User manual
Charging Port
Microphone SIRI
0807 09 10 1211
6.Project Specification and Instruction
- Bluetooth Version : V4.0
- Supported devices: Bluetooth mobile phones, Bluetooth
speakers Bluetooth PC and other Bluetooth devices
- Maximum work range: 33 Feet (10 Meters)
- Talk time: About 15 Hours
- Music play: About 13 Hours
- Charging time: 2.5 Hours
- Charging Voltage: DC 5V
- Work Voltage: 3.7V 250MAH
- Sensitivity: 105±3dB
- Frequency Response: 20Hz~20KHz
※ The actual time may vary from mobile phone types and
functions.
Thank you for selecting our latest Bluetooth headset, please
read this User's Manual carefully before you operate this
headset, and please save this Manual for further reference.
Before operating, please read all the Safety notice to make sure
the safe and appropriate use.
Safety Notice:
Please observe the rules of the Country or Region which you
are in while driving.
Do not disassemble or modify the headset at any reason,
otherwise, It may damage or burn the headset.
If there is any quality problem, please send the headset to
authorized service center for repairing.
Please keep the equipment along with all the accessories out
of the reach of children and pets. It will cause suffocation and
serious injury.
Do not put the device under the environment which the
temperature is too low or too high ( Below 0℃ or over 45℃).
Extreme temperatures will cause the device deformation,
reduce the charging capacity and shorten the working life.
Please do not wet the device, for the liquid can cause serious
damage to the device. Please do not touch the device by wet
hands. It is out of the maintenance range for the damage
caused by water.
Please avoid closing to the eyes of children and pets when
using the flash indicator of the device.
Please do not operate the device in thunderstorm weather.
It will damage your hearing if you listen with high
volume for a long time. It is recommended that
only use the lowest volume which is necessary
for speaking and listening to music.
1. Guide
■Headset introduction
USB Charging Cable:
2.Instruction
■ Key Function
3.Bluetooth Indicator Status
5.Headset Charging
This headset is equipped with built-in non-detachable and
rechargeable battery.
Please make sure that the battery is charged full for the first
time use.
Power switch
Pairing
Play / Pause
Receive
Hang up phone
call
4. SIRI :
The function only applies to phone with siri itself
语音控制
■ Connect the charger to the charging port.
■ Insert the charger into the standard power outlet.
During the charging, indicator will turn to Red. If without
charging, please plug out the travel charger first, then
connect it again.
■ After full charging, red indicator will be off. Please plug out
the travel charger from the power outlet and headset.
■ It will reduce the battery performance after long time /
repeatable charge and dis-charge.
■ And it is normal phenomenon for all the rechargeable battery.
Please do not dial or receive phone call during charging, and
please plug out the charger from the headset, then receive
the phone call. When the battery is low, the headset will
appear the prompt and the red indicator will flash.
Power on
Pairing
Power off
Receive
Hang up
phone call
Play/Pause
Press the key for 3 seconds to switch off (the red
indicator flashes once)
Press the key for 5 seconds to switch on and enter
into pairing mode (The red indicator flashes once and
the blue indicator flashes twice, and then the red and
blue indicators take turns to flash)
When calls coming, press the key once to receive
phone calls, press again to hang up phone calls,
Press the key for 2 seconds to reject phone calls
In music mode, press the key once to pause, and
press it again to play. (when phone call comes, the
music will be off. When phone call is off, the music
will continue)
When the bluetooth is on, press the key twice shortly
can activate siri function
Work Status Indicator Light Status Remark
Switch on Red indicator flash once
Blue indicator flash once
Switch off Red indicator flash once
Connection
Phone call Blue indicator will flash once
every 6 seconds
Blue indicator will flash once
every 6 seconds
Blue indicator will flash once
every 6 seconds
Play Music
Pairing Mode Red and blue indicators take
turns to flash
Charging
Low battery
warning
Red indicator is on all the time when
charging; the light is off when charged full
Red indicator will flash once
every 60 seconds
(1) Turn on the bluetooth function of the phone.
(2) Press “ ” for 5 seconds to swith on and enters into
pairing mode when the red and blue indicators take turns
to flash.
(3) Find “180s BT” from the device list of the phone and make
connection.
4) Press the key twice shortly to activate siri function.
3) Microphone on the phone will appear at that time, and you
can use siri directly.
Bluetooth headphone
Press the
key twice
shortly
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.Changes or modifications not expressly
approved by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for
help.
