not to defeat or tamper
with the safety
interlocks.
Do Not Place
any object
between the oven front
face and the door or
allow soil or cleaner
residue to accumulate
on sealing surfaces.
Do Not Operate
the oven
if it is damaged. It is
particularly important
that the oven door
close properly and that
there is no damage to
the:
1
door (bent),
2
hinges and latches
(broken or loosened),
3
door seals and sealing
surfaces.
The Oven Should Not
be adjusted or repaired
by anyone except
properly qualified
service personnel.
49-401891v03 3/1/01 8:18 AM Page 2
![](/img.php?id=534325&img=bg3.png)
3
Welcome to the GE family.
We’re proud of our quality
products and we believe
in dependable service.
You’ll see it in this easy-to-
use manual and you’ll hear
it in the friendly voices of
our consumer service
department.
Best of all, you’ll
experience these values
each time you use your
microwave. That’s
important, because your
new microwave will be part
of your family for a long
time.
Welcome
Write down the model and
serial numbers here.
They
are on a label inside the
oven.
Model number
Serial number
Date of purchase
Staple your receipt to the
inside back cover of this
manual. You will need it to
obtain service under
warranty.
Help us
help you
Before you call for service,
there are a few things you
can do to help us serve you
better.
Read this manual.
It contains instructions to
help you use and maintain
your microwave properly.
If you received a damaged
oven...
immediately contact
the dealer (or builder) that
sold you the oven.
Save time and money.
Check the section titled
“If Something Goes
Wrong” before calling.
This section helps you
solve common problems
that might occur.
If you do need service,
you can relax knowing help
is only a phone call away.
A list of toll-free customer
service numbers is
included in the back of
this book.
Need Help?
Start Here!…Before using your Microwave
49-401891v03 3/1/01 8:18 AM Page 3
![](/img.php?id=534325&img=bg4.png)
For your safety, the information in this manual must be followed to minimize the risk of fire
or explosion, electric shock, or to prevent property damage, personal injury or loss of life.
WARNING
•Read and follow the
specific “Precautions to
Avoid Possible Exposure
to Excessive Microwave
Energy” on page 2.
•This appliance must be
grounded. Connect only
to properly grounded
outlet. See Grounding
Instructions section on
page 9.
•Do not mount this
appliance over a sink.
•Install or locate this
appliance only in
accordance with the
provided Installation
Instructions.
•Be certain to place the
front surface of the door
three inches or more
back from the countertop
edge to avoid accidental
tipping of the appliance
in normal usage.
•Do not mount the
microwave oven over or
near any portion of a
heating or cooking
appliance.
•Do not store anything
directly on top of the
microwave oven surface
when the oven is in
operation.
•Do not operate any
heating or cooking
appliance beneath
this microwave.
•Use this appliance only
for its intended use as
described in this guide.
Do not use corrosive
chemicals or vapors in
this appliance. This
microwave oven is
specifically designed to
heat, dry or cook food,
and is not intended
for laboratory or
industrial use.
This microwave oven is
not approved or tested
for marine use.
SAFETY
PRECAUTIONS
4
IMPORTANT SAFETY INFORMATION
READ ALL SAFETY
INFORMATION BEFORE USING
49-401891v03 3/1/01 8:19 AM Page 4
![](/img.php?id=534325&img=bg5.png)
•Do not operate this
appliance if it has a
damaged power cord or
plug, if it is not working
properly, or if it has been
damaged or dropped.
If the power cord is
damaged, it must be
replaced by General
Electric Service or an
authorized service agent
using a power cord
available from General
Electric.
•Do not cover or block
any openings on the
appliance.
•Do not store this
appliance outdoors. Do
not use this product near
water—for example, in a
wet basement, near a
swimming pool or near
a sink.
•Keep power cord away
from heated surfaces.
•Do not immerse power
cord or plug in water.
•Do not let power cord
hang over edge of table
or counter.
•To reduce the risk of fire
in the oven cavity:
— Do not overcook food.
Carefully attend
appliance if paper,
plastic or other
combustible materials
are placed inside the
oven while cooking.
— Remove wire twist-ties
and metal handles
from paper or plastic
containers before
placing them in the
oven.
— Do not use the oven
for storage purposes.
Do not leave paper
products, cooking
utensils or food in the
oven when not in use.
— If materials inside oven
should ignite, keep the
oven door closed, turn
the oven off and
disconnect the power
cord, or shut off power
at the fuse or circuit
breaker panel. If the
door is opened, the fire
may spread.
•See door surface cleaning
instructions in the Care
and Cleaning section(s)
of this guide.
•This appliance should
be serviced only by
qualified service
personnel. Contact
nearest authorized
service facility for
examination, repair
or adjustment.
•As with any appliance,
close supervision is
necessary when used
by children.
SAVE THESE INSTRUCTIONS
5
49-401891v03 3/1/01 8:19 AM Page 5
![](/img.php?id=534325&img=bg6.png)
IMPORTANT SAFETY INFORMATION
SPECIAL NOTES ABOUT MICROWAVING
Arcing is the microwave
term for sparks in the oven.
Arcing is caused by:
•Metal or foil touching the
side of the oven.
•Foil not molded to food
(upturned edges act like
antennas).
•Metal, such as twist-ties,
poultry pins, or gold-
rimmed dishes, in
the microwave.
•Recycled paper towels
containing small metal
pieces being used in
the microwave.
If you see arcing, press
the STOP/CLEAR pad
and correct the problem.
ARCING
•Do not pop popcorn in
your microwave oven
unless in a special
microwave popcorn
accessory or unless you
use popcorn labeled for
use in microwave ovens.
•Some products such as
whole eggs and sealed
containers—for example,
closed jars—will explode
and should not be heated
in this microwave oven.
Such use of the microwave
oven could result in injury.
•Do not boil eggs in a
microwave oven. Pressure
will build up inside egg
yolk and will cause it to
burst, possibly resulting
in injury.
•Operating the microwave
with no food inside for
more than a minute or
two may cause damage to
the oven and could start a
fire. It increases the heat
around the magnetron
and can shorten the life
of the oven.
•Foods with unbroken
outer “skin” such as
potatoes, hot dogs,
sausages, tomatoes,
apples, chicken livers
and other giblets, and
egg yolks should be
pierced to allow steam
to escape during cooking.
FOODS
6
49-401891v03 3/1/01 8:19 AM Page 6
![](/img.php?id=534325&img=bg7.png)
7
•Avoid heating baby food
in glass jars, even with the
lid off. Make sure all
infant food is thoroughly
cooked. Stir food to
distribute the heat
evenly. Be careful to
prevent scalding when
warming formula. The
container may feel cooler
than the formula really is.
Always test the formula
before feeding the baby.
•Spontaneous boiling—
Under certain special
circumstances, liquids
may start to boil during
or shortly after removal
from the microwave oven.
To prevent burns from
splashing liquid, we
recommend the following:
before removing the
container from the oven,
allow the container to
stand in the oven for 30
to 40 seconds after the
oven has shut off. Do not
boil liquids in narrow-
necked containers such
as soft drink bottles, wine
flasks and especially
narrow-necked coffee
cups. Even if the
container is opened,
excessive steam can build
up and cause it to burst
or overflow.
•Don’t defrost frozen
beverages in narrow-
necked bottles (especially
carbonated beverages).
Even if the container is
opened, pressure can
build up. This can cause
the container to burst,
possibly resulting in
injury.
•Hot foods and steam
can cause burns. Be
careful when opening
any containers of hot
food, including popcorn
bags, cooking pouches
and boxes. To prevent
possible injury, direct
steam away from hands
and face.
•Do not overcook
potatoes. They could
dehydrate and catch
fire, causing damage to
your oven.
•Cook meat and poultry
thoroughly–meat to at
least an INTERNAL
temperature of 160°F
and poultry to at least an
INTERNAL temperature
of 180°F. Cooking to these
temperatures usually
protects against foodborne
illness.
SAFETY
FACT
SUPERHEATED WATER
Microwaved water and
other liquids do not
always bubble when
they reach the boiling
point. They can actually
get superheated and not
bubble at all.
Superheated liquid will
bubble up out of the cup
when it is moved or
when something like a
spoon or tea bag is put
into it.
To prevent this from
happening and causing
injury, do not heat any
liquid for more than 2
minutes per cup. After
heating, let the cup
stand in the microwave
for 30 seconds before
moving it or putting
anything into it.
49-401891v03 3/1/01 8:19 AM Page 7
![](/img.php?id=534325&img=bg8.png)
IMPORTANT SAFETY INFORMATION
SPECIAL NOTES ABOUT MICROWAVING
Make sure all cookware
used in your microwave
oven is suitable for
microwaving. Most glass
casseroles, cooking dishes,
measuring cups, custard
cups, pottery or china
dinnerware which does not
have metallic trim or glaze
with a metallic sheen can
be used. Some cookware is
labeled “suitable for
microwaving.”
•If you are not sure if a
dish is microwave-safe,
use this test: Place in the
oven both the dish you
are testing and a glass
measuring cup filled with
1 cup of water—set the
measuring cup either in
or next to the dish.
Microwave 1 minute at
high. If the dish heats, it
should not be used for
microwaving.
If the dish remains cool
and only the water in the
cup heats, then the dish
is microwave-safe.
•If you use a meat
thermometer while
cooking, make sure it is
safe for use in microwave
ovens.
•Do not use recycled
paper products. Recycled
paper towels, napkins
and waxed paper can
contain metal flecks
which may cause arcing
or ignite. Paper products
containing nylon or
nylon filaments should
be avoided, as they may
also ignite.
•Some styrofoam trays
(like those that meat is
packaged on) have a thin
strip of metal embedded
in the bottom. When
microwaved, the metal can
burn the floor of the oven
or ignite a paper towel.
•Do not use the microwave
to dry newspapers.
•Not all plastic wrap is
suitable for use in
microwave ovens. Check
the package for proper use.
•Paper towels, waxed
paper and plastic wrap
can be used to cover
dishes in order to retain
moisture and prevent
spattering. Be sure to
vent plastic wrap so steam
can escape.
•Cookware may become
hot because of heat
transferred from the
heated food. Pot holders
may be needed to handle
the cookware.
•“Boilable” cooking
pouches and tightly
closed plastic bags should
be slit, pierced or vented
as directed by package.
If they are not, plastic
could burst during or
immediately after
cooking, possibly resulting
in injury. Also, plastic
storage containers should
be at least partially
uncovered because they
form a tight seal. When
cooking with containers
tightly covered with
plastic wrap, remove
covering carefully and
direct steam away from
hands and face.
MICROWAVE-
SAFE
COOKWARE
8
How to test for a microwave-
safe dish.
49-401891v03 3/1/01 8:19 AM Page 8
![](/img.php?id=534325&img=bg9.png)
GROUNDING INSTRUCTIONS
•Use foil only as directed
in this guide. TV dinners
may be microwaved in
foil trays less than 3/4″
high; remove the top foil
cover and return the tray
to the box. When using
foil in the microwave
oven, keep the foil at
least 1 inch away from
the sides of the oven.
•Plastic cookware—Plastic
cookware designed for
microwave cooking is very
useful, but should be used
carefully. Even microwave-
safe plastic may not be as
tolerant of overcooking
conditions as are glass or
ceramic materials and may
soften or char if subjected
to short periods of
overcooking. In longer
exposures to overcooking,
the food and cookware
could ignite.
Follow these guidelines:
1
Use microwave-safe
plastics only and use
them in strict compliance
with the cookware
manufacturer’s
recommendations.
2
Do not microwave empty
containers.
3
Do not permit children
to use plastic cookware
without complete
supervision.
WARNING
Improper use of the
grounding plug can result in
a risk of electric shock.
This appliance must be
grounded. In the event of
an electrical short circuit,
grounding reduces the risk
of electric shock by
providing an escape wire
for the electric current.
This appliance is equipped
with a power cord having a
grounding wire with a
grounding plug. The plug
must be plugged into an
outlet that is properly
installed and grounded.
Consult a qualified electrician
or service technician if the
grounding instructions are
not completely understood,
or if doubt exists as to whether
the appliance is properly
grounded.
If the outlet is a standard
2-prong wall outlet, it is
your personal responsibility
and obligation to have it
replaced with a properly
grounded 3-prong wall
outlet.
Do not under any
circumstances cut or
remove the third
(ground) prong from
the power cord.
For best operation,
plug this appliance into
its own electrical outlet to
prevent flickering of lights,
blowing of fuse or tripping
of circuit breaker.
GROUNDING
INSTRUCTIONS
Ensure proper ground
exists before use.
PREFERRED
METHOD
9
49-401891v03 3/1/01 8:19 AM Page 9
![](/img.php?id=534325&img=bga.png)
IMPORTANT SAFETY INFORMATION
GROUNDING INSTRUCTIONS
Usage situations where
appliance’s power cord will
be disconnected infrequently.
Because of potential safety
hazards under certain
conditions, we strongly
recommend against the
use of an adapter plug.
However, if you still elect
to use an adapter, where
local codes permit, a
TEMPORARY
CONNECTION may
be made to a properly
grounded two-prong wall
receptacle by the use of a
UL listed adapter which is
available at most local
hardware stores.
The larger slot in the
adapter must be aligned
with the larger slot in the
wall receptacle to provide
proper polarity in the
connection of the power
cord.
CAUTION:
Attaching the
adapter ground terminal
to the wall receptacle cover
screw does not ground the
appliance unless the cover
screw is metal, and not
insulated, and the wall
receptacle is grounded
through the house wiring.
You should have the
circuit checked by a
qualified electrician to
make sure the receptacle
is properly grounded.
When disconnecting the
power cord from the
adapter, always hold the
adapter with one hand. If
this is not done, the adapter
ground terminal is very
likely to break with repeated
use. Should this happen,
DO NOT USE the appliance
until a proper ground has
again been established.
Usage situations where
appliance’s power cord will
be disconnected frequently.
Do not use an adapter plug
in these situations because
frequent disconnection of
the power cord places
undue strain on the adapter
and leads to eventual failure
of the adapter ground
terminal. You should have
the two-prong wall
receptacle replaced with a
three-prong (grounding)
receptacle by a qualified
electrician before using
the appliance.
ADAPTER PLUGS
A short power supply cord is
provided to reduce the risks
resulting from becoming
entangled in or tripping over
a longer cord.
Extension cords may be used
if you are careful in using
them.
If an extension cord is used—
1
The marked electrical
rating of the extension
cord should be at least as
great as the electrical
rating of the appliance;
2
The extension cord must
be a grounding-type 3-wire
cord and it must be
plugged into a 3-slot
outlet;
3
The extension cord
should be arranged so that
it will not drape over the
countertop or tabletop
where it can be pulled on
by children or tripped
over unintentionally.
If you use an extension cord,
the interior light may flicker
and the blower sound may
vary when the microwave
oven is on. Cooking times
may be longer, too.
EXTENSION
CORDS
Ensure proper ground
and firm connection
before use.
TEMPORARY
METHOD
Align large
prongs/slots
(Adapter plugs not
permitted in Canada)
10
49-401891v03 3/1/01 8:19 AM Page 10
![](/img.php?id=534325&img=bgb.png)
Operating Instructions
Features of Your Microwave
(Throughout this manual, features and appearance
may vary from your model.)
1 Door Latches.
2 Window with Metal
Shield.
Screen allows
cooking to be viewed
while keeping
microwaves confined
in the oven.
3 Touch Control Panel
Display.
4 Door Latch Release.
Press latch release to
open door.
5 Removable Turntable.
Turntable and support
must be in place when
using the oven. The
turntable may be
removed for cleaning.
6 Convenience Guide.
NOTE:
Rating plate, oven
vent(s) and oven light are
located on the inside walls
of the microwave oven.
Features
21
65 4
3
11
700 Watts
49-401891v03 3/1/01 8:19 AM Page 11
![](/img.php?id=534325&img=bgc.png)
Time Features
Press Enter
TIME COOK (Press once, twice, or three times) Amount of cooking time.
30 SEC. Starts automatically!
POWER LEVEL Power level 1–9
(automatically set at Hi).
12
Quick Start
The Controls on Your Microwave Oven
(Throughout this manual, features and appearance may vary from your model.)
TIME COOK
POWER
LEVEL
30 SEC
1
You can
microwave by
time or with the
convenience
features.
49-401891v03 3/1/01 8:19 AM Page 12
![](/img.php?id=534325&img=bgd.png)
Press Enter
POPCORN 3.5 oz., 3.0 oz., or 1.75 oz. package
PIZZA 1–3 slices
BEVERAGE 1 cup (8 oz.) or 2 cups (16 oz.) beverage
POTATO 1–4 servings
FOOD PLATE 1 or 2 servings
FRESH VEG. 1–4 cups
AUTO WT. DEF. Food type, food weight
Convenience Features
13
FOOD PLATE
POPCORN BEVERAGE
FRESH VEG.
POTATO
PIZZA
AUTO WT. DEF.
* * *
2
GUIDE ON MICROWAVE
Before you begin, check the guide located
on the inside front of the oven when you
open the door.
GUIDES IN BOOK
•Cooking
49-401891v03 3/1/01 8:19 AM Page 13
![](/img.php?id=534325&img=bge.png)
Operating Instructions
Variable power levels add
flexibility to microwave
cooking. The power levels
on the microwave oven can
be compared to the surface
units on a range. Power
level Hi or full power is
the fastest way to cook
and gives you 100% power.
Each power level gives you
microwave energy a certain
percent of the time. Power
level 7 is microwave energy
70% of the time. Power
level 3 is energy 30% of
the time.
A high setting will cook
faster but food may need
more frequent stirring,
rotating or turning over.
Most cooking will be done
on power level Hi. A lower
setting will cook more
evenly and need less
stirring or rotating of
the food.
Some foods may have
better flavor, texture or
appearance if one of the
lower settings is used. Use
a lower power level when
cooking foods that have a
tendency to boil over, such
as scalloped potatoes.
Rest periods (when the
microwave energy cycles
off) give time for the food
to “equalize” or transfer
heat to the inside of the
food. An example of this is
shown with power level 3—
the defrost cycle. If
microwave energy did not
cycle off, the outside of the
food would cook before
the inside was defrosted.
Here are some examples
of uses for various power
levels:
Power Level Best Uses
Hi
Fish, bacon,
vegetables,
boiling liquids.
Med-High 7
Gentle
cooking of
meat and
poultry;
baking
casseroles
and reheating.
Medium 5
Slow cooking
and tenderizing
such as
stews and less
tender cuts
of meat.
Low 2 or 3
Defrosting
without
cooking;
simmering;
delicate sauces.
Warm 1
Keeping food
warm without
overcooking;
softening
butter.
How to Change the
Power Level
The power level may
be entered or changed
immediately after
entering the feature
time for TIME COOK.
1 Press TIME COOK.
2 Enter cooking time.
3 Press POWER LEVEL.
4 Select desired power
level 1–9.
5 Press START.
Changing Power
Levels
1 32
56
789
0
4
POWER
LEVEL
START
14
49-401891v03 3/1/01 8:19 AM Page 14
![](/img.php?id=534325&img=bgf.png)
Time Features
Time Cook I
Allows you to microwave
for any time up to 99
minutes and 99 seconds.
Power level Hi is
automatically set, but you
may change it for more
flexibility.
You may open the door
during Time Cook to
check the food. Close the
door and press START to
resume cooking.
Time Cook II & III
Lets you change power
levels automatically during
cooking. Here’s how to
do it:
1
Press TIME COOK.
2
Enter the first cook time.
3
Change the power level
if you don’t want full
power. (Press POWER
LEVEL. Select a desired
power level 1–9.)
4
Press TIME COOK
again.
5
Enter the second cook
time.
6
Change the power level
if you don’t want full
power. (Press POWER
LEVEL. Select a power
level 1–9.)
7
Press START, or, to set
a third cooking stage,
repeat steps 4–6 and
press START.
Time Cook I will count
down first, followed by
Time Cook II, then Time
Cook III. If an Auto Weight
Defrost stage was set, it will
count down before the
Time Cook stages.
Time Cook allows you
to program up to three
different cooking stages.
In addition, you can
also set one Auto
Weight Defrost stage
for a total of four stages.
See the Auto Weight
Defrost section for
instructions on how
to set Auto Weight
Defrost.
1 Press TIME COOK.
2 Enter cooking time.
3 Change power level
if you don’t want full
power. (Press POWER
LEVEL. Select a desired
power level 1–9.)
4 Press START.
Time Cook
1 32
56
789
0
4
TIME COOK
START
15
49-401891v03 3/1/01 8:19 AM Page 15
![](/img.php?id=534325&img=bg10.png)
16
Operating Instructions
Cooking Guide for Time Cook
NOTE: Use power level Hi unless otherwise noted.
Vegetable Amount Time Comments
Asparagus
(fresh spears) 1 lb. 7 to 10 min., In 1
1
⁄
2
-qt. casserole, place 1/4 cup water.
Med-High (7)
(frozen spears) 10-oz. package 5 to 8 min. In 1-qt. casserole.
Beans
(fresh green) 1 lb. cut in half 12 to 17 min. In 1
1
⁄
2
-qt. casserole, place 1/2 cup water.
(frozen green) 10-oz. package 6 to 9 min. In 1-qt. casserole, place 2 tablespoons
water.
(frozen lima) 10-oz. package 6 to 9 min. In 1-qt. casserole, place 1/4 cup water.
Beets
(fresh, whole) 1 bunch 18 to 25 min. In 2-qt. casserole, place 1/2 cup water.
Broccoli
(fresh cut) 1 bunch 7 to 10 min. In 2-qt. casserole, place 1/2 cup water.
(1
1
⁄
4
to 1
1
⁄
2
lbs.)
(fresh spears) 1 bunch 9 to 13 min. In 2-qt. casserole, place 1/4 cup water.
(1
1
⁄
4
to 1
1
⁄
2
lbs.)
(frozen, 10-oz. package 5 to 8 min. In 1-qt. casserole.
chopped)
(frozen spears) 10-oz. package 5 to 8 min. In 1-qt. casserole, place 3 tablespoons
water.
Cabbage
(fresh) 1 medium head 8 to 13 min. In 1
1
⁄
2
- or 2-qt. casserole, place 1/4 cup
(about 2 lbs.) water.
(wedges) 7 to 14 min. In 2- or 3-qt. casserole, place 1/4 cup
water.
Carrots
(fresh, sliced) 1 lb. 6 to 9 min. In 1
1
⁄
2
-qt. casserole, place 1/4 cup water.
(frozen) 10-oz. package 5 to 8 min. In 1-qt. casserole, place 2 tablespoons
water.
Cauliflower
(flowerets) 1 medium head 9 to 14 min. In 2-qt. casserole, place 1/2 cup water.
(fresh, whole) 1 medium head 9 to 17 min. In 2-qt. casserole, place 1/2 cup water.
(frozen) 10-oz. package 5 to 8 min. In 1-qt. casserole, place 2 tablespoons
water.
49-401891v03 3/1/01 8:19 AM Page 16
![](/img.php?id=534325&img=bg11.png)
17
Vegetable Amount Time Comments
Corn
(frozen kernel) 10-oz. package 4 to 8 min. In 1-qt. casserole, place 2 tablespoons
water.
Corn on the cob
(fresh) 1 to 5 ears 3 to 5 min. In 2-qt. glass baking dish, place corn.
per ear If corn is in husk, use no water; if
corn has been husked, add 1/4 cup
water. Rearrange after half of time.
(frozen) 1 ear 5 to 7 min. Place in 2-qt. glass baking dish.
2 to 6 ears 2 to 4 min. Cover with vented plastic wrap.
per ear Rearrange after half of time.
Mixed
vegetables
(frozen) 10-oz. package 4 to 8 min. In 1-qt. casserole, place 3 tablespoons
water.
Peas
(fresh, shelled) 2 lbs. unshelled 9
to 12 min.
In 1-qt. casserole, place 1/4 cup water.
(frozen) 10-oz. package 4 to 8 min. In 1-qt. casserole, place 2 tablespoons
water.
Potatoes
(fresh, cubed, 4 potatoes
11 to 14 min.
Peel and cut into 1 inch cubes. Place in
white) (6 to 8 oz. each) 2-qt. casserole with 1/2 cup water. Stir
after half of time.
(fresh, whole, 1 (6 to 8 oz.) 2 to 5 min. Pierce with cooking fork. Place in
sweet or white) center of the oven. Let stand 5 minutes.
Spinach
(fresh) 10 to 16 oz. 5 to 8 min. In 2-qt. casserole, place washed spinach.
(frozen, 10-oz. package 5 to 8 min. In 1-qt. casserole, place 3 tablespoons
chopped water.
and leaf)
Squash
(fresh, summer 1 lb. sliced 4 to 7 min. In 11⁄2-qt. casserole, place 1/4 cup water.
and yellow)
(winter, acorn 1 to 2 squash 7 to 11 min. Cut in half and remove fibrous
or butternut)
(about 1 lb. each)
membranes. In 2-qt. glass baking dish,
place squash cut-side-down. Turn
cut-side-up after 4 minutes.
49-401891v03 3/1/01 8:19 AM Page 17
![](/img.php?id=534325&img=bg12.png)
Operating Instructions
Time Features
Convenience Features
The 30 Second feature is a
quick way to set 30 seconds
of cooking time. The oven
starts automatically. Each
touch will add 30 seconds
up to 3 minutes; after 3
minutes every touch will
add 1 minute. This feature
does not work with other
time cook functions.
30 Seconds
30 SEC
How to Use the
Popcorn Feature
1
Follow package
instructions. Place
the package of popcorn
in the center of the
microwave.
2
Press POPCORN once
for a 3.5 ounce package
of popcorn, twice for a
3.0 ounce package, or
three times for a 1.75
ounce package. The
oven starts automatically.
Popcorn
Use only with prepackaged
microwave popcorn weighing
1.75 to 3.5 ounces.
The Pizza feature is for
reheating 1 to 3 slices of
pizza.
Press PIZZA once for one
slice of pizza, twice for two
slices, or three times for
three slices. The oven starts
automatically.
Pizza
PIZZA
POPCORN
18
49-401891v03 3/1/01 8:19 AM Page 18
![](/img.php?id=534325&img=bg13.png)
The Beverage feature works
best for heating a beverage
that is at room temperature.
Press BEVERAGE once for
1 cup (8 oz.), or twice for
2 cups (16 oz.). The oven
starts automatically.
Beverages heated with the
Beverage feature may be
very hot. Remove the
container with care.
Beverage
The Potato feature cooks up
to four 8–10 ounce potatoes.
Press POTATO. The
serving size is automatically
set at 1, but can be changed
by pressing POTATO a
second time for 2 potatoes,
a third time for 3 potatoes,
or a fourth time for 4
potatoes. The oven starts
automatically.
Potato
BEVERAGE
POTATO
The Food Plate feature
reheats a plate of
previously cooked food.
Press FOOD PLATE once
to reheat one 8 ounce
serving, or twice to reheat
two 8 ounce servings. The
oven starts automatically.
Be sure to cover the plate
with plastic wrap.
Food Plate
FOOD PLATE
19
49-401891v03 3/1/01 8:19 AM Page 19
![](/img.php?id=534325&img=bg14.png)
20
Operating Instructions
Convenience Features
Use the Fresh Vegetable
feature to cook up to
4 cups of fresh vegetables.
Press FRESH VEG. once
to cook 1 cup of vegetables,
twice to cook 2 cups,
three times to cook 3 cups,
or four times to cook
4 cups. The oven starts
automatically.
Fresh Vegetable
FRESH VEG.
49-401891v03 3/1/01 8:19 AM Page 20
![](/img.php?id=534325&img=bg15.png)
21
Auto Weight Defrost
Auto Weight Defrost
automatically sets the
defrosting times and power
levels to give even
defrosting results for
meats, poultry and fish.
There is a handy guide
located on the inside front
of the oven.
•Remove meat from
package and place on
microwave-safe dish.
•Twice during defrost,
the oven signals. At each
signal, turn the food
over. Remove defrosted
meat or shield warm
areas with small pieces
of foil.
•After defrosting, most
meats need to stand
5 minutes to complete
defrosting. This
5 minute stand time
is set automatically.
Conversion Guide
If the weight of food is
stated in pounds and
ounces, the ounces must
be converted to tenths
(.1) of a pound.
Weight of Enter Food
Food in Weight
Ounces (tenths of
a pound)
1–2 .1
3.2
4–5 .3
6–7 .4
8.5
9–10 .6
11 .7
12–13 .8
14–15 .9
Auto Weight Defrost Guide
Auto Weight Defrost will
defrost 0.1 lbs to 6.0 lbs
(0.1 kg to 4.0 kg) of meat,
poultry or fish.
1 Meat:
Beef—ground beef,
steaks, stew meat,
roasts
Lamb—chops, roasts
Pork—chops, hotdogs,
ribs, roasts, sausages
Veal—cutlets
2 Poultry:
Poultry—whole (under
4 lbs), boneless cut-up
breasts
Cornish hens—whole
Turkey—breast (under
6 lbs)
3 Fish:
Fish—fillets, steaks,
whole
Shellfish—crabmeat,
lobster tails, shrimp,
scallops
1 Press AUTO WT. DEF.
1–3 times to select the
desired defrosting
category (see Auto
Weight Defrost Guide
at right).
2 Using the Conversion
Guide at right, enter
food weight. For
example, press pads
1 and 2 for 1.2 pounds
(1 pound, 3 ounces).
3 Press START.
Guide
1 32
56
789
0
4
AUTO WT. DEF.
* * *
START
49-401891v03 3/1/01 8:19 AM Page 21
![](/img.php?id=534325&img=bg16.png)
Operating Instructions
Other Features Your Model May Have
Press CLOCK to enter the
time of day.
1
Press CLOCK.
2
Enter time of day.
3
Press CLOCK.
Clock
1 32
56
789
0
4
CLOCK
22
The Timer operates as a
minute timer.
1
Press TIMER.
2
Enter amount of time
you want to count down.
3
Press START. When the
time is up, the timer will
signal.
The Timer feature
operates without
microwave energy.
Timer
1 32
56
789
0
4
TIMER
49-401891v03 3/1/01 8:19 AM Page 22
![](/img.php?id=534325&img=bg17.png)
23
Press once to pause
cooking (all settings will
be saved).
Press START to continue
cooking.
Press twice to stop and
erase your cooking
settings.
Stop/Clear
STOP
CLEAR
You may lock the control
panel to prevent the
microwave from being
accidentally started or used
by children.
To lock or unlock the
controls, press and hold 0
for about three seconds.
When the control panel
is locked, LOCK or L
appears in the display.
Child Lock-Out
0
49-401891v03 3/1/01 8:19 AM Page 23
![](/img.php?id=534325&img=bg18.png)
24
Notes
49-401891v03 3/1/01 8:19 AM Page 24
![](/img.php?id=534325&img=bg19.png)
25
Arcing
Arcing is the microwave term for sparks in the oven. Arcing is
caused by:
•metal or foil touching the side of the oven.
•foil that is not molded to food (upturned edges act like
antennas).
•metal such as twist-ties, poultry pins, gold-rimmed dishes.
•recycled paper towels containing small metal pieces.
Covering
Covers hold in moisture, allow for more even heating and reduce
cooking time. Venting plastic wrap or covering with wax paper
allows excess steam to escape.
Shielding
In a regular oven, you shield chicken breasts or baked foods to
prevent over-browning. When microwaving, you use small strips of
foil to shield thin parts, such as the tips of wings and legs on poultry,
which would cook before larger parts.
Standing Time
When you cook with regular ovens, foods such as roasts or cakes are
allowed to stand to finish cooking or to set. Standing time is
especially important in microwave cooking. Note that a microwaved
cake is not placed on a cooling rack.
Venting
After covering a dish with plastic wrap, you vent the plastic wrap by
turning back one corner so excess steam can escape.
Term Definition
Helpful Information
Microwave Terms
49-401891v03 3/1/01 8:19 AM Page 25
![](/img.php?id=534325&img=bg1a.png)
26
Open the oven door a few
minutes after cooking to
air out the inside. An
occasional thorough
wiping with a solution of
baking soda and water
keeps the inside fresh.
UNPLUG THE CORD BEFORE
CLEANING ANY PART OF
THIS OVEN.
Helpful Hints
Walls, Floor, Inside Window,
Metal and Plastic Parts on
the Door
Some spatters can be
removed with a paper
towel, others may require
a damp cloth. Remove
greasy spatters with a sudsy
cloth, then rinse with a
damp cloth. Do not use
abrasive cleaners or sharp
utensils on oven walls.
To clean the surface of the
door and the surface of the
oven that come together
upon closing, use only
mild, nonabrasive soaps or
detergents using a sponge
or soft cloth. Rinse with a
damp cloth and dry.
Never use a commercial
oven cleaner on any part
of your microwave.
Removable Turntable and
Turntable Support
To prevent breakage, do
not place the turntable
into water just after
cooking. Wash it carefully
in warm, sudsy water or in
the dishwasher. The
turntable and support
can be broken if dropped.
Remember, do not operate
the oven without the
turntable and support
in place.
How to Clean
the Inside
Helpful Information
Care and Cleaning
49-401891v03 3/1/01 8:19 AM Page 26
![](/img.php?id=534325&img=bg1b.png)
27
Case
Clean the outside of the
microwave with a sudsy
cloth. Rinse and then dry.
Wipe the window clean
with a damp cloth.
Control Panel and Door
Wipe with a damp cloth.
Dry thoroughly. Do not
use cleaning sprays, large
amounts of soap and
water, abrasives or sharp
objects on the panel—they
can damage it. Some paper
towels can also scratch the
control panel.
Door Surface
It’s important to keep
the area clean where the
door seals against the
microwave. Use only mild,
non-abrasive detergents
applied with a clean sponge
or soft cloth. Rinse well.
Power Cord
If the cord becomes soiled,
unplug and wash with a
damp cloth. For stubborn
spots, sudsy water may be
used, but be certain to
rinse with a damp cloth
and dry thoroughly before
plugging cord into outlet.
Do not use cleaners
containing ammonia or
alcohol on the
microwave oven.
Ammonia or alcohol can
damage the appearance
of the microwave.
How to Clean
the Outside
49-401891v03 3/1/01 8:19 AM Page 27
![](/img.php?id=534325&img=bg1c.png)
28
Oven will not start
Control panel
lighted, yet oven
will not start
Problem Possible Cause What to Do
A fuse in your home •Replace fuse or reset circuit breaker.
may be blown or the
circuit breaker tripped.
Power surge. •Unplug the microwave oven, then plug
it back in.
Plug not fully inserted •Make sure the 3-prong plug on the
into wall outlet. oven is fully inserted into wall outlet.
Door not •Open the door and close securely.
securely closed.
START not pressed •Press START.
after entering cooking
selection.
Another selection •Press STOP/CLEAR twice.
entered already in oven
and STOP/CLEAR not
pressed to cancel it.
Cooking time not •Make sure you have entered cooking
entered after pressing time after pressing TIME COOK.
TIME COOK.
STOP/CLEAR was •Reset cooking program and press
pressed accidentally. START.
Defrosting category or •Make sure you have entered a
food weight not defrosting category and food weight
entered after pressing after pressing AUTO WT. DEF.
AUTO WT. DEF.
If Something Goes Wrong
Before You Call For Service
49-401891v03 3/1/01 8:19 AM Page 28
![](/img.php?id=534325&img=bg1d.png)
•Steam or vapor escaping
from around the door.
•Light reflection around
door or outer case.
•Dimming oven light and
change in the blower
sound at power levels
other than high.
•Dull thumping sound
while oven is operating.
•TV-radio interference
might be noticed while
using the microwave.
Similar to the interference
caused by other small
appliances, it does not
indicate a problem with
the microwave. Plug the
microwave into a different
electrical circuit, move the
radio or TV as far away
from the microwave as
possible, or check the
position and signal of the
TV/radio antenna.
Things That
Are Normal
29
49-401891v03 3/1/01 8:19 AM Page 29
![](/img.php?id=534325&img=bg1e.png)
30
GE Service Numbers
We’ll Be There!
www.GEAppliances.com
Have a question or need
assistance with your
appliance? Try the GE
Appliances Website 24
hours a day, any day of the
year!
For greater convenience and
faster service, you can now
download Owner’s Manuals,
order parts, catalogs, or even
schedule service on-line. You
can also “Ask Our Team of
Experts™” your questions,
and so much more...
GE Appliances
Website
www.GEAppliances.com
800-GE-CARES
(800-432-2737)
Expert GE repair service is
only one step away from
your door. Get on-line and
schedule your service at your
convenience 24 hours any
day of the year! Or call
800-GE-CARES (800-432-
2737) during normal
business hours.
Schedule Service
www.GEAppliances.com
800-TDD-GEAC
(800-833-4322)
GE supports the Universal
Design concept—products,
services and environments
that can be used by people
of all ages, sizes and
capabilities. We recognize
the need to design for a wide
range of physical and mental
abilities and impairments.
For details of GE’s Universal
Design applications,
including kitchen design
ideas for people with
disabilities, check out
our Website today. For
the hearing impaired,
please call 800-TDD-GEAC
(800-833-4322).
Real Life
Design Studio
www.GEAppliances.com
800-626-2224
Purchase a GE extended
warranty and learn about
special discounts that are
available while your warranty
is still in effect. You can
purchase it on-line anytime,
or call 800-626-2224 during
normal business hours. GE
Consumer Home Services
will still be there after your
warranty expires.
Extended Warranties
49-401891v03 3/1/01 8:19 AM Page 30
![](/img.php?id=534325&img=bg1f.png)
31
www.GEAppliances.com
800-626-2002
Individuals qualified
to service their own
appliances can have
parts or accessories sent
directly to their home.
(VISA, MasterCard and
Discover cards are
accepted.)
Order on-line today,
24 hours every day or
by phone at
800-626-2002
during normal business
hours.
Instructions contained
in this manual cover
procedures to be
performed by any user.
Other servicing generally
should be referred to
qualified service
personnel. Caution
must be exercised, since
improper servicing may
cause unsafe operation.
Parts and
Accessories
If for some reason you are
not happy with the service
you receive, here are steps
to follow for further help.
First,
contact the people
who serviced your
appliance. Explain why
you are not pleased.
Next,
if you are still not
pleased, write all the
details—including
your phone number—to:
Customer Relations
GE Appliances
Louisville, KY 40225
Contact Us
Register Your
Appliance
www.GEAppliances.com
www.GEAppliances.com
Register your new
appliance on-line–
at your convenience!
Timely product
registration will allow for
enhanced communication
and prompt service under
the terms of your warranty,
should the need arise.
You may also mail
in the pre-printed
registration card included
in the packing material.
49-401891v03 3/1/01 8:19 AM Page 31
![](/img.php?id=534325&img=bg20.png)
LIMITED ONE-YEAR WARRANTY
For one year from date of original
purchase, we will provide, free of charge,
parts and service labor to repair or replace
any part of the microwave oven that fails
because of a manufacturing defect.
LIMITED ADDITIONAL
FOUR-YEAR WARRANTY
For the second through the fifth year
from the date of original purchase, we
will provide, free of charge, a replacement
magnetron tube if the magnetron tube fails
because of a manufacturing defect. You
pay for any service labor charges.
For each of the above warranties:
To avoid any trip charges, you must take
the microwave oven to a General Electric
Factory Service Center or a General Electric
Customer Care® servicer and pick it up
following service. In-home service is also
available, but you must pay for the service
technician’s travel costs to your home.
************************************
This warranty is extended to the original
purchaser and any succeeding owner for
products purchased for ordinary home use
in the 48 mainland states, Alaska, Hawaii
and Washington, D.C.
All warranty service will be provided by our
Factory Service Centers or by our
authorized Customer Care® servicers
during normal working hours.
Should your appliance need service,
during warranty period or beyond, call
800-GE-CARES (800-432-2737).
MICROWAVE OVEN
WARRANTY
What Is Covered
What Is Not Covered
Staple sales slip or cancelled check here. Proof of original
purchase date is needed to obtain service under warranty.
•Service trips to your home to teach you
how to use the product.
•
Improper installation.
If you have an installation problem, contact
your dealer or installer. You are responsible
for providing adequate electrical,
exhausting and other connecting facilities.
•Replacement of house fuses or resetting
of circuit breakers.
•Failure of the product if it is misused, or
used for other than the intended purpose
or used commercially.
•Damage to product caused by accident,
fire, floods or acts of God.
•Incidental or consequential damage
caused by defects with this appliance.
Some states do not allow the exclusion or limitation of incidental or consequential damages,
so the above limitation or exclusion may not apply to you. This warranty gives you specific
legal rights, and you may also have other rights which vary from state to state. To know what
your legal rights are in your state, consult your local or state consumer affairs office or your
state’s Attorney General.
Warrantor: General Electric Company If further help is needed concerning this warranty, write:
Manager—Consumer Affairs, GE Appliances, Louisville, KY 4022
5
Warrantor is not responsible for consequential damages.
Part No. 164D3370P175
Pub. No. 49-40189-1 JES735
JES739
Printed in China
02-01 JR
3828W5A1967
49-401891v03 3/1/01 8:19 AM Page 32
