ACE Hardware YS-AS001 Flame lamp with bluetooth speaker User Manual AceSpeaker 9792854IM 0709

ACE Hardware Corporation Flame lamp with bluetooth speaker AceSpeaker 9792854IM 0709

User Manual

FLAME LAMP WITH
BLUETOOTH SPEAKER
9792854
INSTRUCTION MANUAL
Ace Hardware Corp. Oak Brook, Illinois 60523 USA ©2018
www.acehardware.com
INSTALLATION INSTRUCTIONS
OPERATING INSTRUCTIONS
Ace Hardware Corp. Oak Brook, Illinois 60523 USA ©2018
www.acehardware.com
When turning on the Bluetooth speaker:
1. You will hear a tone/sound and the white LED light will flash.
2. On your device thru the Bluetooth feature search for the name “A1” and connect to it.
3. Once it is connected successfully you will hear that same tone/sound confirming the connection. Note: The white LED lights
will continue to flash.
1. Turn on the ON/OFF button on one of the Bluetooth speaker.
2. On your device thru the Bluetooth feature search for the name “A1” and connect to it.
3. Once it is connected successfully you will hear that same tone/sound confirming the connection. Note: The white LED lights
will continue to flash.
4. Press any buttons on the two Bluetooth speakers, the functions are the same, volume+/-, pre song, next song and
play button.
Operating with one Bluetooth speaker
Operating with two Bluetooth speakers
Standard tripod threaded hole
Tripod
(Tripod not included)
BLUETOOTH SPEAKER MODE
CHARGING INSTRUCTIONS
Ace Hardware Corp. Oak Brook, Illinois 60523 USA ©2018
www.acehardware.com
5. When the two Bluetooth speakers are matched, the two speakers will both sound the same tone. Note: One of the speakers
will be the auxiliary speaker. You will notice this when the LED light is lit for a long period of time (right channel). The other
speaker will be considered the main speaker. You will notice this when the LED light is flashing (left channel).
ON/OFF Button: Press this button for 2 seconds to turn on/off the
Bluetooth speaker.
Quick press this button to connect with the other Bluetooth speaker.
White LED lights will flash to shows Bluetooth speaker is ON.
White LED lights will light for an extended period of time when the
Bluetooth speaker has connected successfully.
Next song/V+key: While in Bluetooth mode, a quick press will go to
the next song and a longer press will increase the audio volume (when
reach the maximum volume, the speaker will sound a tone).
Last song/V-Key: While in Bluetooth mode a quick press will go to the
last song and a longer press will decrease the audio volume. Note:
when the maximum volume is reached, the speaker will sound a tone.
Press + and - together to cancel the pairing.
Play/pause Key: Press to play/pause.
Flame atmosphere lamp ON/OFF key, press to turn on/off the lamp.
• Please do not charge the lamp when the temperature is
below 32º F (0º C) or above 104º F (40º C).
• Not recommended to charge while in use.
• Pull out the USB cable after a full charge.
• Do not charge the lamp with high-humidity conditions.
• Do not place near magnetic and/or electrical places.
Attention
• Put the USB cable into the lamp, when charging the indicator
light is red.
• When fully charged, the indicator light is off.
Power input
FCC Statement
15.19
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause
undesired operation.
15.21
Note: The grantee is not responsible for any changes or modifications not expressly approved by
the party responsible for compliance. Such modifications could void the user’s authority to operate
the equipment.
15.105(b)
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help
