Models 7652V, 7652P, 7652X
Security and Remote Start
Owner’s Guide
© 2008 Directed Electronics, Vista, CA
G5902V 2008-03
![](/img.php?id=962833&img=bg3.png)
Contents
Government regulations ...............................................................................................................5
Warning! safety first ... ............................................................................................................... ...7
What is included .......................................................................................................................... ..9
Important information ... ...............................................................................................................9
Your warranty.......................................................................................................................9
Replacement remotes... ....................................................................................................10
Caution ... ............................................................................................................................10
Responder LC 2-Way ... .......................................................................................................... ...11
Responder LC 1-way ... ...............................................................................................................12
Transmitter configuration ... ...........................................................................................13
System maintenance ... ....................................................................................................19
Charging the Battery ... ................................................................................................... .19
Low battery indicator ... ............................................................................................... ...20
Battery Replacement ........................................................................................................20
LCD Iayout ... ................................................................................................................. ...21
LCD remote features ... ....................................................................................................21
Multi-car control capability .......................................................................................... .22
Using the system ... .................................................................................................................. ...23
Arming the system............................................................................................................23
While the system is armed ... ..........................................................................................24
Modified Arming Modes.................................................................................................26
Disarming the System ... .............................................................................................. ...28
System override ... .............................................................................................................28
Using the remote start ... .............................................................................................................30
Before using your Remote Start ... .................................................................................30
Remote starting your vehicle ..................................................................................... ...30
Points to remember ...................................................................................................... ...30
Runtime Check ... .......................................................................................................... ...31
Manual transmission ... ....................................................................................................31
Timer mode ... ....................................................................................................................32
Turbo timer mode ... ..................................................................................................... ...32
Safety features ... ..........................................................................................................................35
Starter anti-grind circuitry ..............................................................................................35
Disabling the remote start system ... .............................................................................35
Diagnostics ....................................................................................................................................36
Arming .............................................................................................................................. .36
Disarming ... .................................................................................................................. ...37
System status chirps......................................................................................................... .37
Table of zones ................................................................................................................... .38
Interpreting zone diagnostics ... .....................................................................................38
Nuisance prevention® circuitry ....................................................................................39
Owner recognition ................................................................................................................................... .40
![](/img.php?id=962833&img=bg4.png)
Rapid resume logic .................................................................................................................40
Power saver mode.................................................................................................................. .41
System.............................................................................................................................41
2-way remote ... .............................................................................................................41
Programming options ............................................................................................................42
Security & convenience expansions ... ................................................................................ .44
Glossary of terms ....................................................................................................................46
Quick reference guide ........................................................................................................... .49
Limited lifetime consumer warranty ..................................................................................51
![](/img.php?id=962833&img=bg5.png)
Government regulations
This device complies with Part 15 of FCC rules. Operation is subject to the fol-
lowing two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesirable operation.
This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential instal-
lation. This equipment generates and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television, which can be determined by
turning the equipment OFF and ON, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
To satisfy FCC RF exposure compliance requirements, this device should be used
in hand-held, hand operated configurations only. The device and its antenna
must maintain a separation distance of 20 cm or more from the person’s body,
except for the hand and wrists, to satisfy RF exposure compliance. This device
is designed to be used in a person’s hands and its operating configurations do
not support normal transmissions while it is carried in pockets or holsters next to
a persons’ body.
This device complies with the Industry Canada Radio Standards Specification
© 2008 Directed Electronics. All rights reserved. 5
![](/img.php?id=962833&img=bg6.png)
RSS 210. Its use is authorized only on a no-interference, no-protection basis; in
other words, this device must not be used if it is determined that it causes harm
ful
interference to services authorized by IC. In addition, the user of this device
must
accept any radio interference that may be received, even if this interference could
affect the operation of the device.
Warning:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this device.
6 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg7.png)
Warning! safety first
The following safety warnings must be observed at all times:
Due to the complexity of this system, installation of this product must only be
performed by an authorized Directed dealer.
When properly installed, this system can start the vehicle via a command signal
from the remote control transmitter. Therefore, never operate the system in an
enclosed area or partially enclosed area without ventilation (such as a garage).
When parking in an enclosed or partially enclosed area or when having the
vehicle serviced, the remote start system must be disabled using the installed
toggle switch. It is the user’s sole responsibility to properly handle and keep out
of reach from children all remote control transmitters to assure that the system
does not unintentionally remote start the vehicle. THE USER MUST INSTALL A
CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJA-
CENT TO THE VEHICLE. ALL DOORS LEADING FROM ADJACENT LIVING
AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE STORAGE
AREA MUST AT ALL TIMES REMAIN CLOSED. These precautions are the sole
responsibility of the user.
Remote starters on manual transmission vehicles operate differently than those
with automatic transmission because you must leave your car in neutral. You
must read this Owner’s Guide to familiarize yourself with the proper procedures
regarding manual transmission remote starters. If you have any questions, ask
your installer or contact Directed at 1-800-753-0600.
Before remote starting a manual transmission vehicle, be sure to:
• Leave the vehicle in neutral and be sure no one is standing in front or
behind the vehicle.
• Only remote start on a flat surface
• Have the parking brake fully engaged
© 2008 Directed Electronics. All rights reserved. 7
![](/img.php?id=962833&img=bg8.png)
WARNING! It is the responsibility of the owner to ensure the parking/
emergency brake properly functions. Failure to do so can result in
personal injury or property damage. We recommend the owner have
the parking / emergency brake system inspected and adjusted by a qualified
automotive shop bi-annually.
Use of this product in a manner contrary to its intended mode of operation may
result in property damage, personal injury, or death. (1) Never remotely start the
vehicle with the vehicle in gear, and (2) Never remotely start the vehicle with
the keys in the ignition. The user must also have the neutral safety feature of the
vehicle periodically checked, wherein the vehicle must not remotely start while
the car is in gear. This testing should be performed by an authorized Directed
dealer in accordance with the Safety Check outlined in the product installation
guide. If the vehicle starts in gear, cease remote start operation immediately and
consult with the authorized Directed dealer to fix the problem.
After the remote start module has been installed, contact your authorized dealer
to have him or her test the remote start module by performing the Safety Check
outlined in the product installation guide. If the vehicle starts when performing
the Neutral Safety Shutdown Circuit test, the remote start unit has not been
properly installed. The remote start module must be removed or the installer must
properly reinstall the remote start system so that the vehicle does not start in gear.
All installations must be performed by an authorized Directed dealer.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN
GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. OPERAT-
ING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT
IN PROPERTY DAMAGE OR PERSONAL INJURY. YOU MUST IMMEDIATELY
CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN
AU
THORIZED Directed DEALER TO REPAIR OR DISCONNECT THE INSTALLED
REMOTE START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR
PAY
FOR INSTALLATION OR REINSTALLATION COSTS.
8 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg9.png)
What is included
• The control module with Stinger™DoubleGuard®two-stage shock
sensor
• Control center (installed out of sight on your vehicle) with inte-
grated status LED and Valet override switch
• One five-button/2-way Supercode Responder LE Remote Control
• One five-button/ 1-way Supercode remote
• Revenger™Soft Chirp™six-tone siren
• A shut-down toggle switch
• Window decals
• Your warranty registration
Important information
Congratulations on the purchase of your state-of-the-art remote start and
alarm system. Due to the complexity of this system, it must be installed
by an authorized dealer only. Installation of this product by anyone
other than an authorized dealer voids the warranty. All dealers are
provided with a preprinted dealer certificate to verify authorization.
By carefully reading this Owner’s Guide prior to using your system,
you will maximize the use of this system and its features. You can print
additional or replacement copies of this manual by accessing our web
site at www.directed.com.
➤ Your warranty
Your warranty registration must be completely filled out and returned
within 10 days of purchase. Your product warranty will not be validat-
ed if your warranty registration is not returned. Make sure you receive
the warranty registration from your dealer. It is also necessary to keep
© 2008 Directed Electronics. All rights reserved. 9
![](/img.php?id=962833&img=bga.png)
your proof of purchase, which reflects that the product was installed by an
authorized dealer.
➤ Replacement remotes
Your system comes with one Responder LE remote control (P/N
7752V
)
and one companion remote control (P/N 7652V). If additional remotes
are desired, please see your authorized dealer or visit www.directed-
store.com to order.
➤ Caution
This product is designed for fuel injected vehicles only. Use of this
product in a standard transmission vehicle must be in strict accordance with
this guide.
10 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bgb.png)
,& $
Responder LC 2-Way
1 4
5
6
2 7
3 8
Feature
Description
1
LCD
531 9
)&& ,' (=6'(,
,& $
2 Lock button Press for one second to arm.
3 Unlock button
Press for one second to disarm.
4 Auxiliary button Press and hold for 1.5 second to activate
1 4
optional trun k release.
5 531 3
5 Remote start button
Press for on
start.
e second
to
activate remote
)&& ,' (=6'(,
6
6
Function button
2
3
7 Charge Port
8
Label
9 Battery Door
Allows acce ss to programming and modi-
7
fies operation of the other buttons.
8
Plug in the battery charger to this port.
Back of remote has label to identify the
remote as 2-way or 1-way.
For accessing batteries when necessary.
AUX
Note: If Keypad Lock is On, press and then press to exit.
AUX
© 2008 Directed Electronics. All rights reserved. 11
![](/img.php?id=962833&img=bgc.png)
Responder LC 1-way
Feature Description
1 Transmit indicator
2 Lock button Press for one second to arm.
3 Unlock button Press for one second to disarm.
4 Remote start Press for one second to activate remote
button start.
5 Auxiliary Press and hold for 1.5 second to activate
button trunk release.
6 Function Allows access to programming and
button modifies operation of the other buttons.
7 1 WAY Label Back of remote has label to identify the
remote as 2-way or 1-way
8
Battery Door Remove to access batteries when neces-
sary. For more details, see p.10
AUX
Note: If Keypad Lock is On, press and then press to exit.
AUX
12 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bgd.png)
➤ Transmitter configuration
Level
Button
A U X
A
A U X A
U
U
X
X
A U X
Button
Arm
A U X A U X A U X A U X
Direct
Access
x 1 x 2 x 3 x 4
ARM/LOCK
SILENT ARM SENSOR SILENT ALARM SILENT ALARM
(Panic)
BYPASS
SENSORS
ALL ZONES
DISARM/UNLOCK
SILENT DISARM VALET ON/OFF
CAR FINDER
(Panic)
STARTER
RESET RUNTIME
TIMER MODE SMART START
DEFOGGER ON
ON/OFF ON/OFF ON/OFF
TRUNK RELEASE
AUX 1 AUX 2 AUX 3
(Red/White)
Advance Level
REQUEST TEM-
RUNTIME EVENT HISTORY
Change Car (3s)
PERATURE *
REMAINING *
REPORT *
Enter program-
ming (8s) *
* button must be pressed and held to access state.
Command: Press one time to Arm
Feedback: Lock Icon will appear, and one beep from remote
Notes: Press/hold for 1.5 seconds to Arm the system and then acti-
vate the Panic output
Command: Press one time to Arm
Feedback: Unlock icon appears and remote beeps twice
Dis
A U
X
A U
X
arm
Notes:
Command: Press one time to activate Remote Start
Feedback:
Remote Start Icon appears on screen. remote emits a tone
Remote Notes:
Start
A U
X
© 2008 Directed Electronics. All rights reserved. 13
![](/img.php?id=962833&img=bge.png)
A U
X
AUX
A U
X
Function
Shift
Command: Press and hold for 1.5 seconds to activate the Trunk Re-
lease.
Feedback: The trunk icon appears and the remote plays a short tone.
Notes: This is an optional feature. See your sales rep/installer for
details.
Command: Press 1 to 4 times. ( See Function shift table.)
Feedback:
Display shows a text message across the bottom for the com-
mand received.
Notes: Each Press then release, shifts the function of the command
button.
Pressing more than one button simultaneously generates an Error tone
and the F-Shift LED turns ON.
14 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bgf.png)
Feature List:
Silent arm
Command:
Press
AUX
one- time and then press
Feedback: Screen changes to the lock icon
Notes:
Arms the system without chirps
AUX
Silent disarm
Command:
Press
AUX
one- time and then press
Feedback: Screen changes to unlock icon
Notes:
Disarms the system without chirps
AUX
Runtime reset
Command:
Press
AUX
AUX
one-time and then
Feedback: Remote start ON tones.
Notes:
Aux 1
Re-starts the remote start runtime counter if remote start
is active. Note: If remote start is not active, the 2-WAY
remote will respond with error tone.
AUX
Command: Press one time and then press AUX .
Feedback: The screen will show a text of the item activated
Notes: This is an optional feature. See your sales rep/installer
for details.
Cabin temperature
Command:
Press
AUX
one time, then Hold for 1.5 seconds.
Feedback: Screen will display current in cabin temperatue.
Notes: Cabin temperature is displayed on the remote. LED lights
up to indicate a range.
© 2008 Directed Electronics. All rights reserved. 15
![](/img.php?id=962833&img=bg10.png)
AUX
AUX
Sensor Bypass
Command:
Press
AUX
two- times and then
Feedback: Screen will display text of sensor bypass
Notes:
Valet mode
Available when armed only: bypasses warn triggers.
Send again to bypass Warn & Full Trigger; Send again
to turn bypass off and monitor sensors normally. For more
information, see Modified Arming Modes.
AUX
Command: Press two-times and then
Feedback: Unlock Icon appears hollow and text states Valet when
entering Valet mode.
Unlock Icon appears solid and text states Valet when
exiting Valet mode
Notes:
Timer mode
To enter or exit Valet mode, even if Armed. When enter-
ing Valet Mode the unlock LED blinks, and the remote
beeps one time. When exiting Valet Mode the unlock
LED blinks and the remote beeps two-times.
AUX
Command: Press two-times and then
Feedback: Small timer icon appears and text reads timer mode.
Notes:
Aux 2
Enables or disables the remote start timer mode.
AUX
Command: Press two times and then press AUX .
Feedback: Text will display the item activated
Notes: This is an optional feature. See your sales rep/installer
for details.
16 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg11.png)
AUX
Armed status
Command:
Press
AUX
two-times and then Hold for 1.5 seconds.
Feedback: Icon on remote will flash showing current status
Notes:
Replays last Arm /Disarm status message received.
Armed (silent sensor mod
AUX
)
Command:
Press three- times and then
Feedback:
Image of hollow siren appears and text reads Silent Sen-
sor.
Notes:
Car finder
Arms the system; sensor Full Trigger will ONLY page the
remote and will not activate the siren/lights. Wired in-
puts will page and activate the siren/lights.
AUX
Command: Press three-times and then
Feedback: Icon of vehicle flashes and text
AUX
reads car finder. On
Vehicle: 1 long siren chirp and parking lights flash 10
times.
Notes:
Smart start
Arm/Disarm cancels the light flashes.
AUX
Command:
Press
three-times and then press
Feedback:
Text reads Smart Start On
Notes:
Enables or disables the SmartStart feature.
AUX
Aux 3
Command:
Press
AUX
three times and then press AUX
Feedback: Text will display the item activated
Notes: This is an optional feature. See your sales rep/installer
for details.
© 2008 Directed Electronics. All rights reserved. 17
![](/img.php?id=962833&img=bg12.png)
Runtime check
Command:
Press
AUX
three-times, and then Hold for 1.5 seconds.
Feedback: Text reads runtime and displays time left
Notes: Runtime remaining is displayed on the remote. (See
page 28).
Armed (silent trigger moAUXe)
Command: Press four- times and then
Feedback: Text displays Silent Full AUX
Notes: Arms the system; sensor and hardwire Full Triggers will
ONLY page the remote and will not activate the siren/
lights. For more details see Silent Mode 2 section on
page 25.
Rear defogger
AUX
AUX
Command: Press four times, and then (Only after remote
start is on.)
Feedback: Defogger icon appears on remote and text reads Defrost
On.
Notes:
Last trigger
Automatically turns on during remote start.
AUX
Command:
Press four- times and then hold for 1.5 seconds.
Feedback:
Text scrolls last trigger.
Notes:
Trigger refers to the remote tones and LED pattern gener-
ated by the last alarm trigger event.
18 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg13.png)
Out of Range Notification
If a command is issued from the remote, but the remote is beyond the
range of the vehicle to receive the command, the remote will respond
with an Out of Range notification. If this occurs, the remote will emit a
harsh tone and the out of range indicator will appear.
Since conditions will vary in different areas (ie: Weather, RF
interference, etc) range may be affected and require you to be closer to
the vehicle for successful transmission.
➤ System maintenance
The system requires no specific maintenance. Your One way remote is
powered by small coin cell lightweight 3-volt lithium battery that will last
approximately one year under normal use. The 1-way remote uses one
CR2032 cell battery. The 2-way remote contains a non-replaceable
rechargeable battery. When the battery begins to weaken, the operating
range will be reduced.
➤ Charging the Battery
• Plug in the USB charger (alternately a standard mini USB cable
connected to any standard USB port on any laptop or desktop
computer can also be used (cable not included)).
• The LCD displays “ CHARGE” while the battery level bars within
the battery icon flash, displaying the current charge level as the
battery charges.
• When charging is complete the LCD then displays “ FULL” .
Note: If the battery has been severely discharged all remote functions
are disabled for a short charge period. The battery status outline flashes
© 2008 Directed Electronics. All rights reserved. 19
![](/img.php?id=962833&img=bg14.png)
bank selector
1 3 4 5
Control
Toggles
indicator indicator
and CHARGE is displayed on the LCD. Once the battery has accu-
mulated enough charge for functionality, the LCD icons initialize with
a beep sound, the battery status outline stops flashing and the remote
becomes operational while still displaying CHARGE.
Warning! The temperature range over which
the battery can be charged is 0ºC TO 45ºC
(32ºF TO 113ºF). Charging the battery at
temperatures outside this range may cause
severe damage to the battery or reduce bat-
tery life expectancy.
➤ Low battery indicator
When the batteries are low on the 2-way remote it will emit two groups
of beeps, the battery icon will flash and the text will display low batt,
the alarm then emits an additional chirp upon disarming of the alarm to
let you know its time to change the battery. When the battery is low on
the 1-way remote, the remote responds the same, but without the icons
available on the two way remote.
Note: The Arm/Disarm
Sat mode,
Bank and Channel
present Tune mode and text
indicator
chirps sho uld be program med ON for the
alarm to emit any additional chirps during disarm. Ask your autho-
rized dealer if you have any questions.
11:53
CATEGORY CH
Category
XM1-1 CH-001
➤ Battery Replacement
Slide the door up to expose the battery beneath the holder. Remove the
REW FF PLAY/PROG NR DISC- DISC+
2 6
ex
pired battery. Place the new
battery
into the rem
ote
control. When
Scan mode
power is returned the remote control is ready for use.
SCAN VOL
SOUND
20 © 2008 DirecPeW Rlectronics. All rights reserved.
A
UDIO
![](/img.php?id=962833&img=bg15.png)
➤ LCD Iayout
ALL
➤ LCD remote features
1
Armed
2
Locked
ALL
3 disarmed
ALL
4 Unlocked
5
Alarm
6
Remote Start
7
Battery Status
8 Pager On
ALL
ALL
ALL
ALL
ALL
22
Car Door (Zone bypass)
ALL ALL
23
Hood (Tr
ALL
ger)
ALL
ALL
24
Hood (Zone bypass)
25
Trunk (Trigger)
26
Trunk (Zone bypass)
ALL
ALL
27
Home (Garage - Open)
ALL
28
Home (Garage Close)
ALL
29
Small Remote Start
ALL
© 2008 Directed Electronics. All rights reserved. ALL 21
![](/img.php?id=962833&img=bg16.png)
9 Pager Off
30
10
Pager Vibe On
31
ALL
11
Pager Tone On
2 3
ALL
ALL
12
Siren
3
AL L
13
Silent Mode 2
34
LL
14
Transmit
ALL
3
A
15
Receive
36
16
Out of Range
37
17
Sensor
38
18
Sensor Bypassed
39
19
ALL
All Zones
40
ALL
20
1
41
21
Car Door
42
➤ Multi-car control capability
Timer Mode
ALL
ALL
Manual Transmission En-
ALL
abled
ALL
ALL
Car 1
Car 2
ALL
ALL
Thermometer very cold
ALL ALL
Thermometer cold
Thermometer comfortable
Thermometer warm
ALL
Thermometer hot
ALL
Defroster
Arrow
Sound Wave
ALL
Large Siren
You can operate the 2-way remote control system for two cars, with full
command capability for both vehicles.
22 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg17.png)
While holding a command button and transmitting, the car icon at the top
of the remote control will blink in groups to indicate which Car is being
controlled.
• Car 1: 1 blink
• Car 2: 2 blinks
To change the Car to be operated:
Two Way Remote
Press/hold the
AUX
button for 3 seconds or until the rem
AUX
te beeps
and the text reads Car 1 or Car 2. Pressing the button will scroll
between the two.. This will indicate which car the remote currently
operates.
One Way Remote
AUX
Press and hold the
button until the amber light blinks once or twice
indicating current vehicle (one blink = car 1.AUX blinks = car 2) to
scroll from one to the other press the button again.
Using the system
➤ Arming the system
To arm the system, press the
button on the remote control.
AUX
The siren in the vehicle will “ chirp” once and the parking lights will
flash once. If the power door locks have been connected, the doors
will lock. The system will automatically check for errors when it arms.
The 2-way remote will “ chirp” once and blink the LOCK indicator to
© 2008 Directed Electronics. All rights reserved. 23
![](/img.php?id=962833&img=bg18.png)
AUX
confirm arming. If no arm confirmation is received, the remote will give
the Out-Of-Range signal.
If errors are found when arming:
If an alarm trigger zone - such as a door, the trunk, the hood, or a
sensor, was active at the time of arming, the system will “ bypass” , or
ignore, this trigger zone. This allows the system to continue to protect
your vehicle using the remaining trigger zones.
You are notified of this active zone immediately after arming the system.
The siren in the vehicle will “ chirp” again and the parking lights will
flash again. The Status LED indicator in the vehicle will blink in a pattern
to indicate the active zone number error which was found (See Table
of Zones on page 36). The 2-way remote control will sound a short
“ error” tone.
Arming without the chirp (Silent Arm):
AUX
Press the button at the bottom of the remote once, and then press
the button. The system will arm without the confirmation chirp. The
parking li ghts will flash once. The 2-way remote will blink the LOCK
indicator to confirm arming. If no arm confirmation is received, the 2-way
remote will give the Out Of Range signal.
➤ While the system is armed
• Fail-Safe Starter Kill
The starter is disabled by the system’s Fail-Safe starter kill.
Alarm Responses
The security system can generate two levels of alarm: Warn Away - Soft
24 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg19.png)
siren chirps and flashing parking lights.
The purpose of Warn-Away is to warn a would-be thief next to your
vehicle that the vehicle is protected, but in a manner that does not call
attention to it from more than a few feet away.
Full Alarm Trigger
Sounds the siren at maximum volume and flashes the parking lights.
The default duration of the Full Alarm is 30 seconds. This can be
programmed to any duration from 30 to 60 seconds manually. Ask your
authorized dealer for details.
Pages the 2-way remote control. If in range, the two way remote will
display what triggered the alarm.
Warn-Away response is triggered by:
• Lesser or lighter vibrations or impacts (detected by the Stinger
Doubleguard shock sensor)
• Opening a door: the Progressive Door Trigger feature will sound
the Warn Away response, followed immediately by Full Alarm
• Any attempt to start the car: the Progressive Ignition Trigger will
first sound the Warn Away response, followed immediately by Full
Alarm.
• An optional Proximity Sensor (508D) triggered in the outer zone.
Full Alarm response is triggered by:
• Heavier impact to the vehicle (detected by the Stinger Double-
Guard shock sensor).
• Opening the trunk or hood.
• Opening a door: the Progressive Door Trigger feature will first
© 2008 Directed Electronics. All rights reserved. 25
![](/img.php?id=962833&img=bg1a.png)
AUX
sound the Warn-Away response, followed immediately by Full
Alarm.
•
An optional sensor, such as an optional Proximity Sensor triggered
in the inner zone.
Paging Signals
If the Full Alarm response is triggered, the 2-way remote control will be
sent a paging signal by the in-car system.
Note: Call the police immediately if you witness a crime in progress.
Paging range varies with terrain and environmental conditions.
➤ Modified Arming Modes
The Responder LC gives you an unprecedented level of control over
how it will protect your car. “ Normal arming” means that all the
Responder LC security features are active automatically. You can turn
some security features off on a one-time basis.
Turning off the Warn Away response
After arming, you can turn off the Warn-Away response on a one-time
basis.
1.
Press the
2.
Press the
AUX
button twice.
button.
The
LED flashes
and the remote sounds an error tone.
AUX
Now, slight impacts or vibrations will not trigger Warn-Away. Heavy
impacts will still trigger Full Alarm.
Note: The next time you arm the system, Warn-Away will work
normally.
26 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg1b.png)
Turning off the Sensor Full Trigger response
You can completely disable the Stinger Doubleguard Shock Sensor
and any added optional sensors on a one-time basis. The entry points
(doors, hood, etc.) will still be monitored. All sensors will not be able to
trigger the Warn-Away response or the Full Alarm response.
1.
After disabling Warn-away response, press the
twice.
2.
Press the
button.
AUX
AUX
the button
Note: The next time you arm the system, the shock sensor will work
normally.
Silent Mode 2 - Turning off the siren
You can turn off the vehicle siren and flashing lights on a one-time basis,
leaving the system’s paging feature as the only alarm response.
Note: Call the police immediately if you witness a crime in progress.
Paging range varies with terrain and environmental conditions.
Full Silent Mode.
In this mode, the siren cannot be triggered, but any trigger will cause the
2-way remAUX te to be paged.
Press the
button four times, and then press the
seconds.
Sensor Silent Mode
within five
AUX
In this mode, a sensor cannot trigger the siren, but will cause the
2- way remote to be paged. All entry points (doors, hood, etc.) will still
trigger the siren.
AUX
Press the button three times, and then press the button.
Note: The next time you arm the system, it will function normally. AUX
© 2008 Directed Electronics. All rights reserved. 27
![](/img.php?id=962833&img=bg1c.png)
AUX
➤ Disarming the System
While the system is armed normally:
• Press the button once.
The siren in the
AUX
vehicle will “ chirp” twice, and the parking lights
will
flash. The 2-way remote will “ chirp” twice and
the will blink.
LED indicator
AUX
If you hear four chirps on disarming, the system was triggered in your
absence. Immediately look at the Status LED in the vehicle and count
the
number of flashes between pauses. This number is important, it tells what
triggered your alarm. See Disarming section under Diagnostics on
page 34 for
more details.
If you hear five chirps on disarming, the system was repeatedly
trig
gered in your absence. Immediately look at the Status LED in the vehicle
and count the number of flashes between pauses. This number is impor
tant, it
tells what triggered your alarm.
The door locks (if connected) will unlock, and the parking lights will
flash.
While the alarm is triggering:
Press the button on the remote. The siren will stop sounding and
disarm the a
AUX
larm system.
High-Security Disarming
If you want the Full Alarm response to stop without unlocking the doors,
press the button. The system will re-arm and the current alarm re-
sponse will reset.
➤ System override
28
© 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg1d.png)
3. Body color :
CODE
SHEET
OF
94I0600
%/$&.
To disarm the system without a remote control:
You will need to use your Override Switch located on your systems
control center (see diagram below) to disarm the system. The Override
Switch disarms the system only if you have the vehicle key.
10.44
11.50
CASE P/N:IADGH0A1
KEY P/N:IKDEL0A0
To check proper operation
:
%2'< 0
$7
(5,$/ +,+($7
$%6 89
*Tolerance please refer specification
1. Texture is same as
of tolerance limits "c" GRADE
INJE CT TOL ERA NCE SP EC.
2. Radious will be if not specifie d.
SCALE:
UNIT: DRN BY
DATE
1:1 M/M
VICTOR
11/20/07
NUTEK
CORPORATION
• Open the d
o
DIMENSION
UNDER 6
6~30
30~120
120~30
0
o
0.08
r.0.16
Th
0.30
e
a
larm
will sound.
0.10 0.20 0.20 0. 40 0.40 0. 80
0.40 0.80 2.00
MATERIAL
FINISH
CHK BY
FELIX
APPD BY
YGF
TITL
E
SIZE
A4
DEI
OLED IVU
DEPT
DRAWING NO
REV
94I0600
0
Immediately inser
t t
he
key into the ignition and turn i
t to th
e
RU
N or ON
position. (all the indicators in t he dash will turn on).
Press the Override Switch once.
Note: The Override Switch feature allows you to select a specific
number of presses needed to disarm the alarm. If the Override
Switch has been programmed to a new number of presses by your
authorized dealer, that number should be indicated below.
Override Switch Number ___________
© 2008 Directed Electronics. All rights reserved. 29
![](/img.php?id=962833&img=bg1e.png)
Using the remote start
➤ Before using your Remote Start
Read this user guide, including the Warnings section at the begin-
ning.
Ensure that the vehicle is parked in the open air and not in a garage.
To use your remote start to pre-warm or pre-cool your vehicle, remember
to set the climate controls to the desired settings before shutting off the
engine.
➤ Remote starting your vehicle
AUX
• Press the button on the remote control. The vehicle parking
lights flash.
• On the 2-way remote, the Remote Start indicator appears and
ascending Remote Start tone plays.
The preset remote start run time is 12 minutes. This can be changed to
between 12 and 60 minutes (see your authorized dealer for
programming changes).
Your system has a feature (if programmed on) that will automatically
notify you when the run time is running low. When 9 minutes (of the 12
minute default) runtime has elapsed, the system sends the 2-way remote control
a paging signal.
➤ Points to remember
If the hood is open or is the brake pedal is pressed, the vehicle will not
start using remote start. The remote starter shuts down:
• When the brake pedal is pressed
• The hood is opened
30 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg1f.png)
• If the alarm is triggered when armed.
• When the Remote Start command is sent again from a remote
control
➤ Runtime Check
To check the amount of runtime remaining (2 way remote only):
AUX
After the vehicle is remote started, press the
button three-times and
then hold until the remote beeps, and then release. The display will
show a text indicating remaining run time.
➤ Manual transmission
If the vehicle has manual transmission the proper steps must be fol-
lowed before leaving the parked vehicle or the remote start feature is
disabled.
1. Put the transmission in neutral.
2. Press on the vehicle’s foot brake.
3. Apply the emergency brake.
4. Release the vehicle’s foot brake. Note: Pressing the brake again
after this step will disable the remote start feature.
5. Within 15 seconds activate the remote start from the remote.
6. The parking lights will flash 5 times confirming that the remote start
is active.
7. Turn off the ignition (the car should stay running when key is turned
off).
8. Exit the vehicle and close the door.
9. Arm the alarm (the vehicle should shut off when arming the sys-
tem).
You can now remote start the vehicle. If a door is opened or if the alarm
© 2008 Directed Electronics. All rights reserved. 31
![](/img.php?id=962833&img=bg20.png)
AUX
is triggered before the next remote start activation the system will not
remote start.
To drive your vehicle after it has been remote started:
1. Get in without stepping on the brake.
2. Insert the ignition key and turn it to the ON position.
3. Now, step on the brake.
The remote control will play the remote start shutdown tone. You have
now taken direct control from the remote start system.
➤ Timer mode
To activate the runtime of the vehicles engine during remote start:
AUX
1.
Press the
button two-times and then
AUX
2. The vehicle will confirm with 4 fast parking light flashes.
3. The system will start every 3 hours until canceled by the brake,
hood, or neutral safety shut-down wires. The remote will respond
with the Start and Stop remote start notification during each Start
and Stop of the Vehicle while in Timer mode.
Important! Timer Mode should be used only in open areas. Never
start and run the vehicle in an enclosed space such as a garage or
carport.
AUX
To exit timer mode, Press the button two-times and then again.
➤ Turbo timer mode
Turbo timer mode keeps the engine running after arriving at your desti-
nation for a programmable period of 1, 3, 5 or 10 minutes. This allows
the system’s timer to conveniently cool down the turbo after you have
32 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg21.png)
AUX
left the vehicle.
Transmit the time
AUX
mode feature with the remote while the engine is run-
ning, press two-times and then After exiting the vehicle, arm the
alarm and the vehicle will remain running for the programmed runtime.
(The remote start feature is still enabled).
The system monitors the engine speed and will automatically shut the
engine off if the RPMs rise above or fall below the programmed levels.
This feature prevents damage to the motor due to fuel delivery system
failures or other problems which may cause the engine to race.
Note: To enter turbo timer mode with a manual transmission, perform
the manual transmission procedure (See p.29), with the door open.
Rear defogger
The rear defogger (if connected) is programmed to automatically activate
when remote start is turned on. If the interior cabin temperature is above
55˚ F the defogger will not activate.
To manually activate the rear defogger after remote start is on:
AUX
Press four times, and then
Valet take-over
The Valet take-over feature allows the vehicle to remain running after
the key has been removed from the ignition. This feature is useful for
occasions when you wish to exit and lock the vehicle for short periods
of time, but would like to leave the motor running and the climate
controls on.
© 2008 Directed Electronics. All rights reserved. 33
![](/img.php?id=962833&img=bg22.png)
To perform Valet take-over:
1. Before turning off the engine, press and release on the trans-
mitter. Then wait a few seconds.
2. Turn the ignition key to the OFF position (The engine will stay
running).
3. The engine will run until the pre-programmed time elapses or a
shut-down input is received.
Note: To enable Valet take-over with a manual transmission, open the
door when going into a manual transmission mode. After you exit
the vehicle you can arm the alarm and the car will remain running. If
the vehicle shuts down when arming, then the unit did not enter the
valet take-over mode.
34 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg23.png)
Safety features
This system has several important safety features to ensure proper
operation of the motor and prevent accidental damage to the engine or
its components.
➤ Starter anti-grind circuitry
Whenever the vehicle is remote started, advanced anti-grind circuitry
prevents the starter from engaging, even if the key is turned to the start
position. This prevents damage to the starter motor if the key is turned to
the start position during remote start operation.
Note: Anti-grind circuitry only works when the remote start system is
operating the motor and the Failsafe® Starter Kill relay is installed.
➤ Disabling the remote start system
This feature allows the remote start unit to be temporarily disabled to
prevent the vehicle from being remote started accidentally. This
feature is useful when the vehicle is being serviced or stored in an
enclosed area.
To disable the remote start, move the shutdown toggle switch to the
OFF position. Check with your installer for the location.
Location of Shutdown Switch____________________________
© 2008 Directed Electronics. All rights reserved. 35
![](/img.php?id=962833&img=bg24.png)
Diagnostics
The microprocessor at the heart of your system is constantly monitoring
all
of the switches and sensors connected to it. It is designed to detect any
faulty switches and sensors and prevent them from disabling the entire
system. The microprocessor will also record and report any triggers that
occurred during your absence.
Refer to System Status Chirps and Table of Zones sections of this guide for
diagnostic information.
➤ Arming
If the security system is armed at the same time that an input is active
(such as a door opening or sensor triggering), you will hear one siren
chirp to indicate arming and a second siren chirp to indicate Bypass
Notification.
A Bypass Notification chirp means that the security system ignores the
input that was active when the system was armed, until that input
ceases. Three seconds after that input ceases, the security system will
resume normal monitoring.
For example: if your vehicle has an interior light exit delay and you arm
your security system before the interior light turns off, you may hear a
second Bypass Notification chirp.
Once the light turns off, however, the security system resumes normal
monitoring.
Note: Bypass Notification does not occur when the system is in Silent
Mode or if the notification chirps have been programmed off by the
installer.
36 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg25.png)
➤
Disarming
Extra chirps heard when disarming the system are the Tamper Alert.
If four chirps are heard when disarming the system, then the security
system was triggered in your absence.
If five chirps are heard when disarming the system, the system was
triggered so many times that the Nuisance Protection® Circuitry has
bypassed the intended zone. In either case, the status LED will indicate
which zone was involved (see Table of Zones).
The security system will retain this information in its memory, and chirp
four or five times each time it is disarmed, until the next time that the
ignition is turned on.
➤ System status chirps
The siren will chirp when arming/disarming the system. The pattern of
chirps will audibly report the system’s status as described below.
Action Number of Chirps Description
Arm 1 System armed
Arm 1 (3-second delay) System armed with bypass notification
Disarm 2 System armed
Disarm 4 System disarmed with Tamper Alert
Disarm 5 System disarmed
© 2008 Directed Electronics. All rights reserved. 37
![](/img.php?id=962833&img=bg26.png)
➤ Table of zones
A zone is represented by the number of LED flashes used by the system
to
identify a particular type of input. Standard input assignments are listed
in the following table, along with spaces to write in any optional sensors
or switches that have been installed.
Zone Description Dealer installed options
1 Trunk Pin
2 Instant trigger: a heavier impact
detected by the shock sensor
3 Door switch trigger
4 Instant trigger: For optional
sensors
5 Ignition trigger
6 Hood Pin
➤ Interpreting zone diagnostics
Warn Away responses are not reported by arming or disarming
diagnostics. If you receive a Bypass notification when arming or a
Tamper Alert notification when disarming, look at the LED.
Active or triggered zones will be indicated by a pattern of blinks by the
LED.
For example: If zone 3 was active or triggered, the LED will blink three
times with a two-second pause. Then it will blink three times again, and
repeat until the ignition is turned on.
38 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg27.png)
➤ Nuisance prevention® circuitry
Your system has Directed’s Nuisance Prevention® Circuitry (NPC). It
prevents annoying repetitive trigger sequences due to faulty door pin
switches or environmental conditions such as thunder, jackhammers,
airport noise, etc.
For example:
If the alarm triggers three times within a 60-minute period
and
each time the same sensor or switch triggers the alarm, NPC will
interpret those triggers as false alarms. After the third trigger, NPC
ig
nores, or bypasses, that sensor or switch (along with any other sensors or
switches sharing the same zone) for 60 minutes.
If the bypassed sensor tries to trigger the security system while it is being
bypassed, the 60-minute bypass period will start over. This ensures that
a sensor that is continually being triggered will remain bypassed.
The vehicle doors are protected by NPC differently. If your security
system is triggered by an open door for three full cycles, the system will
bypass the doors until the trigger ceases.
© 2008 Directed Electronics. All rights reserved. 39
![](/img.php?id=962833&img=bg28.png)
Owner recognition
Owner Recognition lets up to four users of the system have unique set-
tings that meet their specific needs. It is almost like having four separate
alarms in your vehicle, one for each user. This feature is only available
to authorized dealers using the Bitwriter or Bitwriter 2 program tool.
Rapid resume logic
This Directed system will store its current state to non-volatile memory. If
power is lost and then reconnected the system will recall the stored
state from memory.
For example, if the unit is in Valet Mode and the battery is disconnected
for any reason, such as servicing the car, when the battery is recon-
nected the unit will still be in Valet Mode. This applies to all states of the
system including arm, disarm, and Valet Mode.
40 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg29.png)
Power saver mode
➤ System
Your system will automatically enter Power Saver Mode while armed or
in Valet Mode, after a period of time in which no operation has been
performed. This lowers the current draw on the vehicle’s battery. Power
Saver Mode takes over under the following conditions:
Power Saver when the system is armed: After the system has been
armed for 24 hours the LED will flash at half its normal rate, decreasing the
system’s current draw.
Power Saver in Valet Mode: When the system enters Valet Mode the
Status LED on the Responder LE control center illuminates steadily. If the
vehicle is not used (ignition is not turned on) for a one hour period while
the system is in Valet Mode, the status LED will shut off. If the system
remains in Valet Mode, the LED will come back on the next time the
ignition is turned on and then back off.
➤ 2-way remote
Your Responder LE 2way remote control has a feature called remote
power save mode. When programmed ON under remote options, the
remote will conserve power by disabling the paging function if unused
for more than 72 hours. Pressing any button on the remote will restore
the paging function.
The default setting is ON. See Remote control programming section of
this guide or ask your dealer for details on how to program.
© 2008 Directed Electronics. All rights reserved. 41
![](/img.php?id=962833&img=bg2a.png)
Programming options
Your system has many custom programmable options. Some may
require installation labor. Ask your authorized dealer for details.
The following is a list of the programmable options, with the factory
settings in Bold.
• Active
arming (remote only) passive arming with or without locking
the doors (automatic arming without locking the doors 30 seconds
after the last door has been closed), or Auto Re-arm with or without
locking the doors (Automatically arms 60 seconds after disarm if
no door is opened).
Arming/disarming siren chirps ON with or without Warn-away chirps, Or
OFF with or without Warn-away chirps.
• Ignition controlled door lock feature ON or OFF: When this fea-
ture is programmed on, the doors will lock three seconds after the
ignition is turned on, and unlock when the ignition is turned off.
If your installer is programming the security system with the Directed
Bitwriter®, ignition lock and unlock are independent features that can
be programmed separately.
• Panic mode enabled/disabled when the ignition is turned on or
completely turned OFF. (Some states have laws against sirens
sounding in moving cars.)
• Full trigger response 30 or 60 seconds: This determines how long
the full triggered sequence lasts. Some states have laws regulating
42 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg2b.png)
how long a security system can sound before it is considered a
nuisance.
• If your installer is programming the security system with the Di-
rected Bitwriter®, the full triggered response can be programmed
for any duration ranging from 1 to 180 seconds.
• Siren tones and chirp volume: The output of the Revenger™Soft
Chirp™ siren consists of six different tones in sequence. Any of
these tones can be eliminated by a dealer, resulting in a unique,
easily identifiable siren sound. The chirps can be either full volume
or 6 decibels quieter than the full alarm blast.
• Comfort closure is a programming option which closes the ve-
hicle’s windows after remote locking.
© 2008 Directed Electronics. All rights reserved. 43
![](/img.php?id=962833&img=bg2c.png)
Security & convenience expansions
Listed below are some of the many expansion options available. Please
consult your dealer for a complete explanation of all the options avail-
able to you.
Audio Sensor: Metal on glass, glass cracking, and breaking
glass produce distinctive acoustic signatures. The 506T audio sensor
uses a microphone to pick up sounds, then analyzes them with propri-
etary acoustic software to determine if the glass has been struck.
Backup Battery: The 520T keeps the system armed, triggers the alarm
and keeps the starter interrupt active if main battery is disconnected.
Digital Tilt Sensor: The 507M tilt sensor can be added to your system
to protect your car when its parked. It can protect your vehicle from be-
ing lifted and provide protection for your expensive rims.
Field Disturbance Sensor: An invisible dome of coverage is established
by installing the 508D “ radar” sensor. Your system can react to any
intrusions into this field with the full triggered sequence.
Power Locks: This system offers lock outputs that can control some
manu
facturers’ power door lock systems. For other systems, additional
parts may be required.
Hood Lock: Prevents the vehicle’s hood from being opened without a
key, keeping thieves away from the system’s siren, the battery
connections, and other components under the hood.
Power Trunk Release: The accessory output of the system can operate
a factory power release for the vehicle’s trunk or hatch. Although the
44 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg2d.png)
on-board relay can control most power trunk releases, sometimes an
optional relay is required. If the factory release is not power-activated,
Directed®’s 522T trunk release solenoid can often be added.
Power Window Control: Automatic power window control is provided
with the 529T and 530T systems. These can operate power windows,
and can roll them up automatically when the system is armed, roll them down,
or both up and down.
Ultrasonic Cabin Sensor: Using the 509U Ultrasonic cabin sensor pro-
vides a field of protection inside the car to protect your belongings.
© 2008 Directed Electronics. All rights reserved. 45
![](/img.php?id=962833&img=bg2e.png)
Glossary of terms
2-Way Remote: A hand-held, remote control which operates the
various functions of your system and receives feedback and pages from
the
alarm system.
Control Center: The control center contains the system’s radio-frequency
antenna, the valet and override switch, and the Status LED.
For maximum remote-control range, the Control Center is usually lo-
cated at the top of the windshield, centered near the rear-view mirror.
Control Module: The “ brain” of your system. Usually hidden underneath
the dash area of the vehicle. It houses the microprocessor which monitors
your vehicle and controls all of the alarm’s Functions.
Failsafe® Starter Kill (if equipped): An automatic switch controlled by
the security system which prevents the vehicle’s starter from cranking
whenever the system is armed. The vehicle is never prevented from
cranking when the system is disarmed, in Valet® Mode, or should the
starter kill switch itself fail. Your system is ready for this feature, however
installation of this feature may require additional labor.
Input: Any physical connection to the security system. An input can
be provided through a sensor, pin-switch or by existing systems in the
vehicle, such as ignition or courtesy lights.
In-vehicle status LED: A light used to indicate the status of your system. It is
located on your systems control center.
Shock Sensor: This system has a dual zone shock sensor. This
sensor is mounted in the vehicle and designed to pick up impacts
46 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg2f.png)
to the vehicle or glass.
Trigger or Triggered Sequence: This is what happens when the
alarm “ goes off ” or “ trips.” The triggered sequence of your
system consists of the siren sounding and parking lights flashing
for the
programmed duration.
Valet Button: A small push button switch located on your systems control
center. It is used to override the
starter interrupt when a 2-way remote is lost or damaged, or to
enter or exit Valet Mode.
Warn Away® Response: Light impacts to the vehicle generate the
Warn Away® Response, which consists of several seconds of horn
honks and flashing parking lights.
Zone: A zone is a separate input that the alarm can recognize as
unique. Each input to the system is connected to a particular zone.
Often, two or more inputs may share the same zone.
© 2008 Directed Electronics. All rights reserved. 47
![](/img.php?id=962833&img=bg30.png)
48 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg31.png)
AUX
AUX
AUX
Quick reference guide
Arming
To arm, press . When the system arms, the LOCK LED blinks for
one second, with 1 beep and siren tone.
Arming while driving
To arm the system while driving, press on your remote while the
vehicle is running. The LOCK LED blinks for o
ne second.
Disarming
To disarm, press . The UNLOCK LED blinks for one second, and
REV. 1
DESCRIPTION
you will hear 2 beeps.
Disarming without a remote
Turn on the ignition. Press the Valet button within 15 seconds. The
system should now disarm. If it does not, you may have waited too
long or pressed the button incorrect number of times. Refer to reverse
10.44
side for Valet pushes and try again.
11.50
Number of Valet button pulses for disarming_______________
C
A
K
%2'< 0$7(5,$/ +,+($7$%6 89
*Tolerance pleas e refer s pecification 1. Textur e is same as
SCALE:
UNIT: DRN BY DATE
AUX
Silent Arm
of tolerance limits "c" GRADE
INJE CT TOL ERA NCE SP EC.
3. Body color :
2. Radious will be if not specified. %/$&.
DIMENSION UNDER 6
0.08 0.16 0.30
6~30 0.10 0. 20 0.40
30~ 12 0 120 ~30 0
0.20 0.40 0.40 0.80 0. 80 2.00
1:1 M/M
VICTOR
11/20/07
MATERIAL
CHK BY
FELIX
FINISH
YGF
APPD BY
CODE
SHEET
OF
Press
one time and then press
second with no sound.
AUX
. Arm LED will blink f or on
e
9
AUX
I0600
Silent Disarm
Press
one time and then press
second with no sound.
. Disarm LED will blink for 1
AUX
© 2008 Directed Electronics. All rights reserved. 49
![](/img.php?id=962833&img=bg33.png)
AUX
Remote Start
AUX
Press
. R emote start LED blinks for 3 seconds and remote start
tone sounds.
AUX
Rear Defogger
AUX
Press four times, and then press
(o
nly after remote start is
ON.) Remote start LED turns ON, and you will hear 1 beep.
To disable the remote start system
Move the shutdown toggle switch to the OFF position.
Location of Shutdown Toggle Switch___________________
Valet Mode
AUX
Press two times and then . The UNLOCK LED and Function
LED blink and remote beeps one time. When valet Mode OFF, the
remote beeps two-times.
Valet take over
AUX
Before turning off the engine, press and release . within 3 sec-
onds. Then wait a few seconds.
Turn the ignition key to the OFF position.
The engine will remain running until the programmed time elapses or
a shut-
down input is received.
Location of Valet button_________________________________
50 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg34.png)
Limited lifetime consumer warranty
Directed Electronics. (“ Directed” ) promises to the original purchaser to repair or replace (at
Directed’s election) with a comparable reconditioned model any Directed unit (hereafter
the “ unit” ), excluding without limitation the siren, the remote transmitters, the associated
sensors and accessories, which proves to be defective in workmanship or material under
reasonable use during the lifetime of the vehicle provided the following conditions are met:
the unit was purchased from an authorized Directed dealer, the unit was professionally
installed and serviced by an authorized Directed dealer; the unit will be professionally
reinstalled in the vehicle in which it was originally installed by an authorized Directed
dealer; and the unit is returned to Directed, shipping prepaid with a legible copy of the
bill of sale or other dated proof of purchase bearing the following information: consumer’s
name, telephone number and address; the authorized dealers name, telephone number
and address; complete product description, including accessories; the year, make and
model of the vehicle; vehicle license number and vehicle identification number. All com-
ponents other than the unit, including without limitation the siren, the remote transmitters
and the associated sensors and accessories, carry a one-year warranty from the date of
purchase of the same. ALL PRODUCTS RECEIVED BY DIRECTED FOR WARRANTY REPAIR
WITHOUT PROOF OF PURCHASE WILL BE DENIED. This warranty is non-transferable
and is automatically void if: the original purchaser has not completed the warranty card
and mailed it within ten (10) days from the date of purchase to the address listed on the
card; the unit’s date code or serial number is defaced, missing or altered; the unit has been
modified or used in a manner contrary to its intended purpose; the unit has been damaged
by accident, unreasonable use, neglect, improper service, installation or other causes not
arising out of defects in materials or construction. The warranty does not cover damage
to the unit caused by installation or removal of the unit. Directed, in its sole discretion, will
determine what constitutes excessive damage and may refuse the return of any unit with
excessive damage.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUDING
BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF
MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE AND WARRANTY OF NON-
INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE EXPRESSLY EXCLUDED; AND
DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY PERSON OR ENTITY TO ASSUME
FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS.
DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS
OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS OR INSTALLERS. DIRECTED
SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS AGAINST POSSIBLE
THEFT. DIRECTED IS NOT OFFERING A GUARANTEE OR INSURANCE AGAINST
VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS;
AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUDING
© 2008 Directed Electronics. All rights reserved. 51
![](/img.php?id=962833&img=bg35.png)
WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VANDALISM. THIS
WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE, REMOVAL OR
REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF ANY KIND.
IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY,
THE VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA.
CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN
THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DIRECTED
SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER’S PURCHASE
PRICE OF THE UNIT. DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES
WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,
INCIDENTAL DAMAGES, DAMAGE TO VEHICLE, DAMAGES FOR THE LOSS OF TIME,
LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY
AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER
A LIMITED WARRANTY TO REPLACE OR REPAIR THE CONTROL MODULE SUBJECT TO
THE CONDITIONS AS DESCRIBED HEREIN. THIS WARRANTY IS VOID IF THE UNIT
HAS NOT BEEN PURCHASED FROM DIRECTED, OR AN AUTHORIZED DIRECTED
DEALER, OR IF THE UNIT HAS BEEN DAMAGED BY ACCIDENT, UNREASONABLE USE,
NEGLIGENCE, ACTS OF GOD, NEGLECT, IMPROPER SERVICE, OR OTHER CAUSES
NOT ARISING OUT OF DEFECT IN MATERIALS OR CONSTRUCTION.
Some states do not allow limitations on how long an implied warranty will last or the exclu-
sion or limitation of incidental or consequential damages. This warranty gives you specific
legal rights and you may also have other rights that vary from State to State.
This warranty is only valid for sale of product(s) within the United States of America.
Product(s) sold outside of the United States of America are sold “ AS-IS” and shall have NO
WARRANTY, express or implied. This product may be covered by a Guaranteed Protection
Plan (“ GPP” ). See your authorized Directed dealer for details of the plan or call Directed
Customer Service at 1-800-876-0800.
Make sure you have all of the following information from your authorized Directed
dealer:
A clear copy of the sales receipt, showing the following:
o Date of purchase
o Your full name and address
o Authorized dealer’s company name and address
o Type of alarm installed
o Year, make, model and color of the automobile
o Automobile license number
o Vehicle identification number
o All security options installed on automobile
o Installation receipts
920-0003 06-06
52 © 2008 Directed Electronics. All rights reserved.
![](/img.php?id=962833&img=bg36.png)
© 2008 Directed Electronics. All rights reserved. 53
![](/img.php?id=962833&img=bg37.png)
The company behind this system is Directed Electronics
Since its inception, Directed Electronics has had one purpose, to provide
consumers with the finest vehicle security and car stereo products and
accessories available. The recipient of nearly 100 patents and Innovations
Awards in the field of advanced electronic technology.
Directed is ISO 9001 registered.
Quality Directed Electronics products are sold and serviced throughout
North America and around the world.
Call (800) 274-0200 for more information about our products and services.
G5902 2008-03
Vista, CA 92081
www.directed.com
© 2008 Directed Electronics—All rights reserved
