Texas Instruments 7IDEM The 7IDEM is a development tool for TIs 2.4 GHz 7ID System-on-Chip User Manual EVALUATION BOARD KIT MODULE EVM ADDITIONAL TERMS
Texas Instruments Inc. The 7IDEM is a development tool for TIs 2.4 GHz 7ID System-on-Chip EVALUATION BOARD KIT MODULE EVM ADDITIONAL TERMS
Users Manual
![](/img.php?id=2200216&img=bg1.png)
TI Confidential – NDA Restrictions Page 1 of 4
CC2650 Packet Error Rate Test
Quick Start Guide
Version
Updated
0.0.2
17. September 2013
Revised for rev 0.1.0 of PER Test
![](/img.php?id=2200216&img=bg2.png)
CC2650 Packet Error Rate Test Quick Start Guide
TI Confidential – NDA Restrictions Page 2 of 4
Functional Overview
This guide describes how to use the Packet Error Rate (PER) test with CC2650.
Prerequisites
In order to use the PER test, please set up your SmartRF06EB according to the “CC2650 Alpha
Release Quick start guide” as the silicon qual package can become damaged if not.
Uploading firmware
Upload the per_test.hex file to a CC2650 using the SmartRF Flash Programmer.
Be sure to do full erase/program/verify of uploaded code. After upload, do a power cycling or pin
reset to boot the PER test.
Menu system
The menu system is based on using the buttons on SmartRF06EB to navigate.
There are 5 buttons needed
LEFT – go back to previous menu
UP/DOWN – navigate between menu elements
RIGHT/SELECT – choose menu element
Start menu
The start menu contains the devices supported on the PER test, as well as a settings menu.
Settings menu
To see the difference in power consumption with and without the DC/DC converter, you can press
RIGHT/SELECT on DCDC to toggle it on or off. A “1” indicates that it is currently on.
Channel menu
After selecting a device (e.g. CC2650EM), you can currently select the Bluetooth LE channel you
would like to use for the test.
Since the PER test is implemented using BLE Advertising packages (Non-connectable undirected
advertising), only the advertising channels are available. Together, they cover the allowed frequency
band for Bluetooth LE.
37 – 2402MHz
38 – 2426MHz
39 – 2480MHz
![](/img.php?id=2200216&img=bg3.png)
CC2650 Packet Error Rate Test Quick Start Guide
TI Confidential – NDA Restrictions Page 3 of 4
Mode menu
In the mode menu, you can select which device is transmitting and which is receiving:
BLE Transmitter
BLE Receiver
After selecting “BLE Receiver”, the device goes directly into receive mode and is ready to receive
packets.
Only let 1 PER test device with the advertising address 0x264026402640 transmit packages at the
same time, as the receiver are based on recognizing a sequence number in the payload and will get
restart the receive statistics if packets with a lower sequence number arrives.
TX Power
When selecting “BLE Transmitter”, you can also select which output power you would like to
transmit with. Currently, the following options are available:
0 dBm
+5dBm
Burst size
After selecting output power, you can also select the number of packets you would like to send in
one test.
This is configurable between 1000 and 1 000 000 packets.
Packet rate
To test the device with different data rates, you can also select how many packets per second you
would like to send.
This configures the 32k RTC timer to trigger an interrupt a number of times per second to send a
package.
Note:
The PER test packet rate setting is currently using a low frequency clock derived from the 48MHz
clock, meaning the packet rate is not 100% accurate. The RTC frequency is therefore 31.25kHz
instead of 32.768 kHz but this will be changed in a later release.
TX Idle
The PER test is now ready to send packages but has not yet started. To start sending packages, press
RIGHT/SELECT.
You can restart the test at any time by pressing RIGHT or SELECT.
![](/img.php?id=2200216&img=bg4.png)
CC2650 Packet Error Rate Test Quick Start Guide
TI Confidential – NDA Restrictions Page 4 of 4
Current measurement
To measure power consumption during test modes, connect a measurement device instead of the
jumper ”VDD TO EM” on the SmartRF06EB. This can be e.g. a digital multi meter with the range set
to mA or an oscilloscope.
To get the lowest possible current consumption, restart the SmartRF06EB after programming the
device and remove all the jumpers on the "JTAG Bypass" header (to avoid leakage current to the
debugger on the SmartRF06EB). Also remove the tiny current measurement circuit next to the
jumper, as the instrumentation amplifier will consume several microamperes.
Note:
If using an oscilloscope, do not use more than 1 ohm in series and make sure to run the board on
2xAAA batteries and move the board switch to BAT instead of USB. The scope ground will force the
supply to each potential, shorting the on-board LDO on the SmartRF06EB.
Known bugs and issues
Regulatory Information
The CC2650 evaluation module (7IDEM) is FCC and IC certified and tested to comply with ETSI R&TTE
regulations over temperature from 0 to +35°C. The evaluation module has an integrated PCB
antenna.
FCC/IC Regulatory Compliance
FCC Part 15 Class A Compliant
IC ICES-003 Class A Compliant
