Safety and Regulatory Information
2
Copyright
© 2007 Proxim Wireless Corporation. All rights reserved. Covered by one or more of the following U.S. patents: 5,231,634; 5,875,179;
6,006,090; 5,809,060; 6,075,812; 5,077,753. This user’s guide and the software described in it are copyrighted with all rights reserved. No part
of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any
means without the written permission of Proxim Wireless Corporation.
Trademarks
Tsunami, Proxim, and the Proxim logo are trademarks of Proxim Wireless Corporation. All other trademarks mentioned herein are the property
of their respective owners.
Tsunami MP.11 Models 5012-SUI, 5054-SUI, and 5012-SUR Safety and Regulatory Guide
P/N 73921 June 2007
![](/img.php?id=859689&img=bg3.png)
Products Covered in the Guide Safety and Regulatory Information
3
Products Covered in the Guide
This document contains important safety and regulatory compliance information for the following products:
Please see the following sections for more information:
•Safety Information (USA, Canada, & European Union)
–5012-SUI/5054-SUI
–5012-SUR
•Federal Communications Commission (FCC) Compliance
–Modifications
–Warnings
•Regulatory Compliance Certifications Summary
IMPORTANT!
Visit http://support.proxim.com for the latest safety and regulatory compliance information for this product.
Please read this document before installing and using your product, and save these instructions.
Product Model Numbers
Tsunami MP.11
Models 5012-SUI, 5012-SUR, 5054-SUI
5012-SUI-WA-xx
5054-SUI-xx
5054-SUI-WA-xx
5012-SUR-xx
![](/img.php?id=859689&img=bg4.png)
Safety Information (USA, Canada, & European Union) Safety and Regulatory Information
4
Safety Information (USA, Canada, & European Union)
5012-SUI/5054-SUI
This product has been evaluated to, and complies with the Safety requirements of IEC60950:1999, the Standards for the
Safety of Information Technology Equipment. When using this device, basic safety precautions should always be
followed to reduce the risk of fire, electric shock and injury to persons, including the following:
• Operate and install this product as described in this manual. This device must be installed and used in strict
accordance with the manufacturer's instructions.
• Use only the AC/DC power supply adapter provided. For replacement, contact your local supplier or distributor.
• To avoid the risk of electric shock from lightning, do not use this product during an electrical storm.
• Installation of this product must conform to local regulations and codes.
• When using this product with an external antenna, see the installation documentation provided with the antenna
system.
• No user serviceable parts; all repairs and service must be handled by a qualified service center.
5012-SUR
This product has been evaluated to, and comply with, the U.S. and Canadian (Bi National) Standard for Safety of
Information Technology Equipment, including Electrical Business Equipment and IEC60950:1999, the Standard for the
Safety of Information Technology Equipment.
The product is intended to be installed, used, and maintained by experienced telecommunications personnel only.
When using this device, basic safety precautions should always be followed to reduce the risk of fire, electrical shock,
and injury to persons, including the following:
WARNING: These units are intended for installation in accordance with Articles 110 –18, 110-26, and 110-27, 725,
800, and 810 of the United States National Electric Code ANSINFPA 70, and per the applicable
Articles in the Canadian National Electric Code.
• Operate and install these products as described in this manual. Equipment must be installed and used in strict
accordance with the manufacturer's instructions as described in the user documentation provided.
• Installation of these products in the end use must conform to local regulations and codes.
• Products are to be used with and powered by an 802.3af compliant power injector.
• A 15-amp circuit breaker is required at the power source.
WARNING: This equipment is intended to be grounded. A 10 AWG earthing conductor at a minimum is to be
used for this purpose.
• Do not connect or disconnect the power cable to the equipment when the power injector is plugged into an AC power
outlet.
• Servicing of these products should be performed only by trained personnel. Do not disassemble. By opening or
removing any covers, you may expose yourself to hazardous energy parts. Incorrect reassembly of these products
can cause a malfunction and/or electric shock when the units are subsequently used. No user serviceable parts; all
repairs and service must be handled by a qualified service center.
• Do not insert any objects of any shape or size inside these products while powered on. Object may contact
hazardous energy parts that could result in a risk of fire or personal injury.
• Do not remove or alter the Marking label provided on these products.
• To avoid the risk of electric shock from lightning, do not use these products during an electrical storm.
![](/img.php?id=859689&img=bg5.png)
Federal Communications Commission (FCC) Compliance Safety and Regulatory Information
5
Federal Communications Commission (FCC) Compliance
The 5012-SUI and 5054-SUI operate at 5.15 - 5.35 GHz, 5.47-5.725 GHz and 5.75 - 5.85 GHz in compliance with Part 15 of
the FCC Rules. The 5012-SUR operates at 5.25 GHz - 5.35 GHz, 5.47-5.725 GHz and 5.75 - 5.85 GHz in compliance with
Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference,
and 2) This device must accept any interference received, including interference that may cause undesired operation.
To comply with the FCC radio frequency exposure requirements, the following antenna installation and device operating
configurations must be satisfied:
• 5012-SUI and 5054-SUI models must be used indoors only and must be installed to provide a separation distance of
at least 20 cm (8 inches) from all persons.
• Product models using external antennas require professional installation. The antennas used for professional
installation must be fixed-mounted on indoor/outdoor permanent structures with a separation distance of at least
100 cm from all persons.
• Antennas must not be co-located and must not operate in conjunction with any other antenna or transmitter.
Modifications
The FCC requires the user to be notified that any changes or modifications to this device that are not expressly approved
by the manufacturer may void the user’s authority to operate the equipment. The correction of interference caused by
unauthorized modification, substitution or attachment will be the responsibility of the user. The manufacturer and its
authorized resellers or distributors are not liable for any damage or violation of government regulations that may arise
from failing to comply with these guidelines.
Warnings
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection again harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
In some situations or environments, the use of wireless devices may be restricted by the proprietor of the building or
responsible representatives of the organization. These situations may, for example, include the use of wireless
equipment on board airplanes, or in any other environment where the risk of interference to other devices or services is
perceived or identified as harmful.
If you are uncertain of the policy that applies on the use of wireless equipment in a specific organization or environment
(such as airports), you are encouraged to ask for authorization to use this device prior to turning on the equipment.
![](/img.php?id=859689&img=bg6.png)
Regulatory Compliance Certifications Summary Safety and Regulatory Information
6
Regulatory Compliance Certifications Summary
* European Union includes the following countries: Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany,
Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Poland, Portugal, Slovakia, Slovenia, Spain, Sweden,
and the United Kingdom; also applies to Iceland, Liechtenstein, Norway, and Switzerland.
Country Certification/Reference No.
Australia & New Zealand N11394
Canada IC Cert. No.:
1856A-MP50XXSU
China CMII ID:
2004DJ0340
European Union* CE
Japan Radio Cert. Nos.:
003WY05050 0000
Mexico Pending
South Korea Radio Cert. No:
R-LARN-04-0010
Taiwan DGT Cert. No:
Pending
USA FCC ID:
HZB-MP50XXSU
