VX-210A
Operating Manual
Controls & Connectors
0107Q-AE
This device complies with Part 15 of the FCC rules. Operation is subject to the
condition that this device does not cause harmful interference.
Notice !
There are no owner-serviceable parts inside the transceiver. All service jobs
must be referred to an authorized Service Representative. Consult
your Authorized Dealer for installation of optional accessories.
Microphone
Speaker
MIC/SP Jack
(
External Mic/Earphone
)
VOL/PWR Knob
CH (Channel) Selector
ACC Button
Push To Talk
(PTT) Switch
Antenna
LED Indicator
Glows Green ACC on
Blinking Green Busy Channel (or SQL off)
Glows Red Transmitting
Blinking Red Battery Voltage is low
Blinking Yellow Receiving a Selective Call
Battery Pack Latch
Before You Begin
rTo remove the battery, turn the radio off and remove any protective cases. Open
the Battery Pack latch on the bottom of the radio, then slide the battery down-
ward and out from the radio while holding the Belt Clip.
Caution!
Do not attempt to open any of the rechargeable Ni-Cd packs, as they could
explode if accidentally short-circuited.
Low Battery Indication
rAs the battery discharges during use, the voltage gradually becomes lower. When
the battery voltage reaches 6.3 volts, substitute a freshly charged battery and
recharge the depleted pack. The TX/BUSY indicator on the top of the radio will
blink red when the battery voltage is low.
rAvoid recharging Ni-Cd batteries often with little use between charges, as this
can degrade the charge capacity. We recommend that you carry an extra, fully-
charged pack with you so the operational battery may be used until depletion
(this “deep cycling” technique promotes better long-term battery capacity).
Battery Pack Installation and Removal
rTo install the battery, hold the transceiver with your left hand, so your palm is
over the speaker and your thumb is on the top of the belt clip. Insert the battery
pack into the battery compartment on the back of the radio while tilting the Belt
Clip outward, then close the Battery Pack Latch until it locks in place with a
“Click.”
VOL
CH
1
3
7
9
11
13
1
5
Preliminary Steps
rInstall a charged battery pack onto the transceiver, as described previously.
rScrew the supplied antenna onto the Antenna jack. Never attempt to operate this
transceiver without an antenna connected.
rIf you have a Speaker/Microphone, we recommend that it not be connected until
you are familiar with the basic operation of the VX-210A.
Operation Quick Start
rTurn the top panel’s VOL/PWR knob clock-
wise to turn on the radio on.
rPull and turn the top panel’s CH selector knob
to choose the desired operating channel.
rRotate the VOL/PWR knob to set the volume
level. If no signal is present, press and hold in
the ACC button (the lower button on the left
side) for more than 1 second (when “MONI-
TOR” is assigned to the ACC button); back-
ground noise will now be heard, and you may
use this to set the VOL/PWR knob for the de-
sired audio level.
rPress and hold in the ACC button (when
“MONITOR” is assigned to the ACC button)
for more than 1 second (or press the ACC but-
ton twice) to quiet the noise and resume normal
(quiet) monitoring.
Operation
rTo transmit, press and hold in the PTT switch.
Speak into the microphone area of the front
panel grille (lower left-hand corner) in a nor-
mal voice level. To return to the Receive mode,
release the PTT switch.
rIf a Speaker/Microphone is available, remove the plastic cap and its two mount-
ing screws from the right side of the transceiver, then insert the plug from the
Speaker/Microphone into the MIC/SP jack; secure the plug using the screws
supplied with the Speaker/Microphone. Hold the speaker grille up next to your
ear while receiving. To transmit, press the PTT switch on the Speaker/Micro-
phone, just as you would on the main transceiver’s body.
Note:Save the original plastic cap and its mounting screws. They should be re-
installed when not using the Speaker/Microphone.
Key Functions
The VX-210A provides a programmable “ACC” (Accessory) button. The ACC
button’s functions can be customized (set to any of a variety of functions), via pro-
gramming by your VERTEX STANDARD dealer, to meet your communications/
network requirements. The particular function to be activated or disabled may re-
quire a simple press of the ACC button, or it may require that the ACC button be
pressed and held in for one second (or more). See the discussion below.
Some features may require the purchase and installation of optional internal ac-
cessories.
The possible ACC button
programming features are illus-
trated below, and their func-
tions are explained in the next
chapter. For further details,
contact your VERTEX STAN-
DARD dealer.
For future reference, check
the box next to the function that
has been assigned to the ACC
button on your particular radio,
and keep it handy.
Function ACC button
Press Press and Hold
None
Monitor
Squelch OFF
Low Power
Scan
Follow-me Scan
Dual Watch
Talk Around
Call/Reset
Speed Dial
TX Save Off
ACC 1
ACC 2
EC020U750
![](/img.php?id=171047&img=bg2.png)
Monitor
Press the ACC button to override (disable) the Tone Squelch.
Background noise or incoming signals will now be heard whether or not a match-
ing tone is present on the signal. Press the ACC button once more to resume
normal (quiet) Tone Squelch action.
Squelch OFF
Press the ACC button to override both the Noise and Tone squelch systems.
Again press the ACC button to resume normal (quiet) Noise and Tone squelch
action.
Low Power
Press the ACC button to set the radio's transmitter to the “Low Power” mode,
thus extending battery life. Press the ACC button again to return to “High Power”
operation when in difficult terrain.
Scan
The Scanning feature is used to monitor multiple channels programmed into the
transceiver. While scanning, the radio will check each channel for the presence
of a signal, and will stop on a channel if a signal is present.
rTo activate scanning:
Press the ACC button.
The scanner will search the channels, looking for “active” ones; it will pause
each time it finds a channel on which someone is speaking.
rTo stop scanning:
Press the ACC button.
Operation will revert to the channel to which the CH knob is set.
Follow-Me Scan
“Follow-Me” Scan feature checks a User-assigned Priority Channel regularly as
you scan the other channels. Thus, if only Channels 1, 3, and 5 (of the 8 avail-
able channels) are designated for “Scanning,” the user may nonetheless assign
Channel as the “User-assigned” Priority Channel via the “Follow-Me” feature.
Press the ACC button to activate “Follow-Me” scanning, then pull and turn the
CH selector knob to the channel which you want to designate as the “User-
Assigned Priority Channel”. When the scanner stops on an “active” channel, the
User-assigned Priority Channel will automatically be checked every few seconds.
Dual Watch
The Dual Watch feature is similar to the Scan feature, except that only two chan-
nels are monitored: the current operating channel, and the “Priority” channel.
rTo activate Dual Watch:
Press the ACC button.
The scanner will search the two channels; it will pause each time it finds a
channel on which someone is speaking.
rTo stop Dual Watch:
Press the ACC button.
Operation will revert to the channel to which the CH knob is set.
Description of Operating Functions
VERTEX STANDARD CO., LTD.
4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan
VERTEX STANDARD
US Headquarters
17210 Edwards Rd., Cerritos, CA 90703, U.S.A.
International Division
8350 N.W. 52nd Terrace, Suite 201, Miami, FL 33166, U.S.A.
YAESU EUROPE B.V.
P.O. Box 75525, 1118 ZN Schiphol, The Netherlands
YAESU UK LTD.
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
VERTEX STANDARD HK LTD.
Unit 5, 20/F., Seaview Centre, 139-141 Hoi Bun Road,
Kwun Tong, Kowloon, Hong Kong
Accessories & Options
FNB-V57 7.2 V 1100 mAh Ni-Cd Battery Pack
FNB-V57IS 7.2 V 1100 mAh Ni-Cd Intrinsically safe Battery
FBA-25 Alkaline Battery Case (6 Í AA)
NC-76B 120 VAC Wall Charger
NC-76C 230-240 VAC Wall Charger
VAC-6400 6-Unit Multi Charger
VAC-400B 120 VAC Desktop Rapid Charger
VAC-400C 230-240 VAC Desktop Rapid Charger
VCM-1 Mobile Mounting Bracket for VAC-400
MH-45B4B Speaker/Microphone
MH-37A4B Earpiece/Microphone
VC-25 VOX Headset
FVP-25 Encryption /DTMF Page Unit
VTP-50 VX-Trunk Unit
CT-42 PC-Programming Cable (CT-28 + CT-29)
CT-27 Cloning Cable (Set-to-Set Cloning)
FTT-17 16 keypad for VX-Trunk (VTP-50 required)
LCC-210 Leather Case
Important Notice!
FCC RF Exposure Compliance Requirements for Occupational Use Only:
This Radio has been tested and complies with the Federal Communications
Commission (FCC) RF exposure limits for Occupational Use/Controlled ex-
posure environment. In addition, it complies with the following Standards
and Guidelines:
rFCC 96-326, Guidelines for Evaluating the Environmental Effects of Ra-
dio-Frequency Radiation.
rFCC OET Bulletin 65 Edition 97-01 (1997) Supplement C, Evaluating
Compliance with FCC Guidelines for Human Exposure to Radio Fre-
quency Electromagnetic Fields.
rANSI/IEEE C95.1-1992, IEEE Standard for Safety Levels with Respect
to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz
to 300 GHz.
rANSI/IEEE C95.3-1992, IEEE Recommended Practice for the Measure-
ment of Potentially Hazardous Electromagnetic Fields - RF and Micro-
wave.
mThis radio is NOT approved for use by the general population in an
uncontrolled environment. This radio is restricted to occupational
use, work related operations only where the radio operator must have
the knowledge to control its RF exposure conditions.
mWhen transmitting, hold the radio in a vertical position with its mi-
crophone 1 to 2 inches (2.5 to 5 cm) away from your mouth and keep
the antenna at least 1 inch (2.5 cm) away from your head and body.
mThe radio must be used with a maximum operating duty cycle not
exceeding 50%, in typical Push-to-Talk (PTT) configurations.
DO NOT transmit for more than 50% of total radio use time (50%
duty cycle). Transmitting more than 50% of the time can cause FCC
RF exposure compliance requirements to be exceeded.
The radio is transmitting when the red LED on the top of the radio is
illuminated. You can cause the radio to transmit by pressing the PTT
button.
mDO NOT transmit when the radio is used in Body Worn configura-
tion with the following accessory: belt-clip (Parts # CP7131001). It
must be used ONLY for (1) there is a 4 cm distance from the body
during transmitting, (2) monitoring purposes, using the speaker only
and (3) for carrying purposes.
mAlways use Vertex Standard authorized accessories.
Talk Around
Press the ACC button to activate the Talk Around feature when you are operat-
ing on duplex channel systems (separate receive and transmit frequencies, utiliz-
ing a “repeater” station). The Talk Around feature allows you to bypass the re-
peater station and talk directly to a station that is nearby. This feature has no
effect when you are operating on “Simplex” channels, where the receive and
transmit frequencies are already the same.
Note that your dealer may have made provision for “Talk Around” channels by
programming “repeater” and “Talk Around” frequencies on two adjacent chan-
nels. If so, the ACC key may be used for one of the other Pre-Programmed
Functions.
Call/Reset
When the 2-tone selective calling unit is installed, press the ACC button to si-
lence the receiver and reset for another call, when a communication is finished.
Speed Dial
Your Dealer may have pre-programmed Auto-Dial telephone number memories
into your radio.
To dial a number, just press the Dealer-assigned ACC button for Speed Dialing.
The DTMF tones sent during the dialing sequence will be heard in the speaker.
TX Save Off
Press the ACC button to disable the Transmit Battery Saver, if you are operating
in a location where high power is almost always needed.
The Transmit Battery Saver helps extend battery life by reducing transmit power
when a very strong signal from an apparently nearby station is being received.
Under some circumstances, though, your hand-held radio may not be heard well
at the other end of the communication path, and high power may be necessary at
all times.
ACC 1
Activates an optional Unit (module) while the ACC button is held depressed.
When you release the ACC button, the optional Unit will be disabled.
For further details, contact your VERTEX STANDARD dealer.
ACC 2
Toggles the optional Unit “on” or “off” whenever you press the ACC button.
For example, when the optional “FVP-25” voice encryption unit is installed,
press the ACC button momentarily to disable the voice encryption feature tem-
porarily.
Press the ACC button again to re-enable the voice encryption feature.
