Important Safety Instructions and Product Information
BEFORE USING YOUR TELEPHONE EQUIPMENT, BASIC SAFETY INSTRUCTIONS
SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK AND INJURY TO PERSONS.
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall telephone jack and power
outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use damp cloth for cleaning.
4. Do not use this product near water, for example, near a
bathtub, wash bowl, kitchen sink, or laundry tub, in a wet
basement or near a swimming pool.
5. Place this product securely on a stable surface. Serious
damage and/or injury may result if the unit falls.
6. Slots or openings in the cabinet and the back and bottom are
provided for ventilation, to protect it from overheating.
These openings must not be blocked or covered. This product
should never be placed near or over a radiator or heat
register, or in a place where proper ventilation is not
provided.
7. This product should be operated only from the type of power
source indicated on the marking label. If you are not sure of
the type of power supply to your home, consult your dealer or
local power company.
8. Do not place objects on the power cord. Install the unit
where no one can step or trip on the cord.
9. Do not overload wall outlets and extension cords as this can
result in the risk of fire or electric shock.
10. Never push objects of any kind into this product through
cabinet slots as they may touch dangerous voltage points or
short out parts that could result in the risk of fire or
electric shock. Never spill liquid of any kind on this
product.
11. To reduce the risk of electric shock or burns, do not
disassemble this product. Take it to a qualified service
center when service is required. Opening or removing covers
may expose you to dangerous voltages, dangerous electrical
current or other risks. Incorrect reassembly can cause
electric shock when the appliance is subsequently used.
12. Unplug the product from the wall outlet and refer servicing
to qualified service personnel under the following conditions:
a. When the power cord is damaged or frayed.
![](/img.php?id=54406&img=bg2.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 99 of 129
Exhibit 8
b. If liquid has been spilled into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the
operating instructions. Adjust only those controls that
are covered by the operating instructions because improper
adjustment of other controls may result in damage and may
require extensive work by a qualified technician to restore
the product to normal operation.
e. If the product has been dropped or physically has been
damaged.
f. If the product exhibits a distinct change in performance.
13. Avoid using a telephone (other than a cordless type) during
a thunderstorm. There may a remote risk of electrical shock
from lightning.
14. Do not use the telephone to report a gas leak in the
vicinity of the leak.
BATTERY SAFETY PRECAUTIONS
To reduce the risk of fire, injury or electric shock, and to
properly dispose of batteries, please read and understand the
following instructions.
CONTAINS NICKEL CADMIUM BATTERY. BATTERY MUST BE RECYCLED
OR DISPOSED OF PROPERLY. DO NOT DISPOSE OF IN MUNICIPAL
WASTE.
1. Only use the batteries specified for use with this product.
2. DO NOT USE ALKALINE OR LITHIUM BATTERIES, or mix batteries of
different sizes or from different manufacturers in this
product.
3. Do not dispose of the batteries in a fire; the cells may
explode. Do not expose batteries to water. Check with local
codes for special disposal instructions.
4. Do not open or mutilate the batteries. Released electrolyte is
corrosive and may cause damage to the eyes or skin. The
electrolyte may be toxic if swallowed.
5. Exercise care in handling the batteries in order not to short
the batteries with conducting materials such as rings,
bracelets, and keys. The batteries or conducting material may
overheat and cause burns or fire.
6. Charge the batteries provided with, or identified for use
with, this product only in accordance with the instructions
and limitations specified in the user’s manual. Do not attempt
to charge the batteries with any means other than that
specified in the user’s manual.
7. Periodically clean the charge contacts on both the charger and
handset.
8. The RBRC™ Battery Recycling Seal on the batteries indicates
Siemens is voluntarily participating in an industry program to
collect and recycle these batteries at the end of their useful
life, when taken out of service within the United States or
Canada. The RBRC program provides a convenient alternative to
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 100 of 129
Exhibit 8
placing used batteries into the trash or municipal waste
stream, which is illegal in some areas. Please call 1-800-8-
BATTERY for information on battery recycling in your area.
Siemens involvement in this program is part of our commitment
to preserving our environment and conserving our natural
resources.
Warning: Changes or modifications to this unit not expressly
approved by Siemens Communication Devices could void the FCC
authority to operate the equipment. This includes the addition
of any external antenna device.
INDUSTRY CANADA CERTIFICATION
NOTICE: If the product has an Industry Canada label, this label
identifies certified equipment. This device requires a radio
license, unless it (including antenna) is installed totally
inside a building. (User must obtain this license from Industry
Canada). This certification means that the equipment meets
certain telecommunications network, protective, operational and
safety requirements as prescribed in the appropriate Terminal
Equipment Technical Requirements document(s). The Department does
not guarantee the equipment will operate to the user’s
satisfaction.
Before installing this equipment, users should ensure that it is
permissible to be connected to the facilities of the local
telecommunications company. The equipment must also be installed
using an acceptable method of connection. The customer should be
aware that compliance with the above conditions may not prevent
degradation of service in some situations.
Repairs to certified equipment should be coordinated by a
representative designated by the supplier. Any repairs or
alterations made by the user to this equipment, or equipment
malfunctions, may give the telecommunications company cause to
request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical
ground connections of the power utility, telephone lines and
internal metallic water pipe system, if present, are connected
together. This precaution may be particularly important in rural
areas.
CAUTION: Users should not attempt to make such connections
themselves, but should contact the appropriate electric
inspection authority, or electrician, as appropriate.
FCC INFORMATION
This telephone system complies with Part 68 of the FCC rules. On
the bottom of the base station is a label that contains, among
other information, the FCC Registration Number, Ringer
Equivalence number (REN) and the Universal Service Order Code
(USOC), which is RJ-11C, for this equipment. You must, upon
request, provide this information to your telephone company.
The REN is useful in determining the quantity of devices you may
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 101 of 129
Exhibit 8
connect to your telephone line and still have all of those
devices ring when your telephone number is called. In most, but
not all areas, the sum of the RENs of all devices connected to
one line should not exceed five (5.0). To be certain of the
number of devices you may connect to your line, as determined by
the REN, you should contact your local telephone company to
determine the maximum REN for your calling area.
If your telephone equipment causes harm to the telephone network,
the telephone company may ask you to disconnect the system from
the line until the problem has been corrected or they may
discontinue your service temporarily. If possible, they will
notify you in advance. But if advance notice isn’t practical,
you will be notified as soon as possible. You will be informed
of your right to file a complaint with FCC.
Your telephone company may make changes in its facilities,
equipment, operations, or procedures that could affect the proper
functioning of your telephone system. If they do, you will be
notified in advance to give you an opportunity to maintain
uninterrupted telephone service. If you experience trouble with
this telephone system, disconnect it from the network until the
problem has been corrected or until you are sure that the
equipment is not malfunctioning.
This telephone system may not be used on coin service provided by
the telephone company. Connection to party lines is subject to
state tariffs. Privacy of communications may not be ensured when
using this phone.
This telephone system equipment has been tested and found to
comply with the limits for Class B digital device, pursuant to
Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference
received, including interference that may cause undesired
operation. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. Some cordless telephones operate at frequencies
that may cause interference to nearby TV’s and VCR’s; to minimize
or prevent such interference, the system base should not be
placed near or on top of a TV or VCR; and, if interference is
experienced, moving the base farther away from the TV or VCR will
often reduce or eliminate the interference.
However, there is no guarantee that interference will not occur
in a particular installation. If this telephone system does
cause harmful interference to radio or television reception,
which can be determined by turning the system off and on, the
user is encouraged to try to correct the interference by one or
more of the following measures:
1. Increase the separation between the base station and receiver.
2. Connect the base station into an outlet on a circuit different
from that to which the receiver is connected.
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 102 of 129
Exhibit 8
3. Consult the dealer or an experienced radio TV technician for
help.
Notice to Hearing Aid Wearers: This phone system is compatible
with inductively coupled hearing aids.
Power Outage: In the event of a power outage, your cordless
telephone will not operate. The cordless telephone requires
electricity for operation. You should have a telephone that does
not require electricity available for use during power outages.
Limited Warranty: This limited, non-transferable warranty is
provided to the original purchaser. The product is warranted to
be free from defects in materials and workmanship under normal
installation, use, and service for period of one (1) year from
the date of purchase as shown on the purchaser’s receipt.
Our obligation under this warranty is limited to repair or
replacement (at our option) of the product or any part(s) which
are defective provided that the product is returned to the
original place of purchase or an authorized service location
during the warranty period. A copy of the purchase receipt must
accompany products returned. In the absence of a purchase
receipt, the warranty period shall be one (1) year from the date
of manufacture. Repair or replacement of the product is your
sole and exclusive remedy.
If the product is repaired, reconditioned component parts or materials may be used. If the
product is replaced, we may choose to replace it with a new or reconditioned product of the same
or similar design. The repaired or replacement product will be warranted for either (a) 90 days or
(b) the remainder of the original one (1) year warranty period, whichever is longer. Batteries
provided are warranted for the same time period.
This warranty does not apply to defects outside of our control,
including but not limited to acts of God, fire, flood, damage
while in transit to service facility. We do not warranty that
the product will be compatible with any telephone equipment or
systems or party lines.
This warranty shall be void if the product is damaged as a result
of defacement, misuse, abuse, neglect, accidents, destruction, or
alteration of the serial number, improper electrical voltages or
currents, repair, alteration or maintenance by any person or
party other than our authorized service facility or any violation
of instructions furnished by us.
This warranty is also void if this product is removed from the
country in which the original purchaser purchased it, if it is
used in a country, which it not registered for use, or if it is
used in a country for which it was not designed. Due to
variations in telephone systems and communications laws, this
product may be illegal for use in some countries. We assume no
responsibility for damages or penalties incurred resulting from
the use of this product in a manner or location other than that
for which it is intended.
THIS ONE-YEAR LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 103 of 129
Exhibit 8
EXPRESS OR IMPLIED. ANY IMPLIED WARRANTIES, INCLUDING BUT NOT
LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, SHALL BE LIMITED IN DURATION TO THE
ONE-YEAR DURATION OF THIS WRITTEN LIMITED WARRANTY. WE DISCLAIM
ANY LIABILITY FOR DAMAGES FOR LOSS OF USE OF THE PRODUCTS, LOSS
OF TIME, INCONVENIENCE, INJURY TO CUSTOMER OR ANY OTHER PERSON,
OR DAMAGE TO CUSTOMER PROPERTY CAUSED BY THE PRODUCT, LOSS OF
REVENUE OR PROFIT, OR DAMAGES FOR ANY FAILURE TO PERFORM. IN NO
EVENT SHALL WE BE LIABLE FOR ANY SPECIAL, INCIDENTAL, PUNITIVE OR
CONSEQUENTIAL DAMAGES EVEN IF WE ARE ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES.
Some states do not allow limitations on how long an implied
warranty lasts, so the above limitations may not apply to you.
This warranty is the sole and exclusive warranty provided for the
product. There are no other express warranties. This warranty
gives you specific legal rights, and you may also have other
rights, which vary from state to state.
Siemens Communication Devices
Siemens is a registered trademark of Siemens AG.
Siemens Communication Devices is a division of Siemens
Information and Communication Products, LLC.
RBRC™ is a trademark of the Rechargeable Battery Recycling
Corporation.
Information subject to change since Siemens reserves the right,
without notice, to make changes in equipment design or components
as progress in engineering or manufacturing methods warrant.
Order Number: XXXX Part Number: YYYY
© copyright 1999 – Feb
![](/img.php?id=54406&img=bg7.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 104 of 129
Exhibit 8
User’s Manual
M
Mo
od
de
el
l
2
24
42
2
C
Co
or
rd
dl
le
es
ss
s
P
Ph
ho
on
ne
e
w
wi
it
th
h
C
Ca
al
ll
le
er
r
I
ID
D
(a) WELCOME
Congratulations on your purchase of the Siemens 242 cordless
telephone. This phone has been designed with state of the art
2.4 GHz technology and will provide you with unsurpassed digital
sound quality and security.
Package Contents
If an item listed below is not included in your package, please
contact your local Siemens dealer. (this section should have each
piece identified with a small picture of the piece)
• Handset (Diagram)
• Base (Diagram)
• Rechargeable Battery Pack (Diagram)
• AC Power Adapter / Telephone Line Cord (Diagram)
• Memory Number Label (Diagram)
Installation and Setup
Warning! Use only the Siemens AC power adapter supplied with
this phone. DO NOT use an outlet controlled by a wall switch.
Installing the AC Power Adapter and Base
The AC power adapter has two cords ending in plastic connectors.
The larger of the two connectors (RJ 45) plugs into the base. The
smaller of the two connectors (RJ 11) plugs into a wall telephone
jack. The AC power adapter plugs into an electrical wall outlet.
Desk / Table Installation (Diagram)
1. Plug the large connector (RJ 45) into the Base.
2. Plug the AC power adapter into a wall outlet (standard 110/120
VAC).
3. Plug the small connector (RJ 11) into a wall telephone jack.
Wall Installation (Diagram)
1. Plug the large connector (RJ 45) into the base (diagram).
2. Plug the small connector (RJ 11) into the wall telephone jack.
3. Align the mounting holes on the back of the base to the
mounting posts on the wall plate (not included).
4. Push the base down over the mounting posts until it is tight.
![](/img.php?id=54406&img=bg8.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 105 of 129
Exhibit 8
5. Plug the AC power adapter into the wall outlet (standard
110/120 VAC).
If you do not have a standard wall plate, mount the base
directly to the wall (mounting screws not included).
Installation Tips
Fully charge the battery pack 12 hours before first using the
phone.
To get the maximum distance and the best sound quality from your
handset,
• Install the base away from electrical appliances such as
televisions, personal computers, microwave ovens, and other
cordless phones.
• Install the base in a high, central location with few
obstructions.
• Operate the handset awayfrom appliances and other cordless
phone base units.
Preparing the Handset
Installing / Replacing the Battery Pack (Diagram)
1. Press in on the battery cover release.
2. Slide the battery cover off the handset (Diagram).
3. Plug the plastic connector of Battery Pack into the socket
inside the battery compartment of the handset (Diagram).
4. Insert the Battery Pack into the battery compartment.
5. Slide the battery cover onto the handset; listen for a snap
(Diagram).
Charging the Battery
1. Place the handset in the base for 12 hours before first use
(Diagram).
2. Place the handset in the base for 8 to 12 hours to recharge.
The battery cannot be overcharged.
The handset may face to the front or back while it is in the
base (Diagram).
Maximizing Battery Performance
A fully charged battery pack lasts for approximately
• 4 hours when using the handset continuously (talk time)
• 7 dayswhen the handset is not in use (stand-by time)
To maximize battery performance
![](/img.php?id=54406&img=bg9.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 106 of 129
Exhibit 8
• Place the handset in the base when not in use
• Clean the charging contacts on the handset and base once each
month.
To clean the charging contacts, use a pencil eraser or other
contact cleaner. Do not use liquids or solvents they can damage
your phone.
RBRC Logo goes here
Setting Basic Features
Adjusting the Ring Volume and Turning the Ringer Off/On
1. Press MENU.
2. Press the 6 key once to move to “RING VOLUME?”.
3. Press OK to select “RING VOLUME?” (the current setting will
sound)
4. Press the 5or 6 key to change the ring volume or turn it
off/on
Each time a new volume is selected the ring will sound. If the
ringer is turned off the display will read “Ringer Off.”
5. Press OK to save.
6. Press MENU to exit.
4 RING VOLUME?
RING TONE?
RING VOLUME
2RING VOLUME
RINGER OFF
OR
![](/img.php?id=54406&img=bga.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 107 of 129
Exhibit 8
Selecting a Ring Tone
1. Press MENU.
2. Press the 6 key twice to move to “RING TONE?”.
3. Press OK .to select “RING TONE?”(current tone will sound).
4. Press 1 , 2 , 3 , or 4 to change the ring tone (selected
tone will sound).
5. Press OK to save the ring tone setting.
6. Press MENU to exit.
Selecting Tone or Pulse Dialing
To set the dial mode used by your local phone service (tone or
pulse),
1. Press MENU.
2. Press the 6 key three times to move to “DIAL MODE?”
3. Press OK .to select “DIAL MODE?”.
4. Press the 5or 6 key to change between tone and pulse.
5. Press OK to select dial tone setting.
6. Press MENU to save the setting.
Storing Your Local Area Code (for use with Caller ID services)
When you program a local area code, calls from that area code
will be stored in the call log without the area code. This makes
4 RING TONE?
DIAL MODE?
RING TONE
2
4 DIAL MODE?
YOUR AREA CODE?
TONE DIAL
5 6 TO CHANGE
PULSE DIAL
5 6 TO CHANGE
OR
![](/img.php?id=54406&img=bgb.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 108 of 129
Exhibit 8
a local number readily available for call back or for moving it
to a memory location. To store the local area code,
1. Press MENU.
2. Press the 6 key four times to move to “YOUR AREA CODE?”
3. Press OK .to select “YOUR AREA CODE?”.
4. Enter the local area code.
5. Press OK to save the local area code.
6. Press MENU to exit.
Do not store the local area code in areas with 10-digit
dialing. If an area code changes from 7-digit to 10-digit
dialing, repeat steps 1 through 4 to delete the area code.
Programming Caller ID on Call Waiting (for use with Caller ID
services)
The phone comes from the factory with Caller ID on Call Waiting
turned on. If you do not subscribe to Call Waiting or your local
telephone company does not provide Caller ID on Call Waiting it
is advisable to turn this feature off.
1. Press MENU.
2. Press the 6 key five times to move to “CALL WAIT ID?”.
3. Press OK .to select “CALL WAIT ID?”.
4. Press the 5or 6 key to select on or off.
4CALL WAIT ID?
LANGUAGE?
CALL WAIT ID ON
5 6 TO CHANGE
CALL WAIT ID OFF
5 6 TO CHANGE
4YOUR AREA CODE?
CALL WAIT ID?
ENTER AREA CODE
_ _ _
OR
![](/img.php?id=54406&img=bgc.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 109 of 129
Exhibit 8
5. Press OK to save the setting.
6. Press MENU to exit.
Selecting the Language to Display
To select the language for screen display text,
1. Press MENU.
2. Press the 6 key six times to move to “LANGUAGE?”.
3. Press OK .to select “LANGUAGE?”.
4. Press the 5or 6 key to change the language.
Or
Or
5. Press OK to save the language setting.
6. Press MENU to exit.
Using the Handset Placing a Call
1. Press TALK to get a dial tone.
2. Dial the number
OR
If you would like to view or edit the number before connecting
(composed dialing).
1. Dial the number (Press DEL/MUTE .to delete any wrong digits)
2. Press TALK to connect the call.
4LANGUAGE?
MEMORY DIAL?
ENGLISH
5 6 TO CHANGE
FRANCAIS
5 6 POUR CHANGER
ESPANOL
5 6 PARA CAMBIAR
![](/img.php?id=54406&img=bgd.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 110 of 129
Exhibit 8
Note: The display will show a maximum of 16 digits. If more than
16 are used, the digits at the left of the display move off the
screen as additional digits are dialed.
Note: The call timer will activate when you press TALK.
Answering a Call
1. Remove the handset from the base
OR
2. press TALK ..
Ending a Call
1. Place the handset in the base
OR
2. press TALK .
Redialing a Number
To immediately redial the last number dialed,
1. Press TALK .
2. Press REDIAL/PAUSE .
To display and/or edit the last number dialed,
1. Press REDIAL/PAUSE to display the last number dialed.
2. Press DEL/MUTE .to delete any wrong digits.
3. Press TALK .to dial.
Active Call Features
The following features are only available while you are on an
active call.
Changing the Handset’s Earpiece Volume
1. Press the 5or 6 key to change the handset volume.
2. The earpiece volume is displayed as a digit (1-5)
Turning Mute On and Off
Mute allows you to hear the other caller, but the other caller
cannot hear you. To turn mute on or off,
1. Press MUTE to turn mute on (the display will read “MUTE
JOHN DOE
MUTE ON
![](/img.php?id=54406&img=bge.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 111 of 129
Exhibit 8
ON”).
2. Press MUTE again to turn mute off.
Answering Call Waiting
If you subscribe to a call waiting (or 3-way calling) service
from you local phone company,
1. Press FLASH to answer the second call (or to make a second
call).
2. Press FLASH again to return to the first call (or to
complete the 3-party call).
Speed Dialing and Memory Numbers
Speed dialing enables you to store up to 10 memory numbers for
instant dialing. Each number can have up to 22 digits (including
pauses).
Adding a Memory Number
1. Press MENU to add a memory number.
2. Press OK to select “MEMORY DIAL?”.
3. Press the 5or 6 key to move to the desired memory location.
4. Enter the number (dialing string) to store in the memory
location.
• Press REDIAL/PAUSE to enter a 2-second pause, displayed
as “P.”
• Press * to temporarily switch to tone dialing.
4 MEMORY DIAL?
RING VOLUME?
1: _ _ _ _ _ _ _
_ _ _ _ _
_ _ _ _ _ _ _ _
1: 233-455-6777
![](/img.php?id=54406&img=bgf.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 112 of 129
Exhibit 8
5. Press OK to save the number.
6. Press MENU to exit.
Dialing a Memory Number
1. Press TALK .
2. Press MENU .t
3. Press a memory location (0 to 9); the number is displayed and
dialed.
Dialing Multiple Memory Numbers with Chain Dialing
To dial more than one memory number (such as a bank account
number or password),
1. Press TALK .
2. Press MENU .t
3. Press the first memory location (0 to 9); the number is
displayed and dialed.
4. When prompted by voice or tone to enter another number, press
MENU .
PRESS MEMORY
DIAL LOCATION
1: 233-455-6777
0:00
PRESS MEMORY
DIAL LOCATION
1: 233-455-6777
0:00
PRESS MEMORY
DIAL LOCATION
![](/img.php?id=54406&img=bg10.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 113 of 129
Exhibit 8
5. Press the second memory location (0 to 9); the number is
displayed and entered.
6. Repeat steps 4 to 5 as needed to dial additional numbers.
Deleting or Changing Memory Number
1. Press MENU.
2. Press OK to select “MEMORY DIAL?”.
3. Press the memory location (0 to 9) you want to delete or
change.
4. Press DEL / MUTE to delete some or all the digits or enter
the new number (dialing string).
5. Press OK to save the number.
6. Press MENU to exit.
Memory Numbers Reference Label
For easy reference to memory numbers,
1. List the memory numbers beside the corresponding memory
location number on the label supplied.
2. Place the label on the base or back of the handset.
Base Operation
Locating the Handset with the Page feature
1. Press PAGE on the base.
2: 344-566-7888
0:10
1: 233-455-6777
0:00
2: 455-677-8888
4 MEMORY DIAL?
RING VOLUME?
PRESS MEMORY
DIAL LOCATION
![](/img.php?id=54406&img=bg11.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 114 of 129
Exhibit 8
2. The handset beeps every seconds for 30 seconds and displays
“paging from base”
3. Repeat as needed to locate the handset.
4. Press any button on the handset to end the Page.
Page does not work if the handset is connected to a call or
receiving a call.
Caller ID Operation Receiving Caller ID
1. Caller ID name and number display when a call is received.
2. After 1 minute, the number changes to the call timer.
The caller’s name and number will not be displayed in the
following cases:
• The call is made through a telephone company that does not
offer caller ID services. In this case “UNKNOWN” will be
displayed. (show screen)
• The call was “blocked.” For privacy reasons many phone
companies allow callers the option to prevent their telephone
data from being displayed. In this case “PRIVATE” will be
displayed. (show screen)
Receiving Caller ID from Call Waiting
If a second call is received during a call,
1. The new name and number displays.
2. After 10 seconds, the first Caller ID information returns to
JOHN DOE
222-555-1234
JOHN DOE 0:03
SALLY SMITH
333-888-1234
JOHN DOE 0:20
![](/img.php?id=54406&img=bg12.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 115 of 129
Exhibit 8
the display.
Call Log Operation
When the handset is idle, the display indicates the number of new
calls in the Caller ID call log (if you subscribe to caller ID
services). A maximum of 30 call log entries can be stored in the
order they were received. When the call log is full, the oldest
entry is removed and the newest entry is added.
Viewing the Call Log
1. To review the call log entries, the phone must be idle.
2. Press the 5or 6 key to display call log entries.
3. Continue pressing the 5or 6 key to scroll through and display
all the call log entries.
4. When you reach the end of the call log press the 5 key to
return to the top of the call log.
5. Press OK to exit the call log and return the phone its idle
state.
Calling Back Numbers from the Call Log
To dial a call stored in the call log,
1. Select the call log entry you wish to dial (following steps 1-
3 above).
2. Press TALK to dial the selected number.
JOHN DOE
222-555-1234
12/01 11:30
AM
NEW CALLS: 30
5 6 TO CHANGE
* * * * * END *
* * * *
JOHN DOE
222-555-1234
12/01 11:30
AM
![](/img.php?id=54406&img=bg13.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 116 of 129
Exhibit 8
If the call you wish to dial requires a 1 before the dialing
string (a long distance call) or a 0 (connecting through the
operator) simply press the 1 or 0 before pressing TALK and the
number will be automatically inserted at the beginning of the
dialing string.
Moving Call Log Entries to Memory Locations
1. Select the call log entry to move to a memory location (see
“viewing the call log” steps 1-3).
2. Press MENU to open the call log menu.
3. Press OK .to select “MOVE TO MEMORY”.
4. Press a memory location (0 to 9) to store the number.
5. The display returns to the call log entry.
Moving a log entry to a memory location does not delete the
number from the call log.
If you select a memory location with a memory number, that
number will be replaced with the number moved from the call log.
Deleting a Call Log Entry
1. Select the call log entry to delete (see “viewing the call
SALLY SMITH
333-888-1234
12/10 08:00
PM
4 MOVE TO MEMORY?
DEL ALL CALLS?
SAVE NUMBER TO
MEM LOCATION: 0-
9
SALLY SMITH
333-888-1234
12/10 08:00
PM
![](/img.php?id=54406&img=bg14.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 117 of 129
Exhibit 8
log” steps 1-3).
2. Press DEL/MUTE to delete the call log entry.
3. The next call log entry received will display (or END, if no
entries remain).
Delete All Call Log Entries
1. Select any call log entry.
2. Press MENU to open the call log menu.
3. Press the 6 key once to move to “DEL ALL CALLS?”.
4. Press OK .to select “DEL ALL CALLS?”.
5. Press OK .to confirm the deletion of the call log and return
to idle.
Note: Caller ID information will not be displayed if the handset
is in the programming or call log menu:
JOHN DOE
222-555-1234
12/01 11:30
AM
4 MOVE TO MEMORY?
DEL ALL CALLS?
PRESS OK
TO CONFIRM
MOVE TO MEMORY?
4 DEL ALL CALLS?
NEW CALLS: 0
5 6 TO CHANGE
![](/img.php?id=54406&img=bg15.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 118 of 129
Exhibit 8
• To stop the current operation and display Caller ID
information, press MENU. To answer the call, press TALK.
• To stop the current operation and answer the call, press TALK.
Caller ID information displays while connected to the call.
Warnings Battery Low Warnings
The battery pack needs to be recharged when the handset beeps 3
times every 30 seconds and displays “Battery Low”.
Out of Range Warnings
The handset is too far away from the base to operate when the
handset beeps 3 times every 30 seconds and displays “OUT OF
RANGE”.
An active call is disconnected if out of range for more than 3
seconds. Move the handset closer to the base to make a new call.
Troubleshooting
Problem
The base light does not come on when the handset is placed in the
base.
Solution
Make sure AC adapter is plugged into the base and wall outlet.
Make sure the handset is placed securely in the base.
Make sure the charging contacts on the handset and base are
clean.
NEW CALLS: 0
OUT OF RANGE
NEW CALLS: 0
BATTERY LOW
![](/img.php?id=54406&img=bg16.png)
COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-6954
FCC ID: L82-242240
Page 119 of 129
Exhibit 8
Problem
The audio sounds weak or scratchy.
Solution
Move the handset or base to a different location.
Avoid locating the handset or base near metal objects or
appliances.
Problem
Unable to make or answer calls with the handset.
Solution
Make sure the AC adapter is plugged into the base, wall outlet,
and telephone jack.
Disconnect the AC adapter for a few minutes, and then reconnect
it.
Place the handset back on the charging cradle for a few seconds.
Problem
The handset does not ring or receive a page.
Solution
The battery pack may be weak and may need to be charged for 8 to
12 15 to 20 hours.
Move the handset closer to the base.
Move the base away from appliances or metal objects.
Place the handset on the base for a few seconds.
Problem
A call is disconnected when the handset is out of the base.
Solution
Check to see if the handset light is flashing, indicating the
battery needs to be charged.
Make sure the AC power adapter is plugged into the base.
Make sure the AC power adapter is plugged into the wall outlet.
Customer Service
For customer service in the US or Canada Call (888) 777-0211.
