BLUESOCKET COMPLIANCE NOTICE
61700962F1-17A
August 2015
1. INSTALLATION INSTRUCTIONS
This document includes user requirements for operating ADTRAN Bluesocket products in accordance with
national laws, including usage of radio spectrum and operation of radio devices. Failure of the end-user to
comply with the applicable requirements may result in unlawful operation and adverse action against the
end-user by the applicable national regulatory authority.
ADTRAN Bluesocket products are intended to be installed, maintained, and serviced by qualified
service personnel with knowledge of radio frequency (RF) and related rules. Particular attention should
be given to allowed operation frequencies. The general user should not attempt to install Bluesocket
wireless products outdoors when external antennas, power, and grounding must be installed for use.
Bluesocket products comply with radiation exposure limits set forth for an uncontrolled environment and
meet RF exposure guidelines for wireless access points. Bluesocket products should be installed and
operated keeping the product 28 cm or more away from a person’s body.
Use only the antennas which have been approved by ADTRAN for the specific Bluesocket product.
Non-approved antennas may produce unwanted, spurious, or excessive RF transmitting power which
may lead to the violation of local or national regulatory limits.
Refer to the specific Bluesocket product’s quick start guide (shipped with the unit or available online at
https://supportforums.adtran.com) for information on installing, grounding, and powering the unit.
Ce document comprend les besoins des utilisateurs pour l’exploitation des produits ADTRAN Bluesocket,
conformément aux lois nationales, y compris l’utilisation du spectre radioélectrique et de l’exploitation
d’appareils radio. Le défaut de l’utilisateur final de se conformer aux exigences applicables peut entraîner
une utilisation illégale et des poursuites contre l’utilisateur final par l’autorité réglementaire nationale
compétente.
Les produits ADTRAN Bluesocket sont destinés à être installés, entretenus et réparés par du personnel
d’entretien qualifié ayant une connaissance de la fréquence radio (RF) et des règles relatives à cette
dernière. Une attention particulière devrait être accordée aux fréquences d’exploitation autorisées.
L’utilisateur général ne devrait pas essayer d'installer des produits sans fil Bluesocket à l’extérieur
quand des antennes externes, l’alimentation électrique et la mise à la terre doivent être installées à
l'emploi.
Les produits Bluesocket sont conformes aux limites d’exposition aux rayonnements dans un
environnement non contrôlé et sont conformes aux directives d’exposition RF pour les points d’accès
sans fil. Les produits Bluesocket doivent être installés et exploités en gardant le produit à une distance
de 28 cm ou plus du corps d’une personne.
Utilisez uniquement les antennes qui ont été approuvées par ADTRAN pour le produit Bluesocket
particulier. Des antennes non approuvées peuvent produire une transmission de puissance RF
indésirable, parasite ou excessive qui peut conduire à une infraction aux limites réglementaires locales
ou nationales.
Reportez-vous au guide de démarrage rapide du produit Bluesocket particulier (livré avec l’appareil ou
disponible en ligne à https://supportforums.adtran.com) pour obtenir des informations sur l’installation,
la mise à la terre et la mise sous tension de l’appareil.
DRAFT
BLUESOCKET COMPLIANCE NOTICE
61700962F1-17A
August 2015
2. FEDERAL COMMUNICATION COMMISSION (FCC)
FCC Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Cautions
Bluesocket products contain no user serviceable parts and are to be used with approved antennas only.
Any changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate this equipment.
Bluesocket products and their antennas must not be co-located or operated in conjunction with any other
antenna or transmitter except in accordance with FCC multi-transmitter product procedures.
For outdoor use, antennas must be installed vertically to ensure that all emissions above 30 degrees
elevation will not exceed the FCC 21 dBm EIRP limit.
In Europe, Australia, and New Zealand, the 5 GHz U-NII low band (5.15 to 5.35 GHz, channels 36, 40, 44,
and 48) is designated for indoor use only. If the BSAP 2135 is installed indoors, for example in a harsh
environment such as a warehouse, it must configured for indoor use. For information on configuring a
Bluesocket access point for indoor use, refer to the quick start guide that shipped with the product.
FCC Radiation Exposure Statement
Bluesocket products comply with FCC radiation exposure limits set forth for an uncontrolled environment
and meet RF exposure guidelines for wireless access points. Bluesocket products should be installed and
operated keeping the product 28 cm or more away from a person’s body.
3. INDUSTRY CANADA (IC)
IC Interference Statement
This device complies with RSS-210/RSS-247 of the Industry Canada Rules. Operation is subject to the
following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired
operation.
DRAFT
BLUESOCKET COMPLIANCE NOTICE
61700962F1-17A
August 2015
IC Caution
(i) the device for operation in the band 5150 to 5350 MHz is only for indoor use to reduce the
potential for harmful interference to co-channel mobile satellite systems;
(ii) the maximum antenna gain permitted for devices in the bands 5250 to 5350 MHz and 5470 to
5725 MHz shall be such that the equipment still complies with the EIRP limit;
(iii) the maximum antenna gain permitted for devices in the band 5725 to 5850 MHz shall be such that
the equipment still complies with the EIRP limits specified for point-to-point and non-point-to-point
operation as appropriate;
(iv) the worst-case tilt angle(s) necessary to remain compliant with the EIRP elevation mask
requirement set forth in Section 6.2.2(3) shall be clearly indicated; and
(v) high-power radars are allocated as primary users (i.e., priority users) of the bands 5250 to 5350
MHz and 5650 to 5850 MHz and that these radars could cause interference and/or damage to
LE-LAN devices.
Déclaration d’interférence d’Industrie Canada
Ce dispositif est conforme à la norme CNR-210/CNR-247 d’Industrie Canada. Son fonctionnement est
soumis aux deux conditions suivantes :
ce dispositif ne doit pas produire de brouillage préjudiciable;
ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un
fonctionnement indésirable.
Avertissement d’Industrie Canada
Le guide d’utilisation des dispositifs pour réseaux locaux doit inclure des instructions précises sur les
restrictions susmentionnées, notamment :
i) les dispositifs fonctionnant dans la bande 5150 à 5350 MHz sont réservés uniquement pour une
utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de
satellites mobiles utilisant les mêmes canaux;
ii) le gain maximal d’antenne permis pour les dispositifs utilisant les bandes de 5250 à 5350 MHz et
de 5470 à 5725 MHz doit être conforme à la limite de la PIRE;
iii) le gain maximal d’antenne permis pour les dispositifs utilisant la bande de 5725 à 5850 MHz doit
être conforme à la limite de la PIRE spécifiée pour l’exploitation point à point et l’exploitation non
point à point, selon le cas;
iv) les pires angles d’inclinaison nécessaires pour demeurer conforme à l’exigence de la PIRE
applicable au masque d’élévation, et énoncée à la section 6.2.2 (3), doivent être clairement
indiqués;
v) de plus, les radars de forte puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la
priorité) pour les bandes 5250 à 5350 MHz et 5650 à 5850 MHz et que ces radars pourraient
causer du brouillage et/ou des dommages aux dispositifs LAN-EL.
IC Radiation Exposure Statement
Bluesocket products comply with IC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 28 cm between the radiator
and your body.
Déclaration d’exposition aux rayonnements d’Industrie Canada
Les produits Bluesocket sont conformes aux limites d’exposition aux rayonnements IC établies pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé à une distance minimale de 28 cm
entre la source de rayonnement et votre corps.
DRAFT
BLUESOCKET COMPLIANCE NOTICE
61700962F1-17A
August 2015
4. EUROPEAN UNION (EU)
EU Declaration of Conformity
This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test
methods have been applied in order to prove presumption of conformity with the essential requirements of
the R&TTE Directive 1999/5/EC:
EN 60950-1
EN 50385
EN 300 328
EN 301 893
EN 301 489-1
EN 301 489-17
