FCC ID:EMOiBT69
FCC IC:986B-iBT69
Model iBT69
Bluetooth
Rechargeable
Speaker
Charging the iBT69
Using Bluetooth with the iBT63
Speaker
Bottom of Speaker
Off/Play/Pair Switch
LED
USB Audio/Charging Jack
Charging the iBT63
Bluetooth Mode
Aux-in Mode
mobile phone PSP iPod
Laptop
PC
MP3/MP4
• Slide the Off/Play/Pair Switch on the speaker to the PAIR position.
Tones will sound and the light will flash blue and red to indicate pairing
attempt.
• Place your audio device in Bluetooth mode (often found in the device’s
Settings or Options menu) and make it “discoverable”. “iHome iBT69”
should appear on your device. If “Not Connected” or similar message
appears, select “iHome iBT69” to connect. If prompted for a password,
enter “1234” on your device’s keypad.
• Once paired, the light will glow solid blue and a confirmation beep will
sound and you can then stream audio. If pairing is not successful, turn
the power OFF on the speaker and repeat pairing procedure.
• To listen to Bluetooth audio in the future, slide the Off/Play/Pair Switch
on the speaker to the PLAY position. The light will flash blue as the
speaker attempts to auto-link with the last previously linked unit in range
(30 feet).
• Control Bluetooth audio from your device.
Remember to turn off the speaker and your device after listening.
NOTE: When unit is charging, the blue light will appear solid red.
Using Bluetooth with the iBT69
The iBT69 is powered by a rechargeable battery in the speaker. Make
sure to charge the speaker before using.
• Connect the micro-USB plug to the USB Audio/Charging jack
on the speaker.
• Connect the larger USB plug to a powered USB port, such as that on a
computer. The light on the speaker will turn to solid red while charging
and turn off when fully charged. When the light flashes red, or if you start
to notice sound distortion at higher volumes, it's time to recharge the
batteries.
Charging the iBT69
• Connect the micro-USB plug to the USB Audio/Charging jack
on the speaker.
• Connect the stereo 3.5mm audio plug to the headphone jack or line-out
of any audio device.
• Slide the Off/Play/Pair Switch on the speaker to the PLAY (middle)
position. The blue power light will flash as the speaker attempts to
auto-link.
• Press play on your audio device and adjust its volume to listen to audio.
NOTE: Do not play a Bluetooth device and an audio device connected via
the USB audio/charging jack at the same time or you will hear both at
once.
Using the iBT69 with Aux Devices
Micro USB plug
Standard
USB plug
3.5mm audio
plug
Combination cable
Note: Charge speaker before use.
Computer USB port
Note: When not in use, turn speaker OFF to save battery power
iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants this
product to be free from defects in workmanship and materials, under normal use and conditions,
for a period of one (1) year from the date of original purchase.
Should this product fail to function in a satisfactory manner, it is best to first return it to the store
where it was originally purchased. Should this fail to resolve the matter and service still be required
by reason of any defect or malfunction during the warranty period, SDI will repair or, at its discretion,
replace this product without charge. This decision is subject to verification of the defect or
malfunction upon delivery of this product to the Factory Service Center authorized by SDI Customer
Service. The product must include proof of purchase, including date of purchase. An out-of-warranty
fee for service will be charged for units that are received without proof of purchase.
Before returning this product for service, please first replace the batteries (if applicable) with fresh
ones, as exhausted or defective batteries are the most common cause of problems encountered.
If service is still required:
1. Call SDI Customer Service at 1-800-288-2792 for Return Authorization and for the address
of the Factory Service Center.
2. Remove the batteries (if applicable) and pack the unit in a well padded, heavy corrugated box.
SDI is not responsible for damage that occurs during shipping to the Factory Service Center.
3. Enclose a photocopy of your sales receipt, credit card statement, or other proof of the date
of purchase, if within the warranty period. Also include your name and address information, a
brief description for why the unit is being returned, and the return authorization number. No
unit can be processed without a return authorization number.
4. Write the return authorization number on the side of the shipping package and send the unit
prepaid and insured to the Factory Service Center address authorized by SDI Customer
Service.
Disclaimer of Warranty
NOTE: This warranty is valid only if the product is used for the purpose for which it was designed.
It does not cover (i) products which have been damaged by negligence or willful actions, misuse
or accident, or which have been modified or repaired by unauthorized persons; (ii) cracked or
broken cabinets, or units damaged by excessive heat; (iii) damage to digital media players, CD’s
or tape cassettes (if applicable); (iv) the cost of shipping this product to the Factory Service Center
and its return to the owner.
This warranty is valid only in the United States of America and does not extend to owners of the
product other than to the original purchaser. In no event will SDI or any of its affiliates, contractors,
resellers, their officers, directors,
shareholders, members or agents be liable to you or any third party for any consequential or
incidental damages, any lost profits, actual, exemplary or punitive damages. (Some states do not
allow limitations on implied warranties or exclusion of consequential damages, so these restrictions
may not apply to you.) This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
Your acknowledgment and agreement to fully and completely abide by the above mentioned
disclaimer of warranty is contractually binding to you upon your transfer of currency (money order,
cashier's check, or credit card) for purchase of your SDI product.
© 2014 SDI Technologies, Inc. All rights reserved
Questions? Visit www.ihome.com
or call 1-800-288-2792 Toll Free
Limited 1 Year Warranty Information
Printed in China
iBT69-010714-A
A Consumer Guide to Product Safety
When used in the directed manner, this unit has been designed and manufactured to ensure
your personal safety. However, improper use can result in potential electrical shock or fire hazards.
Please read all safety and operating instructions carefully before installation and use, and keep
these instructions handy for future reference. Take special note of all warnings listed in these
instructions and on the unit.
1. Water and Moisture – The unit should not be used near water. For example: near a
bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement.
2. Ventilation – The unit should be situated so that its location or position does not interfere
with its proper ventilation. For example, it should not be situated on a bed, sofa, rug or
similar surface that may block ventilation openings. Also, it should not be placed in a built-in
installation, such as a bookcase or cabinet, which may impede the flow of air through the
ventilation openings.
3. Heat – The unit should be situated away from heat sources such as radiators, heat registers,
stoves or other appliances (including amplifiers) that produce heat.
4. Power Sources – The unit should be connected to a power supply only of the type
described in the operating instructions or as marked on the appliance.
5. Power-Cable Protection – Power supply cables should be routed so that they are not
likely to be walked on or pinched by items placed upon or against them. It is always best
to have a clear area from where the cable exits the unit to where it is plugged into an AC
socket.
6. Cleaning – The unit should be cleaned only as recommended. See the Maintenance
section of this manual for cleaning instructions.
7. Objects and Liquid Entry – Care should be taken so that objects do not fall and liquids
are not spilled into any openings or vents located on the product.
8. Attachments – Do not use attachments not recommended by the product manufacturer.
9. Lightning and Power Surge Protection – Unplug the unit from the wall socket and
disconnect the antenna or cable system during a lightning storm or when it is left unattended
and unused for long periods of time. This will prevent damage to the product due to lightning
and power-line surges.
10. Overloading – Do not overload wall sockets, extension cords, or integral convenience
receptacles as this can result in a risk of fire or electric shock.
11. Damage Requiring Service – The unit should be serviced by qualified service personnel
when:
A. the power supply cable or plug has been damaged.
B. objects have fallen into or liquid has been spilled into the enclosure.
C. the unit has been exposed to rain.
D. the unit has been dropped or the enclosure damaged.
E. the unit exhibits a marked change in performance or does not operate normally.
12. Periods of Nonuse – If the unit is to be left unused for an extended period of time, such
as a month or longer, the power cable should be unplugged from the unit to prevent damage
or corrosion.
13. Servicing – The user should not attempt to service the unit beyond those methods described
in the user’s operating instructions. Service methods not covered in the operating instructions
should be referred to qualified service personnel.
• Place the unit on a level surface away from sources of direct sunlight or excessive heat.
• Protect your furniture when placing your unit on a natural wood and lacquered finish. A
cloth or other protective material should be placed between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger
cleaning agents such as thinner or similar materials can damage the surface of the unit.
Maintenance For Models That Use Lithium Batteries:
• Lithium batteries can explode or cause burns if disassembled, shorted, recharged,
exposed to water, fire, or high temperatures & not handled appropriately
• Do not place loose batteries in a pocket, purse, or other container containing metal
objects, do not mix with used or other battery types, or store with hazardous or
combustible materials.
• Store in cool, dry, ventilated area.
• Follow applicable laws and regulations for transport and disposal.
Model: iBT69 (Front)
IB (English)
Size: 324Wmm x 184Hmm
Color: Print in Black color
Date: Jan 7, 2014
Model: iBT69 (Back)
IB (English)
Size: 324Wmm x 184Hmm
Color: Print in Black color
Date: Jan 7, 2014
IMPORTANT
Read before proceeding
If you have any question regarding the operation or use of this product, please visit www.ihome.com
to view answers to frequently asked questions.
To learn more about this and other iHome products, please visit us online at www.ihome.com
Questions? Visit www.ihome.com
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to
the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and
compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and
compliance.
• Warning: Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
• NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Part 15 of the FCC Rules, operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
FCC Information
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
CHARGE
BEFORE
USE
