3e Technologies 525A-3 WLAN mini-PCI module User Manual
3e Technologies International, Inc. WLAN mini-PCI module
User manual
INSTRUCTIONS FOR
USE OF QVT-525A-3
RF SAFETY INFORMATION
! To comply with FCC RF exposure compliance requirements,
the antennas used with the 525A-3 must be installed with a minimum
separation distance of 20 cm from all persons, and must not be co-
located or operated in conjunction with any other antenna or
transmitter. Instillation should be accomplished using the authorized
cables and / or connectors provided with the device or available from
the manufacturer / distributor for use with this device. Changes or
modifications not expressly approved by the manufacturer or party
responsible for this FCC compliance could void the user’s authority
to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance to the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Installation should be accomplished using the authorized cables and / or
connectors provided with the device or available from the manufacturer /
distributor for use with this device. Changes or modifications not expressly
approved by the manufacturer or party responsible for this FCC compliance
could void the user’s authority to operate the equipment.
TUNE-UP PROCEDURE
1. Configure the radio module for operation in the 4.9 GHz band using the radio
configuration software.
2. Configure the power setting for Auto using the radio configuration software.
3. Measure the power output during transmit.
4. Verify that the power reading is between 17 dBm and 21 dBm.
LABELING INSTRUCTIONS
1. The radio module used 3e-525 Family products is the Wistron CM9-GP module
(3eTI Part Number 90000782-003).
2. Remove the existing FCC label from the CM9 and replace this label with the
QVT-525A-3 label designated for use with the CM9 (Part Number 5643371007 –
LBL,FCC,QVT-525A-3,CM9).
3. Add an FCC label designated for use with the enclosure (Part Number
5643371008 – LBL,FCC,QVT-525A-3,ENCLOSURE) in place of the FCC label on
the outside of the product enclosure. Remove any existing FCC label on this
enclosure prior to installing the new label. Note: the correct location for
installation of this label is called out in the Manufacturing Assembly
Instructions for the product.
