AAMP of Florida AAMP Global FM4 FM TRANSMITTER User Manual ISFM31
AAMP of Flordia, dba AAMP of America FM TRANSMITTER ISFM31
Users Manual
+
Hold to turn ON
+
+
+
+
+
ISFM31
Caution :
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
FCC Compliance Statement:
This device is verified to comply with Part 15 of the FCC Rules. Operation subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
JamKastTM
Universal Digital FM Transmitter
with dTECT
TM Technology
Instructions
12Volt Outlet
OPTIONAL
AUTOSCANNING
The JamKast™ transmitter uses dTECT™ technology to
locate and lock-in the four best radio frequencies for iPod
or iPhone playback.
NOTE: We recommend activating dTECT™ Autoscanning
when entering new areas while you travel.
SELECTING PRESETS
Use arrow buttons to choose PRESET that
offers best performance
MANUALLY SAVE PRESETS
The JamKast™ iP transmitter allows you to manually save your preferred station on the PRESET
1. Hold both at the same time
to activate scanning (dTECT ™)
2. PRESETS will blink for 20 sec. while scanning
Press to move up
3. Scanning is complete when PRESETS stops blinking
2. Hold once to enter manual tuning mode 4. Press once to save
1. Choose the PRESET you want to save 3. Tune to the desired frequency
Press to move down
MANUALLY SET ANY FREQUENCY
You can choose any frequency
1) Press once to enter manual tuning mode
3. DONE (manual tuning mode will remain active for 30 sec.)
2) Tune to desired frequency
4 5
CONNECT
Plug the JamKast™ iP
transmitter into the
docking port on your
iPod or iPhone. The
JamKast™ iP will
automatically Turn On
when you press any
button.
CONNECT
Insert the 3.5mm input into the
headphone jack on your MP3
player, smartphone or other
portable device.
1PLUG-IN
Plug the power input into the
lighter port on your vehicle’s
dashboard or center console.
2TURN ON
Press to turn JamKast™
3
NOTE: some smartphones feature 2.5mm
headphone inputs. If this is the case, you will
require an input adaptor to use this product.
+
MP3 players
• Apple iPod (all models)
• Microsoft Zune (all models)
• Creative Zen / MuVo
• iRiver Spinn / E100 / Clix
• Sony E / S / X Series Walkman
• Toshiba Gigabeat
• SanDisk Sansa
• Samsung P2 / Q2 / U5
• Archos 5 / 7 Media Tablet
WORKS WITH
The JamKast™ works with a wide variety of today’s most popular portable media players, including:
Smart Phones*
• Apple iPhone
• Blackberry
• Palm Pre & Trio
• LG Dare & Incite
• Samsung Instinct
• Nokia N95 & N97
Other Media Devices
• CD or DVD players
• Portable televisions
• Laptop computers
• Portable HD Radio tuners
• GPS systems
• Handheld gaming systems
iSimple®
A Division of AAMP of America™
13190 56th Court Clearwater, FL 33760
Ph. 866-788-4237
support@isimplesolutions.com
©2009 AAMP of Florida, Inc.
www.isimplesolutions.com
PLAY
To begin enjoying music using your
JamKast™, tune your car radio to the
frequency shown on the digital LCD
display and press play on your portable
media device.
It’s just that simple!
�
*Some smartphones feature 2.5mm headphone inputs. If this is the case, you will require an input adaptor to use this product.
Optimal distance: <10 ft.
Preset memory: 4 FM stations
Screen: white numeric LCD
Frequency response: 50Hz-15000Hz
Transmission range: 88.1MHz-107.9MHz
Separation: > 35dB
Operating current : 18.8+/- 3mA
Power: DC 5V
Power: iPhone, iPod and mini-USB
Optimal distance : <10feet
Operating Range: up to 30 feet
Weight: < 17 gr.
SPECIFICATIONS
Warranty One Year Limited Warranty
The quality controls used in the manufacture of this product will ensure your satisfaction. This warranty applies only to the original purchaser of this product from an authorized iSimple® dealer.
This warranty covers any supplied or manufactured parts of this product that, upon inspection by iSimple® authorized personnel, is found to have failed in normal use due to defects in material
or workmanship. This warranty does not apply to installation expenses. Attempting to service or modify this unit, operating this unit under conditions other than the recommended voltage will
render this WARRANTY VOID.
Unless otherwise prescribed by law, iSimple® shall not be liable for any personal injury, property damage and or any incidental or consequential damages of any kind (including water damage)
resulting from malfunctions, defects, misuse, improper installation or alteration of this product. All parts of this iSimple® product are guaranteed for a period of 1 year as follows:
Within the first 12 months from date of purchase, subject to the conditions above, iSimple® will repair or replace the product at our discretion, if it is defective in material or workmanship
providing it is returned to an Authorized iSimpleTM dealer, with
PROOF OF PURCHASE from an authorized iSimple® dealer.
Warning:
This equipment may be reset by unintentional electrostatic discharge during operation. Exposure to direct sunlight or extreme heat may cause damage or malfunction.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However,there
is no guarantee that interference will not occur in a particular installation.If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications
could void the user's authority to operate the equipment
