Microsoft RM-749 GSM/WCDMA cellular telephone with BT, WLAN, FM Tx and RF ID User Manual Manual 2

Microsoft Mobile Oy GSM/WCDMA cellular telephone with BT, WLAN, FM Tx and RF ID Manual 2

Contents

Manual 2

Product and safety information
9226267
Issue 1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Safety
Read these simple guidelines. Not
following them may be dangerous or
illegal. Read the complete user guide for
further information.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when
mobile phone use is not
allowed or when it may cause
interference or danger, for
example, in aircraft, near
medical equipment, fuel,
chemicals, or blasting areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always
keep your hands free to
operate the vehicle while
driving. Your first
consideration while driving
should be road safety.
INTERFERENCE
All wireless devices may be
susceptible to interference,
which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may
install or repair this product.
BATTERIES, CHARGERS AND OTHER
ACCESSORIES
Use only batteries, chargers,
and other accessories
approved by Nokia for use
with this device. Do not
connect incompatible
products.
KEEP YOUR DEVICE DRY
Your device is not water-
resistant. Keep it dry.
2Safety
2 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
GLASS PARTS
The front cover of the device
is made of glass. This glass
can break if the device is
dropped on a hard surface or
receives a substantial impact.
If the glass breaks, do not
touch the glass parts of the
device or attempt to remove
the broken glass from the
device. Stop using the device
until the glass is replaced by
qualified service personnel.
PROTECT YOUR HEARING
Listen to a headset at a
moderate level, and do not
hold the device near your ear
when the loudspeaker is in
use.
Safety 3
www.nokia.com/support 3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Charge the battery
Your battery has been partially charged
at the factory, but you may need to
recharge it before you can switch on
your device for the first time.
If the device indicates a low charge, do
the following:
1
2
You do not need to charge the battery
for a specific length of time, and you can
use the device while it is charging.
If the battery is completely discharged,
it may take several minutes before the
charging indicator appears on the
display or before any calls can be made.
If the battery has not been used for a
long time, to begin charging, you may
need to connect the charger, then
disconnect and reconnect it.
Tip: You can also use a compatible USB
data cable to charge the battery.
Charge the battery over USB
Battery low, but you don't have a
charger with you? You can use a
compatible USB cable to connect to a
compatible device, such as a computer.
To avoid breaking the charger
connector, be careful when connecting
or disconnecting the charger cable.
4 Charge the battery
4 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
You can use the device while it's
charging. For example, if connected to a
computer, you can synchronise your
device.
Charging over USB can take longer to
start and you may not be able to use the
device immediately. Charging may not
work if you connect through a non-
powered USB hub. Your device charges
more quickly when connected to a wall
outlet.
Product and safety information
Feature specific instructions
Your device contains a complete in-device user guide,
which you can refer to for additional information about
your device. To read the in-device user guide, select
Menu > Applications > User guide.
Using some of the services or downloading content may
cause transfer of large amounts of data, which may result
in data traffic costs.
Some home screen widgets may connect to the internet
automatically. To prevent this, select Options > Widgets
to offline mode.
The social networking services are third-party services and
not provided by Nokia. Check the privacy settings of the
social networking service you are using as you may share
information with a large group of people. The terms of use
of the social networking service apply to sharing
information on that service. Familiarise yourself with the
terms of use and the privacy practices of that service.
This device is able to communicate with Microsoft
Exchange ActiveSync enabled servers. The provision of this
device to you does not grant you, and you do not receive,
any rights under any Microsoft intellectual property with
respect to any server software, or server device, that is
accessed using this device or with respect to use of
Microsoft Exchange ActiveSync apart from this device.
Important: To prevent damage to the SIM card,
always remove the battery before you insert or remove the
card.
Important: Do not use a mini-UICC SIM card, also
known as a micro-SIM card, a micro-SIM card with an
adapter, or a SIM card that has a mini-UICC cutout (see
figure) in this device. A micro SIM card is smaller than the
standard SIM card. This device does not support the use of
micro-SIM cards and use of incompatible SIM cards may
Product and safety information 5
www.nokia.com/support 5
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
damage the card or the device, and may corrupt data
stored on the card.
Use only compatible memory cards approved by Nokia for
use with this device. Incompatible cards may damage the
card and the device and corrupt data stored on the card.
Important: Do not remove the memory card when
an application is using it. Doing so may damage the
memory card and the device, and corrupt data stored on
the card.
Do not connect products that create an output signal as
this may cause damage to the device. Do not connect any
voltage source to the Nokia AV connector. If you connect
an external device or headset, other than those approved
by Nokia for use with this device, to the Nokia AV
connector, pay special attention to volume levels.
Note: Using WLAN may be restricted in some
countries. For example, in France, you are only allowed to
use WLAN indoors. For more information, contact your
local authorities.
Note: FM transmitter can not be used in Greece. For
more information, contact your local operator and go to
www.nokia.com/fmtransmitter.
You can use USB charging when a wall outlet is not
available. Data can be transferred while charging the
device. The efficiency of USB charging power varies
significantly, and it may take a long time for charging to
start and the device to start functioning.
Network services and costs
Your device is approved for use on the GSM 850, 900, 1800,
1900 MHz networks, and WCDMA 850, 900, 1700, 1900,
2100 MHz networks. To use the device, you need a
subscription with a service provider.
Using network services and downloading content to your
device requires a network connection and may result in
data traffic costs. Some product features require support
from the network, and you may need to subscribe to them.
Take care of your device
Handle your device, battery, charger and accessories with
care. The following suggestions help you protect your
warranty coverage.
Keep the device dry. Precipitation, humidity, and all
types of liquids or moisture can contain minerals
that corrode electronic circuits. If your device gets
wet, remove the battery, and allow the device to dry.
Do not use or store the device in dusty or dirty areas.
Moving parts and electronic components can be
damaged.
Do not store the device in high temperatures. High
temperatures can shorten the life of the device,
damage the battery, and warp or melt plastics.
Do not store the device in cold temperatures. When
the device warms to its normal temperature,
moisture can form inside the device and damage
electronic circuits.
Do not attempt to open the device other than as
instructed in the user guide.
Unauthorised modifications may damage the device
and violate regulations governing radio devices.
Do not drop, knock, or shake the device. Rough
handling can break internal circuit boards and
mechanics.
6 Product and safety information
6 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Only use a soft, clean, dry cloth to clean the surface
of the device.
Do not paint the device. Paint can clog the moving
parts and prevent proper operation.
Switch off the device and remove the battery from
time to time for optimum performance.
Keep your device away from magnets or magnetic
fields.
To keep your important data safe, store it in at least
two separate places, such as your device, memory
card, or computer, or write down important
information.
During extended operation, the device may feel warm. In
most cases, this condition is normal. If you suspect the
device is not working properly, take it to the nearest
authorised service facility.
Recycle
Always return your used electronic products, batteries,
and packaging materials to dedicated collection points.
This way you help prevent uncontrolled waste disposal
and promote the recycling of materials. Check product
environmental information and how to recycle your Nokia
products at www.nokia.com/werecycle, or with a mobile
device, http://nokia.mobi/werecycle.
Crossed-out wheeled-bin symbol
The crossed-out wheeled-bin symbol on your product,
battery, literature, or packaging reminds you that all
electrical and electronic products, batteries, and
accumulators must be taken to separate collection at the
end of their working life. This requirement applies in the
European Union. Do not dispose of these products as
unsorted municipal waste. For more information on the
environmental attributes of your device, see
www.nokia.com/ecodeclaration.
About Digital Rights Management
When using this device, obey all laws and respect local
customs, privacy and legitimate rights of others, including
copyrights. Copyright protection may prevent you from
copying, modifying, or transferring images, music, and
other content.
Content owners may use different types of digital rights
management (DRM) technologies to protect their
intellectual property, including copyrights. This device
uses various types of DRM software to access DRM-
protected content. With this device you can access content
protected with WM DRM 10 and OMA DRM 2.0/1.0. If certain
DRM software fails to protect the content, content owners
may ask that such DRM software's ability to access new
DRM-protected content be revoked. Revocation may also
prevent renewal of such DRM-protected content already in
your device. Revocation of such DRM software does not
affect the use of content protected with other types of DRM
or the use of non-DRM-protected content.
Digital rights management (DRM) protected content
comes with an associated licence that defines your rights
to use the content.
If your device has OMA DRM-protected content, to back up
both the licences and the content, use the backup feature
of Nokia Ovi Suite.
Other transfer methods may not transfer the licences
which need to be restored with the content for you to be
able to continue the use of OMA DRM-protected content
after the device memory is formatted. You may also need
to restore the licences in case the files on your device get
corrupted.
Product and safety information 7
www.nokia.com/support 7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
If your device has WMDRM-protected content, both the
licences and the content will be lost if the device memory
is formatted. You may also lose the licences and the
content if the files on your device get corrupted. Losing
the licences or the content may limit your ability to use the
same content on your device again. For more information,
contact your service provider.
Some licences may be connected to a specific SIM card, and
the protected content can be accessed only if the SIM card
is inserted in the device.
Batteries and chargers
Battery and charger information
Your device is intended for use with a BL-5K rechargeable
battery. Nokia may make additional battery models
available for this device. Always use original Nokia
batteries.
This device is intended for use when supplied with power
from the following chargers: AC-10. The exact Nokia
charger model number may vary depending on the plug
type, identified by E, X, AR, U, A, C, K, or B.
The battery can be charged and discharged hundreds of
times, but it will eventually wear out. When the talk and
standby times are noticeably shorter than normal, replace
the battery.
Battery safety
Always switch the device off and disconnect the charger
before removing the battery. When you unplug a charger
or an accessory, hold and pull the plug, not the cord.
When your charger is not in use, unplug it from the
electrical plug and the device. Do not leave a fully charged
battery connected to a charger, as overcharging may
shorten the battery’s lifetime. If left unused, a fully
charged battery will lose its charge over time.
Always keep the battery between 15°C and 25°C (59°F and
77°F). Extreme temperatures reduce the capacity and
lifetime of the battery. A device with a hot or cold battery
may not work temporarily.
Accidental short-circuiting can happen when a metallic
object touches the metal strips on the battery, for
example, if you carry a spare battery in your pocket. Short-
circuiting may damage the battery or the connecting
object.
Do not dispose of batteries in a fire as they may explode.
Dispose of batteries according to local regulations. Recycle
when possible. Do not dispose as household waste.
Do not dismantle, cut, open, crush, bend, puncture, or
shred cells or batteries. If a battery leaks, do not let battery
liquid touch skin or eyes. If this happens, immediately
flush the affected areas with water, or seek medical help.
Do not modify, remanufacture, attempt to insert foreign
objects into the battery, or immerse or expose it to water
or other liquids. Batteries may explode if damaged.
Use the battery and charger for their intended purposes
only. Improper use, or use of unapproved batteries or
incompatible chargers may present a risk of fire,
explosion, or other hazard, and may invalidate any
approval or warranty. If you believe the battery or charger
is damaged, take it to a service centre for inspection before
continuing to use it. Never use a damaged battery or
charger. Only use the charger indoors.
Additional safety information
Emergency calls
Make an emergency call
1 Ensure the device is switched on.
2 Check for adequate signal strength. You may also
need to do the following:
8 Product and safety information
8 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Insert a SIM card.
Remove call restrictions you have activated for
your device, such as call barring, fixed dialling,
or closed user group.
Ensure your device is not in an offline or flight
profile.
If the device screen and keys are locked,
unlock them.
3 To clear the display, press the menu key as many
times as needed.
4Select Call.
5 Enter the official emergency number for your
present location.
6Select
.
7 Give the necessary information as accurately as
possible. Do not end the call until given permission
to do so.
When you switch your device on for the first time, you may
be asked to create a Nokia account. To make an emergency
call during the account setup, press the menu key.
Important: Activate both cellular and internet calls,
if your device supports internet calls. The device may
attempt to make emergency calls both through cellular
networks and through your internet call service provider.
Connections in all conditions cannot be guaranteed. Never
rely solely on any wireless device for essential
communications like medical emergencies.
Small children
Your device and its accessories are not toys. They may
contain small parts. Keep them out of the reach of small
children.
Medical devices
Operation of radio transmitting equipment, including
wireless phones, may interfere with the function of
inadequately protected medical devices. Consult a
physician or the manufacturer of the medical device to
determine whether they are adequately shielded from
external RF energy. Switch off your device when
regulations posted instruct you to do so, for example, in
hospitals.
Implanted medical devices
Manufacturers of medical devices recommend a minimum
separation of 15.3 centimetres (6 inches) between a
wireless device and an implanted medical device, such as
a pacemaker or implanted cardioverter defibrillator, to
avoid potential interference with the medical device.
Persons who have such devices should:
Always keep the wireless device more than 15.3
centimetres (6 inches) from the medical device.
Not carry the wireless device in a breast pocket.
Hold the wireless device to the ear opposite the
medical device.
Turn the wireless device off if there is any reason to
suspect that interference is taking place.
Follow the manufacturer directions for the
implanted medical device.
If you have any questions about using your wireless device
with an implanted medical device, consult your health
care provider.
Product and safety information 9
www.nokia.com/support 9
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Hearing
Warning:
When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it
can endanger your safety.
Some wireless devices may interfere with some hearing
aids.
Operating environment
This device meets RF exposure guidelines in the normal
use position at the ear or at least 1.5 centimetres (5/8
inch) away from the body. Any carry case, belt clip, or
holder for body-worn operation should not contain metal
and should position the device the above-stated distance
from your body.
To send data files or messages requires a quality
connection to the network. Data files or messages may be
delayed until such a connection is available. Follow the
separation distance instructions until the transmission is
completed.
Vehicles
Radio signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles such as electronic fuel injection, electronic
antilock braking, electronic speed control, and air bag
systems. For more information, check with the
manufacturer of your vehicle or its equipment.
Only qualified personnel should install the device in a
vehicle. Faulty installation or service may be dangerous
and may invalidate your warranty. Check regularly that all
wireless device equipment in your vehicle is mounted and
operating properly. Do not store or carry flammable
liquids, gases, or explosive materials in the same
compartment as the device, its parts, or accessories.
Remember that air bags inflate with great force. Do not
place your device or accessories in the air bag deployment
area.
Switch off your device before boarding an aircraft. The use
of wireless devices in an aircraft may be dangerous to the
operation of the aircraft and may be illegal.
Potentially explosive environments
Switch off your device in any area with a potentially
explosive atmosphere. Obey all posted instructions. Sparks
in such areas could cause an explosion or fire resulting in
bodily injury or death. Switch off the device at refuelling
points such as near gas pumps at service stations. Observe
restrictions in fuel depots, storage, and distribution areas;
chemical plants; or where blasting operations are in
progress. Areas with a potentially explosive atmosphere
are often, but not always, clearly marked. They include
areas where you would be advised to turn off your vehicle
engine, below deck on boats, chemical transfer or storage
facilities and where the air contains chemicals or particles
such as grain, dust, or metal powders. You should check
with the manufacturers of vehicles using liquefied
petroleum gas (such as propane or butane) to determine
if this device can be safely used in their vicinity.
Certification information (SAR)
This mobile device meets guidelines for exposure to
radio waves.
Your mobile device is a radio transmitter and receiver. It
is designed not to exceed the limits for exposure to radio
waves recommended by international guidelines. These
guidelines were developed by the independent scientific
organisation ICNIRP and include safety margins designed
to assure the protection of all persons, regardless of age
and health.
10 Product and safety information
10 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
The exposure guidelines for mobile devices employ a unit
of measurement known as the Specific Absorption Rate or
SAR. The SAR limit stated in the ICNIRP guidelines is 2.0
watts/kilogram (W/kg) averaged over 10 grams of tissue.
Tests for SAR are conducted using standard operating
positions with the device transmitting at its highest
certified power level in all tested frequency bands. The
actual SAR level of an operating device can be below the
maximum value because the device is designed to use only
the power required to reach the network. That amount
changes depending on a number of factors such as how
close you are to a network base station.
The highest SAR value under the ICNIRP guidelines for use
of the device at the ear is 0.75 W/kg.
Use of device accessories may result in different SAR
values. SAR values may vary depending on national
reporting and testing requirements and the network
band. Additional SAR information may be provided under
product information at www.nokia.com.
Your mobile device is also designed to meet the
requirements for exposure to radio waves established by
the Federal Communications Commission (USA) and
Industry Canada. These requirements set a SAR limit of 1.6
W/kg averaged over one gram of tissue. The highest SAR
value reported under this standard during product
certification for use at the ear is 1.22 W/kg and when
properly worn on the body is 0.83 W/kg.
Copyright and other notices
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-749
product is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC. A
copy of the Declaration of Conformity can be found at
www.nokia.com/phones/declaration_of_conformity/.
© 2011 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Nokia Original
Accessories logo, and Ovi by Nokia are trademarks or
registered trademarks of Nokia Corporation. Nokia tune is
a sound mark of Nokia Corporation. Other product and
company names mentioned herein may be trademarks or
tradenames of their respective owners.
Reproduction, transfer, distribution, or storage of part or
all of the contents in this document in any form without
the prior written permission of Nokia is prohibited. Nokia
operates a policy of continuous development. Nokia
reserves the right to make changes and improvements to
any of the products described in this document without
prior notice.
Java and all Java-based marks are trademarks or registered
trademarks of Sun Microsystems, Inc.
The Bluetooth word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by Nokia is
under license.
Copyright and other notices 11
www.nokia.com/support 11
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
This product is licensed under the MPEG-4 Visual Patent
Portfolio License (i) for personal and noncommercial use
in connection with information which has been encoded
in compliance with the MPEG-4 Visual Standard by a
consumer engaged in a personal and noncommercial
activity and (ii) for use in connection with MPEG-4 video
provided by a licensed video provider. No license is
granted or shall be implied for any other use. Additional
information, including that related to promotional,
internal, and commercial uses, may be obtained from
MPEG LA, LLC. See http://www.mpegla.com.
To the maximum extent permitted by applicable law,
under no circumstances shall Nokia or any of its licensors
be responsible for any loss of data or income or any special,
incidental, consequential or indirect damages howsoever
caused.
The contents of this document are provided "as is". Except
as required by applicable law, no warranties of any kind,
either express or implied, including, but not limited to, the
implied warranties of merchantability and fitness for a
particular purpose, are made in relation to the accuracy,
reliability or contents of this document. Nokia reserves the
right to revise this document or withdraw it at any time
without prior notice.
Reverse engineering of software in the device is
prohibited to the extent permitted by applicable law.
Insofar as this user guide contains any limitations on
Nokia's representations, warranties, damages and
liabilities, such limitations shall likewise limit any
representations, warranties, damages and liabilities of
Nokia's licensors.
The availability of products, features, applications and
services may vary by region. For more information, contact
your Nokia dealer or your service provider. This device may
contain commodities, technology or software subject to
export laws and regulations from the US and other
countries. Diversion contrary to law is prohibited.
Nokia does not provide a warranty for or take any
responsibility for the functionality, content, or end-user
support of third-party applications provided with your
device. By using an application, you acknowledge that the
application is provided as is. Nokia does not make any
representations, provide a warranty, or take any
responsibility for the functionality, content, or end-user
support of third-party applications provided with your
device.
The availability of Ovi services may vary by region.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for
example, when using a telephone in close proximity to
receiving equipment). The FCC or Industry Canada can
require you to stop using your telephone if such
interference cannot be eliminated. If you require
assistance, contact your local service facility. This device
complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must
accept any interference received, including interference
that may cause undesired operation. Any changes or
modifications not expressly approved by Nokia could void
the user's authority to operate this equipment.
9226267/Issue 1 EN
12 Copyright and other notices
12 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Navigation menu
