3M Traffic Safety Systems PNPUSB USB RFID Reader User Manual CERTIFICATE OF COMPLIANCE

3M Traffic Safety Systems USB RFID Reader CERTIFICATE OF COMPLIANCE

User Manual

Rhein Tech Laboratories, Inc. Client: Sirit Technologies Inc.
360 Herndon Parkway Model #: PnP USB
Suite 1400 Standards: FCC 15.225 & RSS-210
FCC/IC ID: M4ZPNPUSB/3637B-PNPUSB Herndon, VA 20170
http://www.rheintech.com Report #: 2006114
Page 27 of 36
Appendix I: Manual
Please refer to the following pages.
PnP USB User Guide
PnP USB User Guide
Preliminary Document v0.10
Copyright Sirit Inc. 2006
PnP USB User Guide
- 2 -
Table of Contents
1 – PNP USB MODULE OVERVIEW..........................................................................- 3 -
1.1 Description .........................................................................................................................................................- 3 -
1.2 PnP USB Start-Up Guide....................................................................................................................................- 4 -
1.3 Loading Software into Host Computer...............................................................................................................- 4 -
2- HARDWARE DESCRIPTION .................................................................................- 5 -
2.1 Hardware ............................................................................................................................................................- 5 -
3- SAFETY INSTRUCTIONS......................................................................................- 6 -
4- FCC COMPLIANCE................................................................................................- 6 -
PnP USB User Guide
- 3 -
1 – PnP USB Module Overview
1.1 Description
Model Name: PnP USB RFID Reader
Model Number: PnP USB
FCC ID: M4ZPNPUSB
Industry Canada ID: 3637B-PNPUSB
Description:
The Sirit PnP USB RFID Reader is a modular high-frequency radio frequency identification
(RFID) reader operating in the 13.560 MHz ISM band. It is designed to interface to a host
computer using USB protocol. It uses ISO 15693, 14443A and B, 18000-3 Mode 1, and several
other proprietary protocols.
Antenna Specification:
Magnetic loop, 3-turn planer spiral.
Partial Faraday shield on bottom side PCB; 7.1-cm OD, 6.5-cm ID.
Modeled gain: -50dBi (EZNEC, Ver.4).
PnP USB User Guide
- 4 -
1.2 PnP USB Start-Up Guide
Operational Sequence:
First load software on the Host computer as per section below.
Then plug USB module in to host computer.
Start application program in host computer.
Read RFID tags.
Other information or help with this document or the module, please visit the Sirit website at
www.pnprfid.com or email support at support@pnprfid.com.
=========Host Software Setup=========
1.3 Loading Software into Host Computer
========= USB Reader Setup=========
1. Open the CD and locate the installation files.
2. Run the ContactlessONE_USB installer package by double-clicking on the
“ContactlessONE_USB.msi” program.
3. Plug in your USB reader, then choose “No” when prompted to search the Internet for
drivers.
4. Choose “Install software automatically”. If prompted for the FTDI drivers, point to the
USB Drivers directory on the CD.
5. If you do not have the Microsoft .NET environment on your computer you will need to
download it from www.microsoft.com/.net and load it.
6. Disconnect and reconnect the USB Reader.
7. Open the ISOBench demo program that was installed in “C:\Program
Files\TWT\ContactlessONE\Examples”.
8. Run the diagnostic program “Iso-bench.exe” from this location.
PnP USB User Guide
- 5 -
2- Hardware Description
2.1 Hardware
The PnP USB module uses the Inside Contactless (France) PicoRead chip set consisting of the
PicoRead RF processing chip and a custom programmed MicroChip Corporation (USA)
18F2550 micro controller unit (MCU). The USB interface uses a FTDI Chip (England)
FT232BM chip to translate from the serial data stream of the PicoRead MCU to the host device
USB interface.
The host unit provides 5.0 volt power to the module.
The two Inside Contactless chips share a common 13.560 MHz crystal, using the MCU as the
common oscillator and drive source. The FT-232 USB interface chip uses a 6.00 MHz crystal for
its internal oscillator.
PnP USB User Guide
- 6 -
3- Safety Instructions
Power Disconnect Device
This device gets its power from the host computer. Unplug the device to take power away from
it. Do not use the device if it becomes wet. Do not use the device while it is immersed in water.
WARNING:
FCC Radiation Exposure Statement: This device emits low levels of RF energy when in
operation. Do not allow the use of this device by someone using a cardiac pacemaker or other
medical devices sensitive to RF energy.
4- FCC Compliance
Changes or modifications not expressly approved by Sirit Corporation will void the user’s
authority to operate the equipment.
FCC Compliance
This device complies with Part 15 of the U.S. Federal Communications Commission (FCC)
Rules. Operation is subject to the following Conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following means:
1. Rotate or relocate the receiving antenna;
2. Increase the separation between the equipment and receiver;
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected;
4. Consult the manufacturer customer service department for help.
