WINSONIC ELECTRIC SPK128 Portable Speaker System User Manual SPK128
Winsonic Electric Limited Portable Speaker System SPK128
Users Manual
![](/img.php?id=2599245&img=bg1.png)
SPK128 INSTRUCTION MANUAL
Location of controls
1) |<< / V- BUTTON
Short press----------Select a track or Tune to FM radio stations.
Press and hold-----------Reduce volume
2) BLUETOOTH LED INDICATOR
1 2 3 4 5 6 7
8
9 10
![](/img.php?id=2599245&img=bg2.png)
3) >>| / V+ BUTTON
Short press---------------------Select a track or Tune to FM radio stations.
Press and hold------------------Reduce volume
4) FM LED INDICATOR
5)
• In Bluetooth mode, press to pause or resume play.
• In Bluetooth mode, press and hold for three seconds to disconnect Bluetooth connection or enter pairing mode.
6) CHARGING LED INDICATOR
7) FUNCTION BUTTON
Select an audio source.
8) STANDBY BUTTON
Turn the product on or off
9) USB JACK
Recharge the built-in battery.
10) AUX IN JACK
Connect an external audio device.
Get started
Always follow the instructions in this chapter in sequence.
Power supply
The speaker can operate on the built-in rechargeable battery.
Before use, fully charge the built-in battery.
Rechargeable battery has a limited number of charge cycles. Battery life and number of charge cycles vary by use and
settings.
To recharge the built-in battery:
Connect the supplied USB cable to:
• the USB 5V socket on the speaker.
• the USB socket on a computer .
Note: CHARGING LED INDICATOR will be on in red. RED LED indicator will be off once the charging is finished.
Battery status CHARGING LED INDICATOR
While charging ON in red
Fully charged or charging stopped Off
Turn on or off
•To turn the product on, press the STANDBY button.
the product switches to the last selected source.
•To turn the product off, press standby button again.
Select a source
Press FUNCTION button repeatedly to select an audio source: FM tuner, Bluetooth & Audio-in.
Play from Bluetooth-enabled devices
With this product, you can listen to audio from Bluetooth-enabled devices.
Connect a device
1 Turn on the unit first by pressing the STANDBY button.
2 Press FUNCTION button repeatedly to select bluetooth source.The BLUETOOTH LED INDICATOR flashes blue.
![](/img.php?id=2599245&img=bg3.png)
3 On your Bluetooth device, enable Bluetooth and search for Bluetooth devices (refer to the user manual of the
device).
4 When [SPK128] is displayed on your device, select it to start pairing and connection. If necessary, enter default
password “0000”. After successful pairing and connection, the product beeps and the Bluetooth indicator turns solid
blue.
Note:
Make sure that your Bluetooth device is compatible with this product.
Before pairing a device with this product, read its user manual for Bluetooth compatibility.
Make sure that Bluetooth function is enabled on your device, and your device is set as visible to all other Bluetooth
devices.
Any obstacle between this product and a Bluetooth device can reduce the operational range.
Keep away from any other electronic device that may cause interference.
The operational range between this product and a Bluetooth device is approximately 10 meters.
To disconnect the Bluetooth-enabled device:
• Press and hold button for three seconds;
• Disable Bluetooth on your device; or
• Move the device beyond the communication range.The product beeps and the bluetooth indicator flashes blue.
To reconnect the Bluetooth-enabled device:
• Next time this product enters Bluetooth mode, it will reconnect the last connected device automatically; or
• On your Bluetooth device, select "" on your Bluetooth menu to start connection.
To connect another Bluetooth-enabled device:
1) Press and hold button for three seconds to disconnect the currently connected device.The
product enters Bluetooth pairing mode.
2)Connect another Bluetooth device.
Play from Bluetooth device
After successful Bluetooth connection, press the button to play audio on the Bluetooth device.
Press |<< / - or >>| / + button to skip the tracks backwards or forwards.
To pause or resume play, press button .
Play from an external device
With this product, you can listen to an external audio device such as an MP3 player.
1) Turn on the unit first by pressing the STANDBY button.
2) Press FUNCTION button repeatedly to select bluetooth source.
3) Connect an audio input cable with a 3.5 mm connector on both ends to the AUX IN JACK on the speaker and
the headphone socket on an external device.
4) Play audio on the device (refer to its user manual).
Note:the bluetooth is disconnected automatically once the AUX IN JACK is plugged in.
LISTEN TO FM RADIO
Tune to FM radio stations
Note: Keep the product away from other electronic devices to avoid radio interference.
1) Press the STANDBY button to turn on the unit .
2) Press FUNCTION button repeatedly to select FM tuner source. The FM LED INDICATOR turns solid green.
3) Press |<< / -or >>| / + button to tunes to a station with strong reception automatically.
4) Repeat step 3 to tune to more radio stations.
![](/img.php?id=2599245&img=bg4.png)
Adjust volume
During play, press and hold >>| / + or |<< / - BUTTON for 3 seconds to increase or decrease volume.
Specification:
Power Source : Built-in Li-Polymer rechargeable battery.
Recharge by DC 5V through Micro USB Port
Frequency : FM 87.5-108MHz
BT Effective range : Up to 32 feet in open area
Audio Power : 4.0W THD 10%
Impedance of Speaker : 7W 4 Ohm
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
