![](/img.php?id=699924&img=bg1.png)
Please read this user’s guide before
installing, setting up and using your new car
www.radioshack.com
60-4458
James Bond Aston Martin DBS
1:12 Scale RC Car
James Bond Aston Martin DBS Transmitter
Transmitter Antenna User’s guide
Vehicle Antenna Tube
what’s included
In your transmitter
Your transmitter requires one 9V alkaline
battery (not supplied). Replace the battery
when your transmitter’s control range
decreases.
1. Open the battery cover and insert the
battery as marked (+ and -).
2. Replace the cover.
In your vehicle
Your vehicle requires one 9.6V rechargeable
battery pack (not supplied).
1. Set ON/OFF on the vehicle under the body
on the driver’s side to OFF.
2. Use a coin to turn the battery compartment
latch to OPEN.
3. Slide the battery compartment cover in the
direction of the arrow and lift to open it.
4. Attach the vehicle’s connector to battery
pack. Do not force them; they t together
only one way.
5. Place the battery pack in the battery
compartment. The battery pack’s
connector must be on the same side as
the car’s matching connector.
6. Close the lid and snap it shut.
installing your batteries
• Do not use your vehicle near devices with
transmitters using the same frequency (27
or 49 MHz).
• If someone uses a CB nearby, it might
interfere with the control of your vehicle. If
this happens, move the vehicle away from
the CB.
• Never play with the vehicle in the street.
• Be careful when you use the vehicle to
avoid high-impact collisions with people
and objects.
• If your vehicle does not respond, drives
slowly, or the range reduces, recharge the
batteries in the vehicle.
safety information
Note: Actual product may vary from the images found in this document.
Thank you for purchasing your James
Bond Aston Martin DBS 1:12 Scale RC
Car from RadioShack. Your vehicle comes
in two frequencies (27MHz and 49MHz),
so you and your friends can drive your
car.
60-4458_UG_en.indd 1 08/22/2006 16:48:24
![](/img.php?id=699924&img=bg2.png)
©2006. RadioShack Corporation.
All rights reserved. RadioShack and
RadioShack.com are trademarks
used by RadioShack Corporation.
60-4458
07A06
printed in China
This product is warranted by RadioShack against manufacturing
defects in material and workmanship under normal use for ninety
(90) days from the date of purchase from RadioShack company-
owned stores and authorized RadioShack franchisees and dealers.
For complete warranty details and exclusions, check with your local
RadioShack store.
RadioShack Customer Relations
300 RadioShack Circle, Fort Worth, TX 76102
04/04
limited 90-day warranty
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radi-
ate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particu-
lar installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult your local RadioShack store or an experienced radio/TV
technician for help.
If you cannot eliminate the interference, the FCC requires that you stop
using your Vehicle. Changes or modications not expressly approved by
RadioShack may cause interference and void the user’s authority to oper-
ate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
Field Strength.........................................27.145MHz: 67.9 dBµV/m at 3m
.................................................................49.86MHz: 65.6 dBµV/m at 3m
Only use the antenna supplied with this product.
This radiocommunication device complies with all the requirements of
Industry Canada Standard RSS-310.
This Class B digital apparatus complies with Canadian ICES-003.
RF emission informations
1. Slide ON/OFF on the vehicle to ON.
2. Use the transmitter’s controls to steer your
vehicle in the directions shown below.
3. Slide ON/OFF on the vehicle to OFF when
you nish driving.
Wheel alignment
If the vehicle does not drive in a straight
line when you release the right stick, adjust
WHEEL ALIGNMENT (located between the
front wheels, underneath the vehicle). Push to
L if the vehicle is pulling to the right or to R if
the vehicle is pulling to the left.
driving your vehicle
• Dispose of old batteries promptly and
properly. Do not burn or bury batteries.
• Use only fresh batteries of the required
size and recommended type.
• Do not leave dead or weak batteries in
your transmitter or vehicle. If you do not
plan to use your RC vehicle for a few
weeks, remove the batteries from your
transmitter and vehicle. Batteries can leak
chemicals that may damage electronic
parts.
• Do not charge or recharge your battery
pack when it is in the vehicle.
• Do not overcharge your battery pack.
• Do not recharge your battery pack
immediately after use. Allow it to cool rst.
• Make sure your battery pack is securely
fastened to your vehicle before playing.
battery notes
• Handle your vehicle and transmitter
carefully. Do not drop them.
• Used and store them only in normal
temperature environments.
• Keep the vehicle and transmitter away
from dust and dirt, and wipe them with
a damp cloth occasionally to keep them
looking new.
safety and care
Forward
Stop
Reverse
Left Straight Right
