Voxx Accessories HPA225 Bluetooth Wireless Earbuds User Manual 2
Voxx Accessories Corp. Bluetooth Wireless Earbuds 2
User Manual
![](/img.php?id=3411562&img=bg1.png)
Unpack
Make sure you have the following items in your 808 EarCanz
TRU package:
• 808 EarCanz TRU Bluetooth earbuds
• Micro USB charging cable
• Eartips in 3 sizes
• Ear fins in 3 sizes
• Travel case
For best performance, we recommend you charge your
EarCanz TRU earbuds fully before using them.
Open the flaps on the bottom
of each earbud.
Plug the micro-USB ends of the
included USB charging cable into
the charging jack behind the
flap on each earbud.
Plug the other end of the charging
cable into a USB power source (like
a computer or a USB charger).
The indicator light on the side of
each earbud turns red while that
earbud is charging. It turns white
when the earbud is fully charged.
Unplug the USB charging cables
when the earbuds are charged.
Place each earbud in its assigned
ear (marked R or L on the inside
of each bud).
1. Charge the EarCanz TRU
If you have any questions about this product, visit
808Audio.com or call our toll-free help line at
1-800-732-6866.
IMPORTANT: If you’ve previously paired your phone or other Bluetooth
device with these earbuds, the earbuds will automatically attempt to
reconnect to that device when you turn them on. If you want to pair to a
new device, turn Bluetooth o on the previously paired device. The earbuds
will enter pairing mode. Then choose 808 EarCanz TRU from the pairing
options on the new device.
Right and left
earbuds (side)
2. Turn on the EarCanz TRU 3. Pair + Connect
Choose 808 EarCanz TRU from the pairing options on your
smartphone. (If it’s not in the list, choose “Scan” from your
phone’s Bluetooth menu.)
Enable Bluetooth on your smartphone or
other device.
Wi-Fi
Bluetooth
Bluetooth Settings
VPN Settings
Wi-Fi Settings
8:45PM
The earbuds say “device connected” when the process is
complete. The indicators blink white every 6 seconds.
Note: The process of enabling Bluetooth and connecting varies from device
to device. See your device’s owners manual for more information and
specific instructions.
To turn the EarCanz TRU o: Press and hold the button on
one of the earbuds for 3 seconds.
Right and left
earbuds
(bottom) R
Right earbud
Right ear
To turn on the EarCanz TRU:
Press and hold the button
on each earbud (front of the
left, back of the right) for
about 3 seconds, until you hear
“power on” from each earbud.
IMPORTANT: You must turn each
earbud on separately! For best
results, press both at the same
time.
Linking for Wireless Stereo
After you turn them both on, the earbuds start the linking
process for wireless stereo. The indicator on the back of each
earbud starts blinking red, then white when the earbuds are
linked to each other. The left earbud says “left connected”
and the right says “right connected.” Now you’re ready to pair
with your smartphone or other Bluetooth device!
If you don’t hear “left connected” and “right connected”:
Turn the earbuds o (press and hold the button until they
say “power o”). Then turn them both back on again.
TIP: You can use the right earbud by itself as an earpiece for
Bluetooth calls. Just turn it on by itself (and leave the left
earbud o).
Left ear:
FRONT
Right ear:
BACK
![](/img.php?id=3411562&img=bg2.png)
Listening to music
Set your device’s volume for music to 50%.
Note: This is to make sure the sound from the earbuds isn’t too loud
when you start streaming.
Start playing music or other audio on your device. Within
seconds, the earbuds start streaming the audio wirelessly via
Bluetooth.
Controlling playback and volume
The button on either earbud lets you control music playback
wirelessly.
To play/pause music: Press the button.
To adjust volume: Use the volume controls on your phone.
Answering/ending phone calls
The right earbud has a built-in microphone, so you can use it
for phone calls. Your phone will ring through the right earbud
when you’re receiving a call.
To answer or end a phone call: Give a short press on the
button.
To decline a phone call: Press and hold the button for one
second.
IMPORTANT: Not all phones support playback control and phone answer/
end control. Check your phone’s user manual for more information if you’re
having trouble with these functions. quick start guide
HPA225 QSG 01
Using the EarCanz TRU
Putting the EarCanz TRU in your ears
The EarCanz TRU earbuds come with medium-sized eartips
and ear fins installed. You can use dierent-sized tips and
fins, but first try them with the medium sizes.
Changing the eartips or fins
Find the L and R markings on the
buds.
Place each eartip in your ear as
shown here. The fin should go in
the small ridge just above your ear
canal on your outer ear—it might go
automatically, or you might need to
move it into place.
If the tips or fins don’t fit, follow the directions in the next
section to change them.
If you want to use a dierent size ear fin or bud, find the size
you want, and match the L/R fins to L/R buds.
Bluetooth Wireless Connection Tips
• Make sure the Bluetooth capability of your device is turned on.
• The earbuds’ Bluetooth wireless connection works up to a range of roughly
33 feet (10 meters). This range may vary, however, based on other factors,
such as room layout, wall material, obstacles, your device’s Bluetooth
performance, etc. If you’re having problems connecting to the earbuds,
move closer to your phone.
• Make sure your device supports audio transfer A2DP.
• If your device asks you for a password to connect, use “0000”.
To pair the EarCanz TRU again
After turning your earbuds back on, they automatically
attempt to reconnect to the last connected device. If the
last connected device is not available, the earbuds will enter
pairing mode and be ready to pair to a new or dierent device.
Forget to turn on your device’s Bluetooth before turning on the
earbuds? Just give a quick single-press to the button on either
earbud once you’ ve turned on your device’s Bluetooth to reconnect
to it.
3. Pair + Connect (continued)
L
Left earbud Left ear
Turning the EarCanz TRU Off
To turn the EarCanz TRU o: Press and hold the button on
one of the earbuds for 3 seconds.
