Mikrotikls SIA SXTSQ-2ND Digital Transmission System TX User Manual
Mikrotikls SIA Digital Transmission System TX
User Manual
![](/img.php?id=3810066&img=bg1.png)
SXTsq series
The SXTsq is an outdoor wireless router with a built in directional antenna. It can be used as a CPE or for point to point links
(use RouterOS wireless mode “bridge” to work as a single-client AP for point to point scenarios).
Assembly and mounting
The device comes bundled with a metallic mounting ring, which can be used on one if the three ring mount slots on the back
side of the device. Use a Phillips screwdriver to loosen the metallic ring, slide one end of it through the most convenient of the
three mounting slots and then position the device on the pole where it will be mounted. Slide the loose end of the mounting ring
back to it’s closing latch and use the screwdriver to tighten it. The included ring mount allows for mounting on 2-7 cm diameter
poles.
Connecting
1. Open the ethernet door to connect an ethernet cable to the ethernet port, connect the other end of the ethernet cable
to the included PoE injector
2. Plug the PoE injector into your network switch or computer
3. Plug the included power supply into the PoE injector to start up the device
4. Set LAN computer IP configuration to automatic (DHCP)
5. Default IP address of the unit is 192.168.88.1, open this address in your web browser to start configuration. The
username is admin and there is no password
The device is preconfigured as a wireless client (CPE), and all you need to do is select the AP to connect to and set a device
password. You can do this in the quickSET tab that is loaded by default. In case IP connection is not available, Winbox can be
used to connect to the MAC address of the device.
In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of the device
when starting it, until the LED light turns off, then the device will start to look for Netinstall servers.
More information about using RouterOS and connecting to this device in our documentation: http://mt.lv/help
Powering
The device only accepts 10-30 V power from Passive PoE injectors (one power supply and PoE injector are included)
Extension Slots and Ports
One ethernet (10/100 Mbit or Gigabit, depends on model), supporting automatic cross/straight cable correction (Auto
MDI/X), so you can use either straight or cross-over cables for connecting to other network devices.
One Integrated Wireless with built in 23 degree directional antenna, max gain 16dBi
Buttons and Jumpers
RouterBOOT reset button has the following functions. Press the button and apply the power, then:
Release the button when green LED starts flashing, to reset RouterOS configuration to defaults.
Release the button when the LED turns solid green to clear all configuration and defaults.
Release the button after LED is no longer lit (~20 seconds) to cause device to look for Netinstall servers (required for
reinstalling RouterOS over network).
Regardless of the above option used, the system will load the backup RouterBOOT loader if the button is pressed before power
is applied to the device. Useful for RouterBOOT debugging and recovery.
The device includes a grounding connection (marked )⏚ which you should connect to the grounding installation of the tower or
building where the device will be used. This is to substantially reduce risk of ESD and lightning damage.
See www.mikrotik.com for more information or contact support@mikrotik.com Document #36712. Modified on 09/21/17.
![](/img.php?id=3810066&img=bg2.png)
Operating System Support
The device only supports RouterOS software with the version number at or above what is indicated in the RouterOS menu
/system resource. Other operating systems have not been tested.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
This device and its antenna must not be co-located or operation in conjunction with any other antenna or transmitter.
IMPORTANT: Exposure to Radio Frequency Radiation.
20 cm minimum distance has to be maintained between the antenna and the occupational user and 28 cm to general public.
Under such configuration, the FCC radiation exposure limits set forth for an population/uncontrolled environment can be
satisfied.
Antenna Installation. WARNING: It is installer's responsibility to ensure that when using the authorized antennas in the United
States (or where FCC rules apply); only those antennas certified with the product are used. The use of any antenna other than
those certified with the product is expressly forbidden in accordance to FCC rules CFR47 part 15.204. The installer should
configure the output power level of antennas, according to country regulations and per antenna type. Professional installation is
required of equipment with connectors to ensure compliance with health and safety issues.
FCC ID numbers: SXTsq Lite5: TV7LHG5NDM; SXTsq 5: TV7LHG5HPND; SXTsq 5 ac: TV7LHG5ACD; SXTsq Lite2: TV7SXTSQ-2ND
Industry Canada
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
IC numbers: SXTsq Lite5: 7442A-LHG5NDM; SXTsq 5: 7442A-LHG5HPND; SXTsq 5 ac: 7442A-LHG5ACD; SXTsq Lite2: 7442A-SXTSQ2ND
See www.mikrotik.com for more information or contact support@mikrotik.com Document #36712. Modified on 09/21/17.
![](/img.php?id=3810066&img=bg3.png)
CE declaration of conformity
