Transmitter Programming Guide
This transmitter is designed for use with your upgrade
remote start unit and is programmed by using the remote
start's program switch in combination with the transmitter
button. Although this transmitter can be programmed into any
of the Audiovox remote start and/or alarm, remote start
systems, it will offer limited use and should be used for the
remote start upgrade only.
To program this transmitter into your remote start upgrade
unit:
1) Turn the ignition to the on position.
2) Press and release the programming switch 3 times.
3) Press and hold, for 3 seconds, the button of the transmit-
ter you wish to add until the parking light flashes, indicating
the transmitter has been learned.
4) Repeat step 3 for each transmitter up to a total of 4
transmitters.
5) Turn the ignition off to exit the program mode.
NOTE: Do not allow more than 15 seconds to lapse between
steps or the program mode will automatically exit and you
will have to start over.
Model 101BP
![](/img.php?id=1295996&img=bg2.png)
128-8802
2 of 4
Battery Replacement
After removing the three #0 point
phillips screws shown, pry the
case apart with the edge of a
finger nail or a small common
screwdriver. Keep hold of the
metal key ring loop to prevent its
loss as it will separate from the
transmitter case.
Carefully remove the discharged
battery by sliding it out from
under the clip in the direction
indicated by the arrow in the
diagram below. Properly dispose
of the exhausted battery and
insert a new CR2032 battery
taking care to arrange it so that
the + is facing up toward the +
symbol on the battery clip.
Reassemble in the reverse of
above.
This device complies with FCC Rules Part 15 Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference that may be
received, including interference that may cause
undesired operation.
NOTE:The manufacturer is not responsible for any radio or
TV interference caused by unauthorized modifications to
this equipment. Such modifications could void the user’s
authority to operate the equipment.
![](/img.php?id=1295996&img=bg3.png)
128-8802
3 of 4
Attention: Transmitter Ordering Department
Important: To help us expedite your order, please
print all of the information legibly and mail this form
and your payment according to the instructions
below.
1) Name:_____________________________________
2) Address:_________________________________________
3) City:________________State:________Zip Code:__________
4 Telephone Number: ( )_____________________
5) Total Number Of Transmitters Required:_______
Cost Per Transmitter is: $65.00
Multiply By Number Of Transmitters X
6) Enter Total Amount Enclosed _______
(New York State Residents must include the appropriate sales tax.)
7) Method of Payment:
Mastercard Visa Check or Money Order (do not send cash)
Make Checks Payable To Audiovox Corporation
Credit Card Number:___________________________________
Credit Card Expiration Date: ____/___/____
8) Mail this form along with your payment to:
Transmitter Ordering Department
Audiovox Corporation 150 Marcus Blvd., Hauppauge N.Y.
11788
Credit card purchasers can order additional or replacement
transmitters by phone. Simply dial 1 - 800 - 645 - 4994, and
follow the instructions from the operator interface.
ORDER FORM
FOR TRANSMITTER 101BP
2
![](/img.php?id=1295996&img=bg4.png)
128-8802
4 of 4
This Page Intentionally Left Blank
