Safety and Support
Sécurité et support technique
Seguridad y soporte técnico
Before using this product, carefully read the supplied documentation and retain it for future reference.
Avant d'utiliser ce produit, lisez attentivement la documentation fournie et conservez-la pour pouvoir la consulter ultérieurement.
Antes de utilizar este producto, lea detenidamente la documentación suministrada con el mismo y consérvela para consultarla en el futuro.
2-894-628-11(1)
01FR01COV.fm Page 1 Thursday, September 7, 2006 10:19 AM
![](/img.php?id=704278&img=bg2.png)
masterpage:Left
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB02WAR.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
2WARNING
To avoid electrical shock, do not open the cabinet. Refer
servicing to qualified personnel only.
Caution
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
The use of optical instruments with this product will increase
eye hazard.
This appliance is classified as a CLASS 1 LASER product under IEC60825-
1+A2:2001.
This equipment complies with FCC/IC radiation exposure limits set forth for
uncontrolled equipment and meets the FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF)
Exposure rules. This equipment should be installed and operated with at least 20 cm
and more between the radiator and person's body (excluding extremities: hands,
wrists, feet and legs).
This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter.
The wireless controller complies with FCC/IC radiation exposure limits set forth for
uncontrolled equipment and meets the FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF)
Exposure rules. This equipment has very low levels of RF energy that are deemed to
comply without testing of specific absorption ratio (SAR).
NOTE:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
WARNING
01GB01COV.book Page 2 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg3.png)
masterpage:Right
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB02WAR.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
3
WARNING
USUS
About the lithium coin memory back-up battery
The lithium coin memory back-up battery inside this product contains Perchlorate.
The following statement is required by the State of California, USA:
Perchlorate Material - special handling may apply, See
http://www.dtsc.ca.gov/hazardouswaste/perchlorate.
A very small percentage of individuals may experience epileptic seizures or
blackouts when exposed to certain light patterns or flashing lights. Exposure to
certain patterns or backgrounds on a television screen or when playing video games
may trigger epileptic seizures or blackouts in these individuals. These conditions
may trigger previously undetected epileptic symptoms or seizures in persons who
have no history of prior seizures or epilepsy. If you, or anyone in your family, has an
epileptic condition or has had seizures of any kind, consult your physician before
playing.
IMMEDIATELY DISCONTINUE use and consult your physician before
resuming gameplay if you or your child experience any of the following health
problems or symptoms:
• dizziness,
• altered vision,
• eye or muscle twitches,
• loss of awareness,
• disorientation,
• seizures, or
• any involuntary movement or convulsion.
RESUME GAMEPLAY ONLY ON APPROVAL OF YOUR PHYSICIAN.
Use and handling of video games to reduce the likelihood of a
seizure
• Use in a well-lit area and keep as far away as possible from the television screen.
• Avoid large screen televisions. Use the smallest television screen available.
• Avoid prolonged use of the PS3™ system. Take a 15-minute break during each
hour of play.
• Avoid playing when you are tired or need sleep.
If you have questions about this product, call our technical support line at
1-800-345-7669, or write to:
Sony Computer Entertainment America
Consumer Services/Technical Support
PO Box 5888, San Mateo, CA 94402-0888 U.S.A.
This device complies with Part 15 of the FCC Rules and RSS-Gen of IC
Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation of this device.
Declaration of Conformity
Trade Name :
Model No. :
Responsible Party :
Address :
Telephone No. :
SONY
CECHA01
Sony Electronics Inc.
16530 Via Esprillo
San Diego, CA 92127 U.S.A.
858-942-2230
Photosensitivity/Epilepsy/Seizures
01GB01COV.book Page 3 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg4.png)
masterpage:Left
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB02WAR.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
4WARNING
Radio waves may affect electronic equipment or medical devices (for example,
pacemakers), which may cause malfunctions and possible injuries.
• If you use a pacemaker or other medical device, consult your physician or the
manufacturer of your medical device before using the wireless networking feature.
• Do not use the wireless networking feature in the following locations:
– Areas where wireless network use is prohibited, such as in hospitals. Abide by
medical institution regulations when using the system on their premises.
– Areas near fire alarms, automatic doors and other types of automated equipment.
Some PlayStation®2 or PlayStation® format software titles may perform differently
on this system than they do on PlayStation®2 or PlayStation® systems, or may not
perform properly on this system. For more information, visit our Web site at
http://www.us.playstation.com or call SCEA Consumer Services at 1-800-345-7669.
Sony Computer Entertainment Inc. uses DNAS (Dynamic Network Authentication
System), a proprietary authentication system, to help protect copyright and security
in connecting the PS3™ system to a network. DNAS may retrieve information about
a user's hardware and software for authentication, copy protection, account blocking,
system, rules, or game management and other purposes. The information collected
does not identify the user personally. The unauthorized transfer, exhibition, export,
import or transmission of programs and devices circumventing its authentication
scheme may be prohibited by law.
System software included within this product is subject to a limited license from
Sony Computer Entertainment Inc. Refer to http://www.scei.co.jp/ps3-eula.
Radio waves
PlayStation® and PlayStation®2 format software
About DNAS
System software
01GB01COV.book Page 4 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg5.png)
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
5
masterpage:Left
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB01COVTOC.fm]
US
WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
About the PS3™ system documentation . . . . . . . . . . . . . . . . . . . 5
xBefore use
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
xTroubleshooting
Before requesting service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
LIMITED HARDWARE WARRANTY AND LIABILITY . . . . . . . . 13
xAdditional information
Removing / replacing the hard disk . . . . . . . . . . . . . . . . . . . . . . 15
Caution on disposal of the PS3™ system . . . . . . . . . . . . . . . . . 17
Wireless controller battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
The PS3™ system documentation includes the following:
Safety and Support (this document)
This document contains safety information related to the use of the PS3™ system,
troubleshooting, specifications and other information.
Quick Reference
This document contains information on setting up the PS3™ system, preparing for
use and basic hardware operations.
User's Guide (http://manuals.playstation.net/document/)
This online document is accessed through the Internet and contains detailed
information related to use of the PS3™ system software.
Notice
For up-to-date information regarding the PS3™ system, visit http://www.us.playstation.com.
Table of contents About the PS3™ system documentation
01GB01COV.book Page 5 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg6.png)
masterpage:Left
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB03PRE.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
6Precautions
This product has been designed with the highest concern for safety. However, any
electrical device, if used improperly, has the potential for causing fire, electrical
shock or personal injury. To help ensure accident-free operation, follow these
guidelines:
• Observe all warnings, precautions and instructions.
• Regularly inspect the AC power cord for damage.
• Stop use, unplug the AC power cord from the electrical outlet and disconnect any
other cables immediately if the device functions in an abnormal manner, produces
unusual sounds or smells or becomes too hot to touch.
• Call SCEA Consumer Services at 1-800-345-7669 if the device does not operate
properly.
• Use in a well-lit area and keep as far away as possible from the television screen.
• Avoid prolonged use of the PS3™ system and wireless controller.
• Stop using the system immediately if you begin to feel tired or if you experience
discomfort or pain in your hands or arms while operating the wireless controller. If
the condition persists, consult a doctor.
• If you experience any of the following health problems, discontinue use of the
system immediately. If symptoms persist, consult with your physician.
– Dizziness, nausea, fatigue or symptoms similar to motion sickness
– Discomfort or pain in a part of the body, such as eyes, ears, hands or arms
• Keep the system and accessories out of the reach of small children.
• Do not connect cables other than a USB cable while the system is turned on
(indicator red).
• Do not touch the system or connected cables or accessories during an electrical
storm.
• Do not use the system or accessories near water.
• Do not allow liquid, small particles or other foreign objects to get into the system
or accessories.
• Do not touch the connectors of the system or accessories.
• Do not expose the system or accessories to dust, smoke or steam. Also, do not place
the system in an area subject to excessive dust or cigarette smoke. Dust build-up or
cigarette smoke residue on the internal components (such as the lens) may cause
the system to malfunction.
• Do not expose the system or accessories to high temperatures, high humidity or
direct sunlight.
• Do not place the system or accessories on surfaces that are unstable, tilted or
subject to vibration.
• Do not set the system other than in the vertical or horizontal position. Also, do not
change the position while the system is turned on.
• Be careful when carrying the system. If you do not have a good grip or attempt to
carry by holding the slot cover on the system front, the system may drop causing
potential damage or injury.
• Do not move or change the position of the system with a disc inserted. The
vibration may result in scratching of the disc or the system.
• Do not stand on or put objects on the system, and do not stack the system with other
devices.
• Be careful not to pinch your fingers in the slot cover.
• Do not place the system and connected accessories on the floor or in a place where
they may cause someone to trip or stumble.
• Do not allow bodily contact with the system or air from the system vents for an
extended period of time while in use. Extended contact under these conditions may
cause low-temperature burns.
• When connecting the system to a plasma or projection* TV, do not leave a still
image on the TV screen for an extended period of time, as this may leave a faint
image permanently on the screen.
*Except LCD screen types
• Parents are encouraged to monitor children in online activities to ensure safe and
responsible Internet usage.
Before use
Precautions
Safety
Use and handling
01GB01COV.book Page 6 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg7.png)
masterpage:Right
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB03PRE.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
7
Precautions
US
Before use
Do not block any vents. To maintain good ventilation, follow the guidelines below:
• Place the system at least 10 cm (4 in) away from a wall surface.
• Do not place on a carpet or rug with long fibers.
• Do not place in a narrow or cramped space.
• Do not cover with cloth.
• Do not allow dust to build up on the vents.
• To help ensure safe operation, regularly inspect the AC power cord. If damaged,
stop use immediately and call SCEA Consumer Services at 1-800-345-7669 for
assistance.
• Do not use a power cord other than the supplied AC power cord. Do not modify
the cord.
• Do not touch the plug of the AC power cord with wet hands.
• Protect the AC power cord from being walked on or pinched particularly at plugs,
expansion receptacles and the point where the cord exits from the system.
• Do not place heavy items on the cord.
• Do not place the AC power cord near heating equipment and do not expose the cord
to heat.
• Unplug the AC power cord from the electrical outlet before cleaning or moving the
system, or when you do not intend to use the system for an extended period of time.
When disconnecting, grasp the power cord by the plug and pull straight out of the
electrical outlet. Never pull by the cord and do not pull out at an angle.
• Do not connect the AC power cord to a voltage transformer or inverter. Connecting
the AC power cord to a voltage transformer for overseas travel or an inverter for
use in an automobile may cause heat to build up in the system and may cause burns
or a malfunction.
Use the PS3™ system and accessories according to the instructions in the product
documentation. No authorization for the analysis or modification of the system or
accessories, or the analysis and use of its circuit configurations, is provided.
Unauthorized modification of the system or accessories will void your warranty.
There are no user serviceable components inside the PS3™ system (the supplied
hard disk may be removed but not disassembled or modified). Additionally, there is
a risk of exposure to laser radiation as well as to electrical shock.
• A broadband connection is required to access the Internet. Note that dial-up
connectivity is not supported.
• User is responsible for Internet service fees. For details, refer to the information
provided in your service contract or contact your Internet service provider.
• Use only an Ethernet cable compatible with 10BASE-T, 100BASE-TX or
1000BASE-T networks. Do not use a cord for a standard residential telephone line
or cables of types other than those mentioned here. Using the wrong type of cord
or cable can cause more electrical current than necessary to flow through the LAN
connector, which may lead to heat build-up, fire or malfunction.
• When using the PS3™ system's scan function to select a wireless LAN access
point, access points that are not intended for public use may be displayed. Only
connect to an access point that you are authorized to use.
If the system or disc is brought directly from a cold location to a warm one, moisture
may condense on the lens inside the system or on the disc. Should this occur, the
system may not operate properly. In this case, remove the disc and turn off and
unplug the system. Do not put the disc back in until the moisture evaporates (this may
take several hours). If the system still does not operate properly, call SCEA
Consumer Services at 1-800-345-7669 for assistance.
Vents
AC power cord use
Never disassemble or modify the system or accessories
Network
Moisture condensation
01GB01COV.book Page 7 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg8.png)
masterpage:Left
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB03PRE.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
8Precautions
For safety reasons, before cleaning the system or connected accessories, disconnect
the AC power cord from the electrical outlet.
Exterior surfaces (plastic cover of system and wireless
controller)
Follow the instructions below to help prevent the product exterior from deteriorating
or becoming discolored.
• Wipe with a soft, dry cloth.
• Do not place any rubber or vinyl materials on the product exterior for an extended
period of time.
• Do not use solvents or other chemicals. Do not wipe with a chemically-treated
cleaning cloth.
Vents
When dust accumulates in the system vents, remove the dust with a low-powered
vacuum cleaner.
Backing up data
It is recommended that you regularly back up any data on the hard disk that is of a
type that can be backed up. If for any reason software or data loss or corruption
occurs, it may not be possible to restore or repair the software or data. Sony
Computer Entertainment Inc. and its subsidiaries and affiliates will not be held liable
for damage or injury related to software or data loss or corruption.
xFile types that can be backed up
The following file types saved on the system's hard disk can be backed up by copying
the files to storage media or a USB device. Select the file that you want to copy, press
the button, and then select "Copy" from the options menu.
You may not be able to copy files that contain copyright-protected data.
The 2.4 GHz range of radio waves used by the wireless networking feature of this
product is a range shared by various devices. This product has been designed to
minimize the effect of other devices using the same range. However, in some cases
interference from other devices may reduce the connection speed, shorten the signal
range or cause the connection to be terminated unexpectedly.
Note on compatibility
Some media may have region or territorial restrictions and may not work with your
system. See media packaging for details.
Handling
• Do not touch the disc surface when handling a disc; hold it by the edges.
• Do not stick paper or tape onto discs and do not write on discs.
• Fingerprints, dust, dirt or scratches on the disc can distort the picture or reduce
sound quality. Always handle carefully and check that discs are clean before use.
Storage
• Do not expose discs to high temperatures, high humidity or direct sunlight.
• When discs will not be used for an extended period of time, store them in their
cases. Stacking uncased discs or storing them at an angle can cause them to warp.
Cleaning
Hard disk
File type Back up destination
Video, audio, image files
Memory Stick™ media, SD Memory Card,
CompactFlash®, USB mass storage device (USB
flash drive, etc.)
Saved data from games Memory Stick™ media
Wireless networking feature
Discs
01GB01COV.book Page 8 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg9.png)
masterpage:Right
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB03PRE.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
9
Precautions
US
Before use
Cleaning method
• Clean discs with a soft cloth, lightly wiping from the center outwards.
• Do not use solvents, record cleaners, anti-static spray or
other chemicals as these can damage the discs.
01GB01COV.book Page 9 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bga.png)
masterpage:Left
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB04GET.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
10 Before requesting service
Go through this section if you experience difficulty in operating the PS3™ system.
Should any problem persist, call SCEA Consumer Services at 1-800-345-7669 for
assistance. For additional support information, visit our Web site at
http://www.us.playstation.com.
The system does not turn on.
,Check that the main power switch on the system rear is turned on.
,Check that the AC power cord is securely inserted in the system and the electrical
outlet.
There is no picture on the TV screen.
,Check that the input mode of the TV is appropriate for the connector in use on
the system.
,There may be a problem with the AV cable in use. Try using another cable that
is compatible with the PS3™ system.
,If the video output settings on the system do not match those of the cable or TV
in use, there may be no picture. If the screen goes blank, turn off the system.
Then, with only the system and the TV connected, touch the system's power
button for more than 5 seconds to turn the system back on. The video output
settings will automatically be reset to the standard resolution.
,If the resolution of the video content is not supported by the TV in use, when the
video is played the screen may go blank. If this happens, go to the screen for
selecting the resolution in the system's video output settings, select "Custom",
and then select all the resolutions that are supported by the TV.
The Blu-ray Disc (BD) or DVD cannot be played, or the picture is
distorted.
,When outputting DVD content or PLAYSTATION®3 format software in SD
resolution, only discs recorded in the NTSC standard can be played.
,If the system is connected to a VCR or a combination TV/VCR unit, copy
protection encoding on some BDs and DVDs may cause image distortion, or may
cause the image to become lighter or darker. In such cases, connect the system to
the TV directly.
,If the BD or DVD does not match the region code set in the system, it cannot be
played.
,Some DVDs are preset with parental control restrictions. Enter the password that
was set in "Security Settings" to temporarily increase the viewer age restriction
level.
,Some BDs are preset with parental control restrictions. Enter the password that
was set in "Security Settings" to change the parental control level.
,The BD may be disc-locked. Enter the password that was set when the disc was
created.
,See also the notices under "Playable discs" ( page 20).
The size of the video image and the TV screen do not match.
,Check that the system's video output settings are correct.
,Check that the settings of the connected TV are correct. For details, refer to the
instructions supplied with your TV.
,With some video content, the screen size cannot be changed.
The screen color does not seem right.
,The system's background color changes automatically in time with the hour of
the day.
There is no sound.
,Check that the muting function on the TV or speakers is turned off. Also check
that the volume is at the appropriate level.
Troubleshooting
Before requesting service
Power
Audio
01GB01COV.book Page 10 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bgb.png)
masterpage:Right
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB04GET.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
11
Before requesting service
Troubleshooting
US
,If an audio device is connected, check the settings of the device. For details, refer
to the instructions supplied with the audio device.
,There may be a problem with the AV cable. Try using another cable that is
compatible with the PS3™ system.
,Some software do not support digital audio output.
,If the system's audio output settings do not match the AV cable or device in use,
the system may not produce sound. Check that the system's audio output settings
are correct.
,Some content that support Dolby Digital, DTS, and other formats may not
produce audio from all channels.
Music files do not play.
,Tracks with a time limit or a limited number of playing times cannot be played.
,Some copyright-protected music data cannot be played.
Even after selecting an item from the control panel, the desired
operation cannot be performed.
,Playback conditions may be set in advance by the software developer. In such
cases, certain options may not be available, even if you follow the instructions in
the product documentation.
A connection to the network cannot be established.
,Check that the Ethernet cable is securely connected.
,Check that the network settings are correct. Refer to the instructions supplied by
your Internet service provider or in the software manual to make the correct
network settings.
The Web page does not display properly.
,Some Web pages may not display properly due to the browser.
The system does not recognize the disc.
,Remove the disc and reinsert it.
,If the disc has a label, insert it with the label side up.
,Check whether the disc is scratched or dirty. If dirty, wipe it gently with a soft
cloth.
,See also the notices under "Playable discs" ( page 20).
The system does not recognize the media.
,Check that the media is inserted correctly.
,If the storage media is formatted (initialized) on a PC, the system may not
recognize it. After copying the required data to a PC, try reformatting the media
on the PS3™ system.
,There may be a problem with the media in use. Try using another media that is
compatible with the PS3™ system.
Storage media or a USB Mass Storage Class device is not recognized
by the system.
,In some cases, the system may not recognize storage media or a USB Mass
Storage Class device if more than the allotted number of media or devices are
connected. Try removing unused media or devices.
The disc cannot be removed.
,Touch the eject button on the system front for 10 seconds or longer to force the
disc to eject. After removing and before reinserting a disc into the system, turn
off the system, and then turn on the system again to resume use.
The wireless controller does not function.
,When using the controller wirelessly, if the controller and the system are too far
apart, you will not be able to operate the system effectively.
Video
Network
Storage media and disc media
Wireless controller
01GB01COV.book Page 11 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bgc.png)
masterpage:Left
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB04GET.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
12 Before requesting service
,When using the wireless controller, you must pair it with the system and assign
it a controller number. With the system turned on (power indicator on the system
front is lit solid green), connect the system and the controller using the USB
cable, and then press the PS button on the controller.
,Check the charge level of the wireless controller battery. When the controller is
used in wireless mode, it will not function if the battery does not have any charge
left. Charge the battery by connecting the controller to the system with the USB
cable.
,Wireless controllers for the PS3™ system are not equipped with a vibration
function and will not vibrate when using software that support the vibration
function.
,Reset the wireless controller by pushing the reset button on the controller rear
with a sharp-tipped object such as a pen.
The battery does not charge or does not fully recharge.
,The battery can only be charged when the system is turned on (when the power
indicator on the system front is lit green).
,See "Wireless controller battery" ( page 18).
The battery charge does not last long.
,The battery may be wearing out. Battery duration will gradually decrease with
repeated usage and age. See "Wireless controller battery" ( page 18).
Even when the battery is not being used, it loses its charge.
,Battery charge is used even when the wireless controller is not in use. It is
recommended that you charge the battery frequently.
The system makes noise.
,Because some discs read at higher speeds, disc noise may be louder than normal.
You forgot your password.
,If you initialize the system using "System Settings" > "Restore Default Settings",
your password will return to "0000". However, note that all settings other than
the password will also be reset. Once these settings are reset, they cannot be
recovered.
The system is warm.
,When the system is being used or is turned on, it may become warm. This is not
a malfunction.
The screen is frozen. The system does not operate.
,Restart the system. Touching the power button on the system front for 10 seconds
or longer will force the system to shut down. After shutdown, turn on the system
again.
The power indicator on the system front is flashing red and green
alternately.
,The interior of the system has become hot. Check whether the system is being
used in a hot location or whether the vents are blocked. Continuing to use the
system in the above condition will cause it to stop functioning. Turn the system
off and leave it unused until it cools down. After the system cools down, turn it
on again.
The power indicator on the system front is flashing red and the system
does not operate.
,The temperature inside the system has risen too high. Check whether the system
is being used in a hot location or whether the vents are blocked. Touch the power
button on the system front to stop the flashing, and then leave the system unused
until it cools down. After it cools down, turn on the system again.
Reset button
Other issues
01GB01COV.book Page 12 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bgd.png)
masterpage:Right
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB04GET.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
13
LIMITED HARDWARE WARRANTY AND LIABILITY
Troubleshooting
US
The system does not recognize content.
,The content may be of a format that is not supported by the system. Content of
types not supported by the system will not be recognized. For information on
supported formats, refer to the online user's guide.
Saved data from a game cannot be copied to the hard disk.
,Copying of certain data is prohibited.
When connecting a USB device, the message "An unknown USB device
has been connected." is displayed.
,The connected USB device may not be usable with the system.
,The device may be compatible with specific software only. If software that is
compatible with the device is started, the device will become usable.
,There may be too many USB hubs connected. Try removing a USB hub.
Sony Computer Entertainment America ("SCEA") warrants to the original purchaser
that the PS3™ hardware shall be free from material defects in material and
workmanship for a period of one (1) year from the original date of purchase (the
"Warranty Period"). If the product is determined to be materially defective during
the Warranty Period, your sole remedy and SCEA's sole and exclusive liability shall
be limited to the repair or replacement of this product with a new or refurbished
product at SCEA's option. For purpose of this Limited Hardware Warranty and
Liability, "refurbished" means a product that has been returned to its original
specifications. Visit www.us.playstation.com or call 1-800-345-7669 for
instructions on how to deliver the product, freight prepaid, to an authorized service
facility.
THIS WARRANTY SHALL NOT APPLY IF THIS PRODUCT (A) IS USED
WITH PRODUCTS THAT ARE NOT COMPATIBLE WITH THIS
PRODUCT; (B) IS USED FOR COMMERCIAL PURPOSES (INCLUDING
RENTAL); (C) IS MODIFIED, OR TAMPERED WITH; (D) IS DAMAGED
BY ACTS OF GOD, MISUSE, ABUSE, NEGLIGENCE, ACCIDENT, WEAR
AND TEAR, UNREASONABLE USE, OR BY OTHER CAUSES
UNRELATED TO DEFECTIVE MATERIALS OR WORKMANSHIP; (E)
HAS HAD THE SERIAL NUMBER ALTERED, DEFACED OR REMOVED;
OR (F) HAS HAD THE WARRANTY SEAL ON THE PS3™ SYSTEM
ALTERED, DEFACED, OR REMOVED. THIS WARRANTY DOES NOT
COVER CONSUMABLES (SUCH AS BATTERIES) OR PRODUCTS SOLD
"AS IS" OR WITH ALL FAULTS. THIS WARRANTY SHALL ALSO BE
VOIDABLE BY SCEA IF (1) SCEA REASONABLY BELIEVES THAT THE
PS3™ SYSTEM HAS BEEN USED IN A MANNER THAT WOULD
VIOLATE THE TERMS AND CONDITIONS OF A SEPARATE END USER
LICENSE AGREEMENT FOR SYSTEM SOFTWARE; OR (2) THE
PRODUCT IS USED WITH PRODUCTS NOT SOLD OR LICENSED BY
SCEA (INCLUDING, BUT NOT LIMITED TO, NON-LICENSED GAME
ENHANCEMENT DEVICES, CONTROLLERS, ADAPTORS AND POWER
SUPPLY DEVICES). YOU ASSUME ALL RISKS AND LIABILITIES
ASSOCIATED WITH USE OF THIRD PARTY PRODUCTS. A VALID
PROOF OF PURCHASE IN THE FORM OF A BILL OF SALE OR RECEIPT
LIMITED HARDWARE WARRANTY AND LIABILITY
01GB01COV.book Page 13 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bge.png)
masterpage:Left
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB04GET.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
14 LIMITED HARDWARE WARRANTY AND LIABILITY
FROM AN AUTHORIZED RETAILER WITH THE DATE OF THE
ORIGINAL PURCHASE MUST BE PRESENTED TO OBTAIN
WARRANTY SERVICE.
THIS WARRANTY IS PROVIDED TO YOU IN LIEU OF ALL OTHER
EXPRESS OR IMPLIED WARRANTIES INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
FOR THE PS3™ HARDWARE, WHICH ARE DISCLAIMED HEREUNDER.
HOWEVER, IF SUCH WARRANTIES ARE REQUIRED AS A MATTER OF
LAW, THEN THEY ARE LIMITED IN DURATION TO THE WARRANTY
PERIOD.
YOUR SOLE AND EXCLUSIVE RECOURSE IN THE EVENT OF ANY
DISSATISFACTION WITH OR DAMAGE ARISING FROM THE USE OF
THE PS3™ HARDWARE AND SCEA'S MAXIMUM LIABILITY SHALL BE
LIMITED TO REPAIR OR REPLACEMENT OF THE PS3™ SYSTEM.
EXCEPT AS EXPRESSLY STATED ABOVE, SCEA EXCLUDES ALL
LIABILITY FOR ANY LOSS OF DATA, LOSS OF PROFIT, OR ANY
OTHER LOSS OR DAMAGE SUFFERED BY YOU OR ANY THIRD
PARTY, WHETHER SUCH DAMAGES ARE DIRECT, INDIRECT,
CONSEQUENTIAL, SPECIAL, OR INCIDENTAL AND HOWEVER
ARISING UNDER ANY THEORY OF LAW, AS A RESULT OF USING
YOUR PS3™ HARDWARE. SOME STATES OR PROVINCES DO NOT
ALLOW LIMITATION ON HOW LONG AN IMPLIED WARRANTY
LASTS AND SOME STATES DO NOT ALLOW THE EXCLUSION OR
LIMITATIONS OF CONSEQUENTIAL OR INCIDENTAL DAMAGES, SO
THE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state or province to province. This warranty is valid only in
the United States and Canada. The warranty offered by Sony Computer
Entertainment America on your PS3™ hardware is the same whether or not you
register your product.
This warranty does not apply to any system software that is pre-installed in the
PS3™ hardware, or is subsequently provided via update or upgrade releases.
Such system software is licensed to you under the terms and conditions of a
separate end user license agreement at http://www.scei.co.jp/ps3-eula/ and such
software is provided pursuant to its own warranty.
Service policy
You understand and acknowledge that any time SCEA services your PS3™ system
(either within the Warranty Period or under a separate service arrangement), it may
become necessary for SCEA to provide certain services to your PS3™ system to
ensure it is functioning properly in accordance with SCEA guidelines. Such services
may include the installation of the latest software or firmware updates, or service or
replacement of the PS3™ hard disk or the PS3™ system with a new or refurbished
product. You acknowledge and agree that some services may change your current
settings, cause a removal of cosmetic stickers or system skins, cause a loss of data or
content, or cause some loss of functionality. You should back up your hard disk
regularly to prevent loss or alteration of data, although some content cannot be
backed up and must be reinstalled by the user. You should also remove any
peripherals, non-PS3™ system components, and any content that you consider
proprietary, private, or confidential before you send in your PS3™ system for
service. SCEA shall not be liable for damages resulting from your failure to comply
with the foregoing, or any instructions provided to you by SCEA. SCEA reserves the
right to refuse service or void the warranty of any PS3™ system that has been
modified or tampered with.
Except as otherwise stated in the Limited Hardware Warranty and Liability
above, you agree that (i) the services are provided "AS IS" without any express
or implied warranties; and (ii) SCEA shall not be liable for any direct and
indirect, consequential, or special damages, including any damages that may
arise from loss of data or functionality. The foregoing limitation shall apply to
the extent permitted by applicable law.
01GB01COV.book Page 14 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bgf.png)
masterpage:Right
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB05GAM.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
15
Removing / replacing the hard disk
Additional information
US
The following section explains how to remove and replace the hard disk.
Notices
• All hard disks, including a PS3™ hard disk must be reformatted before use in a PS3™ system.
However, reformatting may not occur if the original PS3™ hard disk is reinstalled onto the
original PS3™ system that was provided with the PS3™ hard disk, and such PS3™ hard disk
has not been previously reformatted.
• The PS3™ system cannot execute any content stored on a hard disk of any other computer or
operating system, including a PS3™ hard disk that has been reformatted.
• It is recommended that you regularly back up any data on the hard disk that is of a type that can
be backed up. If for any reason software or data loss or corruption occurs, it may not be possible
to restore or repair the software or data. Sony Computer Entertainment Inc. and its subsidiaries
and affiliates will not be liable for damage or injury related to software or data loss or
corruption.
• The PS3™ hard disk is intended for use with the PS3™ system, and it may not be possible to
execute content stored on a PS3™ hard disk on any other operating system.
• Improper removal or installation of a hard disk may cause damage to your PS3™ system or loss
of data, and may void your PS3™ hardware warranty. SCEA shall not be liable for any resulting
damages, including any damages to your hard disk. User assumes all risks and liabilities
associated with using a replacement hard disk, including any incompatibility or interoperability
problems with the PS3™ system. Services will not be provided on any non-PS3™ hard disks.
1Touch the power button on the system front for at least two
seconds.
The power indicator will turn solid red and the system will enter standby mode.
2Turn off the system using the main power switch on the system
rear.
3Unplug the AC power cord and detach the other cables from
the system.
For safety reasons, remove the plug for the power cord from the electrical outlet,
and then detach the other cables.
4Remove the HDD bay cover on the system's left side.
Use the space at the right edge of the HDD bay cover to pull it out from the
system.
If the cover is difficult to remove, gently insert a small screwdriver in the space
and pry the cover off. Be careful not to damage the system or the cover when
using a screwdriver.
Additional information
Removing / replacing the hard disk
Caution
• Remove the hard disk in a location out of the reach of small children to help
prevent accidental swallowing of small parts such as the screws.
• The inside of the system is hot directly after use. Allow time for the system to
cool down before starting to remove the hard disk.
• Be careful not to injure yourself when removing or handling the hard disk.
• Be sure to reattach the HDD bay cover before turning the PS3™ system on.
If the cover is not attached, it may cause heat to build up inside the system.
Removing the hard disk
01GB01COV.book Page 15 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg10.png)
masterpage:Left
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB05GAM.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
16 Removing / replacing the hard disk
5Free the hard disk from the system.
1Remove the blue screw with a crosshead screwdriver.
2Raise the metal handle.
3Slide the hard disk to the right.
6Remove the hard disk from the system.
Use the metal handle to pull the hard disk out from the system.
Notices
The hard disk is a sensitive piece of equipment and should be handled with care at all times. To
help prevent software or data loss or corruption, or damage to the hard disk, carefully follow the
precautions listed below:
• Do not drop the system or hard disk, or subject to physical shock or vibration.
• Do not allow liquid or small particles to get into the system or hard disk.
• Do not touch the connectors or insert foreign objects into the connectors.
• Do not place the system or hard disk close to magnetic fields such as those produced by magnets
or loudspeakers. Also, do not place devices that may be sensitive to magnetic forces (such as a
wrist watch or a magnetic card) near the hard disk.
• Do not put heavy objects on the hard disk.
• When handling the hard disk hold it only by the edges or metal frame.
• The hard disk is sensitive to static electricity. Ensure that proper handling methods are used
when installing the hard disk.
• Store in a cool, dry location.
When replacing the hard disk, follow the procedure below to remove the metal
frame.
1Use a crosshead screwdriver to remove the screws (4 places).
2Remove the hard disk from the metal frame.
Lift one end and slide the hard disk out to remove.
3Place the replacement hard disk on the PS3™ system hard
disk's metal frame, and then attach using the screws (4 places).
Do not to over tighten the screws.
1
3
2
Replacing the hard disk
Caution
For safety reasons, be sure to turn off and unplug the system before attempting
to install the hard disk.
01GB01COV.book Page 16 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg11.png)
masterpage:Right
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB05GAM.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
17
Caution on disposal of the PS3™ system
Additional information
US
4Install the hard disk in the system.
Fully insert the hard disk in the HDD bay, and then slide it to the left. Attach the
blue screw to lock the hard disk in place. Refer to the instructions for
"Removing the hard disk" ( page 15) in reverse order when installing.
5Reattach the HDD bay cover.
6Turn on the PS3™ system.
Follow the on-screen instructions to perform initial setup.
Replacement hard disks
You can use hard disks of the following types with the PS3™ system:
*1 Proper operation is not guaranteed for all models.
*2 Parallel ATA is not supported.
Hint
If you lose the HDD bay cover, screws, or metal attachment, for availability of replacement parts
contact SCEA Consumer Services at 1-800-345-7669.
Before disposing of the system, it is recommended that personal information and
other data of similar nature be deleted. To delete data, go to "System Settings" >
"Restore PS3™ System".
Size 2.5 inch (internal type)*1
Interface format Serial ATA*2
Caution on disposal of the PS3™ system
01GB01COV.book Page 17 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg12.png)
masterpage:Left
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB05GAM.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
18 Wireless controller battery
Wireless controller battery life
• The battery has a limited lifespan. Battery duration will gradually decrease with
repeated usage and age.
• Battery life also varies depending on the storage method, usage state, environment
and other factors.
Storage
When the wireless controller is not used for an extended period of time, it is
recommended that you fully charge it at least once a year in order to maintain battery
functionality.
The lithium-ion battery of the wireless controller is recyclable. When disposing of
the wireless controller, remove the battery and follow local regulations regarding
disposing of batteries.
Removing the battery
Notice
Other than when disposing of the wireless controller, never remove the screws and never remove
the battery from the wireless controller.
1Remove the USB cable from the wireless controller.
2Using a cross-head screwdriver, remove the screws (5 places).
3Remove the casing.
1Push in the direction of the arrow.
2Pull the casing apart.
Wireless controller battery
Caution
If you come into contact with material from a leaking battery, take the following
actions:
• If the material gets into the eyes, do not rub. Immediately flush the eyes with
clean water and seek medical attention.
• If the material comes into contact with the skin or clothes, immediately rinse
the affected area with clean water. Consult your physician if inflammation or
soreness develops.
Do not allow the battery to come into contact with fire or subject it to extreme
temperatures such as in direct sunlight, in a vehicle exposed to the sun or near
a heat source.
When disposing of the wireless controller
Caution
• Remove the battery in a location out of the reach of small children to help
prevent accidental swallowing of small parts such as the screws.
• Be careful not to hurt your nails or fingers when removing the controller
casing.
• For safety reasons, attach tape or a seal on the metal part of the battery
before disposing.
1
2
01GB01COV.book Page 18 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg13.png)
masterpage:Right
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB05GAM.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
19
Specifications
Additional information
US
4After removing the connector, remove the battery.
Recycling Lithium-Ion Batteries
Lithium-Ion batteries are recyclable.
You can help preserve our environment by returning your
used rechargeable batteries to the collection and recycling
location nearest you.
For more information regarding recycling of rechargeable
batteries, call toll free 1-800-822-8837, or visit http://www.rbrc.org/
Design and specifications are subject to change without notice.
PLAYSTATION®3 system
Caution
Do not handle damaged or leaking Lithium-Ion batteries.
Connector
Battery
Specifications
CPU Cell Broadband Engine™
GPU RSX™
Audio output Dolby Digital 5.1 ch, DTS 5.1 ch, LPCM 7.1 ch,
AAC, others*1 *2
Memory 256 MB XDR Main RAM,
256 MB GDDR3 VRAM
Hard disk 2.5" Serial ATA 60 GB
Inputs/outputs*3
Hi-Speed USB
(conforms to USB
2.0)
4
Memory Stick™
slot
Memory Stick™
(supports standard/Duo size, MagicGate™, Memory
Stick PRO™ and high-speed data transmission)
SD Memory Card
slot SD Memory Card*4
CF slot CompactFlash® (Type I/II), Microdrive
Networking
Ethernet (10BASE-T, 100BASE-TX, 1000BASE-T)
× 1
IEEE 802.11 b/g
Bluetooth 2.0 (EDR)
Controller Wireless controller (Bluetooth)
01GB01COV.book Page 19 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg14.png)
masterpage:Left
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB05GAM.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
20 Specifications
*1 A device compatible with Linear PCM 7.1 Ch. is required to output 7.1 Ch. audio, supported
by Dolby TrueHD or a similar format, from the HDMI OUT connector.
*2 This system does not support output from the DTS-HD 7.1 Ch. DTS-HD 7.1 Ch. audio is
output from a 5.1 or lower channel.
*3 Usability of all storage media types is not guaranteed.
*4 The SD Memory Card copyright-protection function is not supported.
Wireless controller
MagicGate™
MagicGate™ is a term of copyright-protection technology developed by Sony
Corporation.
Supplied AV cable, USB cable and Ethernet cable
For additional information on compatible media types, visit our Web site at
http://www.us.playstation.com.
AV output
Resolution 1080p, 1080i, 720p, 480p, 480i
HDMI OUT
connector HDMI (supports Deep Color/Ver 1.3) × 1
AV MULTI OUT
connector 1
Digital out (optical)
connector 1
BD/DVD/
CD drive
(read only)
Maximum read rate
BD × 2 (BD-ROM)
DVD × 8 (DVD-ROM)
CD × 24 (CD-ROM)
Power 120 V AC, 60 Hz
Power consumption Approx. 380 W
External dimensions
(excluding maximum projecting part)
Approx. 325 × 98 × 274 mm
(12.8 × 3.86 × 10.79 in)
(width × height × length)
Mass Approx. 5 kg (11.02 lb)
Operating temperature 5°C - 35°C (41°F - 95°F)
Battery type Lithium-ion battery
Voltage DC 3.7 V
Capacity 610 mAh
Mass Approx. 136 g (4.8 oz)
AV cable Company: SONY
Parts No.: 1-792-028-81
USB cable Company: SONY
Parts No.: 1-833-625-11
Ethernet cable Company: SONY
Parts No.: 1-833-636-11
Playable discs
Blu-ray Disc (BD)
PLAYSTATION®3 format BD-ROM
BD-ROM
BD-R
BD-RE*
DVD
PlayStation®2 format DVD-ROM
DVD-ROM
DVD+R/RW
DVD-R/RW
AVCHD
01GB01COV.book Page 20 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg15.png)
masterpage:Right
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB05GAM.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
21
Specifications
Additional information
US
* Playback of BD-RE ver. 1.0 discs is not supported.
Notices
• Use only circular-shaped discs with the system. Do not use irregularly-shaped
discs (for example, heart- or star-shaped discs). Using irregularly-shaped discs
may cause a malfunction.
• Do not use damaged, re-shaped or repaired discs. Use of such discs may cause a
malfunction.
• When using an 8 cm disc, insert the disc in the system without an adaptor.
• The audio CD playback feature of this system is designed to conform to the
Compact Disc (CD) standard. Recently, some record companies have started
marketing music discs encoded with copyright protection technologies. Some of
these music discs do not conform to the CD standard and may not be playable on
this system.
• A DualDisc is a dual-sided disc that combines a DVD side and an audio side. Note
that the audio side is not guaranteed to play because this type of disc does not
conform to the specifications required for an audio Compact Disc (CD).
• If a device that is not compatible with the HDCP (High-bandwidth Digital Content
Protection) standard is connected to the system using an HDMI cable, video or
audio cannot be output from the system.
• Copyright-protected Blu-ray video discs can only be output at 1080p using an
HDMI cable connected to a device that is compatible with the HDCP (High-
bandwidth Digital Content Protection) standard.
• When you use the AV MULTI OUT connector of the system to connect to a TV,
copyright-protected video from a BD or from video files may be output at
resolutions lower than 1080p (or may not be playable).
• Audio from Super Audio CDs cannot be output from the system's digital out
(optical) connector. Multi-channel content from Super Audio CDs can only be
output from the HDMI OUT connector.
• CD-DA (audio CD) is output at 48 kHz from the system.
• When playing discs with content that was copied fraudulently, abnormal sounds
may be produced or the content may not play correctly.
• To continuously enjoy playback of copyright-protected BDs, in some cases the
AACS (Advanced Access Control System) key may need to be renewed. To renew
the key, the system must be updated.
• Some discs may not be playable due to scratches, dust, the quality of recording, or
the characteristics of the recording device.
• In rare instances, CDs, DVDs, BDs and other media may not operate properly
when played on the PS3™ system. This is primarily due to variations in the
manufacturing process or encoding of the software.
Region codes
Depending on the disc, a region code that is based on the geographic region where
the disc is distributed may be assigned. This system can play discs marked with the
following region codes.
DVD and PLAYSTATION®3 format software
• When outputting DVD content or PLAYSTATION®3 format software in SD
resolution, only discs recorded in the NTSC standard can be played.
• When playing PLAYSTATION®3 format software in HD resolution, a TV that
supports video playback at 59.94 Hz is required.
CD
PlayStation®2 format CD-ROM
PlayStation® format CD-ROM
CD-DA (audio CD)
CD-R/RW
Super Audio CD
Disc Region code
Blu-ray Disc (BD)
DVD
PLAYSTATION®3 format BD-ROM
PlayStation®2 format DVD-ROM
PlayStation®2 format CD-ROM
PlayStation® format CD-ROM
ALL
01GB01COV.book Page 21 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg16.png)
masterpage:Left
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB05GAM.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
22 Specifications
DVD-R/DVD-RW/DVD+R/DVD+RW discs
Discs that have not been finalized cannot be played.
" ", "PlayStation" and "PLAYSTATION" are registered trademarks of Sony
Computer Entertainment Inc. Also, "PS3" is a trademark of the same company.
"SONY" and " " are registered trademarks of Sony Corporation. "Memory Stick",
"Memory Stick PRO", "Memory Stick Duo", "Memory Stick PRO Duo", " "
and "MagicGate" are trademarks or registered trademarks of Sony Corporation.
The Super Audio CD logo is a trademark.
"AVCHD" is a trademark of Matsushita Electric Industrial Co., Ltd. and Sony
Corporation.
Contains Macromedia® Flash® Player technology by Adobe
Copyright © 1995-2006 Adobe Systems Incorporated. All rights reserved. Flash,
Macromedia, and Macromedia Flash are either trademarks or registered trademarks
of Adobe Systems Incorporated in the United States and/or other countries.
© 2006 All Media Guide, LLC
Content and technology provided by All Media Guide®.
"Blu-ray Disc" and are trademarks.
Copyright © 2004-2006 Cambridge Silicon Radio Ltd.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any
use of such marks by Sony Computer Entertainment Inc. is under license.
"DTS" and "DTS Digital Surround" are registered trademarks of DTS, Inc.
Manufactured under license from Dolby Laboratories. Dolby and the double-D
symbol are trademarks of Dolby Laboratories.
The DVD logo is a trademark.
All of the Japanese fonts and some parts of the Latin fonts in this machine use
characters provided by Fontworks Japan, Inc.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing, LLC.
Copyright and trademarks
01GB01COV.book Page 22 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg17.png)
masterpage:Right
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB05GAM.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
23
Specifications
Additional information
US
ATOK is a registered trademark of JUSTSYSTEM CORP. in Japan and other
countries.
This product incorporates copyright protection technology that is protected by
method claims of certain U.S. patents and other intellectual property rights owned by
Macrovision Corporation and other rights owners. Use of this copyright protection
technology must be authorized by Macrovision Corporation, and is intended for
home and other limited viewing uses only unless otherwise authorized by
Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Anti-Grain Geometry - Version 2.0
Copyright © 2002-2004 Maxim Shemanarev (McSeem)
Permission to copy, use, modify, sell and distribute this software is granted provided
this copyright notice appears in all copies.
This software is provided "as is" without express or implied warranty, and with no
claim as to its suitability for any purpose.
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO
LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A
CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC
STANDARD ("AVC VIDEO") AND/OR (ii) DECODE AVC VIDEO THAT WAS
ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND
NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS
GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE
HTTP://WWW.MPEGLA.COM
THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT
PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE
OF A CONSUMER TO (i) ENCODING VIDEO IN COMPLIANCE WITH THE
MPEG-4 VISUAL STANDARD ("MPEG-4 VIDEO") AND/OR (ii) DECODING
MPEG-4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A
PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS
OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO
PROVIDE MPEG-4 VIDEO. NO LICENSE IS GRANTED OR SHALL BE
IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION
INCLUDING THAT RELATING TO PROMOTIONAL, INTERNAL AND
COMMERCIAL USES AND LICENSING MAY BE OBTAINED FROM MPEG
LA, LLC. SEE HTTP://WWW.MPEGLA.COM
This product includes RSA BSAFE® Cryptographic software from RSA Security
Inc.
RSA, BSAFE are either registered trademarks or trademarks of RSA Security Inc. in
the United States and/or other countries.
RSA Security Inc. All rights reserved.
This product adopts S3TC texture compression technology under license from S3
Graphics, Co., Ltd.
Sony Computer Entertainment Inc. is an authorized licensee of the CompactFlash®
registered trademark.
MPEG Layer-3 audio coding technology and patents licensed from Fraunhofer IIS
and Thomson.
01GB01COV.book Page 23 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg18.png)
masterpage:Left
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB05GAM.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
24 Specifications
The "Wi-Fi CERTIFIED" logo is a certification mark of the Wi-Fi Alliance.
eZiText® and Zi® are registered trademarks of Zi Corporation.
Portions of this software are copyright © 1996-2006 The FreeType Project
(www.freetype.org). All rights reserved.
This software is based in part on the work of the Independent JPEG Group.
linungif
Copyright © 1997 Eric S. Raymond
libtiff
Copyright © 1988-1997 Sam Leffler
Copyright © 1991-1997 Silicon Graphics, Inc.
Visit http://www.scei.co.jp/ps3-license/index.html for other licensees and
trademarks.
All other trademarks are the properties of their respective owners.
This product may fall within the scope of national export control legislation. You
must comply fully with the requirements of such legislation and of all other
applicable laws of any jurisdiction in relation to this product.
About national export control
01GB01COV.book Page 24 Wednesday, September 6, 2006 2:30 PM
![](/img.php?id=704278&img=bg19.png)
masterpage:Right
filename[G:\FM\SCE\0906_3\PS3-1001\01_US\01GB05GAM.fm]
model name1[PS3-1001_US/FR/ES]
[2-894-628-11(1)]
25
Specifications
Additional information
US
01GB05GAM.fm Page 25 Thursday, September 7, 2006 10:14 AM
