User manual
![](/img.php?id=2375892&img=bg1.png)
Quick guide / User Manual
K9708B Bluetooth
Keyboard
![](/img.php?id=2375892&img=bg2.png)
Installation:
STEP1:Install the two AAA batteries.
STEP2:Slide the power switch to ON
position.
ON OFF
POWER
Note:
If no signal is received within 30 sec, the
keyboard will revert to Power-saving
Mode. To reactivate the keyboard, click
any key on the keyboard.
STEP4:The keyboard is now ready to
connect with a Bluetooth ready
system.
Bluetooth Setting
Success!
Bluetooth Keyboard is connection.
STEP3:Press the pair (ID) button on the
bottom side of the keyboard for
3 seconds.
![](/img.php?id=2375892&img=bg3.png)
Installation:
WINDOWS
❶
Make sure that the Bluetooth
Function has been activated on
your computer. Double click the
Bluetooth Icon in the Task Bar or in
the Control Panel. Click ‘Add a
device’
❷
In the Bluetooth program, use the
option to add a new device and
follow the instructions on the
screen. A random Bluetooth
passkey will be provided by your
system.
❸
IMPORTANT: Press ENTER after
typing the passkey on each device.
❹
Setup of your device is complete.
MAC
❶
Make sure that the Bluetooth
Function has been activated on
your computer. Select
Set up Bluetooth device from the
Bluetooth status dropdown in the
menu bar.
❷
When the system finds the
keyboard, select Bluetooth
Keyboard and click Continue.
❸
A random Bluetooth passkey will be
provided by your system. Type the
Bluetooth passkey onto the
keyboard, and press Enter to
complete the pairing.
❹
Click Quit. Now your wireless
Bluetooth keyboard is successfully
connected with your computer.
iPad/iPhone
❶
On your iPad/iPhone, go to
Settings then select
General.
❷
Turn Bluetooth ON, it will
start searching for
Bluetooth devices.
❸
When the system finds the
keyboard, select Bluetooth
Keyboard.
❹
A random Bluetooth
passkey or pin will be
provided by your system.
Type this number onto the
keyboard, and press Enter
to complete the pairing.
❺
Now the keyboard is
successfully connected with
your iDevice.
Android Tablet
❶
On your tablet, go to
Settings then select
Wireless and Network, then
Bluetooth Settings.
❷
Turn Bluetooth ON and
select Scan Devices, it will
start searching for
Bluetooth devices.
❸
When the system finds the
keyboard, select Bluetooth
Keyboard.
❹
A random Bluetooth
passkey or pin will be
provided by your system.
Type this number onto the
keyboard, and press Enter
to complete the pairing.
❺
Now the keyboard is
successfully connected with
the Android Tablet.
![](/img.php?id=2375892&img=bg4.png)
Windows+IOS Icon Description:
change language
keyboard
Home
Serch
Mail
Previous
Stop/pause
Next
Mute
Volume Up
Volume down
Lock/Unlock
(supported IOS6/7 )
Windows/Command
Alt/Option
Menu
Fn + F1~F2 = F1~F12
= Num Lock
= Scroll Lock
= page up
= home
= End
= page down
![](/img.php?id=2375892&img=bg5.png)
Windows+Android Icon Description:
back
calendar
map
Home
Serch
Mail
Previous
Stop/pause
Next
Mute
Volume Up
Volume down
Lock/Unlock
(supported IOS6/7 )
Windows
Alt
Menu/
change Language
Fn + F1~F2 = F1~F12
= Num Lock
= Scroll Lock
= page up
= home
= End
= page down
Specifcations:
• Bluetooth Version: Bluetooth V3.0 HID
• 83 keys enhanced layouts compacted with fashion styling
• Power saving mode design
• Excellent tactile feel scissors key switch
• Working range: 10 meter
System requirements:
Built-in Bluetooth functionality on any of the following systems:
• Computers with Windows, Mac OS
• Apple iPad, iPhone/Touch with iOS 6 & later
• Android Phone and tablets with Android 4.1 & later
For more information and user manuals in other languages go to our website: www.keytronic.com
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Statement
This device complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause undesired operation.
Caution!
Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
