users manual
SPECIFICATION
Of
MLKF-8005 Cordless Optical Mouse
And
Multimedia Keyboard COMBO Set
Note:
This device complies with Part 15 of the FCC rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Caution:
The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such
modifications could void the user authority to operate the equipment.
REV : 1.00
Prepared by MLK Technologies Limited
15. SEP.2002
![](/img.php?id=283828&img=bg2.png)
Part 1.0 : General features and description
- Radio frequency : 27 MHz, single channel with 8 changeable ID for both mouse and
keyboard.
- Battery suggestion: Two AA alkaline batteries for mouse, Two AA alkaline batteries for
keyboard.
- The operation distance of 1.3M(typically under normal office environment)
- Mouse resolution of 400cpi counts per inch of motion.
- Mouse Sensor detects motion on all kinds of surface, including wood, plastics, pants, etc…
( Highly reflective like mirror or deep dark color may not work properly)
- Compatible with windows 98/ME/2000/XP
- Keyboard come with multimedia and internet hotkeys.
- Nice feeling, light touch membrane tactile switches for keyboard
Part 2.0 : Preface
The functionality and performance requirements related to the mouse are defined in this
specification.
Part 3.0 : Version
- USB Interface
Part 4.0 : Physical characteristics and configuration
Item 4.1: Dimension
- Mouse : 116mm(L) x 62.5mm(W) x 38.20mm(H)
- Keyboard: 460mm(L) x196.09mm(W) x 41.77 mm(H)
- Receiver: 81.00mm(L) x 67.50mm x 23.00mm(H)
![](/img.php?id=283828&img=bg3.png)
![](/img.php?id=283828&img=bg4.png)
Item 4.2: Material
Mouse Body ABS
Wheel Rubber
Keyboard Body HIPS
Key-Caps ABS
Receiver Body ABS
Item 4.3: Finish: Texture
Item 4.4: Color: To be defined by ID
Item 4.5: Button
Mouse: 3 Buttons, 1 CONNECT button,
Keyboard: 104/105/107/109 enhanced layout , 1 Power Management Key,
16 External Multi Media Hot Key.
Receiver: 1 CONNECT button.
Item 4.6: Mechanical Performance
4.6.1 Operating force of mouse buttons: 80g±20gf
4.6.2 Operating force of mouse browser switches: 170g ± 25gf
4.6.3 Operating force of mouse wheel scrolling: 20 ± 10gf
4.6.4 Operating force of mouse movable: 60 ± 10gf
4.6.5 Mouse weight: 140 ± 15g
4.6.6 Operating force of keyboard standard Key Top: 55 ± 12 g
4.6.7 Operating force of keyboard Hot Key : 65 ± 12 g
4.6.8 Travel Length of Keyboard Standard Key Top: 4.0 ± 0.2 mm
4.6.9 Travel Length of Keyboard Hot key: 2.6 ± 0.2 mm
4.6.10 Keyboard Weight: 730g ± 20g
Part 5.0 : Electrical specification
Item 5.1: Compatibility
- The USB mode is using the low speed interface defined in the USB specification. It’s
compliant to the USB specification as well as to the HID class specifications.
- The USB mode shall be compatible with IBM PC/PENTIUM and works with operating system
such as Windows 98/2000/ME/XP as well as the most software applications.
Item 5.2 : Technical of mouse
Optical sensor for X/Y axis, the precise sensor detects motion on hundreds of surfaces, including
wood, plastic, and even your pants leg. ( highly reflective surface or deep dark color surface may
not work properly) .Wheel button uses a mechanical encoder.
Item 5.3 : Sensor Report Rate on Mouse
1500 times per second
Item 5.4 : Sensor Light on mouse
Red LED
Item 5.5 : Power Requirement (Receiver)
5V/ DC 20mA directly from Computer USB Port
Item 5.6 : Cable
The length of the cable on receiver is 1.2 meters and the color is defined by ID.
Item 5.7 : Operating Angle
The mouse and Keyboard operation angle is 360 degrees.
Item 5.8 : Operating Distance
The Mouse and Keyboard operation distance is 1.3 Meter ( typically under normal office
environment, Mouse to Receiver set),
Item 5.9 : ID changeable
The ID is changed by the CONNECT button .
Item 5.10 Battery
5.10.1 Battery Type
The mouse and keyboard both use two AA alkaline batteries.
5.10.2 Mouse Battery Consumption
Mouse will be on sleep mode while hand off the mouse over 2 second. Mouse work again by hand
touch.
Operating mode: 32mA±10% @ 3V
Stand-by mode: 15mA ±10% @ 3V
Sleep mode: 0.08mA ±10% @ 3V
5.10.3 Keyboard Battery Consumption
Keyboard will be on sleep mode while key released over 2 second. Keyboard work again by key
pressed.
Operating mode: 8mA±2 mA @ 3V
Stand-by mode: 1.5mA ±10% @ 3V
Sleep mode: 0mA
5.10.4: Low Battery Indicator
When the mouse battery voltage is less than 2.2V, the indicator on front of the rubber wheel
should be blinking when moving the mouse.
Item 5.11 : Mouse Tracking Speed
The unit shall be capable of tracking between 50mm/s and 254mm/s of hand movement on the
matt white paper without loss of data.
Item 5.12 : LED on Receiver
The receiver unit have four LEDs
COM: Indicator for Connecting.
Num: indicator for Num Lock status
Caps: indicator for Capital Lock status
Scroll: indicator for Scroll Lock starus
Part 6.0: Reliability and environmental specification
Item 6.1 : Mouse Button Switch Activation
Conditions: 3 cycles per second.
Testing methods : a small DC motor fixed with cam automatically press the key for three time per
second. The switch is connected to a calculator. The number displayed on
calculator is pressed cycle of the key.
Result: key tested have a lift cycle of more than 1,000,000.00.
![](/img.php?id=283828&img=bg6.png)
Item 6.2 : Cable Bending Strength
Conditions: Cable load at 100gram,
Testing methods: bend 60 degrees any direction from its centerline at speed of 30 cycles/min.
5000 cycles.
Result: No visible damage and no breakage in each wire.
Item 6.3 : Drop Shock with Bare Unit
Conditions: Drop the Unit from 76cm height onto floor.
Testing Methods: drop the unit on top, bottom and 4 side of the unit ( 1 time for each side).
Result: The Unit function properly, no mechanical failure.
Item 6.4 : Drop Shock in Gift box
Conditions: Unit have been packed with gift box
Testing Methods: Drop the gift box from 91cm onto a floor, on the 4 corners and 6 sides of the box
(1 time for each side)
Result: no content escape from packaging.
Item 6.5 : High Temperature Test for operating pattern
Conditions: N/A
Testing Methods: Keep the unit at the temperature of 0 to 40 degrees Celsius and relative
humidity of 0% to 95% for 25 hours and then left at ambient room temperature
for 2 hours.
Result: the unit work properly
Item 6.6 : Heat Cycle Test for Shipment Pattern
Conditions: N/A
Testing Methods: -40 degrees Celsius to 65 degrees Celsius under 0% to 90% related humidity
with total time of 40 hours, and then left at ambient room temperature for 2
hours.
Result: The unit work properly
Item 6.7 : Vibration Test
Unit shall survive a vibration within a frequency range of 10 to 200Hz at 0.015 square of g/Hz and
200 to 500 Hz at –6dB/oct for X,Y, and Z axis and 0.5 hour per aixs.
Part 7.0 : Product Compliance
Item 7.1 : Actual Compliance Label
The mouse is certified to comply with the limits for class B computing device pursuant, to subpart
of part of 15 of FCC rules and CE mark.
