AAMP of Florida AAMP Global ISFM2201 IN CAR BLUETOOTH TRANSMITTER User Manual
AAMP of Flordia, dba AAMP of America IN CAR BLUETOOTH TRANSMITTER Users Manual
Users Manual
Certified : 10801A-ISFM220X : XBD-ISFM2201
ISFM2201 User Manual and
Installation Guide
Certified : 10801A-ISFM220X : XBD-ISFM2201
Table of Contents
1. Introduction
2. ISFM2201 Components
3. Installation Options
4. Frequency Selection and App Operation
5. Bluetooth pairing and connecting
Troubleshooting
Warranty Information
Certified : 10801A-ISFM220X : XBD-ISFM2201
1. Introduction
Thank you for choosing the iSimple ISFM2201 as your media and hands-free integration
solution. The ISFM2201 is designed to provide the connecting link between your iPhone,
Android or Bluetooth powered device and your vehicle.
InSeam is not a simple car kit, but goes far beyond the hands-free or streaming audio by
allowing the user to fully pilot its smartphone or Tablet via Voice Recognition (VR). InSeam is
fully integrated into the vehicle steering wheel control buttons, providing a seamless
transition between radio mode and smartphone mode. InSeam allows the user to open any
application installed on the user smartphone by simply pushing a button on the steering
wheel and speak the name of the application – the commands depend on the VR application
chosen by the user.
It is now possible to hear the text messages on the car audio system, see them on the radio
display and even reply by speaking the message without touching the device. Or launch the
Navigation and hear confirmation by simply speaking the direction. InSeam has also parental
controls build in. Parents can disable notifications (email or text messages) based on speed
detection to avoid driver distraction.
For best results AAMP recommends the use of iPhone 4S and iPhone 5 and Android 3.0 and
higher devices.
2. ISFM2201 Components
• Bluetooth Module
• Microphone
• Harness
• InSeam Application (Free download from iTunes store or Android Play Store)
• CAN bus adapter module (only required for CAN enabled vehicle)
3. Installation Options
The ISFM2201 interrupts the incoming antenna signal when in use, to deliver the cleanest
audio possible from your device.
A. Connecting to any FM equipped radio
1. Red Wire. Connect to switched accessory power (not constant)
2. Yellow Wire. Connect to constant battery power
3. Black Wire. Connect to ground.
4. Microphone. Once installed, plug the connector from the microphone
into this location..
5. Antenna input. Connect antenna lead from the vehicle.
6. Antenna output. Connect antenna lead into back of radio.
Note: Antenna adaptors may be needed for select vehicles!
The ISFM2201 is compatible with amplified antenna systems, and adaptors.
B. Additional connections for vehicles with compatible
steering wheel controls
Certified : 10801A-ISFM220X : XBD-ISFM2201
The ISFM2201 is designed with an interface to utilize the Steering Wheel Controls
of select vehicles to provide advanced control of a connected iPhone or Android
devices
Note: The following Steering Wheel Contol connection options apply to select vehicles. See
detailed application notes at www.isimplesolutions.com for a list of applicable
vehicles.
OPTION A: SWI Interface
1. Set the 4-position DIP switch to the correct setting for your vehicle (as
outlined in the application notes)
2. YYY Wire. Cut and direct the Steering Wheel control line from select
vehicles to the vehicle to the radio into this connection.
3. ZZZ Wire. Connect this line out of the ISFM2201 to the Steering Wheel
control input of the radio
4. Follow the instructions in the application notes to program the ISFM2201
to recognize the steering wheel controls for your vehicle.
OPTION B SWI interface – vehicles with CAN bus
For vehicles that utilize a CAN communications bus for Steering Wheel Control
communication to the radio, an additional adapter QQQQQQ must first be installed
before making the following connections.
1. TTT Wire. Connect to the AAA line of the QQQQQQ module.
2. VVV Wire. Connect to the BBB line of the QQQQQQ module.
3. Follow the instructions in the application notes to program the
ISFM2201 to recognize the steering wheel controls for your
vehicle.
C. Installing the Microphone for Hands-free Calling
Decide on a mounting location for the microphone either on the headliner or
overhead console. Avoid placing the microphone by the side windows to eliminate
extra noise. Carefully run the microphone cable down into the dash where the
ISFM2201 is to be installed.
Note: The Microphone cable should be routed to avoid interference with
any airbags (ex: side curtain and/or driver’s airbag). The microphone should not
be mounted on the steering wheel or in any manner which would impair proper
operation of the vehicle.
Note: Vehicle Airbags deploy with great force. Consult vehicle service
information for proper handling of the vehicle’s airbags during installation.
When securing the ISFM2201 within the dash cavity of the vehicle, placement of
the module is very important. Bluetooth technology supports devices
communicating wirelessly up to 30 feet away in most cases. However metal
structures inside the dash can reduce the communication between the module and
the Bluetooth device. Please keep this in mind when installing the ISFM2201
module and ensure to place it where it will have the least obstructions from metal
objects.
Certified : 10801A-ISFM220X : XBD-ISFM2201
4. Frequency Selection and App
Operation
Selecting the ISFM2201 Frequency
The factory-set operating frequency is 98.1 FM. If an alternate frequency is desired, the
frequency may be easily adjusted from the ISFM2201 app, Settings Menu on your iPhone or
Android device. We recommend setting the FM frequency on the user’s favorite FM station
frequency. If a call comes in, the unit will switch from FM radio to the call audio and the user
can answer from the dedicated button on the steering wheel, or reject the call and resume
FM radio.
In case the user is not listening on the FM frequency selected for InSeam operation, the
correct frequency needs to be selected first to hear the phone audio. The Steering wheel
buttons will then perform phone functions.
Activating the Voice Control Application on your device with the
Steering Wheel Controls
With the ISFM2201 app installed on your device and the device connected via Bluetooth to
the ISFM2201, press the programmed Steering Wheel designated key to activate the voice
control of your iPhone or Android device. The other programmed Steering Wheel keys can
be used to navigate options of the phone during voice control.
5. Bluetooth Pairing and Connecting
To pair your iPhone or Android device with the ISFM2201 (this is only required the first time
you use ISFM2201, after being paired, it will automatically reconnect with the device when
returning to the vehicle)
A. Turn the vehicle on.
B. Open your device’s Bluetooth settings menu, and search for new
Bluetooth adaptors.
C. Select the device called “ISFM2201”. Choose “Connect”. The module connects
automatically with the phone, no pass code is necessary. Every time the phone
connets to the unit, the InSeam application starts and runs in the background
(visible in the Android notification bar, not visible on Apple devices).
Note: If pairing is not successful within the first 2 minutes after turning the vehicle on, cycle
ignition off, then begin again at step A.
6. Utilizing the ISFM2201 for hands-
free calling
Note: To utilize the vehicle stereo for hands-free call audio, the FM radio mode must be
selected and the radio must be tuned to the set frequency utilized by the ISFM2201. Check
your ISFM2201 App for the currently active FM frequency setting.
Certified : 10801A-ISFM220X : XBD-ISFM2201
With incoming or outgoing calls, the connected device will automatically route call audio
through the ISFM2201 to your vehicle stereo.
Utilize the Voice control of your device (via the optional steering wheel activation press) as a
handsfree means to dial an outgoing call.
Troubleshooting
LICENSED APPLICATION END USER LICENSE AGREEMENT
The Products transacted through the Service are licensed, not sold, to You for use only under the terms
of this license, unless a Product is accompanied by a separate license agreement, in which case the
terms of that separate license agreement will govern, subject to Your prior acceptance of that separate
license agreement. The licensor (“Application Provider”) reserves all rights not expressly granted to
You. The Product that is subject to this license is referred to in this license as the “Licensed
Application.”
a. Scope of License: This license granted to You for the Licensed Application by Application Provider
is limited to a nontransferable license to use the Licensed Application on any iPhone or iPod touch that
You own or control and as permitted by the Usage Rules set forth in Section 9.b. of the App Store
Terms and Conditions (the “Usage Rules”). This license does not allow You to use the Licensed
Application on any iPod touch or iPhone that You do not own or control, and You may not distribute
or make the Licensed Application available over a network where it could be used by multiple devices
at the same time. You may not rent, lease, lend, sell, redistribute or sublicense the Licensed
Application. You may not copy (except as expressly permitted by this license and the Usage Rules),
decompile, reverse engineer, disassemble, attempt to derive the source code of, modify, or create
derivative works of the Licensed Application, any updates, or any part thereof (except as and only to
Symptom
