Savi Technology 612T-V1 Active RFID Tag User Manual
Savi Technology Inc Active RFID Tag
Users Manual
![](/img.php?id=185909&img=bg1.png)
6DYL7DJ6HULHV,QVWDOODWLRQ*XLGH 1
.HHS7KLV'RFXPHQW
Savi P/N 805-03671-001 (Rev. B)
The SaviTag 600 Series Tags consist of a hermetically-sealed plastic case enclosing a printed circuit
board with a non-replaceable battery. The SaviTag 605 includes an interface to a standard bolt seal
for use in security applications. See Figure 3.
• The SaviTag 602 contain three labels; one is on the face of the tag and contains the Savi Technology
logo and tag model number. The second label is also on the face of the tag and contains the tag serial
number in both bar code and numerical format. The third label is on the back surface of the SaviTag
and contains compliance markings.
The SaviTag 604 and 605 combine the Savi compliance and model number labels. This label is
located on the back surface of the SaviTag.
• The 600 Series Tags can be exposed to environments including rain, snow, and direct exposure
to sunlight.
• Tag battery life varies by model as shown in the table below. The tags contain an internal lithium
battery and should be discarded according to local safety requirements.
The lithium battery can be harmful
to the environment. Please follow
current procedures for safely
disposing of lithium batteries.
7DJ0RXQWLQJ
The 600 Series SaviTags have a variety of mounting options:
• The SaviTag 602 may be attached using adhesives.
• The SaviTag 604 has two mounting holes for attachment using screws or rivets.
• The SaviTag 605 is attached using the Bolt Seal.
The 600 Series SaviTags can be mounted on items of any material. However, the SaviTag 602
requires a 0.75 inch separation from metal surfaces.
After installation, verify tag operation by exposing it to a 600 Series Signpost and reading the Tag ID
with a 600 Series SaviReader.
Figure 1 SaviTag 602 Figure 3 SaviTag 605
Tag Model Battery Life (Years)
ST 602 4
ST 604 8
ST 605 5
Figure 2 SaviTag 604
![](/img.php?id=185909&img=bg2.png)
6DYL7DJ6HULHV,QVWDOODWLRQ*XLGH 1
.HHS7KLV'RFXPHQW
)HGHUDO&RPPXQLFDWLRQV
&RPPLVVLRQ)&&1RWLFH
The Federal Communications Commission has
established technical standards regarding radio frequency
energy that computer devices emit. This equipment has
been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference with radio/TV reception. However,
there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try and correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment
and the receiver.
•Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV
technician for assistance.
Changes or modifications to this equipment
that are not expressly approved by Savi
Technology could void the warranty and
the authority to operate this equipment.
Using this equipment in a manner not
specified by the manufacturer might impair
the protection that the equipment provides.
Savi Technology is not responsible for
radio/TV interference caused by using
unauthorized cable or by making
unauthorized changes to this equipment.
)HGHUDO&RPPXQLFDWLRQV
&RPPLVVLRQ)&&
/DEHO 6WDWHPHQW
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following conditions:
•This device may not cause harmful interference, and
•This device must accept any interference received,
including interference that may cause undesired
operation.
The label statement corresponds to the following devices:
'HFODUDWLRQRI&RQIRUPLW\
Hereby, Savi Technology, Inc., 615 Tasman Drive
Sunnyvale, California 94086-1707
declares that the SaviTag 602, 604, and 605 are in
compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
Savi Technology, Inc.
615 Tasman Drive
Sunnyvale, CA 94089-1707
Phone: (408) 743-8000
Fax: (408) 543-8650
E-mail: help@savi.com
Web site: www.savi.com
Copyright © 2001, Savi Technology, Inc. All rights reserved. First
edition printed September 2001.
Copyright protection claimed includes all forms and matters of
copyrightable material and information, now allowed by statutory
or judicial law or hereinafter granted. Information in this guide is
subject to change without notice and does not represent a
commitment from the vendor.
Savi is a registered trademark and EchoPoint is a trademark of Savi
Technology, Inc. Other product names mentioned in this guide may
be trademarks or registered trademarks of their respective owners
and are hereby acknowledged.
Device Model FCC ID
Radio Tag ST-602-01 KL7-612T-V1
Radio Tag ST-604-01 KL7-612T-V2
Radio Tag ST-605-SL1 KL7-612T-V2
