ACE ELECTRONICS G-50 G-GRIP User Manual Bb G Grip UserGuide native v10
ACE INTERNATIONAL ELECTRONICS LTD G-GRIP Bb G Grip UserGuide native v10
Manual
PORTABLE WIRELESS SPEAKER
G-GRIPG-GRIP
GRP Glass-Reinforced
Polymer Chassis
Compact & Powerful
Bass Boom Radiator
Rechargeable Battery
8 Hours Play Time
PACKAGE CONTENTS:
• G-GRIP
• AC Power Adapter
• Micro USB Charging Cable
• Wrist Strap
• 3.5mm Line In Audio Cable
• User Guide
Welcome to G-PROJECT
Thanks for purchasing a G-GRIP and joining the G-Project. With just
the right combination of performance, durability, features, and style
at the right price, our goal is to provide rugged speakers and
accessories that t your modern lifestyle. We hope you agree.
For more info, please visit our website at www.enterG-project.com
™
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
NOTE: Any unapproved changes or modications will void the warranty.
IMPORTANT SAFETY NOTIFICATIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DANGEROUS VOLTAGE: The lightning ash with arrowhead symbol,
within an equilateral triangle is intended to alert the user to the presence
of uninsulated dangerous voltage within the product’s enclosure that may
be of sufcient magnitude to constitute a risk of electric shock to persons.
ATTENTION: The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
PORTABLE WIRELESS SPEAKER
G-GRIPG-GRIP
1. Read and keep these instructions
2. Follow all instructions and heed all warnings
3. Do not use G-GRIP near water or expose it to dripping or splashing
4. Clean only with a dry cloth
5. Do not block any ventilation openings
6. Do not place near any heat sources such as radiators, heat registers, stoves,
or other devices (including ampliers) that produce heat
7. Only use attachments or accessories approved by G-Project
8. Refer all servicing to qualied service personnel. Servicing may be required when:
a. G-GRIP has been damaged in any way or does not operate normally
b. the power supply cord or plug have been damaged
c. G-GRIP has been exposed to rain, moisture, or other liquids
d. objects have fallen into G-GRIP
e. G-GRIP has been dropped
WARNING:
• Never remove the casing of G-GRIP
• Never lubricate any part of G-GRIP
• Never place G-GRIP on other electrical equipment
IMPORTANT SAFETY INSTRUCTIONS
NOTICE FOR THE USA AND CANADA
This device complies with Part 15 of the FCC Rules and RSS standard of Industry
Canada. Operation is subject to the following two conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including interference that
may cause undesired operation.
This speaker has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules and ICES-003 of Industry Canada.
These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This speaker generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this speaker does cause harmful interference to radio or television reception, which can
be determined by turning the speaker off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Relocate the receiving antenna
• Increase the separation between the speaker and the receiver
• Connect the speaker into an outlet on a circuit different from
that to which the receiver is connected
• Consult the dealer or an experienced radio technician for help
PORTABLE WIRELESS SPEAKER
G-GRIPG-GRIP
NOTICE:
approved by G-Project may void the user’s authority to operate the equipment.
SPECIFICATIONS
Power Adapter Input ...........................................................................100 - 240V AC, 50Hz/60Hz
Power Adapter Output ................................................................ 5V DC, 1300mA, Center positive
Bluetooth v2.1 compliant ......................................supports Enhanced Data Rate (EDR) and A2DP
Battery........................................................................... 3.7V, 800mAh, Rechargeable Lithium-ion
Power Output ..................................................................................................................... 2W x 2
Output Level ............................................................................................................ 85dB at 0.5m
Frequency Response ............................................................................................... 60Hz - 20kHz
Speakers ........................................................1.5” x 2 acoustic drivers with Neodymium magnets
Radiator................................................................................................ Rear ring passive radiator
Battery Playback Time.............................................................................................. Up to 8 hours
Battery Recharging Time............................................................................................... ~3.5 hours
CAUTION
PORTABLE WIRELESS SPEAKER
G-GRIPG-GRIP
LOCATION OF CONTROLS
1. Power / Charging LED
2. Charging LED / Low
battery indicator LED
3. Bluetooth LED
4. 3.5mm AUX Input
5. Reset Button
6. 5V DC Power Input
7. Mode / Play Button
8. Power Button
9. Pair Button
10. Volume + Button
11. Volume – Button
710
811
9
4
6
RE SE T
5
1 32
INDICATORS
BLUETOOTH LED
Once Bluetooth has paired successfully, the Bluetooth LED will turn solid blue.
If G-GRIP has not paired with another device after 30 minutes, it will stop trying to
pair and turn off.
POWER / CHARGING LED
The red and white LEDs indicate the following statuses:
Power Adapter Battery Power White LED Red LED Status
Connected Full OFF OFF OFF --
Connected Not Full OFF OFF ON Battery charging
Connected Full ON ON OFF --
Connected Not Full ON ON ON Battery charging
Not Connected Not Full ON ON OFF Using battery power
Not Connected Low ON ON
for 3 min Battery low
Not Connected Very Low ON ON
for 2 min Battery very low
Not Connected Empty OFF OFF OFF Power off,
cannot power on
PORTABLE WIRELESS SPEAKER
G-GRIPG-GRIP
CONNECTIONS and MODES
CHARGING MODE (left) - For a full charge, plug G-GRIP into your Power Adapter
or computer via the micro USB charging cable (included)
NOTE: A full charge takes up to 3.5 hours
BLUETOOTH MODE (center) - Pair and connect your Bluetooth device (see the
Pairing section for instructions) to stream audio wirelessly (make sure that no cable
is connected to the AUX Input)
AUX MODE (right) - Connect a 3.5mm cable (included) from the AUX Input to your
audio device and initiate playback
G-GRIP
OPERATION
POWER ON / OFF
1 In Standby mode, press the Power Button to turn G-GRIP on
2 If a 3.5mm cable is connected to the AUX Input, G-GRIP will default to AUX mode
3 If no cable is connected to the AUX Input, G-GRIP will switch to Bluetooth
mode and begin Bluetooth pairing
4 While G-GRIP is on, press the Power Button again to turn G-GRIP off
5 The speaker will automatically turn off if there is no audio playback for 30 minutes
VOLUME CONTROL
• The volume level can be set from 0 - 15 (the default level is 10)
• G-GRIP will remember the volume setting when it is turned off
PLAYBACK MODES
• If a 3.5mm cable is connected to the AUX Input, G-GRIP will default to AUX mode
• If no cable is connected to the AUX Input, G-GRIP will switch to Bluetooth mode
and begin Bluetooth pairing
• To return to AUX mode, simply connect a 3.5mm cable to the AUX Input
PORTABLE WIRELESS SPEAKER
G-GRIPG-GRIP
BLUETOOTH OPERATION
Pair with Bluetooth* capable devices to stream stereo audio wirelessly for music,
movies, video games and apps.
PAIRING
1 In Standby mode, press the Power Button to turn G-GRIP on and begin Bluetooth
pairing (make sure that no cable is connected to the AUX Input). The Bluetooth
LED will ash blue
2 On your Bluetooth device, select “G-GRIP” from the device list to pair with it
(no password is required). Once Bluetooth has paired successfully, the Bluetooth
LED on G-GRIP will turn solid blue
NOTE: Even if G-GRIP changes to AUX mode, the Bluetooth LED will remain blue
3 To clear the Bluetooth memory on G-GRIP, turn G-GRIP on and hold the
Pairing Button for a few seconds
* Compatible up to 30’ range with A2DP Bluetooth capable devices.
MUSIC PLAYBACK
• Pressing the Mode / Play Button while in Bluetooth mode will play or pause the
audio playback on your Bluetooth device
• Pressing the Mode / Play Button quickly 2x while in Bluetooth mode will skip to
the next track on your Bluetooth device
• Pressing the Mode / Play Button quickly 3x while in Bluetooth mode will skip to
the previous track (or to the beginning of the current track depending on the
paired devic e)
TROUBLESHOOTING
PORTABLE WIRELESS SPEAKER
G-GRIPG-GRIP
Solution
Lower the volume on your G-GRIP and/or audio source
Turn up the volume on your G-GRIP and/or audio source
Recharge the batteries using the included Power Adapter
If using Bluetooth, move the audio source and G-GRIP closer together
(within the 30’ range)
Unpair G-GRIP from your Bluetooth device (check with your device
manufacturer for more information about Bluetooth pairing), then re-pair
following the steps in the section BLUETOOTH OPERATION
Conrm your device is A2DP Bluetooth compatible. Ensure that both your
Bluetooth device and G-GRIP are not connected to any other devices
If your G-GRIP is connected to a Line In source, the Bluetooth will not
function. Unplug the 3.5mm Line In cable and press the Pair Button to
switch to Bluetooth
Unpair G-GRIP from your Bluetooth device (check with your device
manufacturer for more information about Bluetooth pairing), then re-pair
following the steps in the section BLUETOOTH OPERATION
Issue
Distortion
Not loud enough
Intermittent sound
Cannot play audio
via Bluetooth
For further assistance, please visit our website at www.enterG-project.com
or contact customer service at support@enterG-project.com or 1-855-896-1795
Life Lab International Ltd.
