4-Group RF Remote Control
Model CS-YJ-4GC-WH • For Serena® Powered Window Shades • Setup Guide—Please Read Before Operating
Lutron Electronics Co., Inc.
7200 Suter Road
Coopersburg, PA 18036-1299, U.S.A.
08/2013
P/N 045411 Rev. A
Lutron, O, and Serena are registered trademarks of Lutron Electronics Co., Inc.
Device Description Battery Replacement Troubleshooting Limited Warranty
For Assistance:
The Serena® 4-Group RF handheld remote control provides remote
shade operation from the palm of your hand. The radio frequency
enabled control transmits signals to compatible Lutron® shades and
shading systems. To access advanced features, please refer to the
installation and operation instructions for the Lutron device(s) under
control.
The Serena® 4-Group RF handheld remote control uses 2 AAA
alkaline batteries which are pre-installed (see diagram).
DO NOT use NiCad or rechargeable batteries.
To replace batteries:
A. Remove the battery cover.
B. Replace with 2 size AAA alkaline batteries as shown.
C. Replace the battery cover.
Open
Close
Shade
1 2
3 4
All
Open Button
Tap once: shade
opens to its upper limit
Close Button
Tap once: shade
closes to its lower limit
Shade Group
Buttons
Tap once to select
shades assigned to
the corresponding
group (number)
All Shade
Groups Button
Tap once to select
all shades
Raise & Lower
Buttons
Tap to move the
shade; tap again
to stop it
Preset Button
Tap once to move
the shade to a
preset position
Press on arrow,
slide and lift off
battery cover.
Install 2 AAA
Alkaline
batteries
with terminals
as shown.
The Serena® 4-Group RF remote control
is safe for use around baths and spas.
