ACE ELECTRONICS G-60 G-DROP Waterproof Wireless Speaker User Manual G DROP UserGuide PROOF 070814v3 5

ACE INTERNATIONAL ELECTRONICS LTD G-DROP Waterproof Wireless Speaker G DROP UserGuide PROOF 070814v3 5

Manual

Waterproof
Bluetooth
Wireless
G-60
Shockproof
Dustproof
WATERPROOF WIRELESS SPEAKER
G-DROPG-DROP
PACKAGE CONTENTS:
G-DROP Waterproof Wireless Speaker
USB Charging Cable
User Guide
Welcome
Thanks for purchasing G-DROP and joining G-Project. With just the
right combination of performance, durability, features, and style at the
right price, our goal is to provide rugged speakers and accessories that
fit your lifestyle. We hope you agree.
If you need a hand using your new G-DROP, we’re here to help.
Email us at support@gprojectgear.com or give us a call at
1-855-896-1795 between 6AM - 6PM PST.
STOP BY AND SAY HELLO TO US:
A NEW SONG EVERYDAY:
facebook.com/gprojectgear
twitter.com/gprojectgear
instagram.com/gprojectgear
We’ve got a new song for you everyday and
a collection of playlists to get you going.
Have a listen at songs.gprojectgear.com
WATERPROOF WIRELESS SPEAKER
G-DROPG-DROP
PA I R
P O W E R
EQ
Play / Speakerphone
Button
Skip Forward /
Skip Back Button
EQ Button
Pair Button
Power Button
Bluetooth LED (Blue)
Power LED (White)
Charging LED (Red) /
Low Battery Indicator
Volume + Button
Volume – Button
Accessory Clip
WATERPROOF WIRELESS SPEAKER
G-DROPG-DROP
External Jack Door
Front Speaker
5V USB Output
Charging Jack
Rear Firing
Passice Radiator
3.5mm AUX Input
WATERPROOF
The waterproof G-DROP is the take anywhere, portable
Bluetooth speaker.... aljhlfh ghg ghkzv hjsod ghw odhkj ghd
sghv llkhv owai dghv kw ughv svuv oadg,bv q oweufgy vjghvqw
ogghkzv hjsod ghw odhkj ghd sghv llkhv owai dghv kw ughv ui
DUSTPROOF
The sealed designed of G-DROP help withstand dust, dirt and
sand.... aljhlfh ghg ghkzv hjsod ghw odhkj ghd sghv llkhv owai
dghv kw ughv svuv oadg,bv q oweufgy vjghvqw ogui
SHOCKPROOF
G-DROP is designed to be rugged.... aljhlfh ghg ghkzv hjsod
ghw odhkj ghd sghv llkhv owai dghv kw ughv svuv oadg,bv q
oweufgy vjghvqw ogui
FPO
WATERPROOF WIRELESS SPEAKER
G-DROPG-DROP
White LED
OFF
OFF
ON
ON
ON
ON
ON
OFF
Red LED
OFF
ON
OFF
ON
OFF
Flash once
every 3 secs
Flash once
every 2 secs
OFF
Battery Status
FULL
NOT FULL
FULL
NOT FULL
NOT FULL
LOW
VERY LOW
NO POWER
Power Status
OFF
OFF
ON
ON
ON
ON
ON
OFF
Speaker Status
––
Battery Charging
––
Battery Charging
Using Battery Power
Battery Low
Battery VERY Low
Will Not Power On
LED INDICATORS
Bluetooth LED: When G-DROP is in paring mode, the Bluetooth LED
will flash blue. Once G-DROP has paired successfully with a Bluetooth
compatible device, the Bluetooth LED will turn solid blue.
Power / Charging LED: The red and white LEDs indicate the following
statuses:
GETTING CHARGED UP
G-DROP includes a USB power jack on the side (located under the
External Jack Door). Below are two ways you can charge G-DROP.
1 Connect G-DROP to a USB powered port on your computer or laptop
(PC/MAC) using the supplied USB charging cable.
2 You can also charge G-DROP by connecting G-DROP to a USB power
adaptor (not included) via the supplied USB charging cable.
NOTES: When fully charged, the G-DROP battery will provide playback time of
approximately 8 hours, based on volume level and type of music.
Approximate time to fully recharge the G-DROP battery is 3 hours.
WATERPROOF WIRELESS SPEAKER
G-DROPG-DROP
GET IN CONTROL
POWER ON / OFF
Press the Power Button to turn G-DROP on and again to turn G-DROP off.
VOLUME CONTROL
Increase or decrease the volume by using the + or buttons. The White LED
will flash once each time indicating the volume change. When max or
minimum volume is reached, the White LED will not flash. G-DROP will
remember the volume setting when it is turned off.
MUSIC PLAYBACK
• Pressing the PLAY Button while in Bluetooth mode will play or pause the
audio playback on your Bluetooth device.
• Pressing the >> Button while in Bluetooth mode will skip to the next
track on your Bluetooth device.
• Pressing the >> Button quickly 2x while in Bluetooth mode will skip to
the last track on your Bluetooth device.
EQUALIZER (EQ)
G-DROP has 2 EQ presets (EQ1 / EQ2). Press the EQ Button to toggle between
them. The White LED will flash 1 or 2 times when the EQ Button is pressed to
indicate preset EQ1 or EQ2, respectively. The default setting is EQ1.
BLUETOOTH WIRELESS
You can stream audio to G-DROP from up to 33 away using your iPod,
iPhone, iPad, Android, laptop, or other A2DP Bluetooth enabled device.
1 Press the Power Button to turn G-DROP on and the Blue LED will begin to
flash. If the last paired Bluetooth device is powered on and within range
with Bluetooth enabled, the device will automatically reconnect G-DROP.
If you want to connect a different Bluetooth device, press and hold the Pair
Button for about two seconds, the Blue LED will begin to flash indicating
G-DROP is in pairing mode.
2 On your A2DP-enabled device, enable Bluetooth, then search for
Bluetooth devices. Select G-DROP from the available list.
3 The Blue LED on G-DROP will change from flashing to solid, indicating that
your Bluetooth device is connected to G-DROP.
4 Once your Bluetooth device has been paired with G-DROP, it is simple to
reconnect them. Make sure G-DROP is powered on and within range then
simply select G-DROP from the list on your Bluetooth device.
NOTES: For the best audio performance, turn the volume on your Bluetooth source
device all the way up.
WATERPROOF WIRELESS SPEAKER
G-DROPG-DROP
HANDS-FREE SPEAKERPHONE
You can use G-DROP as a hands-free speakerphone when answering phone
calls on your mobile device.
1 Press the Play Button to answer an incoming call.
2 Press the Play Button again to hang up and end the call.
3 To ignore an incoming call, press and hold the Play button when a call is
received.
NOTE: Normal use of this function requires that G-DROP is powered on and paired
successfully with your Bluetooth enabled device.
NOTES (con’t): G-DROP can only play audio from one source at a time. If G-DROP
is connected to a Line In source, the Bluetooth will not function. Simply unplug
the 3.5mm Line In audio cable and press the Pair Button to switch to Bluetooth
(if necessary, select ”G-DROP” on your Bluetooth device).
G-DROP will automatically turn off if it has not paired with a device after 15
minutes.
LINE IN CONNECTION
You can also play audio from external devices using a standard 3.5mm Line
In audio cable.
1 Open the Jack Door located on the left of your G-DROP.
2 Then insert one end of a standard 3.5mm audio cable (not included) into the
AUX jack of G-DROP (located underneath the External Jack Door) and the
other end into the Line Out or headphone jack of your audio device (e.g.
iPad, iPod, mobile phone, MP3 player, digital media player, etc.).
3 Power on G-DROP, then power on the external audio source and select the
music you want to listen to. Press play on the external audio source and
playback will begin and sound will be heard through G-DROP.
NOTES: For the best audio performance and minimal distortion, avoid turning the
volume on your audio source all the way up.
If a Line In cable is connected to the AUX jack, G-DROP will default to AUX mode.
If the Pairing Button is pressed while the 3.5mm Line In cable is still connected to
the AUX input, G-DROP will change to Bluetooth paring mode.
To return to AUX mode, simply connect a cable to the AUX jack.
If no Line In cable is connected to the AUX jack, G-DROP will default to Bluetooth
mode and begin searching for a Bluetooth pairing device.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
NOTE: Any unapproved changes or modifications will void the warranty.
IMPORTANT SAFETY NOTIFICATIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to alert the user to the presence
of uninsulated dangerous voltage within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock to persons.
ATTENTION: The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
WATERPROOF WIRELESS SPEAKER
G-DROPG-DROP
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Compliance information: This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may
cause undesired operation.
SURGE PROTECTORS: It is recommended to use a surge protector for AC connection.
Lightning and power surges ARE NOT covered under warranty for this product.
a. Do not expose the AC/DC adaptor to dripping or splashing water. Keep liquid-filled
objects, such as vases, away from the AC/DC adaptor.
b. Only use attachments / accessories specified by the manufacturer.
c. Ensure that the AC/DC adaptor is easily accessible.
d. Please note the information printed underneath the unit.
e. Keep open flames, such as lighted candles, away from this unit.
f. Unplug this unit during lightning storms or when unused for long periods of time.
g. Use only the same or equivalent type batteries as there is a danger of explosion if the
incorrect batteries are used or they are installed incorrectly.
h. Do not expose the battery to flames or dispose of it in a fire.
i. Dispose of batteries properly according to environmental regulations.
SAFETY PRECAUTIONS
WATERPROOF WIRELESS SPEAKER
G-DROPG-DROP
G-Project is a registered trademark of Goodhatch, LLC
G-DROP is distributed by Life Lab International LTD.
The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Life Lab International LTD. is under license.
Other trademarks and trade names are those of their respective owners.
