User manual
Cooler Keg
User Manual
TR-CK001
Thank you for purchasing our product TR-CK001
please read carefully this manual before using!
ON/OFF DC
9V/1A
TFCARD INPUT USB
1
Important Information
Attention
This device complies with part 15 of the FCC Rules.Operation is subject to the following
two conditions:
(1)This device may not cause harmful interference,and
(2)This device must accept any interference received, including interference that may c-
ause undesired operation.
Please read below safety warnings carefully.If you don’t read,don’t understand,and don’t
comply with,there is the possibility to cause death and serious human & property damages
. Check the related regulations and restrictions for Bluetooth devices in your area before
you use this product.
. Do not change the battery of TR-CK001.It is the built-in battery, and irreplaceable. Oth-
erwise, the serious human damage will be caused.
. Do not repair, refit and dismantle TR-CK001. It does not contain any part which can be
repaired by the end user.
. Do not contact TR-CK001 with sharp items, because it may cause scratches and dama-
ges.
. Please avoid to use the poduct in the extremely hot or cold or humid environment.
. Please store this product in the dry,dustless and stable temperature environment.
. Do not drop, bend and throw or do any other violent actions to this product.
. Do not use this product on the plane.Turn if off before boarding.
. Do not use this product in any place where storing flammable and combustible items.
. Do not let children use this product.
. Do not expose the battery in the extremely hot environment to avoid explosion.And low
temperature many affect the battery life.
FCC Rlue
ID
1
Standard
FCC Part 15
Changes or modifications not expressly approved by the partly responsible for compliance
could void the user’s authority to operate the equipment.
2
Package
AC／DC Adaptor
ManuaI
ON/OFF DC
9V/1A
TFCARD I NPUT USB
Speaker unit
Audio cable
Button Definitions3
31 2 64 5
1).Play/Pause
3).The volume increase/the next song
2).The volume decrease/previous song
6).Mode key
4).EQ key
5).Repeat key
3
Interface Description4.
31 2 4 5
1).Power switch ON/OFF
2).DC 9V 1A charging port(input)
3).TF card input port
4).AUX Line in(input)
5).USB Disk
Switch Operation Instruction5.
1).Turn on
2).Turn off
4
BT Mode Operation6.
1).Turn on the power,the product enter BT status automatically,
or Short press “mode” key ,switch status to BT status.
2).In bluetooth devices,bluetooth search “Speaker Cooler”,The
indication voice “dingdong” after match successlly.Speaker
will store the paired name in the bluetooth list and it could ac-
hieve fast connected through click “Speaker Cooler” directly
for next time using.
Bluetooth
Bluetooth ON
Device
Speaker Cooler
5
TF card reader7.
1) Input TF card under power on status, change to TF play status
automatically. Input TF card under power off status, need short
press mode key to change to TF play status after power on.
USB disk reader8.
1) Input USB disk under power on status, change to USB play status
automatically. Input USB disk under power off status, need short
press mode key to change to USB play status after power on.
TF CARD
USB DISK
6
AUX LINE IN9.
1).Press mode key to change to “LINE ” play status,When connect with other
music source through 3.5mm jack
Volume and Previous/Next Song10.
1).VOL- KEY :
Short press “VOL-”,switch to the previous song;
Long press “VOL-”,volume down.
2).VOL+ KEY :
Short press “VOL+”,switch to the next song;
Long press “VOL+”,volume up.
EQ and REPEAT11.
1).EQ KEY :
Short press “EQ”,switch sound mode under TF 、USB DISK、BT play status
Sound mode :NOR、POP、roC、JA2、CLA、CUT
2).REPEAT KEY :
Short press “REPEAT”,switch play mode under TF、USB DISK play status
Play mode : ONE 、FOD、ALL
7
Specification12.
Function Specification
Bluetooth Version 3.0
Distance 6.0M at Max
Frequency Range 2.4GHz-2.48GHz
Power Supply Built-in Chargeable Li-ion Battery
Play time more than 4hrs at 80% volume
RMS 30W
Driver Impedance 8Ω
Frequency Response 90Hz-20KHz
Size Φ360*120mm
Weight 1600g
Working Temperature 10℃~40℃
