USERS MANUAL
FareBox Embedded –
FBE420 OPERATOR
GUIDE
EN-OPE2322-A
WARNING STATEMENT
NOTE:
- THE MANUFACTURER IS NOT
RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY
UNAUTHORIZED MODIFICATIONS TO
THIS EQUIPMENT.
- SUCH MODIFICATIONS COULD VOID
THE USER’S AUTHORITY TO OPERATE
THE EQUIPMENT.
MESSAGES DISPLAYED
by the FBE420
•Out of operation
•Out of operation, no cashbox
•Out of operation, cashbox full
•In operation
•Hot listed card detected
•Test card detected
•Communication error with card or
error when writing on card
•No known contract on the card
•No contract on the card
•No contract authorized for
reloading on the card
•Banknote not accepted
•Coins not accepted
•Card reloaded successfully
NOTE: All these messages can be
modified on the Revenue System Server
IN OPERATION
The FBE420 displays a welcome message,
visible by the patron, when entering the bus,
provides information concerning fare or any
other relevant data. The different operation can
be selected by four switches located near the
patron display
Once a bank bill or coins is inserted, the
FBE420 verifies its validity and checks if it
belongs to the list of authorized bills or coins:
When the payment is accepted, the FBE420
delivers a magnetic transportation ticket.
When entering the bus, the patron must
validate its transportation ticket:
When the payment is accepted and the
transportation card is presented, the
FBE420 reads the data stored on this one
and performs the reloading operations.
WELCOME MESSAGE
PAYMENTS WITH BILL OR COINS
Any bill or coins not belonging to the list of
authorized bills or coins is given back to the
patron. Another banknote can be inserted as
soon as the refused bill is removed by the patron.
TICKETS DELIVERING
TICKETS VALIDATION
CARD RELOADING
OPERATION RESULT
A display, a green and red indicator are
located on the top of the housing to indicate
whether the operation is correct or not.
This information is associated with a
specification sound.
- Banknotes: $1, $5, $10, $20
- Coins: 1c, 5c, 10c, 25c, $1
PAYMENTS WITH CARDS
Once the credit card is read by the swipe reader,
the FBE420 verifies its validity and processes
payments
- By inserting the magnetic tickets into the
FBE420 front slot
- By presenting the contactless card on the
FBE420 top target.
