KEEPSAKE USB Turntable
CR249
12-08-08
27-6-07
Instruction Manual
910-264500-0010-100
![](/img.php?id=1011501&img=bg2.png)
IMPORTANT SAFETY INSTRUCTION
PLEASE READ CAREFULLY ALL THE FOLLOWING IMPORTANT SAFEGUARDS
THAT ARE APPLICABLE TO YOUR EQUIPMENT
1. Read Instructions - All the safety and operating instructions should be read before the product is operated.
2. Retain instructions - The safety and operating instructions should be retained for future reference.
3. Heed Warnings - All warnings on the product and in the operating Instructions should be adhered to.
4. Follow Instructions - All operating and use instructions should be followed.
5. Cleaning - Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use
a damp cloth for cleaning.
6. Attachments - Do not use attachments not recommended by the product manufacturer as they may cause hazards.
7. Water and Moisture - Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near a swimming pool; and the like.
8. A product and cart combination should be moved with care. Quick stops, excessive force, and uneven
surfaces may cause the product and cart combination to overturn.
9. Ventilation - Slots and openings in the cabinet are provided for ventilation and to ensure reliable
operation of the product and to protect it from overheating, and these openings must not be blocked
or covered, The openings should never be blocked by placing the product on a bed, sofa, rug, or
other similar surface. This product should not be placed in a built - in installation such as a bookcase
or rack unless proper ventilation is provided or the manufacturer's instructions have been adhered to.
10. Power Sources - This product should be operated only from the type of power source indicated on the marking label,
if you are not sure of the type of power supply to your home. Consult your product dealer or local power company. For
products intended to operate from battery power, or other sources, refer to the operating instructions.
11. Grounding or Polarization - This product may be equipped with a polarized alternating-current line plug (a plug having
one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you
are unable to insert the plug fully into the outlet try reversing the plug, If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
12. Power - Cord Protection - Power - supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point where they exit from the product.
13. Lightning - For added protection for this product during a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from the wall outlet and disconnect
the antenna or cable system. This will prevent damage to the product due to lightning and power - line surges.
14. Power Lines - An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
15. Overloading - Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result
in a risk of fire or electric shock.
16. Object and Liquid Entry - Never push objects of any kind into this product through openings as they may touch
dangerous voltage points or short - out parts that could result in a fire or electric shock. Never spill liquid of any kind
on the product.
17. Servicing - Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
18. Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to qualified service personnel
under the following conditions;
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating instructions. Adjust only those controls that
are covered by the operating instructions as an improper adjustment of other controls may result in damage and
will often require extensive work by a qualified technician to restore the product to its normal operation.
e. If the product has been dropped or damaged in any way.
f. When the product exhibits a distinct change in performance - this indicates a need for service.
19. Replacement Parts - When replacement parts are required, be sure the service technician has used replacement
parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
20. Safety Check - Upon completion of any service or repairs to this product, ask the service technician to perform safety
checks to determine that the product is in proper operating condition.
21. Wall or ceiling Mounting - The product should be mounted to a wall or ceiling only as recommended by the manufacturer.
22. Heat - The product should be situated away from heat sources such as radiators. Heat registers, stoves, or other
products (including amplifiers) that produce heat.
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could
void the users authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful intereference to radio or
television reception, which can be determined by turning the equipment off and on , the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio TV technician for help.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications
to this equipment. Such modifications could void the User's authority to operate the equipment.
AC
Polarized Plug
18
WARRANTY
Crosley Radio Products are warranted against defects in material and
workmanship for a period of 90 days beginning from the date of sale to the
original purchaser.
Should the unit fail under normal usage during the 90 day warranty period, a
request for RETURN AUTHORIZATION (R.A.) must be made by the original
customer before returning the unit. Call Crosley Radio customer service for
Return Authorization at (502) 583-4246 from 9 AM to 5 PM (EST) Monday to
Friday.
Upon receiving the RETURN AUTHORIZATION number from the Customer
Service Department, properly pack your unit in its original packaging. Include
any adapters, parts, & accessories which were originally provided with the
product, along with a check or money order for $19.95 made out to Crosley
Radio to cover the handling and return postage. Display the R.A. # on the
outside of the carton and ship PREPAID via standard UPS or its equivalent.
ATTN: RETURNS DEP'T
2001 PRODUCTION DRIVE
BAY 2 & 3
LOUISVILLE, KY 40299
CROSLEY RADIO assumes no responsibility for units sent without prior Return Authorization.
The purchasers bill of sale is the only proof of warranty entitlement and must accompany the unit.
The warranty does not cover damage due to acts of nature, accident, misuse, abuse, negligence, commercial
use or modification of, or to any part of the product. This warranty does not cover damage due to improper
operation or maintenance, connection to improper voltage supply, or attempted repair by anyone other than
a facility authorized by Crosley Radio to service the product. This warranty does not cover products sold
AS IS or consumables (such as fuses or batteries). This warranty is valid only in the United States.
This warranty gives the purchaser specified legal rights in addition to any rights which may vary from state
to state.
In accordance with the "Moss-Magnuson Warranty Act" of July 10, 1975, this is termed a "limited warranty"
which in no way compromises Crosley Radio high standards of Quality and Workmanship.
![](/img.php?id=1011501&img=bg3.png)
6
Using the included software and cable, the USB
connection allows you record your records onto your
computer. Follow these instructions to use the USB.
1 Insert the enclosed software CD into your
computer.
2Follow the instructions on the computer screen
to install the software. If the software does not
load automatically, browse the CD and open
the Read Me folder for further instructions.
3Connect the small end of the USB cable to the
USB JACK (15) on the back of the unit.
4 Connect the other end to a USB port on your
computer.
5On your computer, open the Record Recording
Software.
6 For instructions on operating the Record
Recording Software, browse the software CD
and open the Read Me folder.
Getting Started
Unpacking................................. 4
Power Source........................... 4
Control Locators....................... 5
Operation
General.................................... 6
USB/Recording........................ 6
General
Troubleshooting Guide............ 7
Warranty................................... 8
About This Manual
Thank you for purchasing the Crosley Keepsake
(CR249). Before operating this unit, please read this
manual thoroughly and retain it for future reference.
Instructions in this manual describe the control
functions of the CR249.
Included in this package:
·Keepsake USB Turntable
·Record Recording Software
·USB Cable
·45rpm Adapter
Welcome Table of Contents
3
Operation
Turntable Operation
1 Turn the unit on by rotating the ON/OFF-
VOLUME KNOB (7) clockwise.
2 Set the SPEED CONTROL SWITCH (4) to
to the correct speed (33 1/3,45 or 78 rpm).
3 Place the record on the turntable.
4Use the CUE LEVER (2) to raise the tone arm
off its rest. Move the tone arm over the record
and use the cue lever to lower it onto the record.
The record will begin to turn automatically.
5At the end of the record, the tone arm will return
to its rest.
Accessory: ADAPTER FOR 45 RPM
This adaptor allows you to play 45 RPM records.
1 Place the 45 RPM adaptor over the spindle.
2 Gently place your 45 RPM record onto the
turntable.
3 Follow the steps under turntable operation to
play your record.
USB Operation
Follow the instructions on the computer screen to install the software. If the software does not load automatically, browse the CD and
open the Read Me folder for further instructions.
For instructions on operation the Record Recording Software, browse the software CD and open the Read Me folder.
![](/img.php?id=1011501&img=bg4.png)
2
SPECIFICATION
Power Supply : AC adapter -(DC 12V 0.5A)(Included)
Power Consumption : 12W
Speed : 33
1/3
/ 45 /78 RPM
Speaker : 3 x 5 Dynamic Type x 2
Replacement Needle
:
NP4
DESIGN AND SPECIFICATION SUBJECT TO CHANGE WITHOUT NOTICE.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER - SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lighting flash with arrowhead symbol, within an equilateral
triangle, is intended to alert user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be
of sufficient magnitude to constitute risk of electric shock to
persons.
The exclamation point within an equilateral triangle is intended
to alert user to the presence of important operating and
maintenance (servicing) instruction in the literature accompanying
the appliance.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE. DO NOT REMOVE COVER. PILOT LAMPS SOLDERED
IN PLACE. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
7
The unit does not operate.
1The AC Power cord is not connected. Make sure
it is connected to an AC outlet and the back of
the unit.
2The unit is not turned on : rotate the VOLUME
knob from the OFF position.
Turntable
No sound is coming from unit.
1The white protective needle cover was not
removed.
2The volume is not turned unit.
Tone arm will not move.
1Block tie-wrap was not removed from underneath
tone arm.
2Tone arm hold down clip was not released.
Needles are available for additional charges, please
call us at 1-800-926-7801 for assistance
www.crosleyradio.com
Troubleshooting
General
![](/img.php?id=1011501&img=bg5.png)
4 5
1Untie the wire on the AC ADAPTER (16).
2Plug the AC ADAPTER into appropriate wall
outlet.
3Plug the small end of the adapter into the
ADAPTER JACK (12) on the back of the unit.
Getting Started
Unpacking
1Remove packing materials from unit.
Note: Save all packing materials.
2Remove plastic bag covering radio.
3Remove AC ADAPTER from packing.
4Remove tie from A/C ADAPTER.
5Open lid and remove styrofoam shipping
material from turntable.
6Remove black tie-wrap from under the tone
arm.
7Remove white protective needle cover by gently
pulling towards the front of the unit.
8Turn the TURNTABLE SUSPENSION SCREW
(31) clockwise until it is all the way down.Do
not force or over tighten it. This allows the
turntable to float on its shock absorbers.
9Release tone arm hold down clip by gently
pushing to the right. This will unlock tone arm
from its arm rest. Re-lock the hold down clip
when moving the unit to another location.
Power Source
1. Tone Arm
2. Cue lever
3. Power light indicator
4. Speed control switch
5. Security Hook
6. Tone Control
7. ON/OFF Volume Knob
8. Tone Arm Rest
9. Turntable
10. Adapter for 45 RPM records
11. Speaker
12. Adapter Jack
13. Aux In Jack
14. Aux In Phono on/off
15. USB Jack
16. AC Adapter
(placed in a white cardboard box inside
the styrofoam packaging)
10
11
11
16
13 15
12 14
Control Locators
Unit Controls
1
3
4
5
6
7
8
9
2
