SDI Technologies IBT77V2 Rechargeable Bluetooth Speaker with Speakerphone User Manual iBT77v2 EN QSG TT
SDI Technologies Inc. Rechargeable Bluetooth Speaker with Speakerphone iBT77v2 EN QSG TT
Users Manual
![](/img.php?id=3939393&img=bg1.png)
» Press and hold the Battery
Button to enter Battery
Review Mode. The built-in
voice will announce the
current battery level.
BACK
FRONT
Contact Us: 1•800•288•2792
In the Box » iBT77v2 speaker
» charging cable » carry strap
QUICK START GUIDE
For warranty
visit: www.ihome.com/support
For warranty and full instructions
visit: www.ihome.com/support
Contact Us: 1•800•288•2792
BATTERY CHARGE LEVEL REVIEW
AUX-IN
» To play aux audio, connect a standard
audio cable (not included) to the
headphone jack of your audio device and
connect the other end to the aux-in jack
on iBT77v2. Make sure Bluetooth audio is
paused (not playing) or you will not hear
Aux audio.
Rechargeable
Bluetooth Speaker
with Speakerphone
Model: iBT77v2
iHome
iBT77v2
BLUETOOTH: PAIRING & PLAYING
» Make your Bluetooth device “discoverable”
» Press and hold the Power Button on
bottom of unit for 3 sec. to power ON.
» The first time the unit is powered on it will
enter auto-pairing mode.
» Select “iHome iBT77V2” on your device’s
Bluetooth menu to complete pairing.
» To manually pair, power on then
press and hold Bluetooth Button for 2 sec.
» Press Play/Pause Button to play and pause
Bluetooth audio.
» Press –/+ Buttons to adjust volume.
» Press Power Button to power OFF.
» Press and hold Bluetooth Button for 10
seconds to reset Bluetooth.
Manual Pairing
Pairing the First Time
iHome
iBT77v2
2s
3s
2s
Bluetooth/
Speakerphone/
Play/Pause Button
Battery Review
Button
(press and hold
for voice)
Lower/Raise
Volume Buttons
USB in
Charging Port
Aux-in
Jack
Water Resistant
Rubber Jack
Cover
CHARGE UNIT
BEFORE USE
ABOUT 7 HOURS
Charge via USB AC
adapter (not included)
or other powered
USB port
2s
» The speaker must be on and connected with
a paired Bluetooth device to recieve calls.
» Press the Speakerphone Button to answer
incoming call. Press and hold to ignore/end
call.
USING SPEAKERPHONE
Answer Call
End Call
LED STATUS INDICATOR (TOP OF UNIT)
Solid red = charging
Red LED o = fully charged
Flashing red = low battery (not connected)
Flashing blue = pairing
Solid blue = connected to bluetooth
PMS7467C
iBT77v2 QSG-English-TopTeam
material: 260gsm2 art card, 2C + 2C
size: 240W x 100H mm
June 12, 2018
FCC Information
This device complies with Part 15 of the FCC Rules,
operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits
set forth for an uncontrolled environment.
• Warning: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
• NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
CAN ICES-3 (B)/NMB-3(B)
Canada Statement
This device complies with Industry Canada’s
licence-exempt RSSs. Operation is subject to the following
two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including
interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d’Industrie
Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux conditions
suivantes :
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
The device meets the exemption from the routine
evaluation limits in section 2.5 of RSS 102 and compliance
with RSS-102 RF exposure, users can obtain Canadian
information on RF exposure and compliance.
Le dispositif rencontre l'exemption des limites courantes
d'évaluation dans la section 2.5 de RSS 102 et la
conformité à l'exposition de RSS-102 rf, utilisateurs peut
obtenir l'information canadienne sur l'exposition et la
conformité de rf.
FCC ID: EMOIBT77V2
IC: 986B-IBT77V2
iBT77v2-180612-A(TT) Printed in China
This device uses an internal non-replaceable rechargeable
lithium-ion battery that should last the lifetime of the device.
If you suspect your battery may be dead, try charging it for
an extended period of time and try resetting the unit. If this
fails, contact Customer Service at 1-800-288-2792.
WARNING/DISPOSAL OF UNIT
Do NOT attempt to change the battery. Doing so will void
the warranty and could cause injury and damage to your
device. To dispose of the unit, follow the instructions below:
• Never dispose of used batteries/electronics with ordinary
solid wastes, since they contain toxic substances.
• Always dispose of used batteries/electronics in accordance
with the prevailing community regulations.
• Many electronics retailers now recycle batteries and other
electronic components at no charge
GENERAL BATTERY PRECAUTIONS
• Never use or charge a battery if it appears to be leaking,
discolored, deformed, or in any way abnormal.
• Never disassemble the unit or attempt to remove battery
as that could cause leakage of alkaline solution or other
electrolytic substances.
• Avoid charging a rechargeable battery when the
temperature is not within 5°C - 35° C (41° - 95°
Fahrenheit).
• Never expose a battery to any liquid.
• Never expose a battery to excessive heat such as direct
sunlight or fire. Never use a battery pack in an unventilated
vehicle where excessive internal temperatures may be
encountered.
• Always keep batteries out of the reach of infants and small
children.
Internal Rechargeable Lithium-ion Battery
Bluetooth is a registered trademark of Bluetooth SIG Inc.
Bluetooth technology is incorporated under license from Bluetooth SIG Inc.
Apple App Store and Apple Watch are trademarks of Apple Inc., registered in
the U.S. and other countries
Google Play Store is a trademark of Goggle, Inc..
