MGA Entertainment 367314 Two Way Radio with FRS User Manual 338659 P4F FM Mic IM
MGA Entertainment (HK) Ltd. Two Way Radio with FRS 338659 P4F FM Mic IM
User Manual
![](/img.php?id=875087&img=bg1.png)
Ages: 5+
ADULT BATTERY INSTALLATION REQUIRED
Item no. 367314
INTRODUCTION
CONTENTS
1
Welcome to the Bratz™ Chat Mobile – the hottest accessory for your mobile lifestyle. Every
on-the-go Bratz™ girl needs to keep in contact with her BFFs, and this is the perfect high-tech
tool. Chat at distances up to 2 miles, carry a picture of your friends in the photo frame, and more!
• 2 Bratz™ Chat Mobiles
a. Photo Frame
b. Power button
c. Talk button
d. Call button
e. Volume + button
f. Volume – button
g. Earpiece Jack
• 6 AAA Alkaline Batteries
Illustrations may vary from actual contents.
BEFORE YOU BEGIN
Before you can chat with your your Bratz™ Chat Mobile,
have an adult follow these steps to install the batteries:
1. Using a Phillips screwdriver (not included),
remove the screw from the battery
compartment cover from the back of
the Bratz™ Chat Mobile (Fig. 1).
2. Place your thumb in the recess on
the back of the unit and, while
pressing down firmly, slide open
the battery compartment door
on the back of each unit.
3. Install three (3) AAA alkaline batteries
(included) in each Bratz™ Chat
Mobile, making sure the (+) and (-)
ends face the proper direction as
indicated inside the battery
compartment.
4. Replace the compartment cover,
slide it closed, and tighten the screw.
www.bratz.com
TM & © MGA Entertainment, Inc.
BRATZ™, BRATZ PETZ™, LIL’ BRATZ™,
BRATZ BABYZ™, BRATZ KIDZ™ and all
related logos, names, characters, distinctive
likenesses and slogans, as well as the
packaging and images appearing thereon,
are the exclusive property of MGA.
16300 Roscoe Blvd.
Van Nuys, CA 91406 USA
(800) 222-4685
Printed in China.
1007-0-E
The preferred method of contact for
Customer Service is through our e-mail
contact form at www.mgae.com
Please keep this manual as it contains important information.
4
b.
a.
c.
d.
Fig. 1
e. f. g.
AAA/1.5V/LR03
AAA/1.5V/LR03
AAA/1.5V/LR03
![](/img.php?id=875087&img=bg2.png)
2
QUICK START
Turning On/Off the Bratz™ Chat Mobile
1. Hold down the Power button for two seconds to turn the power on.
2. When you are done using your Bratz™ Chat Mobile, hold down the Power button again for two
seconds to turn the power off.
NOTE: Remember to always shut your Bratz™ Chat Mobile off when you are not using it to avoid
draining the batteries.
Using the Bratz™ Chat Mobile
1. When powered on, the Bratz™ Chat Mobile is always in Listening Mode, allowing you to hear
what other nearby Bratz™ Chat Mobile users are saying!
2. To change the volume, press the Volume + and – buttons.
3. When you want to talk, just hold down the Talk button and speak. Release the Talk button to
listen.
4. Press the Call button to make other Bratz™ Chat Mobiles ring!
Personalize Your Bratz™ Chat Mobile
• Lift the cover of the photo frame and slide a picture of
your BFF inside! (Fig. 2)
• Want to go hands-free? Insert any standard
2.5mm cell phone earpiece (not included)
into the Earpiece Jack (Fig. 3). You will now
hear the audio from the Bratz™ Chat Mobile
in your earpiece!
NOTE: To talk while using an earpiece, hold
the Talk button down as you normally would.
3
NOTE: This equipment has been tested and found to comply with the limits for Class B digital
device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
• Use alkaline batteries for best performance and longer life.
• Use only the type battery recommended for the unit.
• Batteries should be replaced only by an adult.
• Insert batteries with the correct polarity ( + and – ).
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries.
• Do not short-circuit batteries.
• When not used for an extended time, remove batteries to prevent possible leakage and damage
to the unit.
• Do not mix rechargeable and non-rechargeable batteries.
• Rechargeable batteries are to be removed from the toy before charging.
• Rechargeable batteries are to be recharged only under adult supervision.
• Do not recharge non-rechargeable batteries.
• Exhausted batteries are to be removed from the toy.
• Do not dispose of batteries in fire as they may leak or explode.
NOTE: The voltage of a fully-charged, rechargeable battery is often lower than that of a fresh
alkaline battery. Therefore, it is recommended that alkaline batteries be used instead of
rechargeable batteries for best performance and for longest play time.
DISPOSAL OF BATTERIES: Do not treat old batteries as household waste. Take them to a
designated recycling facility.
FCC STATEMENT
SAFE BATTERY USAGE
‘Let’s care for the environment!’
The wheelie bin symbol indicates that the product must not be disposed of with other household
waste. Please use designated collection points or recycling facilities when disposing of the item.
Do not treat old batteries as household waste. Take them to a designated recycling facility.
Fig. 2
Fig. 3
![](/img.php?id=875087&img=bg3.png)
Supplementary Instruction Manual
FCC WARNING STATEMENT
Warning: Changes or modifications to this equipment not expressly approved by the
party responsible for compliance could void the user's authority to operate the equipment.
Warning: Any adjustment to this equipment is recommended to be performed by or
under the immediate supervision and responsibility of a person certified as technically
qualified to perform transmitter maintenance and repair duties in the private land mobile
services and fixed services by an organization or committee representative of users of
those services.
Warning: Replacement of any transmitter component (crystal, semiconductor, etc.) for
this equipment could result in violation of FCC rules.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Cell phone earpiece must be used with this equipment to ensure compliance with the
Class B FCC limits.
SAFETY INFORMATION
Your wireless hand-held portable transceiver contains a low power transmitter. When the
Push-to-Talk (PTT) button is pushed it sends out radio frequency (RF) signals. The
device is authorized to operate at a duty factor not to exceed 50%. In August 1996, the
Federal Communications Commissions (FCC) adopted RF exposure guidelines with
safety levels for hand-held wireless devices.
CAUTION: To maintain compliance with the FCC's RF exposure guidelines hold the
transmitter and antenna at least 1 inch (2.5 centimeters) from your face and speak in a
normal voice, with the antenna pointed up and away from the face. If you wear the
handset on your body while using the headset accessory, use only the supplied belt clip
for this product and when transmitting, take it out of the belt to ensure that the antenna is
at least 1 inch (2.5 centimeters) from your body.
Use only the supplied antenna. Unauthorized antennas, modifications, or attachments
could damage the transmitter and may violate FCC regulations.
