Pro-Kart Racer
Instruction Manual
SAFETY AND PLAYING TIPS:
Please read instructions carefully before operating Pro-Kart Racer.
1. NEVER drive your vehicle on streets.
2. DO NOT pick up vehicle while in motion.
3. Keep fingers, hair, and loose clothing away from the tires and the wheel hubs while the vehicle is switched ON.
4. Keep vehicle and parts out of reach of very young children. Adult supervision is recommended.
5. Do not play outdoors during thunderstorms.
6. Do not drive your vehicle in sand or through water or snow.
7. Always turn your vehicle and transmitter "OFF" when not in use.
8. Do not store near heat or direct sunlight.
DRIVING CONTROLS
Starting to Drive
Helpful tips: • For maximum speed, fully pull the trigger.
• Control the speed by releasing slowly.
• Be a Pro! Practice at different speeds and stopping by varying the amount you pull the trigger.
1. To go forward, pull the trigger.
3. To stop, release the trigger.
Helpful tip: Remember that when Pro-Kart Racer is coming towards you, the steering is opposite to the way you turn.
Please note: The illuminated red light on the hand controller indicates that the remote controller is in operation.
DRIVING YOUR PRO-KART RACER
To start up the engine, turn the Pro-Kart Racer and transmitter to ON. Then fully extend the antenna
on the transmitter. Now you are ready to race!
2. To go in reverse, push the trigger forward.
1. For wide turns towards the left,
QUICKLY turn the wheel left and
release.
2. For wide turns towards the right,
QUICKLY turn the wheel right and
release.
3. For sharp left turns, turn & hold
(briefly) the wheel to the left while the
trigger is pulled.
4. For sharp right turns, turn & hold
(briefly) the wheel to the right while
the trigger is pulled.
Transmitter (controller)
Pro-Kart Racer
Contents
Nose Cone
Tires
Spoiler
SPARE PARTS
Steering
Wheel Trigger
On/Off
Indicator
TURNING
When the motor is running (trigger is pulled), Pro-Kart Racer turns with the turning angle of the steering wheel.
Transmitter
Antenna
Decal Sheet
ASSEMBLY
1. Before you begin to play, screw-in the
transmitter antenna into the transmitter. For
further details see Battery and Power
ON/OFF Diagram.
Item No.0223
Ages 4+
PRO KART RACER
4 x AA
BATTERIES NOT INCLUDED
REMOTE CONTROL
1 x 9V
BATTERIES NOT INCLUDED
![](/img.php?id=275727&img=bg2.png)
NG
0223
US
01
Manufactured and Distributed by:
© 2002 WowWee
All rights reserved.
WowWee (Asia Office)
Unit 301A-C, 92 Granville Rd.,
T.S.T. East, Kowloon, H.K.
WowWee (North America Office)
4480 Cote de Liesse, Suite 320,
T.M.R. Quebec, H4N 2R1, Canada
Consumer Hotline: (514) 344-1250
http://www.wowwee.com
Printed in China
Manufactured and Distributed by:
© 2002 WowWee
All rights reserved.
WowWee (Asia Office)
Unit 301A-C, 92 Granville Rd.,
T.S.T. East, Kowloon, H.K.
WowWee (North America Office)
4480 Cote de Liesse, Suite 320,
T.M.R. Quebec, H4N 2R1, Canada
Consumer Hotline: (514) 344-1250
http://www.wowwee.com
Printed in China
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful
interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect one equipment into an outlet on a circuit different from that to which the receiver is needed.
• Consult the dealer or an experienced radio / TV technician for help.
ATTENTION !!! IMPORTANT BATTERY INFORMATION
Use only fresh batteries of the required size and recommended type. Do not mix old and new batteries, different types of batteries (standard alkaline, or rechargeable), or
rechargeable batteries of different capacities. We suggest the use of alkaline batteries for best results.
Please respect the correct polarity + and –
Do not try to recharge batteries, nor to open them.
Do not throw batteries into the fire.
Remove rechargeable batteries from the toy before being charged.
Rechargeable batteries are only to be charged under adult supervision.
Use only the battery types as recommended.
Replace all batteries of same type/brand at the same time.
Do not short-circuit the battery contacts.
Remove exhausted batteries from the toy.
WARNING:
Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
Transmitter
Bottom of Pro-Kart Racer
ON
OFF
ON
OFF
See how fast you can change all of the spare parts - the tires, spoiler and bumper!
Use a phillips screw driver to change the tires. For the nose cone, gently remove the
front bumper then replace the nose cone. Spoiler: gently remove and replace.
REPLACE YOUR PARTS
Nose Cone
spoiler
tire
bumper
Note:
•Quality of control function
may deteriorate when
battery power is low.
BATTERY INSTALLATION
•Remove the battery compartment
cover using a screwdriver as shown.
•Insert correct battery - as shown in
diagram, making sure to match the
polarity direction.
•Replace the battery cover.
STUNTS
bumper
Transmitter Antenna
Screw-in to the base
Spare Nose Cone
Spare Spoiler
1. For super fast 360˚ spins, turn the
wheel all the way to the right or left,
while the trigger is fully pulled.
2. Do a reverse 180˚! Drive in reverse,
then spin the racer around 180˚ and
drive forward! Drive like a PRO for this
stunt!
BATTERY AND POWER
ON/OFF DIAGRAM
APPLYING DECALS
- Apply the decals as shown,
in orderly sequence from 1
