User Manual for SCM-RF/CI

SCM Reader, RFID/Contact IC For Mi3c

3M Cogent SCM-RF/CI Module is made for MI3C and so on. It

consists of 2 different modules. The user can use it to read contact card,

RF card. RF part works at 13,56MHz. All the function can read out card

number, time info and character info, Barcode and so on. It is convenient

for you to get all the data you want. It communicates with cogent device

MI3C. It is applicable in many areas. For Example: gate forbidden,

checking on work attendance, charging and patrolling.

Front

BACK

Contact Card RF Card

Please follow the steps below to use this module. Here to take Mi3c

for example.

Before using SCM-RF/CI, please install it to Mi3c. Start up Mi3c

n Contactless/contact Card.

1) Choose ‘File Explorer’ under the Start menu.

2) Start ‘Manual Check’ in the Cogent category.

3) Enter into ‘SmarCard pcsc(MobileID3)’ and install the driver.

4) Press ‘OK’.

FCC INFORMATION

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) this device may not cause

harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate the

equipment.

This equipment complies with FCC radiation exposure limits set forth

for an uncontrolled environment. End users must follow the specific

operating instructions for satisfying RF exposure compliance. This

transmitter must not be co-located or operating in conjunction with any

other antenna or transmitter.
